2AEPIBLACKG3Smart Phone

1 Kalley Black G3 Smart Phone Quick Start Guide 1. BEFORE USING The phone is a Dual SIM mobile that allows you to use two mobile networks. Insert SIM cards and SD card 1) This machine supports standard Nano card hot-swappable, in the power-on state, when you insert the Nano card, the phone can automatically identify. Insert the thimble into the thimble hole and press inward, the card tray pops out. Take out the card tray, play the Nano card with chip facing down into the corresponding card slot. Then put the card tray into the phone. Make sure that it is correctly inserted. 2) To have additional storage for your images, videos, music and files, you can purchase a memory card and install it in your device. Insert the thimble into the thimble hoe and press inward, the card tray pops out. Put the SD card with chip facing downwards into the corresponding card slot, and put the card tray into the phone. ✓ Note: SD card can be used as internal storage. Option : Notification Center--> Tap the notice to set up-->Use for portable storage ->Next ->Done(For transferring files and media between devices) ✓ Note: • Do not remove the cards while the device is transferring data. Doing so may cause data to be lost or damage to the cards and device. • The SIM cards and SD card are small parts. Please keep them away from children to avoid swallowing the card by accident. • Please do not touch the metal surface of SIM and SD card and keep them away fro m electromagnetic field to avoid damaged data. Charge the Battery Charge the battery before using it. Connect the USB cable to the USB power adaptor, and then plug the end of the USB cable into the USB Port. 2. GETTING STARTED 2 Basic Function • Turn on the phone Press and hold the power key for a while to turn on the phone. • Turn off the phone Long press the power key until a menu shows. Choose “Power off’’ to turn off the phone. • Restart the phone Long press the power key until a menu shows. Choose “Restart’’to restart the phone. • Lock the screen Option 1: Press the power key to turn off the screen and lock it Option 2: The screen will auto lock if you don't use the phone for a while. • Unlock the screen Press the power key, and then slide to top for unlocking. 3. COMMUNICATION & CONNECTION Make a call • Touch the phone icon on the Home screen. • Enter the phone number you want to dial. • Touch the phone icon to dial the number that you entered. Send a Message You can use this phone to exchange text messages and multimedia messages with others. The messages from the same contact will be grouped into one conversation list. So you can see your entire message history with a person conveniently. WLAN WLAN is a wireless networking technology that can provide internet access at distance of up to 100 meters, depending on the WLAN router and your surroundings. You can configure the WLAN as follow: • Settings-->Network & internet-->Internet-->Wi-Fi to turn it on. The device scans for available WLAN networks and displays the names of those it finds. 3 Tap one of the listed networks and enter the password, if asked to join in. 4. WARNING The power supply type is UT-681A-5200ZCY, output is 5V/2A .the device is restricted to indoor use only when operating in the 50-60 Hz frequency range Supports Bands (MHz) : Max Power: GSM GSM850 : Tx 824~849, Rx 869~894 32±1dBm GSM900 : Tx 880~915, Rx 925~960 32±1dBm DCS1800 : Tx 1710~1785, Rx 1805~1880 29±1dBm PCS1900 : Tx 1850~1910, Rx 1930~1990 30±1dBm WCDMA WCDMA Band 1 : Tx 1920~1980, Rx 2110~2170 22.5±1dBm WCDMA Band 2: TX 1850~1910,RX 1930~1990 22±1dBm WCDMA Band 4: Tx 1710~1755, Rx 2110~2155 22±1dBm WCDMA Band 5: TX 824~849,RX 869~894 22±1dBm LTE LTE Band 2:Tx 1920~1980, Rx 2110~2170 23.0±1dBm LTE Band 3:Tx 1710~1785, Rx 1805~1880 22.5±1dBm LTE Band 4:TX 824~849,RX 869~894 23.0±1dBm LTE Band 5:TX 824~849,RX 869~894 23.0±1dBm LTE Band 7:TX 2500~2570,RX 2620~2690 23.0±1dBm LTE Band 13:Tx 880~915, Rx 925~960 23.0±1dBm LTE Band 28A & 28B:TX 703~748,RX 758~803 23.0±1dBm WLAN Frequency (MHz) : MaxPower: B/G：16.0±1dBm 2412~2472 WLAN Frequency (MHz) : MaxPower: N：17.5±1dBm 2412~2472 BT Frequency (MHz) : 2402~2480 MaxPower: 5.0±1dBm 4 Emergency call If any emergency arises, dial 112/911 (or other emergency call number) for emergency help. Due to the nature of cellular networking, the success of emergency call is not guaranteed. FCC Warning: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. 5 The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types Smart Phone (FCC ID: 2AEPIBLACKG3) has als…

Text truncated - open the document above for the full version.

