2ADRB-KSHIVE2BKHIVE 2 Bluetooth Speaker

CREATIVISION LIMITEDFCC Confidentiality Request Number: CF303 Version: V05 Date: 21-05-2012 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company nameCREATIVISION LIMITED. AddressRm 2003, 20/F, 303 Hennessy Road, Wanchai CityHong Kong CountryChina request for this certification filing under: Grantee CodeProduct Number FCC ID:2ADRB-KSHIVE2BK to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) ExhibitFile NameDescription xOperational Descriptionexplaining the functioning of the block diagram xBlock Diagramsshowing the systematic building blocks of the EUT xSchematics Diagramsshowing components, their values and interconnection Bill of MaterialsList of components used on the PCB’s of the EUT Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) Enschede, The Netherlands 2015-06-15M. Koop (authorized) Manager

CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name CREATIVISION LIMITED. Rm 2003, 20/F, 303 Hennessy Road, Wanchai, City Hong Kong, Country China declare that the following representative (agent): Name (person) KAIT CHEN Company name WST Certification & Testing (HK) Limited Address 12/F., San Toi Building,137-139 Connaught Road Central, City Hong Kong, Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description HIVE 2 BLUETOOTH SPEAKER Type or Model(s) KSHIVE2BK, HIVE 2, BL-206, KSHIVE2XX (XX = refer to color code) Tradename or Brand(s) KITSOUND / Uchoice We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) HK, ChinaJune 12,2015Joe WongProject Executive

