Wireless Pairing 1.Please check to make sure the device to which you are pairing has Bluetooth® capabilities. This information should be included in your phone or music player’s instructions or packaging. 2.Make sure that the headset is turned off. 3.Place the headset and the device in proximity so that both devices are in view. 4.Press the power button to turn on. A blue and red light will alternately flash and the voice prompt will let you know the device is ready to pair. 5.Check your smartphone or music player’s list of items available for pairing. Select the headphones and complete the pairing. 6.Once paired, the blue light will stay on solid and the voice prompt will let you know the devices are connected. Note: Some mobile phones or other devices may pair automatically when re-started. Answer / End / Redial a Call When a call comes in, the ring will be heard through the headset. 1.Press the Pause\Play\Phone button >II / to answer the call. 2.You may also accept or decline a call using your phone’s functions. 3.To end a call, Press the Pause\Play\Phone button >II / . You may also end the call using your phone’s functions. 4.Redial the last dial-out number: On standby mode, press and hold the Pause\Play\Phone button >II / twice. Auxiliary Line-In Mode (Plugging in a phone or music player) Plug one end of the provided 3.5mm AUX cable into the smart phone of music player’s headphone or speaker jack and plug the other end into the TEK163. The headphones will automatically switch to Line-In mode. Operate the song selections and volume from the smart phone or music player. The mini USB cord may also be used to connect to USB devices for headphone use. Please Note: Volume, Pause\Play, Next, and Previous song function buttons are not available in AUX Line-in mode. (Use your music player controls.) FM Scan Radio Mode 1.Press the mode (M) button until the speaker says “FM Tuner”. 2.Press and release the pause\play\phone button to cycle through stations. To stop scanning, press one of the seek buttons a nd then use them to find the desired station. 3.Use the next or previous buttons to find a station. 4.Press and hold next or previous buttons to control volume. TF Card Mode Plug the TF Card into the slot and use the Bluetooth® protocols for the button functions. Precautions •Please only use the computer USB or the DC 5V power adaptor matching the Mini USB interface to charge. Only use quality cords and adaptors. •Please keep and use in normal environments. Exposure to extreme elements such as extreme heat and cold, fire, excessive moisture, dust, or other extreme elements may damage the unit. Do not touch with wet hands. •Keep debris or other items from blocking the speakers or from entering any of the ports. •Do not attempt to open, repair, or take apart the headphones. The headphones will be damaged during that process. •If the speaker quality seems lessened, or a popping noise is heard, it may be due to low battery. Please recharge the speaker. •This product is not for children. TROUBLESHOOTING No Sound •Make sure that the music player is working and that the headphones are charged. •Make sure the Bluetooth® is paired or the AUX 3.5mm cable is plugged in properly on both ends. •Make sure the TEK163 is in the proper mode. If in FM Scan Radio mode, you ma y have to press the Next\Previous or Scan button to find a station. Not charging Check to make sure that you are using the correct cable and that it is fully plugged into both the device and the USB port that you are charging from. Also check to make sure the PC or other USB charger is turned on. 28002 Wireless Over the Ear Headphone INSTRUCTIONS Features •Wireless Headphones •Wireless Speaker Phone Option •FM Scan Radio Function •Auxiliary Line-in Play Function •TF Card Reading Function •Mini USB Charging Cable and 3.5mm Line-in Cable •Rechargeable Battery Product Specifications: Wireless Version: V2.1+DR Operation distance: 30 Feet Range of frequency: 2.4 to 2.4835 Gigahertz ISM band Sensitivity: +85 dB MP3 PC interface: USB2.0 Music format: MP3/WMA TF card support: 128M-32GB Rechargeable lithium battery: 350mAh Stereo headphone with MIC Speaker: φ40mm Sensitivity: 115dB S.P.L at 1KHZ Impedance: 32Ω Frequency response: 20HZ-20KHZ Rated power: 40mW Power capacity: 100mW Cable length: 4.5 Feet Microphone unit: 4.5mmx2mm -58dB±3dB Buttons of Operation (N\A for Auxiliary Line-In mode) Power: Press and hold for 3 seconds to turn on or off. I<< / V- Previous\Volume Down: Press and release to go to previous song. Press and hold to decrease volume. In FM Scan Radio mode, search to the next station. Functions not available in AUX Line in mode. >II / Pause\Play\Phone: Press and release to pause/play music. Press and release to answer/end call. Press and hold for 3 seconds twice to redial the last call. >>I \ V+ Next\Volume Up: Press and release to go to the next song. Press and hold to increase volume. In FM Scan Radio mode, search to the next station. Functions not available in AUX Line in mode. M Mode: Press to toggle between Bluetooth®, Aux Input, TF Card, and Scan Radio Functions. Charging the Headphones Plug the mini USB end of the charging cable into the headset and then connect the USB end of the charging cable to the USB port of your PC or other USB power source. The red LED light will light up during charging. It is strongly recommended that the headphones be fully charged before first use and after long periods of inactivity. Turn On\Off Press and hold the power button for 3 seconds to turn on. To turn off, press and hold the power button for 3 seconds. Please Note: It is strongly recommended that you turn off the headset and Bluetooth® on the device while not in use. 145*180MM FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, …

Text truncated - open the document above for the full version.

DATE : July 15, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADW3-28002 Product Name: Bluetooth Headphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this July 15, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Youkiy Lou Signature Printed Title: Manager On behalf of : LEADER INNOVATIONS LTD. Telephone: 0574-87723018

Outside view Outside view

Label Location

FCC ID: 2ADW3-28002

Inside view Inside view Inside view

RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (Worse Case): GFSK Mode: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =1.89/5 * 1.56= 0.59, this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. The SAR measurement is not necessary.

ISO/IEC17025Accredited Lab. Report No.: FCC 1507007 File reference No.: 2015-07-03 Applicant: LEADER INNOVATIONS LTD Product: BLUETOOTH HEADPHONE Model No.: 28002 Trademark: N/A Test Standards: FCC Part 15 Subpart C, Paragraph 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10&FCC Part 15 Subpart C, Paragraph 15.247 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: July 03, 2015 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Room 512-519, 5/F., East Tower, Building 4, Anhua Industrial Zone, Futian District, Shenzhen, Guangdong, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No: FCC1507007 Page 2 of 79 Date: 2015-07-03 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:1999 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 899988 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.:899988. IC- Registration No.: IC5205A-02 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. The acceptance letter from the IC is maintained in our files. Registration No.: IC 5205A-02. Report No: FCC1507007 Page 3 of 79 Date: 2015-07-03 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 5 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condition....................................................................................9 5.5 Conducted Emi…

Text truncated - open the document above for the full version.

Conducted Emission Test Setup: Radiated Emission Test Setup:
