2ADRQNXTBFVM2Boardcomputer with card reader

Nextbike GmbH Nextbike Boardcomputer Instruction Manual 13.01.2015 1 Read me first o Before using the device, please read the entire manual and all safety instructions to ensure safe and proper use. o The descriptions in this manual is based on the default settings of the device. o The images and screenshots used in this manual may differ from the actual product. o The contents of this manual may differ from the product, or from software provided, software versions are individually created based on the requirements of the particular bicycle rental system. o Formatting and delivery of this manual is based on nextbike operating systems. o Functions of this boardcomputer may be different from those provided with the bicycles - functions vary by region or hardware specifications. o Please keep this manual for future reference. Copyright © 2014 nextbike GmbH This manual is protected under international copyright laws. No part of this manual may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of nextbike GmbH. 2 Table of contents 1. Summary .............................................................................................................................................................. 3 2. Applications ......................................................................................................................................................... 3 3. Hardware Description .......................................................................................................................................... 3 4. Functional Description ......................................................................................................................................... 8 5. Specification ....................................................................................................................................................... 10 6. Usage ................................................................................................................................................................. 10 7. GPS Usage .......................................................................................................................................................... 12 8. Cautions ............................................................................................................................................................. 12 9. FCC Statement ................................................................................................................................................... 13 3 1. Summary The nextbike on-boardcomputer is integrated into the nextbike smart bike. This on- boardcomputer enables the customers to rent and return smart bikes directly through its interface via Smart Card and mobile number including PIN code, automating the release and lock process for all registered customers. Customers without Smart Cards or personal log in information also have the choice to activate the rental via App or phone call to the IVR-service hotline. Furthermore, the system is connected to the nextbike Office Software via existing GSM/GPRS network and GPS satellites, which permits locating and monitoring bicycle in real time on kiosk terminals, App or calling the IVR-service hotline. 2. Applications o Bicycle rental/return o Bicycle tracking 3. Hardware Description 3.1 Nextbike’s components: On the bike a boardcomputer (above the rear wheel) and a lock unit (at the front) is mounted, which are connected by a 2-pin cable. The lock unit contains a motor for locking a bar and two switches for detecting an inserted bar and the motor end position. Apart from that, the boardcomputer is connected to the generator parallel to the two lamps of the bicycle. The lock unit FVML is encapsulated in a plastic housing board. The built-in components and connections are clearly in Figure 2. The boardcomputer FVM2 consists of two PCBs (base PCB and antenna PCB) that are connected by an 8 pin ribbon cable and inserted into a housing. The structure is shown in Figure 1. On the bottom side of the housing a 4-pin connector is screwed, which is soldered to the base PCB. So the generator and the lock unit can be connected. Besides boardcomputer includes the following main components: o A 10-number keyboard to wake up the system and to enter information (codes, ID o numbers and pins) o A RFID-Reader to wake up the system and to read customer cards o A display and LEDs to show status, lock codes and other information o A speaker for key feedback and alert tones o A GSM module for communication with central server o A WPAN-module (Synapse SM200) for local data exchange with the terminal 4 o A boost converter and a high side switch for supplying the lock unit o A power supply unit including battery o A Microcontroller with serial data flash memory o The system is supplied by an on-board battery that is charged by the bicycle generator. Cautions: A. Are developed with particular focus on vandalism and weather resistance (temperature range between 14 °F and 122 °F). B. Are developed for energy efficiency. As a standard the boardcomputer rests in sleep modus. With activating the unit via numeric key-pad the unit wakes up for 8 seconds if no other activity is recognized. The boardcomputer is designed to operate without any recharging for several weeks. One ride per week of 15-30 minutes will be sufficient to recharge the battery to 100%. C. The units are fixed in the upper cover of the back wheel. D. The electric components are covered by a waterproof glued acrylic box. E. Please maintain a minimum distance of 20 cm from the antenna. 3.2 Design Front Face 5 Rear Face Interior 6 Interior Front Face Interior Top Face Interior Bottom Face 7 3.3 Block Diagramm Cable Connector Female – WEiPU - S…

Text truncated - open the document above for the full version.

