BSPB-6/6408 WIRELESS 3 IN 1 POWERPLAY SPEAKER With built-in 2600mAh Power Bank INSTRUCTION MANUAL PLEASE READ ALL INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE USE Getting Started • Remove the device from the box. • Remove any packaging from the product. • Please retain all packaging until you have checked and counted all the parts and the contents against the parts list. Package Contents • Wireless 3 In 1 Power-play Speaker with Built-in Power Bank • USB rechargeable cord • 3.5mm Auxiliary cord • Instruction Manual Key Features • Play wireless music via Bluetooth technology • Use as Hands-Free speaker phone device, with a built-in microphone • Charge various devices through built-in 2600mAh Power Bank • Compatible with all Bluetooth enabled devices such as Smart Phones, Tablets, etc. • Built-In Power Bank to charge your mobile devices • 3.5mm AUX wired Connection for MP3/MP4 Players, iPods, computers, netbooks, laptops etc. • Wireless Range – 26 to 33 Feet SAFETY INSTRUCTIONS • Keep the unit away from heat sources, direct sunlight, humidity, water and any other liquids. • Do not operate the unit if it has been exposed to water, moisture or any other liquids to prevent against electric shock, explosion and/or injury to yourself and damage to the unit. • Do not use the unit if it has been dropped or damaged in any way. • Repairs to electrical equipment should only be performed by a qualified electrician. Improper repairs may place the user at serious risk. • Do not use the unit with wet hands. • Do not put objects into any of the openings. • Keep the unit free from dust, lint etc. • Do not use this unit for anything other than its intended use. • Keep the unit out of reach of children. • This appliance is not a toy. • Do not use the handset at excessive levels as damage to hearing may occur. Specifications – Bluetooth® Version: 2.1 Wireless Distance: 30 to 33 feet Working time: Music ~3 hours, Talk ~3 hours Speaker: 2 x 3Watts Unit size: 6.5”x2.2”x2.5” Unit weight: 12 Oz Power Input: DC 5V Built-In Rechargeable Battery: 2600mAh Built-in 3.7V rechargeable Li-ion battery Charging Time: 6 to 8 Hours USB Charging Port – 5V / 1A (Max) Output (Note: Battery life, Working time & charging time may vary based on usage & types of devices used.) Care and maintenance Read the following recommendations before using the product. Following these you will be able to enjoy the product for many years. •Do not expose the unit to liquid, moisture or humidity to avoid the product’s internal circuit being affected. •Don’t use abrasive cleaning solvents to clean the unit. •Do not expose the unit to extremely high or low temperature as this will shorten the life of electronic devices, destroy the battery or distort certain plastic parts. •Don’t dispose of the unit in fire as it will result in an explosion. •Don’t expose the unit to contact with sharp objects as this will cause scratches and damage. •Don’t let the unit fall down onto the floor. The internal circuit might get damaged. •Don’t attempt to disassemble the unit as it may get damaged if you are not professional. In case the unit does not function properly, please contact the number shown on the Warranty Page for help. FCC Instructions Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the product does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : - Reorient or relocate the receiving antenna. - Increase the separation between the product and receiver. - Connect the product into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. LIMITED WARRANTY This manufacturer's product warranty extends to the original consumer purchaser of the product. Neither the retailer nor any other company involved in the sale or promotion of this product is a co-warrantor of this manufacturer warranty. WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser for a period of ninety (90) days from the original purchase date. WARRANTY COVERAGE: This product is warranted against defective materials or workmanship. This warranty is void if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect, improper service, commercial use, repairs by unauthorized personnel or other causes not arising out of defects in materials or workmanship. This warranty doesn’t cover the following which may be supplied with this product, including but not limited to; LCD Screens, glass parts, lenses, bulbs etc. This warranty is effective only if the product is purchased and operated in USA and Canada, and does not extend to any units which have been used in violation of written instructions furnished by manufacturer or to units which have been altered or modified or, to damaged products or parts thereof which have had the serial number removed, altered, defaced or rende…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F, bldg F7, F518 Idea Land ,Baoyuan Road,Xixiang Avenue, Bao’an District,Shenzhen,China 2015-4-6 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, SHENZHEN TEKSUN TECHNOLOGY CO.,LTD hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ADXM522066MBT Model: 522066-MBT Product name: Bluetooth speaker Sincerely, signature : name / title: Mandy Peng / PMC address: 3F, bldg F7, F518 Idea Land ,Baoyuan Road,Xixiang Avenue, Bao’an District,Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F, bldg F7, F518 Idea Land ,Baoyuan Road,Xixiang Avenue, Bao’an District,Shenzhen,China 2015-4-7 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADXM522066MBT We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Mandy Peng / PMC address: 3F, bldg F7, F518 Idea Land ,Baoyuan Road,Xixiang Avenue, Bao’an District,Shenzhen,China

