2AEMI-MONEDEMontior One DE

Particle Industries, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 05, 2023
Application Purpose: Original Equipment
Date of Application: Dec 04, 2023
Equipment Note: Montior One DE
Frequency Range: 2412.00000000 - 2462.00000000
Company: Particle Industries, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/1/56 The pictures in this preliminary datasheet are of a pre-release unit. The production units will be a diff erent color, and may have other minor differences. The Monitor One is an off-the-shelf complete gateway design, like the Tracker One. The Monitor One is in a larger IP67 waterproof enclosure with room inside for an expansion card and additional connectors, allowing it to be used in more custom scenarios than the Tracker One. Ready to go with rugged IP67-rated enclosure with room inside for an expansion card. Monitor One datasheet 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/2/56 Flexible power supply to easily add asset tracking to most devices with a 6 - 30 VDC power input and a large 18650 LiPo battery pack. Internal or external antennas for cellular and GNSS. Temperature sensors on the carrier board, and also a battery pack temperature sensor. Expansion card connector to allow for custom application speciic hardware. RGB LED for system status, and two user RGB LEDs for your own use, visible from outside the enclosure. User button, waterproof and accessible from outside the enclosure. Particle gateway device like the Monitor One and Tracker One are designed to be used off-the-shelf to interface to other devices and sensors using standard protocols such as CAN bus, I2C, and serial. For information on setting up a Monitor One Developer Edition, see the Monitor One Quickstart. Block diagram 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/3/56 Details about the Tracker SoM that is contained within the Monitor One can be found in the Tracker SoM Datasheet. The Monitor One Developer's Edition is currently in the engineering sample stage. Certiication is not expected until September or October 2023. Certiication External features 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/4/56 LabelFeature 1System RGB LED 2GNSS antenna (internal) 3Cellular antenna (internal) 4External connectors (on bottom) 5Magnetic, bolt-down, or strap-down mounting bracket 6User RGB LEDs (2) 7User button (externally accessible) 8Wi-Fi geolocation antenna (internal, optional) 9Cover screws (6) (M2 hex, 2mm) 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/5/56 A waterproof button is available from the outside of the enclosure. Long press (10 seconds) resets the device (as if the RESET button was pressed) Shorter press and multiple press can be handled by your user irmware for your own features There are two small RGB LEDs visible from the outside on the side of the unit, next to the user button. The upper LED defaults to being a GNSS lock indicator: Off: GNSS off Blinking (green): attempting to get a GNSS ix On (green): GNSS ix acquired You can program custom colors, blinking, and fade effects from your user irmware for the lower LED. LEDs are controlled by a ADP8866 I2C LED controller. User button User LEDs (2) Connectors 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/6/56 The bottom plate of the Monitor One can be customized with different connectors for your application. LabelFeature 1Cellular antenna (SMA) 2M12 connector (8-pin) 3M12 connector (4-pin) 4GNSS antenna (SMA) 5Mounting plate attachment screw 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/7/56 By default the Monitor One uses the internal cellular and GNSS antennas, but can be switched to using the external connectors inside the enclosure. The cellular (1) and GNSS (4) antennas are not connected internally at the factory. In order to use the external connectors you must open the case, disconnect the internal antenna, and instead connect the U.FL connector for the external jack. The Monitor One is equipped with 2 external-facing SMA bulkhead connectors for both cellular and GNSS but are disconnected internally. The hardware is ready for use with external antennas giving the ability to connect a wide variety of application-speciic antennas. It is recommended that the user perform required RF certiications with the selected antenna installed as the Monitor One has only been certiied for use in select regions with the internal antennas. The Monitor One is intended to be mounted in the orientation shown at the top of the page, with the connectors facing down. You can also mount it with the mounting plate mounted on a lat surface as the GNSS antenna is angled to allow it to work in either orientation. When using external cellular and GNSS antennas you can orient the Monitor One in other directions. Mounting 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/8/56 LabelDetails 1Mounting screw or bolt holes 2Slots for strap mounting 3Magnets 4Mounting plate removal screw (M3 hex, 3mm) The mounting plate contains two magnets (3) that allow it to be easily mounted on a metal surface. The mounting plate is removable from the back of the unit after removing the screw on the bottom (4), near the expansion connectors. 2023/9/22 14:58Monitor One Datasheet | Reference | Particle https://docs.particle.io/reference/datasheets/tracker/monitor-one-datasheet/9/56 Once removed, you can screw or bolt the mounting plate through the four holes (1) and reattach the Monitor One. This is good for rough conditions and for mounting on non-metal surfaces. The mounting plate can be strap mounted through the two slots (2). The mag…

