2AEPIBLACK1Smart Phone

1 Black 1 Kalley Smart phone Quick Start Guide 1. BEFORE USING The phone is a Dual SIM mobile that allows you to use two mobile networks. Insert SIM cards and SD card 1) This machine supports standard Nano card hot-swappable, in the power-on state, when you insert the Nano card, the phone can automatically identify. Insert the thimble into the thimble hole and press inward, the card tray pops out. Take out the card tray, play the Nano card with chip facing down into the corresponding card slot. Then put the card tray into the phone. Make sure that it is correctly inserted. 2) To have additional storage for your images, videos, music and files, you can purchase a memory card and install it in your device. Insert the thimble into the thimble hoe and press inward, the card tray pops out. Put the SD card with chip facing downwards into the corresponding card slot, and put the card tray into the phone. ✓ Note: SD card can be used as internal storage. Option : Notification Center--> Tap the notice to set up-->Use for portable storage ->Next ->Done(For transferring files and media between devices) ✓ Note: • Do not remove the cards while the device is transferring data. Doing so may cause data to be lost or damage to the cards and device. • The SIM cards and SD card are small parts. Please keep them away from children to avoid swallowing the card by accident. • Please do not touch the metal surface of SIM and SD card and keep them away from electromagnetic field to avoid damaged data. Charge the Battery Charge the battery before using it. Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable into the USB Port. 2. GETTING STARTED 2 Basic Function • Turn on the phone Press and hold the power key for a while to turn on the phone. • Turn off the phone Long press the power key until a menu shows. Choose “Power off’’ to turn off the phone. • Restart the phone Long press the power key until a menu shows. Choose “Restart’’to restart the phone. • Lock the screen Option 1: Press the power key to turn off the screen and lock it Option 2: The screen will auto lock if you don't use the phone for a while. • Unlock the screen Press the power key, and then slide to top for unlocking. 3. COMMUNICATION & CONNECTION Make a call • Touch the phone icon on the Home screen. • Enter the phone number you want to dial. • Touch the phone icon to dial the number that you entered. Send a Message You can use this phone to exchange text messages and multimedia messages with others. The messages from the same contact will be grouped into one conversation list. So you can see your entire message history with a person conveniently. WLAN WLAN is a wireless networking technology that can provide internet access at distance of up to 100 meters, depending on the WLAN router and your surroundings. You can configure the WLAN as follow: • Settings-->Network & internet-->Internet-->Wi-Fi to turn it on. The device scans for available WLAN networks and displays the names of those it finds. 3 Tap one of the listed networks and enter the password, if asked to join in. 4. WARNING The power supply type is UT-681A-5200ZCY, output is 5V/2A .the device is restricted to indoor use only when operating in the 50-60 Hz frequency range Supports Bands (MHz) : Max Power: GSM GSM850 : Tx 824~849, Rx 869~894 32dBm±1dBm GSM900 : Tx 880~915, Rx 925~960 32dBm±1dBm DCS1800 : Tx 1710~1785, Rx 1805~1880 29dBm±1dBm PCS1900 : Tx 1850~1910, Rx 1930~1990 29dBm±1dBm WCDM A WCDMA Band 1 : Tx 1920~1980, Rx 2110~217022.5dBm±1dBm WCDMA Band 5: TX 824~849,RX 869~894 22.5dBm±1dBm WCDMA Band 8: Tx 880~915, Rx 925~960 22.5dBm±1dBm LTE LTE Band 1:Tx 1920~1980, Rx 2110~2170 22.5dBm±1dBm LTE Band 3:Tx 1710~1785, Rx 1805~1880 22.5dBm±1dBm LTE Band 5:TX: 824~849,RX 869~894 22.5dBm±1dBm LTE Band 7:TX: 2500~2570,RX 2620~2690 22.5dBm±1dBm LTE Band 8:Tx 880~915, Rx 925~960 22.5dBm±1dBm LTE Band 28A & 28B:TX: 703~748,RX 758~803 22.5dBm±1dBm WLAN Frequency (MHz) : MaxPower: B：18dBm±1dBm 2412~2472 WLAN Frequency (MHz) : MaxPower: G/N： 16dBm±1dBm 2412~2472 BT Frequency (MHz) : 2402~2480 MaxPower: 7dBm±1dBm 5. Emergency call 4 If any emergency arises, dial 112/911 (or other emergency call number) for emergency help. Due to the nature of cellular networking, the success of emergency call is not guaranteed. 6. FCC Warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types Black X (FCC ID: 2AEPIBLACK1) has also been tested against this SAR limit. The highest…

Text truncated - open the document above for the full version.

