TRACKER ONE (005) The Tracker One is a ready-to-go Tracker SoM carrier board with optional weatherproof enclosure. It is used with other equipment, such as on a truck. It is not a portable device.  Ready to go with IP67-rated enclosure.  GNSS Antenna Onboard: convenient high-gain GNSS antenna for easy access to GNSS signals.  Flexible Power Supply: easily add asset tracking to most devices. A wide 6-30V power supply copes with most power delivery systems. Also accepts 5V supply via USB-C. LiPo battery connector, charge LED, backup battery for GPS. Supports up to 90V when connecting directly to the carrier board.  High‐precision Thermistor with accuracy to 1%.  Extensible: IP67-rated M8 connector includes CAN Bus, UART, GPIO, and power for simple expansion.  USB‐C for flashing, debugging and power with higher charging rates than Micro-USB or for use without an internal battery.  RGB LED for use as both a user-configurable device as well as Particle status information. Block Diagram Description (Different models have different corresponding Cellular module models. Another model is T523M) Num ID Description 1 J1 Power and I/O connector 3 LiPo Connector 4 MCU USB-C 5 RGB Status LED 6 USER User Button 7 GNSS LED GNSS Status LED 8 RESET RESET Button 9 MODE MODE button 10 CHRG LiPo charge status LED 11 NFC 12 JTAG/SWD debugging connector for nRF52 MCU 13 GNSS USB u-blox GNSS USB connection (Micro USB) 14 GNSS Antenna 15 Tracker SoM (on back side) Power and I/O Connector (M8) M8 Pin Function Function FunctionI/OColor 1 CAN_P IO 2 Yellow 2 VIN 3 I Red 3 Analog A3 GPIO D3 IO 1 White 4 Serial1 RX Wire3 SDA GPIO D8 IO 1 Green 5 Serial1 TX Wire3 SCL GPIO D9 IO 1 Brown 6 CAN_5V 4 CAN_PWR O Orange 7 CAN_N IO 2 Blue 8 GND Black The IP67 M8, 8-pin, male pins with threaded barrel connector is accessible from the outside of the enclosure. View as looking into the M8 connector on the outside of the enclosure. Note: Version 003 and earlier of this datasheet had a different pin numbering for M8 connector that didn't match the connector manufacturer's numbering. Only the numbering has changed; the function of the pin at a given location is unchanged and the change should not affect existing designs. 1 MCU GPIO is limited to 3.3V maximum. 2 CAN Bus specifications can be found in the Tracker SoM datasheet. CAN Bus termination is provided on the carrier board. 3 6.0 to 30 VDC at 2A when using the M8 connector. 6.0 - 90 VDC at 2A when connecting directly to the board. 4 5V, 400 mA maximum. Controlled by the CAN_PWR GPIO. The connector on the carrier board itself is is a JST B8B-PH-SM4- TB(LF)(SN), 8-position, 2mm pitch, male pins, shrouded. The mating connector is the JST PHR-8. The female sockets are available plain, with leads, and in pre-manufactured ribbon cable formats. PHR‐8 Pin M8 Pin Function Color 1 2 VIN Red 2 1 CAN_P Yellow 3 7 CAN_N Blue 4 6 CAN_5V Orange 5 5 TX_SCL_D9 Brown 6 4 TX_SDA_D8 Green PHR‐8 Pin M8 Pin Function Color 7 3 A3 White 8 8 GND Black Additional Peripherals Signal Device OS Description THERM A0 NTC Thermistor USER A1 USER button GNSS_LOCK A2 GNSS lock indicator GPIO1 A3 GPIO on power and I/O connector MCU TX TX MCU serial TX, GPIO D9, Wire3 SCL MCU RX RX MCU serial RX, GPIO D8, Wire3 SDA Note: While the USER button exists inside the Tracker One, the Tracker One is a sealed unit and opening it will void the warranty and may affect certifications, thus it is not practical to use. It can be used with the Tracker Carrier Board. Powering the Tracker Carrier Board There are several options for powering the carrier board: The MCU USB connector (USB-C). If using a laptop with a USB-A to USB-C cable and a 500 mA USB port, you should also use the LiPo battery. With an true USB-C port and cable, or a 2A tablet charger, you can power only by USB. The VIN connector (6 to 30 VDC at 2A on the M8 connector, or 6 to 90 VDC at 2A to the B8B-PH connector on the board). This is useful with an external power supply. The LiPo connector. This is typically used with a LiPo battery. USB connectors There are two USB connectors on the carrier board, however you most commonly will only use the MCU USB connector. The MCU USB connector is connected to the nRF52 MCU and can be used for Serial debugging, flashing code, and setup by USB. It can also power the AssetTracker SoM. If using a laptop with a 500 mA USB port, you should also use the LiPo battery. With a 2A tablet charger, you can power only by USB. The GNSS USB connector is connected to the u-blox NEO-M8U GNSS. It can be used for firmware upgrades or with the u-blox u-center application. LED Indicators The RGB LED default behavior is:  Red breathing: Attempting to connect to the cellular network  Yellow breathing: Connecting to the cloud, weaker cellular signal  Green breathing: Connecting to the cloud, good cellular signal  Yellow solid: Connected to the cloud, weaker cellular signal  Green solid: Connected to the cloud, good cellular signal Alternatively the LED can be configured to the typical Particle color scheme (blinking green, blinking cyan, breathing cyan) via device or cloud configuration. Custom device firmware can provide other color schemes if desired. The CHRG LED indicates the charge status:  Off: Not charging or no power  On: Charging  Blinking: Charge fault  Flickering: No battery The GNSS LED indicates the GNSS fix status:  Off: GNSS is powered off.  Blinking (1 Hz): Attempting to get a GNSS fix  On: Has a GNSS fix. Tracker One Schematics Will be provided at a later date. Peripheral Details Thermistor The Tracker Carrier Board contains a 100K NTC thermistor, connected to A0. It is a Panasonic ERT-J1VR104FM connected high-side. It can be read using the getTemperature() API. Mechanical specifications Dimensions and weight Parameter Value Units Width 88 mm Length (case only) 146 mm Length (including M8 connector) 154 mm Thickness 33 mm Weight g Weight will be provided at a later date. Case Dimensions (mm): Bottom: Maximum Ca…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 October 29, 2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Particle Industries, Inc. hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AEMI-ONE40X Product Description: Tracker One LTE M1 Model: ONE402M , ONE404M Sincerely, _____________________ Zach Supalla / CEO Particle Industries, Inc Tel: (415)316-1024 E-mail: [email protected]