SLG Prüf- und Zertifizierungs GmbH Burgstädter Straße 20 D – 09232 Hartmannsdorf Test report Board computer with card reader [Bordcomputer mit Kartenlesegerät] FVM2 FCC rules, Part 15, Subpart C Radio test 1363-14-EE-15-PB003 Testing is a confidential matter Test report no. [Prüfbericht- Nr.]: 1363-14-EE-15-PB003 Date [Datum]: 2015-02-12 Revised by [geprüft]: Tested by [gemessen]: Svadlenka Puder Head of EMC laboratory [Leiter EMV-Labor] EMC laboratory [EMV-Labor] SLG Prüf- und Zertifizierungs GmbH Burgstädter Straße 20 D-09232 Hartmannsdorf EMC laboratory Phone: +49 (0) 37 22 / 73 23 - 760 Fax: +49 (0) 37 22 / 73 23 - 899 e-mail: [email protected] http://www.slg.de.com This report consists of [Dieser Bericht besteht aus]: 35 Pages [Seiten] Customer [Auftraggeber] nextbike GmbH Represented by [vertreten durch] Thomasiusstraße 16-18 Mr. [Herr] Vockeroth 04109 Leipzig, Germany [Deutschland] Order [Auftrag] Dated: 2014-11-05 [vom:] Aim of test [Zweck der Prüfung] Verification of conformity to the radio requirements according to customer’s test plan [Nachweis der Einhaltung der Funk- Anforderungen nach Prüfplan des Auftraggebers] Product [Erzeugnis] Board computer with card reader [Bordcomputer mit Kartenlesegerät] Type [Typ] FVM2 Manufacturer [Hersteller] nextbike GmbH Thomasiusstraße 16-18 04109 Leipzig, Germany [Deutschland] Date of test [Prüfzeitraum] 2014-12-10 – 2014-12-16 Location of test [Prüfungsort] Accredited EMC laboratory of the SLG Prüf- und Zertifizierungs GmbH Hartmannsdorf [akkreditiertes EMV-Labor der SLG Prüf- und Zertifizierungs GmbH Hartmannsdorf] Test according to [Prüfung nach] Customer’s specifications / test plan [Lastenheft / Prüfplan des Auftraggebers] Test base [Prüfgrundlage] 47 CFR Ch. I (14-1-10 Edition) FCC Part 15, Subpart C, §15.225 Test result [Prüfergebnis] The sample tested fulfills the radio requirements according to test plan of customer. [Der vorgestellte Prüfling erfüllt die Funk- Anforderungen nach Prüfplan des Auftraggebers] The test results refer to the tested samples only. Authorisation for the copying of details of this report must be obtained from the SLG Prüf- und Zertifizierungs GmbH. [Die Prüfergebnisse beziehen sich ausschließlich auf die in diesem Bericht genannten Prüfungsgegenstände. Die auszugsweise Ver- vielfältigung dieses Berichtes für Dritte ist nur mit schriftlicher Genehmigung der SLG Prüf- und Zertifizierungs GmbH gestattet.] Test report no. [Prüfbericht-Nr.]: 1363-14-EE-15-PB003 Page [Seite] 3 Details of accreditation / recognition status [Einzelheiten zu Akkreditierungen / Anerkennungen] The SLG EMC laboratory is accredited by the German Accreditation Body (DAkkS) [Das SLG EMV-Labor ist akkreditiert durch die Deutsche Akkreditierungsstelle GmbH (DAkkS)] DAkkS registration number [DAkkS-Registriernummer]: D-PL-15110-01-01 The SLG EMC laboratory is appointed as technical service of category A by the Federal Motor Transport Authority (KBA) [Das SLG EMV-Labor ist benannt als Technischer Dienst der Kategorie A von der Benennungsstelle des Kraftfahrt-Bundesamtes (KBA)] Registration number [Registriernummer]: KBA-P 00030-01 The Notified Body according to EMC directive is recognized by the Federal Network Agency for Electricity, Gas, Telecommunications, Post and Railway [Die Benannte Stelle nach EMV-Richtlinie ist anerkannt durch die Bundesnetzagentur für Elektrizität, Gas, Telekommunikation, Post und Eisenbahn (Bundesnetzagentur)] BNetzA registration number [Registriernummer]: BnetzA-bS-07/61-13/1 The SLG EMC laboratory is listed by the Federal Communications Commission (FCC) [Das SLG EMV-Labor ist gelistet bei der Federal Communications Commission (FCC)] Registration number [Registrierungsnummer]: 883849 The SLG EMC laboratory is listed by the Industry Canada Certification and Engineering Bureau [Das SLG EMV-Labor ist gelistet beim Industry Canada Certification and Engineering Bureau] Company number [Firmennummer]: 6114A Test report no. [Prüfbericht-Nr.]: 1363-14-EE-15-PB003 Page [Seite] 4 Contents [Inhalt] 1 General information [Allgemeines] ................................................................................................. 5 1.1 Report chronology [Berichtschronologie] ............................................................................... 5 1.2 Declaration concerning the translation German / English [Erklärung zur Übersetzung Deutsch / Englisch] .................................................................... 5 1.3 General test conditions [Allgemeine Prüfbedingungen] ......................................................... 5 2 Summary of radio test results [Übersicht über die Funk-Prüfergebnisse] ................................. 7 3 Description of the test sample [Angaben zum Prüfling] ............................................................... 8 4 Emission tests [Störaussendungsprüfungen] ............................................................................. 10 4.1 Field strength in the band 13.110 – 14.010 MHz (spectrum mask) [Feldstärke in dem Frequenzband 13,110 – 14,010 MHz (Spektrum- Maske)] ................... 10 4.2 Field strength outside of the 13.110 – 14.010 MHz band (field stength < 30 MHz) [Feldstärke außerhalb dem 13,110 – 14,010 MHz Band (Feldstärke < 30 MHz)] ............... 16 4.3 Field strength outside of the 13.110 – 14.010 MHz band (field stength > 30 MHz) [Feldstärke außerhalb dem 13,110 – 14,010 MHz Band (Feldstärke > 30 MHz)] ............... 21 4.4 Frequency tolerance of the carrier signal [Frequenzabweichung des Trägersignals] ........................................................................... 28 4.5 Signal bandwidth [Signalbandbreite] .................................................................................... 32 5 List of test equipment [Messmittel und Prüfgeräte] .................................................................... 34 Test report no. [Prüfbericht-Nr.]: 1363-14-EE-15-PB003 Page [Seite] 5 1 General information [Allgemeines] 1.1 Report chrono…