Text truncated - open the document above for the full version.

Attestation Statements

Rev 1/26/2023 Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 8,2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AEMI-MONEDE Particle Industries,Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, _______________ Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592 Rev 1/26/2023 Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 8,2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AEMI-MONEDE Particle Industries,Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered”equipment. Sincerely, _______________ Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592

Attestation Statements

Cover Letter(s)

Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Date: November 28, 2023 Declaration To whom it may concern, We, Particle Industries,Inc, declare that the device, FCC ID: 2AEMI-MONEDE, does not support any non-US channels in all the operational mode(s). All non-US frequencies, US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours, _______________ Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592

Cover Letter(s)

Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Date: November 28, 2023 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: 2AEMI-MONEDE To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.  Schematic Diagram  Block Diagram  Parts List  Operational Description  Tune up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, _______________ Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592

Cover Letter(s)

Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Date: November 28, 2023 Power of Attorney To whom it may concern, Please be notified that I, Zach Supalla, have designated Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co., Ltd as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co. Ltd on the matters relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.U.S.C. 862, we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act. This authorization is limited to the product of as following: FCC ID: 2AEMI-MONEDE If you have any acknowledgement and response, please send it to Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co., Ltd directly. Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, _______________ Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592

Cover Letter(s)

Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Date: November 28, 2023 Statement and explanations The host MON404-DE (FCC ID: 2AEMI-MONEDE) is a new product with one certified module BG96/BG96 MINIPCIE (Module ID: XMR201707BG96; Grant Date: 09/04/2020) integrated. The referenced module report number is: R2007A0435-R4, R2007A0435-R5, R2007A0435-R6. This BG96/BG96 MINIPCIE module is a single modular and it was integrated into the host that not any effect on RF performance. Bureau Veritas 7Layers Communications Technology (Shenzhen) Co. Ltd have performed MPE for the host and the ERP/EIRP and RSE re-tested. Please refer to the lab test results accordingly. The Module supports LTE Cat M1 B2/4/5/12/13/25 ,LTE Cat NB1 B B2/4/5/12/13/25,GSM850/1900 but the host with the integrated module BG96/BG96 MINIPCIE only supports LTE Cat M1 B2/4/5/12/13 and GSM850/1900, it disable other bands by software. Consequently, Radio test data retrieved from the initial application FCC ID: XMR201707BG96 can be re-used for the FCC ID: 2AEMI-MONEDE. Spot check test data are described as below: FCC Rule Part Frequency Band Re-test items FCC Part 22 GSM850 LTE B5 Conducted output power Effective Radiated Power Radiated spurious emissions FCC Part 24 GSM1900 LTE B2 Conducted output power Equivalent Isotropic Radiated power Radiated spurious emissions FCC part 27 LTE B4,LTE B12,LTE B13 Conducted output power Equivalent Radiated power and Radiated spurious emissions DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592 Particle Industries,Inc 325 9th Street, San Francisco, CA 94103, United States Of America Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, Zach Supalla Particle Industries,Inc Tel: +1-415-316-1024 Fax: +1-415-316-1024 E-mail: [email protected] DocuSign Envelope ID: 2859054F-3B98-43D2-AF9B-90370C14E592