PaUWicle IndXVWUieV,Inc 126 Post St, 4th floor, San Francisco, CA 94108 USA Date:​ OcWobeU 12, 2020 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 SXbjecW: ReqXeVW foU ConfidenWialiW\ FCC ID:​ ​2AEMI-ONE40X To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission¶s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. ●Schematic Diagram ●Block Diagram ●Parts List ●Tune-up Procedure ●Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission¶ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until ​180 da\V​ after the Grant Date of Equipment Authorizations. ◆External Photos ◆Internal Photos ◆Test Setup Photos ◆Users Manual Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatandcorrespondentduring certificationreviewprocesscannotbegrantedasconfidentialdocumentsandthoseinformationwillbe available for public review once the grant of equipment authorization is issued. Best Regards, Zach Supalla / CEO Particle Industries, Inc Tel: (415)316-1024 E-mail: [email protected]

Product Difference Statement The schematic and PCB of the two models ONE402M and ONE404M used by our company for the certification application is completely the same , and the HW&SW used is the same. Because the product is sold in different market using different models eSIM , different models are named. The differences are as follows: ONE402M uses eSIM of Kore; ONE404M uses eSIM of Twilio. Hereby declare. Zach Supalla / CEO Particle Industries, Inc Tel: (415)316-1024 E-mail: [email protected]

PaUWicle IndXVWUieV,Inc 126 PRVW SW, 4WK IORRU, SDQ FUDQFLVFR, CA 94108 8SA DDWH:​ OcWobeU 12, 2020 PoZeU of AWWoUne\ 7R ZKRP LW PD\ FRQFHUQ, POHDVHEHQRWLILHGWKDWI,ZachSXSalla​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email protected]