Model: 522066-MBT FCC ID: 2ADXM522066MBT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

FCC ID: 2ADXM522066MBT Keyway Testing Technology Co., Ltd. Report No. 15KWE042421F Page 1 of 26 FCC TEST REPORT(Bluetooth) for SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Bluetooth Speaker Model Number: 522066-MBT FCC ID: 2ADXM522066MBT Prepared for : SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Address : 3F，bldg F7,F518 Idea Land,Baoyuan Road, Xixiang Avenue,Bao’an District,Shenzhen,CN Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE042421F Date of Test : Mar. 28~ Apr. 3, 2015 Date of Report : Apr. 3, 2015 FCC ID: 2ADXM522066MBT Keyway Testing Technology Co., Ltd. Report No. 15KWE042421F Page 2 of 26 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION ......................................................................................... 4 2.1. Product Function .................................................................................................................... 4 2.2. Description of Device (EUT) .................................................................................................. 4 2.3. Difference between Model Numbers ...................................................................................... 4 2.4. Independent Operation Modes .............................................................................................. 4 2.5. Test Supporting System ......................................................................................................... 4 3. TEST SITES .................................................................................................................................. 5 3.1. Test Facilities ......................................................................................................................... 5 3.2. List of Test and Measurement Instruments ............................................................................ 6 4. TEST SET-UP AND OPERATION MODES .................................................................................. 7 4.1. Principle of Configuration Selection ....................................................................................... 7 4.2. Block Diagram of Test Set-up ................................................................................................ 7 4.3. Test Operation Mode and Test Software ............................................................................... 7 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 7 4.5. Countermeasures to Achieve EMC Compliance .................................................................... 7 5. EMISSION TEST RESULTS ......................................................................................................... 8 5.1. Radiated Emission Test ....................................................................................................... 11 6. 20DB OCCUPY BANDWIDTH ..................................................................................................... 17 6.1. Limits .................................................................................................................................... 17 6.2. Test setup ............................................................................................................................ 17 7. BAND EDGE COMPLIANCE TEST ............................................................................................. 21 7.1. Limits .................................................................................................................................... 21 7.2. Test setup ............................................................................................................................ 21 8. ANTENNA REQUIREMENTS ...................................................................................................... 22 8.1. Limits .................................................................................................................................... 22 8.2. Result ................................................................................................................................... 22 9. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 23 10. PHOTOGRAPHS OF THE EUT ............................................................................................... 25 FCC ID: 2ADXM522066MBT Keyway Testing Technology Co., Ltd. Report No. 15KWE042421F Page 3 of 26 Keyway Testing Technology Co., Ltd. Applicant: Address: SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F，bldg F7,F518 Idea Land,Baoyuan Road,Xixiang Avenue,Bao’an District,Shenzhen,CN Manufacturer: Address: SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F，bldg F7,F518 Idea Land,Baoyuan Road,Xixiang Avenue,Bao’an District,Shenzhen,CN E.U.T: Bluetooth Speaker Model Number: 522066-MBT Trade Name: ------ Serial No.: ------ Date of Receipt: Mar. 27, 2015 Date of Test: Mar. 28~ Apr. 3, 2015 Test Specification: FCC Part 15, Subpart C Section 15.249: Oct. 1, 2014 ANSI C63.4:2014 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Apr. 3, 2015 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ADXM522066MBT Keyway Testing Technology Co., Ltd. Report No. 15KWE042421F Page 4 of 26 1. TEST SUMMARY Test Items Test R…