F CC ID LABEL: Label Location FCC ID: 2ADRB-KSHIVE2BK This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 23 Report No.: WST150611001 FCC TEST REPORT Test report On Behalf of CREATIVISION LIMITED For HIVE 2 BLUETOOTH SPEAKER Model No.: KSHIVE2BK, HIVE 2, BL-206, KSHIVE2XX (XX = refer to color code) FCC ID: 2ADRB-KSHIVE2BK Prepared for : CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Prepared By : WST Certification & Testing (HK) Limited 12/F., San Toi Building,137-139 Connaught Road Central,Hong Kong Date of Test: June 04, 2015 ~ June 11, 2015 Date of Report: June 12, 2015 Report Number: WST150611001 Page 2 of 23 Report No.: WST150611001 TEST RESULT CERTIFICATION Applicant’s name ................. : CREATIVISION LIMITED Address ................................. : Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Manufacture's Name ............ : DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LIMITED Address ................................. : JINDUOGANG DEVELOPMENT ZONE, DATANG VILLAGE, DALINGSHAN TOWN, DONGGUAN CITY, GUANGDONG, CHINA Product description Trade Mark: KITSOUND / Uchoice Product name............................ : HIVE 2 BLUETOOTH SPEAKER Model and/or type reference : KSHIVE2BK, HIVE 2, BL-206, KSHIVE2XX (XX = refer to color code) Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.4: 2009 This publication may be reproduced in whole or in part for non-commercial purposes as long as the WST Certification & Testing (HK) Limited is acknowledged as copyright owner and source of the material. WST Certification & Testing (HK) Limited takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ........................................... : Date (s) of performance of tests ............. : June 04, 2015 ~ June 11, 2015 Date of Issue .......................................... : June 12, 2015 Test Result.............................................. : Pass Testing Engineer : (Eric Xie) Technical Manager : (Dora Qin) Authorized Signatory : (Kait Chen) Page 3 of 23 Report No.: WST150611001 Table of Contents Page 1. . TEST SUMMARY 4 2. . GENERAL INFORMATION 5 2.1. GENERAL DESCRIPTION OF EUT 5 Operation of EUT during testing 7 2.2. DESCRIPTION OF TEST SETUP 7 2.3. MEASUREMENT INSTRUMENTS LIST 8 3. . CONDUCTED EMISSIONS TEST 10 3.1 Conducted Power Line Emission Limit 10 3.2 Test Setup 10 3.3 Test Procedure 10 3.4 Test Result 11 4 RADIATED EMISSION TEST 12 4.1 Radiation Limit 12 4.2 Test Setup 12 4.3 Test Procedure 13 4.4 Test Result 13 5 BAND EDGE 18 5.1 Limits 18 5.2 Test Procedure 18 5.3 Test Result 18 6 OCCUPIED BANDWIDTH MEASUREMENT 19 6.1 Test Setup 19 6.2 Test Procedure 19 6.3 Measurement Equipment Used 19 6.4 Test Result 19 7 ANTENNA REQUIREMENT 21 8 PHOTOGRAPH OF TEST 22 Page 4 of 23 Report No.: WST150611001 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST RESULT CONDUCTED EMISSIONS TEST COMPLIANT RADIATED EMISSION TEST COMPLIANT BAND EDGE COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT COMPLIANT ANTENNA REQUIREMENT COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen WST Testing Technology Co., Ltd. Certificated by FCC, Registration No.: 939433 Address : 1F,No.9 Building,TGK Science & Technology Park,Yangtian Rd., NO.72 Bao'an Dist., Shenzhen,Guangdong,China. 518101 Tel : (86)755-33916437 Fax : (86)755-27822175 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty = 2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz) = 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 5 of 23 Report No.: WST150611001 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment HIVE 2 BLUETOOTH SPEAKER Model Name KSHIVE2BK Serial No HIVE 2, BL-206, KSHIVE2XX (XX = refer to color code) FCC ID 2ADRB-KSHIVE2BK Model Difference All the model are the same circuit and RF module,except the appearance colour, this report only test mode name: KSHIVE2BK Antenna Type Internal monopole Antenna BT Operation frequency 2402-2480MHz Number of Channels 79CH Modulation Type GFSK Power Source DC 5V Power Rating / Adapter Model / Page 6 of 23 Report No.: WST150611001 2.1.1 Carrier Frequency of Channels Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 2402 31 2432 61 2462 02 2403 32 2433 62 2463 03 2404 33 2434 63 2464 04 2405 34 2435 64 2465 05 2406 35 2436 65 2466 06 2407 36 2437 66 2467 07 2408 37 2438 67 2468 08 2409 38 2439 68 2469 09 2410 39 2440 69 2470 10 2411 40 2441 70 2471 11 2412 41 2442 71 2472 12 2413 42 2443 72 2473 13 2414 43 2444 73 2474 14 2415 44 2445 74 2475 15 2416 45 2446 75 2476 16 2417 46 2447 76 2477 17 2418 47 2448 77 2478 18 2419 48 2449 78 2479 19 2420 49 2450 79 2480 20 2421 50 2451 21 2422 51 2452 22 2423 52 2453 23 2424 53 2454 24 2425 54 2455 25 2426 55 2456 26 2427 56 2457 27 2428 57 2458 28 2429 58 2459 29 2430 59 2460 30 2431 60 2461 Page 7 of 23 Report No.: WST150611001 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode Low Channel: 2402MHz Middle Channel: 2440MHz High Channel: 2480MHz 2.2 DESCRIPTION OF TEST SETUP Page 8 of 23 Report No.: WST150611001 2.3 MEASUREMENT INSTRUMENTS LIST Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval 1. EMI Receiver Rohde & Schwarz ESCI 100627 May 19, 2015 1 Year 2. LISN SchwarzBeck NSLK 8126 8126377 May 19, 2015 1 Year 3. RF Switching Unit Compliance Direction RSU-M2 38303 May 19, 2015 1 Year 4. EMI Test Software ES-K1 Rohde & Schwarz N/A N/A N/A N/A 5. EMI Test Receiver Rohde & Schwarz ESCI 100627 May 19, 2015 1 Year 6. Trilog Broadband Antenna Schwarzbeck VULB9163 VULB 9163-289 May 17, 2015 1 Year 7. Pre-amplifier Compliance Direction PAP-0203 22008 May 19, 2015 1 Year 8. EMI Test Software EZ-EMC SHURPLE N/A N/A N/A N/A 9. EMI Receiver Rohde & Schwarz ESCI 100627 May 19, 2015 1 Year 10. LISN Sch…

Text truncated - open the document above for the full version.

Radiated Emission Ac power line conducted emission