Non-portable product declaration Our Tracker product (ONE402M&ONE404M) is used in fleet management, cold chain management,Micro Mobility,heavy equipment monitoring,bus, rental heavy equipment location monitoring and other fields. It is placed under the glass of the cab of the car , or where there is no metal obstruction above the EUT. Because matal objects will affect the GNSS antenna receiving satellite signals, you can charge the device through the M8 connector of the EUT or the USB-C interface. It is not a protable device. Hereby declare. Zach Supalla / CEO Particle Industries, Inc Tel: (415)316-1024 E-mail: [email protected]

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 3 Report Version 1 Reference No.: 2008WDG0081 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 3 Report Version 1 Reference No.: 2008WDG0081 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 3 Report Version 1 Reference No.: 2008WDG0081

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 4 Report Version 1 Reference No.: 2008WDG0081 PHOTOGRAPHS OF THE EUT BT ANT WIFI ANT LTE ANT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 4 Report Version 1 Reference No.: 2008WDG0081 GPS ANT(receiving only) NFC ANT(receiving only) Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 4 Report Version 1 Reference No.: 2008WDG0081 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 4 Report Version 1 Reference No.: 2008WDG0081

FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Sept. 14, 2020 Report No. : SA200807W004 FCC RF Exposure Test Report Report No. : SA200807W004 Applicant : Particle Industries,Inc Address : 126 Post St,4th floor, San Francisco,CA 94108 USA Product : Tracker One LTE M1 FCC ID : 2AEMI-ONE40X Brand : Particle Model No. : ONE402M, ONE404M Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 General RF Exposure Guidance v06 Sample Received Date : Aug. 07, 2020 Date of Testing : Aug. 08, 2020 ~ Sept. 10, 2020 CERTIFICATION: The above equipment have been tested by BV 7LAYERS COMMUNICATIONS TECHNOLOGY (SHENZHEN) CO. LTD., and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA or any government agencies. Prepared By : Jerry Chen / Engineer Approved By : Luke Lu / Manager This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Sept. 14, 2020 Report No. : SA200807W004 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Description of Equipment Under Test ................................................................................................................................. 4 2. MPE(Maximum Permissible Exposure) Assessment .......................................................................................................... 5 2.1 Introduction .................................................................................................................................................................. 5 2.2 RF Radiation Exposure Limits ...................................................................................................................................... 5 2.3 MPE Assessment Method ............................................................................................................................................ 6 2.4 MPE Calculation for Standalone Operations ................................................................................................................ 6 2.5 CONCLUSION OF SIMULTANEOUS TRANSMITTER ................................................................................................ 7 3. Information on the Testing Laboratories ............................................................................................................................. 8 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Sept. 14, 2020 Report No. : SA200807W004 Release Control Record Report No. Reason for Change Date Issued SA200807W004 Initial release Sept. 14, 2020 FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Sept. 14, 2020 Report No. : SA200807W004 1. Description of Equipment Under Test EUT Type Tracker ONE LTE M1 FCC ID 2AEMI-ONE40X Brand Name Particle Model Name ONE402M, ONE404M Tx Frequency Bands (Unit: MHz) GSM850 : 824.2 ~ 848.8 GSM1900 : 1850.2 ~ 1909.8 LTE Band 2 : 1850.7 MHz ~ 1909.3 MHz LTE Band 4 : 1710.7 MHz ~ 1754.3 MHz LTE Band 5 : 824.7 MHz ~ 848.3 MHz LTE Band 12 : 699.7 MHz ~ 715.3 MHz LTE Band 13 : 779.5 MHz ~ 784.5 MHz LTE Band 25 : 1850.7 MHz ~ 1914.3 MHz WLAN : 2412 ~ 2462 MHz Bluetooth : 2402 ~ 2480 MHz GPS/ GLONASS/ BDS/ GALILEO: 1559MHz ~ 1610MHz NFC : 13.56 MHz Uplink Modulations GPRS : GMSK EDGE : 8PSK LTE : QPSK, 16QAM 802.11b : DSSS 802.11g/n : OFDM Bluetooth : GFSK, π/4-DQPSK, 8-DPSK NFC : ASK GPS/ GLONASS / BDS/ GALILEO: BPSK Antenna Type WLAN: FPCB Antenna WWAN: External Antenna EUT Stage Production Unit Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. FCC RF Exposure Test Report Report Format Version 5.0.0 Issued Date : Sept. 14, 2020 Report No. : SA200807W004 2. MPE(Maximum Permissible Exposure) Assessment 2.1 Introduction According to 47 CFR §2.1091, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20…
