2ADRB-POCKETBOOMBluetooth Speaker

PktBm wireless_manual_60x50_viz_b.indd 1-110/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 2-310/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 4-510/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 6-710/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 8-910/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 10-1110/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 12-1310/06/2014 17:29 PktBm wireless_manual_60x50_viz_b.indd 14-1510/06/2014 17:29 +EDR PktBm wireless_manual_60x50_viz_b.indd 16-17 —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit dif ferent from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipmen generates, uses and can radiate radio frequency energ and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radi or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: FCC Statement: 10/06/2014 17:29 1617

PAGE 4 OF 5 CREATIVISION LIMITED Date :2014-11-20 PHOENIX TESTLAB GmbH Königswinkel 10 D-32825 Blomberg Dear Sirs, Re. : Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for CREATIVISION LIMITED , Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of CREATIVISION LIMITED. Product name : Bluetooth speaker Model : KSPKBOOM KSPBWH KSPBRD KSPBPI KSPBPU KSPBGN KSPBBL KSPBOR This authorization will expire one year from the date of this letter. Print name： Joe Wong Title: Project Executive Signature:

Page 1 CREATIVISION LIMITED Company Name：CREATIVISION LIMITED Address： CREATIVISION LIMITED , Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Date : 2014-11-20 FCC ID: 2ADRB-POCKETBOOM To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, “CREATIVISION LIMITED” requests that the following materials be withheld from public inspection under 47CFR 0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1) detailed circuit schematic of unit under test (2) parts list (3) block diagram (4) operational description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, Print name：Joe Wong Title: Project Executive Signature:

Updated on 2005/02/07 by Kally Chan CREATIVISION LIMITED To : STC (DongGuan) COMPANY LIMITED DECLARATION OF IDENTITY Hereby we: CREATIVISION LIMITED (Name of Manufacturer) Basic Model Number: KSPKBOOM Basic Brand Name: KS Basic Product Name: Bluetooth speaker Basic Test Report Application Number: Declare the Circuit, PCB Layout, Electrical Parts and Outlook of the following product(s) are identical to the basic model: New / Additional Model Number(s): KSPBWH/KSPBRD/KSPBPI/KSPBPU/ KSPBGN/KSPBBL/KSPBOR New / Additional Brand Name(s): Except the following(s) : Models of different Colour of different Remarks: Signature with Company Chop : Printed Name : Joe Wong DATE:2014-11-13

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

20mm 12mm 1:1图 INPUT: DC 5V FCC ID: 2ADRB-POCKETBOOM Made in China Model no: KSPKBOOM POCKETBOOM INPUT: DC 5V FCC ID: 2ADRB-POCKETBOOM Made in China Model no: KSPKBOOM POCKETBOOM