Rev 1/26/2023 COLOMBIANA DE COMERCIO S.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03‐27‐2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AEPIBLACK1 COLOMBIANA DE COMERCIO S.A. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) Julian Orozco Rev 1/26/2023 COLOMBIANA DE COMERCIO S.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03‐27‐2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AEPIBLACK1 COLOMBIANA DE COMERCIO S.A. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. The applicant is not a named entity or any of its subsidiaries or affiliates. Sincerely, (Applicant signature) Julian Orozco

COLOMBIANA DE COMERCIO S.A. Car. 43E No 8-7 Medellin Colombia Date: 03-27-2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEPIBLACK1 FRN: 0024577066 US Agent – Attestation Statement / Part 2.911(d)(7) COLOMBIANA DE COMERCIO S.A. certifies, that as of 03-27-2024, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AEPIBLACK1. COLOMBIANA DE COMERCIO S.A., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of COLOMBIANA DE COMERCIO S.A. for FCC ID: 2AEPIBLACK1. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: COLOMBIANA DE COMERCIO S.A. Designated Agent: FCC US Agent, LLC Company Representative: Julian Orozco Designated Agent Representative: Tim Payne Signature: Signature:

COLOMBIANA DE COMERCIO S.A. Date: Mar. 27, 2024 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AEPIBLACK1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf Part List Part Placement Schematics PCB Layout Schematics Tune-up Procedure Part List.pdf Part Placement Schematics.pdf PCB Layout Schematics.pdf Tune-up Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, COLOMBIANA DE COMERCIO S.A. Julian Orozco / Manager Typed name and Title

COLOMBIANA DE COMERCIO S.A. Date: 4/15/2024 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD To Whom It May Concern: We, COLOMBIANA DE COMERCIO S.A., state that our device, FCC ID: 2AEPIBLACK1, has a battery, but the battery will not be placed in the battery compartment when delivery, the label is visible to the users as they purchase the products and install the battery. Sincerely, Signature Julian Orozco Manager COLOMBIANA DE COMERCIO S.A.

COLOMBIANA DE COMERCIO S.A. FCC ID: 2AEPIBLACK1 POWER OF ATTORNEY Date: Mar. 27, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on Mar. 26, 2025. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, COLOMBIANA DE COMERCIO S.A. are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, COLOMBIANA DE COMERCIO S.A. Julian Orozco / Manager Typed name and Title

COLOMBIANA DE COMERCIO S.A. Date: 2024-03-27 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEPIBLACK1 To Whom It May Concern: This letter is to statement that Black 1 / Smart Phone. has been tested according to FCC Part 15B by Waltek Testing Group Co., Ltd. (Test Report No.: WTD24D03060913W001). And the SDOC file, meetting the requirements of the FCC regulations, would been provided when the device is sold by the responsible party in US. The service will not be sold until the SDOC is provided. If the sale does not have an SDOC, all responsibility is the responsibility of the applicant. Sincerely, Signature Julian Orozco Manager COLOMBIANA DE COMERCIO S.A.

Appendix- Black 1-Photos Page 3 of 13 2. Photographs –Constructional Details 2.1. EUT – External View Model Black 1 FCC ID: 2AEPIBLACK1 Appendix- Black 1-Photos Page 4 of 13 Appendix- Black 1-Photos Page 5 of 13 Appendix- Black 1-Photos Page 6 of 13

Label and Label Location

Appendix- Black 1-Photos Page 7 of 13 2.2. EUT – Internal View Model Black 1 FCC ID: 2AEPIBLACK1 BT/WIFI ANT GSM/WCDMA/LTE DiversityANT GSM/WCDMA/LTE Main ANT Appendix- Black 1-Photos Page 8 of 13 Appendix- Black 1-Photos Page 9 of 13

Appendix- Black 1-Photos Page 10 of 13 Appendix- Black 1-Photos Page 11 of 13 Appendix- Black 1-Photos Page 12 of 13 Appendix- Black 1-Photos Page 13 of 13

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn SAR TEST REPORT Reference No. ................... : WTD24D03060913W008 FCC ID ................................ : 2AEPIBLACK1 Applicant ........................... : COLOMBIANA DE COMERCIO S.A. Address ............................. : Car. 43E No 8-71, Medellin, Colombia Manufacturer .................... : Mobiwire Mobiles (Ningbo) Co.,Ltd Address ............................. : No. 518, Changting East Road, Yuelin Street, Fenghua District, Ningbo City, Zhejiang Province, China Product .............................. : Smart Phone Model(s).. ........................... : Black 1 Brand Name ..................... : Kalley Standards .......................... : FCC 47 CFR Part2(2.1093) ANSI/IEEE C95.1-2006 IEC/IEEE 62209-1528:2020 & Published RF Exposure KDB Procedures Date of Receipt sample .... : 2024-03-25 Date of Test ....................... : 2024-03-25 to 2024-04-02 Date of Issue ..................... : 2024-04-11 Test Result ........................ : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD24D03060913W008 Page 2 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 4 4 GENERAL INFORMATION ....................................................................................................................... 5 4.1 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................... 5 4.2 DETAILS OF E.U.T. ............................................................................................................................. 5 4.3 TEST FACILITY .................................................................................................................................... 7 5 EQUIPMENT USED DURING TEST ......................................................................................................... 8 5.1 EQUIPMENT LIST ................................................................................................................................. 8 6 SAR INTRODUCTION............................................................................................................................... 9 6.1 INTRODUCTION .................................................................................................................................... 9 6.2 SAR DEFINITION ................................................................................................................................. 9 7 SAR MEASUREMENT SETUP ............................................................................................................... 10 8 EXPOSURE LIMIT .................................................................................................................................. 19 9 SYSTEM AND LIQUID VALIDATION ..................................................................................................... 20 9.1 SYSTEM VALIDATION .......................................................................................................................... 20 9.2 LIQUID VALIDATION ............................................................................................................................. 22 10 TYPE A MEASUREMENT UNCERTAINTY............................................................................................ 31 11 OUTPUT POWER VERIFICATION ......................................................................................................... 34 11.1 TEST CONDITION........................................................................................................................... 34 11.2 TEST PROCEDURES ...................................................................................................................... 34 11.3 TEST RESULT ............................................................................................................................... 35 12 EXPOSURE CONDITIONS CONSIDERATION ...................................................................................... 72 12.1 EUT ANTENNA LOCATION .............................................................................................................. 72 12.2 TEST POSITION CONSIDERATION .................................................................................................... 72 12.3 RF EXPOSURE .............................................................................................................................. 73 13 SAR TEST RESULTS ............................................................................................................................. 74 13.1 TEST CONDITION........................................................................................................................... 74 13.2 GENERALLY TEST PROCEDURES .................................................................................................... 74 13.3 SAR SUMMARY TEST RESULT ......................................................…

