2ADRQNXTBFVL3Locking Unit with RFID Reader

Nextbike GmbH Nextbike Electric Lock Instruction Manual 09.01.2015 1 Read me first o Before using the device, please read the entire manual and all safety instructions to ensure safe and proper use. o The descriptions in this manual is based on the default settings of the device. o The images and screenshots used in this manual may differ from the actual product. o The contents of this manual may differ from the product, or from software provided, software versions are individually created based on the requirements of the particular bicycle rental system. o Formatting and delivery of this manual is based on nextbike operating systems. o Functions of this on-boardcomputer may be different from those provided with the bicycles - functions vary by region or hardware specifications. o Please keep this manual for future reference. Copyright © 2014 nextbike GmbH This manual is protected under international copyright laws. No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of nextbike GmbH. 2 Table of contents 1. Summary .............................................................................................................................................................. 3 2. Applications ......................................................................................................................................................... 3 3. Hardware Description .......................................................................................................................................... 4 4. Further Characteristics ......................................................................................................................................... 6 5. Specification ......................................................................................................................................................... 6 6. Usage ................................................................................................................................................................... 6 7. Cautions ............................................................................................................................................................... 7 8. FCC-statements .................................................................................................................................................... 8 3 1. Summary The nextbike electric lock is an electronic system used in a bike rental system, to lock and unlock bicycles in a rack at central rental places. The complete system contains of one terminal and several racks. A trigger switch recognizes the presence of a bicycle. Via RFID reader ID of each bike is read. An electromechanical locking mechanism locks the front wheel securely or releases it for usage. A buzzer and a led give the customer feedback about the status. The communication between the lock unit and terminal is done via a fail-safe bidirectional data bus. The power supply is provided from the terminal. The power supply is low-power optimized, because the whole system is battery and solar powered. A RJ45-connector and –cable is used for connecting the systems. Electronics such as mechanics are realized vandal-proof and weather resistant. Due to the electronic is put in a small cup and potted with a compound. All connectors are partially filled with Vaseline. 2. Applications o Bicycle rental/return 4 3. Hardware Description 3.1 Design 3.2 Block Diagram 5 3.3 Microcontroller A low-power microcontroller provides a bus node, it checks the input and output components and minimizes the power consumption of the unit. The bus address and other specific parameters must be stored in non-volatile memory. The firmware of the controller must be updatable during operation. Updates run via the data bus. The firmware and the parameters are protected by 16 bit CRC. 3.4 RFID Reader The RFID reader AS3910 is used to read the ISO14443 tags at the front wheel of the bicycle. The lock module is located in a metal construction and so antenna is optimised for working in this environment. 3.5 Acoustic Signal and LED An acoustic signal and a green LED indicates to the user locking and unlocking of the bike. 3.6 Interface for communication and power supply The RS485 bus for data communication between the lock modules and the terminal has the following characteristics: o Fail safe o Bidirectional o Low-Power optimized o Maximum 20 modules and one terminal o Maximum 10m to terminal, 15m complete system o Power supply via bus cable o Data protection with 16 bit CRC 3.7 Bicycle detection Detecting an inserted bike by cyclic RFID queries requires too much energy. So instead a small switch is closed by a knob mounted at the bicycle fork. 3.8 Housing The actual body of the whole system is the rack coming from customer. Electronic module, switches and motor unit are mounted into this rack. Additionally electronic module is potted. 6 4. Further Characteristics 4.1. Operational conditions Degree of protection IP 52. Temperature range between 14 °F and 122 °F. 4.2. Quality management The product development and if necessary production is ensured by a quality management system according to DIN EN ISO 9001. 5. Specification Content Electric lock specification Dimensions Roller – Dimension: 45 mm x Height: 38 mm Weight 150 g Storage temp. - 4 °F to 40 °F Operation temp 14 °F to 122 °F Degree of protection IP 52. Sockets 2 x RJ45 Humidity 5% - 85% non-condensing 6. Usage 6.1 Locking and Unlocking The electromechanical locking and unlocking is controlled by the terminal. In open and in closed state, no electrical energy is required for this. Therefore the actuator is a bi-stable system. In case of a breakdown of the power supply the lock remains in its current …

Text truncated - open the document above for the full version.