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT

Date: 2014-12-15 Page 1 of 88 No.: DM117676 Applicant: CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Manufacturer: Shenzhen Adition Audio Science & Technology Co., Ltd. Mingzhuo Industry Park, Guangming Main Street, Guangming New District, Shenzhen, 518107, China Description of Sample(s): Product: Bluetooth Speaker Brand Name: KS Model Number: KSPKBOOM FCC ID: 2ADRB-POCKETBOOM Date Sample(s) Received: 2014-11-18 Date Tested: 2014-11-26 to 2014-12-12 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47 CFR [Codes of Federal Regulations] Part 15: 2014 and ANSI C63.4: 2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): For additional model(s) details, see page 3 LONG Yun Jian, Along Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of STC (Dongguan) Company Limited Date: 2014-12-15 Page 2 of 88 No.: DM117676 CONTENT: Cover Page 1 of 88 Content Page 2-3 of 88 1.0 General Details 1.1 Test Laboratory Page 4 of 88 1.2 Equipment Under Test [EUT] Page 4 of 88 Description of EUT operation 1.3 Date of Order Page 4 of 88 1.4 Submitted Sample Page 4 of 88 1.5 Test Duration Page 4 of 88 1.6 Country of Origin Page 4 of 88 1.7 RF Module Details Page 5 of 88 1.8 Antenna Details Page 5 of 88 2.0 Technical Details 2.1 Investigations Requested Page 6 of 88 2.2 Test Standards and Results Summary Page 6 of 88 2.3 Table for Test Modes Page 7 of 88 3.0 Test Results 3.1 Emission Page 8 - 83 of 88 Date: 2014-12-15 Page 3 of 88 No.: DM117676 Appendix A List of Measurement Equipment Page 84 of 88 Appendix B Ancillary Equipment Page 84 of 88 Appendix C Photographs Page 85- 88 of 88 Date: 2014-12-15 Page 4 of 88 No.: DM117676 1.0 General Details 1.1 Test Laboratory STC (Dongguan) Company Limited EMC Laboratory 68 Fumin Nan Road, Dalang, Dongguan, Guangdong, China Telephone: (86 769) 81119888 Fax: (86 769) 81116222 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Bluetooth Speaker Manufacturer: Shenzhen Adition Audio Science & Technology Co., Ltd. Brand Name: KS Model Number: KSPKBOOM Additional Model Number(s): KSPBWH, KSPBRD, KSPBPI, KSPBPU, KSPBGN, KSPBBL, KSPBOR Rating: 5.0Vd.c. (Powered by PC USB port) / Li-ion rechargeable battery x1 = 3.7Vd.c 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Bluetooth Speaker of CREATIVISION LIMITED, it is Audio System, modulation by IC; and type is frequency hopping spread spectrum Modulation. 1.3 Date of Order 2014-11-18 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2014-11-26 to 2014-12-12 1.6 Country of Origin China Date: 2014-12-15 Page 5 of 88 No.: DM117676 1.7 RF Module Details Module Model Number: F-6288 Module FCC ID: N/A Module Transmission Type: Bluetooth V2.1+EDR Modulation: FHSS (GFSK / π/4-DQPSK / 8DPSK) Data Rates: 1Mbps: GFSK 2 Mbps: π/4-DQPSK 3 Mbps: 8DPSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: Meander line antenna Antenna Gain: 0dBi Date: 2014-12-15 Page 6 of 88 No.: DM117676 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2014 Regulations. FCC Pubic Notice DA 00-705 and ANSI C63.4: 2009 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Maximum Peak Conducted Output Power FCC 47CFR 15.247(b)(1) FCC Pubic Notice DA 00-705 N/A Radiated Spurious Emissions FCC 47CFR 15.209 ANSI C63.4:2009 N/A AC Mains Conducted Emissions FCC 47CFR 15.207 ANSI C63.4:2009 N/A Number of Hopping Frequency FCC 47CFR 15.247(a)(2)(b)(1) FCC Pubic Notice DA 00-705 N/A 20dB Bandwidth FCC 47CFR 15.247(a)(2) FCC Pubic Notice DA 00-705 N/A Hopping Channel Separation FCC 47CFR 15.247(a)(1) FCC Pubic Notice DA 00-705 N/A Band-edge measurement (Radiated) FCC 47CFR 15.247(d) FCC Pubic Notice DA 00-705 N/A Pseudorandom Hopping Algorithm FCC 47CFR 15.247(a)(1) N/A N/A Time of Occupancy (Dwell Time) FCC 47CFR 15.247(a)(1)(iii) FCC Pubic Notice DA 00-705 N/A Antenna requirement FCC 47CFR 15.203 N/A N/A RF Exposure FCC 47CFR 15.247(i) N/A N/A Note: N/A – Not Applicable Date: 2014-12-15 Page 7 of 88 No.: DM117676 2.3 Table for Test Modes Preliminary tests were performed in different data rate to find the worst radiated emission. The data rate in the table below is the worst case rate with respect to the specific test item. Investigation has been done on all the possible configurations for searching the worst cases. The following table is a list of the test modes shown in this test report. Test Items Mode Data Rate Maximum Peak Conducted Output Power GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Hopping Channel Separation GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Number of Hopping Frequency GFSK / π/4-DQPSK / 8DPSK 2MBps Time of Occupancy(Dwell Time) 8DPSK (DH1 / DH3 / DH5) 2MBps Radiated Spurious Emissions GFSK / π/4-DQPSK / 8DPSK 1MBps / 2MBps / 3MBps Band-edge compliance of Conducted Emission GFSK / π/4-DQPSK / 8DPSK 2MBps Date: 2014-12-15 Page 8 of 88 No.: DM117676 3.0 Test Results 3.1 Emission 3.1.1 Maximum Peak Conducted Output Power Test Requirement: FCC 47CFR 15.247(b)(1) Test Method: FCC Pubic Notice DA 00-705 Test Date: 2014-11-26 Mode of Operation: Tx mode Test Method: The RF output of the EUT was connected to the spectrum analyzer. All the attenuation or cable loss will be added to the measured maximum output power. The results are recorded in dBm. Spectrum Analyzer Setting: RBW = 3 MHz, VBW= 3MHz, Sweep = Auto, Span = 10MHz Det…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF CONDUCTED EMISSION TEST SET UP