Text truncated - open the document above for the full version.

Reference No.: WTD24D03060913W008 Page 125 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 126 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 127 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 128 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 129 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 130 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 131 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 132 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 133 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 134 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 135 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 136 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 137 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 138 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 139 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 140 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 141 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 142 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 143 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 144 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 145 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 146 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 147 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 148 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn

Reference No.: WTD24D03060913W008 Page 149 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 150 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 151 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 152 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 153 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 154 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 155 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 156 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 157 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 158 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 159 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 160 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 161 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 162 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 163 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 164 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 165 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 166 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 167 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 168 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 169 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn

Reference No.: WTD24D03060913W008 Page 170 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 171 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 172 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 173 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 174 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 175 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 176 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 177 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 178 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 179 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 180 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 181 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 182 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 183 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 184 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 185 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 186 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 187 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 188 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 189 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 190 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 191 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 192 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 193 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn

Reference No.: WTD24D03060913W008 Page 194 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 195 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 196 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 197 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 198 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 199 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 200 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 201 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 202 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 203 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 204 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 205 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 206 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 207 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 208 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 209 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 210 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 211 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D03060913W008 Page 212 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 16 SAR System Photos Liquid depth ≥ 15cm Reference No.: WTD24D03060913W008 Page 213 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 17 Setup Photos Right Head Cheek Right Head Tilt Left Head Cheek Left Head Tilt

Reference No.: WTD24D03060913W008 Page 214 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Hotspot( Front Side ) Hotspot ( Back Side ) Hotspot(Right Edge) Hotspot(Left Edge) Hotspot(Top Edge) Hotspot(Bottom Edge) 10mm separation 10mm separation 10mm se paration 10mm se paration 10mm se paration 10mm se paration Reference No.: WTD24D03060913W008 Page 215 of 215 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 18 EUT Photos Front Side Back Side ======End of Report======

品名 : GH6321-4IN1ANT-V2.0 History List 版本 REV. 修訂者 EDITOR 修訂頁次 PAGE 修訂內容 ITEMS OF CHANGE 申請日期 DATE 生效日期 VALID DATE ECN 编号 ECN NO V2.0 骆业辉 ALL 发行正式 2023/05/10 203/05/10 N/A UNLESS OTHER SPECIFIED TOLERANCES ON： 深圳市可信华成通信科技有限公司 SHENZHEN CITY KEXIN HUACHENG COMMUNICATION TECHNOLOGY CO.,LTD X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF KEXIN HUACHENG COMMUNICATION TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：黄土勇 CHECKED BY： 肖坤雄 DESIGNED BY：骆业辉 APPROVED BY： 王伟 TITLE：GH6321-4IN1ANT-V2.0Specification DOCUMENT PAGE REV. NO. A0 PAGE 1 OF 5 GH6321-4IN1ANT-V2.0 Specification 1. Explanation of part number : GH6321 _ 4IN1ANT _ V2.0 (1) (2) (3) (1) Model Name：GH6321 (2) Frequency : 1575Mhz, 2400-2500MHz，5150-5850MHz (3) Suffix :V2.0 2. Electrical Specification : 2-1. Frequency Band: Frequency Band MHz GPS&BT&WIFI 1575Mhz, 2400-2500MHz， 5150-5850MHz 2-2. Impedance 50 ohm nominal UNLESS OTHER SPECIFIED TOLERANCES ON： 深圳市可信华成通信科技有限公司 SHENZHEN CITY KEXIN HUACHENG COMMUNICATION TECHNOLOGY CO.,LTD X＝±2 X.X＝±0.1 X.XX＝±0.05 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF KEXIN HUACHENG COMMUNICATION TECHNOLOG…

Text truncated - open the document above for the full version.