External Photos

Internal Photos

BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 1 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE PHOTOGRAPHS OF THE EUT BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 2 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 3 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 4 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 5 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 6 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 7 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 8 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 9 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 10 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE GNSS ANT BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 11 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE WIFI ANT BV 7Layers Communications Technology (Shenzhen) Co., Ltd No.B102, Dazu Chuangxin Mansion, North of Beihuan Avenue, North Area, Hi-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Tel: +86 755 8869 6566 Fax: +86 755 8869 6577 Email: [email protected] Page 12 of 12 Report Version 1 Reference No.: W7L-P23100004 FCC ID: 2AEMI-MONEDE BT ANT WWAN ANT

RF Exposure Info

FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Oct. 20, 2023 Report No. : W7L-P23100004SA01 FCC RF Exposure Test Report Report No. : W7L-P23100004SA01 Applicant : Particle Industries,Inc Address : 325 9th Street, San Francisco, CA 94103, United States Of America Product : Montior One DE FCC ID : 2AEMI-MONEDE Brand : Particle Model No. : MON404-DE Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 General RF Exposure Guidance v06 Sample Received Date : Oct. 11, 2023 Date of Testing : Oct. 11, 2023 ~ Oct. 20, 2023 CERTIFICATION: The above equipment have been tested by BV 7LAYERS COMMUNICATIONS TECHNOLOGY (SHENZHEN) CO., LTD., and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA or any government agencies. Prepared By : Approved By : Jerry Chen / Engineer Luke Lu / Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Oct. 20, 2023 Report No. : W7L-P23100004SA01 Table of Contents RELEASE CONTROL RECORD .................................................................................................................................................... 3 1. DESCRIPTION OF EQUIPMENT UNDER TEST .................................................................................................................... 4 2. MPE(MAXIMUM PERMISSIBLE EXPOSURE) ASSESSMENT ............................................................................................. 4 2.1 INTRODUCTION .......................................................................................................................................................... 5 2.2 RF RADIATION EXPOSURE LIMITS ........................................................................................................................... 5 2.3 MPE ASSESSMENT METHOD .................................................................................................................................... 6 2.4 MPE CALCULATION FOR STANDALONE OPERATIONS .......................................................................................... 6 2.5 CONCLUSION OF SIMULTANEOUS TRANSMITTER ................................................................................................ 8 3. INFORMATION ON THE TESTING LABORATORIES ........................................................................................................... 9 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Oct. 20, 2023 Report No. : W7L-P23100004SA01 Release Control Record Report No. Reason for Change Date Issued W7L-P23100004SA01 Initial release Oct. 20, 2023 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Oct. 20, 2023 Report No. : W7L-P23100004SA01 1. Description of Equipment Under Test Product: Montior One DE Brand Name: Particle Model Name: MON404-DE Tx Frequency Bands (Unit: MHz) GSM850 : 824.2 ~ 848.8 GSM1900 : 1850.2 ~ 1909.8 LTE Band 2 : 1850.7 MHz ~ 1909.3 MHz LTE Band 4 : 1710.7 MHz ~ 1754.3 MHz LTE Band 5 : 824.7 MHz ~ 848.3 MHz LTE Band 12 : 699.7 MHz ~ 715.3 MHz LTE Band 13 : 779.5 MHz ~ 784.5 MHz WLAN : 2412 ~ 2462 BT_LE : 2402 ~ 2480 Uplink Modulations GSM & GPRS : GMSK EDGE : 8PSK LTE : QPSK, 16QAM 802.11b : DSSS 802.11g/n: OFDM BT_LE : GFSK, π/4-DQPSK, 8-DPSK Antenna Type WWAN: Fixed External Antenna WLAN: PIFA Antenna BT_LE : Chip Antenna EUT Stage Production Unit Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Oct. 20, 2023 Report No. : W7L-P23100004SA01 2. MPE(Maximum Permissible Exposure) Assessment 2.1 Introduction According to 47 CFR §2.1091, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitting antenna and the …

Text truncated - open the document above for the full version.

