2ADXM5B126BTWireless waterproof floating speaker

SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F, bldg F7, F518 Idea Land, Baoyuan Road, Xixiang Avenue, Bao’an District, Shenzhen, CN TEL: +86-755-29402650 FAX: +86-755-29402650 DATE 11-11-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADXM5B126BT Product Name: Wireless waterproof floating speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 11-11-2015 By: Mandy Peng Signature Printed Title: PMC On behalf of : SHENZHEN TEKSUN TE CHNOLOGY CO.,LTD Telephone: +86-755-29402650

SHENZHEN TEKSUN TECHNOLOGY CO.,LTD 3F, bldg F7, F518 Idea Land, Baoyuan Road, Xixiang Avenue, Bao’an District, Shenzhen, CN TEL: +86-755-29402650 FAX: +86-755-29402650 USB Port Statement FCC ID: 2ADXM5B126BT Date: Nov. 11, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: 5B126BT) USB port only used for charge, no any data transfer to PC. Sincerely, Mandy Peng/ PMC

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: 5B126BT FCC ID: 2ADXM5B126BT FCCID Label Location

RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Ant gain 1.2dBi ;so Ant numeric gain=1.32 Field strength = 97.16 dBuV/m @3m So Pt={ [10 (97.16 /20) /10 6 x3] 2 /30x1.32}x1000 mW = 1.18 mW So ( 1.18 mW/5mm)x √2.402 GHz =0.366 < 3 Then SAR evaluation is not required

- Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT Report Reference No.: CTL1511033179-WF Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Tracy Qi (Manager) Product Name...............................: Wireless waterproof floating speaker Model/Type reference..................: 5B126BT Trade Mark....................................: N/A FCC ID...........................................: 2ADXM5B126BT Applicant’s name.........................: SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Address of applicant...................: 3F, bldg F7, F518 Idea Land, Baoyuan Road, Xixiang Avenue, Bao’an District, Shenzhen, CN Test Firm.......................................: Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm...................: Floor 1- A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification.........................: Standard........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator..........................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF..............................: Dated 2011-01 Date of Receipt.............................: Nov. 03, 2015 Date of Test Date..........................: Nov. 03, 2015 - Nov. 09, 2015 Data of Issue.................................: Nov. 09, 2015 Result............................................: Positive Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 29 Report No.: CTL15111033179-WF T E S T R E P O R T Test Report No. : CTL15111033179-WF Nov. 09, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Wireless waterproof floating speaker Model /Type : 5B126BT Applicant : SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Address : 3F, bldg F7, F518 Idea Land, Baoyuan Road, Xixiang Avenue, Bao’an District, Shenzhen, CN Manufacturer : SHENZHEN TEKSUN TECHNOLOGY CO.,LTD Address : 3F, bldg F7, F518 Idea Land, Baoyuan Road, Xixiang Avenue, Bao’an District, Shenzhen, CN Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 29 Report No.: CTL15111033179-WF Contents 1.TEST STANDARDS .................................................................. 4 2.SUMMARY............................................................................. 5 2.1.Equipment Under Test 5 2.2.Description of the Equipment under Test (EUT) 5 2.3.EUT operation mode 6 2.4.EUT configuration 6 2.5.Related Submittal(s) / Grant (s) 6 2.6.Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1.Address of the test laboratory 7 3.2.Test Facility 7 3.3.Environmental conditions 7 3.4.Configuration of Tested System 7 3.5.Statement of the measurement uncertainty 8 3.6.Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1.Conducted Emissions Test 10 4.2. Transmitter Radiated Unwanted Emissions and Bandedge 13 4.3.Occupied Bandwidth Measurement 19 5. ANTENNA REQUIREMENT ....................................................... 23 6.TEST SETUP PHOTOS OF THE EUT .......................................... 24 7.EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 26 V1.0 Page 4 of 29 Report No.: CTL15111033179-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10-2013 ANSI C63.4-2014 V1.0 Page 5 of 29 Report No.: CTL15111033179-WF 2. SUMMARY 2.1. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ƽ Other (specified in blank below) DC 3.7V from battery 2.2. Description of the Equipment under Test (EUT) The EUT (Wireless waterproof floating speaker) support Bluetooth function. Name of EUT Wireless waterproof floating speaker Model Number 5B126BT Antenna Type Internal BT Operation frequency 2402MHz-2480MHz BT Modulation Type GFSK,8DPSK,/4DQPSK(BT V2.1+EDR) Bluetooth BT V2.1+EDR Antenna Gain 1.2dBi Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 77 2479 24 2426 51 2453 78 2480 25 2427 52 2454 26 2428 53 2455 For more details, refer to the user’s manual of the EUT. Serial number: Prototype V1.0 Page 6 of 29 Report No.: CTL15111033179-WF 2.3. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel T…