Test Report

AT5020-E3R0HBAT/LF REV:3 PAGE:1/8 ACX Advanced Ceramic X Features  Monolithic SMD with small, low-profile and light-weight type.  Wide bandwidth Applications 2.4GHz WLAN, Home RF, Bluetooth Modules, etc. Specifications Part Number Operating Frequency (MHz) Peak Gain (dBi typ.) Average Gain (dBi typ.) VSWR Impedance AT5020 -E3R0HBA_ 2400~25000dBi (XZ-V) -1.5dBi (XZ-V)2 max. 50  Q’ty/Reel (pcs) : 2,000 pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Storage Period : 12 months max. Power Capacity : 2W max. Part Number  Type AT : Antenna  Dimensions ( L × W ) 5.0× 2.0 mm  Material Code E  Initial center frequency 3R0=3000MHz  Specification Code HBA  Packaging T: Tape & Reel B: Bulk  Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal NameNo. Terminal Name  Feeding Point  NC  NC  NC AT5020 Series Multilayer Chip Antenna AT 5020 - E 3R0 HBA          A CX  AT5020-E3R0HBAT/LF REV:3 PAGE:2/8 ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Mark L W L1 W1 T a Dimensions 5.0±0.2 2.0±0.2 2.6±0.2 0.5±0.2 2.0+ 0.1/-0.2 0.5±0.3 (a) Without Matching Circuits (Unit in mm) (b) With Matching Circuits *Line width should be designed to match 50 characteristic impedance, depending on PCB material and thickness Unit : mm (Matching circuit and component values will be different, depending on PCB layout) a T L1 W1 L W ACX Top view Bottom view Side view 1.03 2.8 1 0.7 1 0.7 0.82 0.7 1 1 2 2 8 3.86 0 Ohm 0.7 A CX 2.8 10.7 1 1 0.7 1.03 0.7 0.82 0.7 1 2 2 8 3.86 3.3 nH 1.5 nH ACX AT5020-E3R0HBAT/LF REV:3 PAGE:3/8 ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C)  Test Board (Unit in mm) Return Loss(with matching) 3.86 40 20 Ground No Ground 8 Antenna AT5020-E3R0HBAT/LF REV:3 PAGE:4/8 ACX Advanced Ceramic X Radiation Patterns XZ cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H XY cut @2.45GHz Vertical Horizontal XY-V/XY-H 180 o 270 o 0 o 90 o X Z Y XY-cut scanning direction 180 o 270 o 0 o 90 o X Z Y XZ-cut scanning direction 180 o 270 o 0 o 90 o X Z Y YZ-cut scanning direction XZ cut @2.45GHz Vertical Horizontal AT5020-E3R0HBAT/LF REV:3 PAGE:5/8 ACX Advanced Ceramic X Taping Specifications Tape & Reel Dimensions (Unit: mm) vs. Quantity (pcs) Type A A’ B C D E F T Quantity/per reelTape material AT5020 4.0± 0.1 4.0± 0.1 2.4± 0.1 5.4± 0.1 2.0± 0.05 5.5± 0.1 12.0± 0.1 2.3± 0.1 2,000pcs Plastic (Embossed) Reel Dimensions (Unit: mm) Leader and Trailer Tape Type W2 W3 W4 W5 AT5020 178±1 60±1 1.4±0.2 17±0.5 F A’ D E 1.75 ± 0.1 AB EMBOSS TA P E T C ∣ W2 13.5±0.5 2.3 ±0.5 Label Label: Customer’s Name, ACX P/N, Q’ty, Date, ACX Corp. W4 W5 W3 Trailer End Trailer (160 mm min.) Leader End Empty Compartments with Cover Tape (500 mm min.) AT5020-E3…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zach Supalla(CEO)

[email protected]+1-415-316-1024Fax: +1-415-316-1024

Test Firm

BV 7Layers Communications Technology (Shenzhen) CoEdwin Ye

[email protected]86-20-8714 8549

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	390.00 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed and operated so as to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing. End-users must be informed of operating requirements for satisfying RF exposure compliance. This device supports 20 and 40 MHz bandwidth modes.