Rev 1/26/2023 COLOMBIANA DE COMERCIO S.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 07-03-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AEPIBLACKG3 COLOMBIANA DE COMERCIO S.A. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) Julian Orozco Rev 1/26/2023 COLOMBIANA DE COMERCIO S.A. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 07-03-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AEPIBLACKG3 COLOMBIANA DE COMERCIO S.A. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. The applicant is not a named entity or any of its subsidiaries or affiliates. Sincerely, (Applicant signature) Julian Orozco

COLOMBIANA DE COMERCIO S.A. Car. 43E No 8-7 Medellin Colombia Date: 07-03-2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AEPIBLACKG3 FRN: 0024577066 US Agent – Attestation Statement / Part 2.911(d)(7) COLOMBIANA DE COMERCIO S.A. certifies, that as of 07-03-2024, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AEPIBLACKG3. COLOMBIANA DE COMERCIO S.A., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of COLOMBIANA DE COMERCIO S.A. for FCC ID: 2AEPIBLACKG3. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: COLOMBIANA DE COMERCIO S.A. Designated Agent: FCC US Agent, LLC Company Representative: Julian Orozco Designated Agent Representative: Tim Payne Signature: Signature:

COLOMBIANA DE COMERCIO S.A. Date: July 03, 2024 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AEPIBLACKG3 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf Part List Part Placement Schematics PCB Layout Schematics Tune-up Procedure Part List.pdf Part Placement Schematics.pdf PCB Layout Schematics.pdf Tune-up Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, COLOMBIANA DE COMERCIO S.A. Julian Orozco / Manager Typed name and Title

COLOMBIANA DE COMERCIO S.A. FCC ID: 2AEPIBLACKG3 POWER OF ATTORNEY Date: July 03, 2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group Co., Ltd. (Deval Qin) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group Co., Ltd. (Deval Qin) on our behalf shall have the same effect as acts of our own. This authorization expires on July 02, 2025. Sincerely, COLOMBIANA DE COMERCIO S.A. Julian Orozco / Manager Typed name and Title

Appendix-Black G3-Photos Page 3 of 12 2. Photographs –Constructional Details 2.1. EUT – External View Model Black G3 FCC ID: 2AEPIBLACKG3 Appendix-Black G3-Photos Page 4 of 12 Appendix-Black G3-Photos Page 5 of 12 Appendix-Black G3-Photos Page 6 of 12

Label and Label Location

Appendix-Black G3-Photos Page 7 of 12 2.2. EUT – Internal View Model Black G3 FCC ID: 2AEPIBLACKG3 BT/WIFI ANT GSM/WCDMA/LTE Diversity ANT GSM/WCDMA/LTE Main ANT Appendix-Black G3-Photos Page 8 of 12 Appendix-Black G3-Photos Page 9 of 12 Appendix-Black G3-Photos Page 10 of 12 Appendix-Black G3-Photos Page 11 of 12 Appendix-Black G3-Photos Page 12 of 12

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 201 SAR TEST REPORT Reference No. ................... : WTD24D06151713W008 FCC ID ................................ : 2AEPIBLACKG3 Applicant ........................... : COLOMBIANA DE COMERCIO S.A. Address ............................. : Car. 43E No 8-71, Medellin, Colombia Manufacturer .................... : MOBIWIRE MOBILES (NINGBO) CO.,LTD Address ............................. : Ningbo Fenghua No.999, Dacheng East Road, Fenghua, Zhejiang, China Product .............................. : Smart Phone Model(s).. ........................... : Black G3 Brand Name ..................... : Kalley Standards .......................... : FCC 47 CFR Part2(2.1093) ANSI/IEEE C95.1-2006 IEC/IEEE 62209-1528:2020 & Published RF Exposure KDB Procedures Date of Receipt sample .... : 2024-07-02 Date of Test ....................... : 2024-07-29 to 2024-08-05 Date of Issue ..................... : 2024-08-09 Test Result ........................ : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD24D06151713W008 Page 2 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 3 4 GENERAL INFORMATION ....................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................... 4 4.2 DETAILS OF E.U.T. ............................................................................................................................. 4 4.3 TEST FACILITY .................................................................................................................................... 6 5 EQUIPMENT USED DURING TEST ......................................................................................................... 7 5.1 EQUIPMENT LIST ................................................................................................................................. 7 6 SAR INTRODUCTION............................................................................................................................... 8 6.1 INTRODUCTION .................................................................................................................................... 8 6.2 SAR DEFINITION ................................................................................................................................. 8 7 SAR MEASUREMENT SETUP ................................................................................................................. 9 8 EXPOSURE LIMIT .................................................................................................................................. 18 9 SYSTEM AND LIQUID VALIDATION ..................................................................................................... 19 9.1 SYSTEM VALIDATION .......................................................................................................................... 19 9.2 LIQUID VALIDATION ............................................................................................................................. 22 10 TYPE A MEASUREMENT UNCERTAINTY............................................................................................ 31 11 OUTPUT POWER VERIFICATION ......................................................................................................... 34 11.1 TEST CONDITION........................................................................................................................... 34 11.2 TEST PROCEDURES ...................................................................................................................... 34 11.3 TEST RESULT ............................................................................................................................... 35 12 EXPOSURE CONDITIONS CONSIDERATION ...................................................................................... 62 12.1 EUT ANTENNA LOCATION .............................................................................................................. 62 12.2 TEST POSITION CONSIDERATION .................................................................................................... 62 12.3 RF EXPOSURE .............................................................................................................................. 63 13 SAR TEST RESULTS ............................................................................................................................. 64 13.1 TEST CONDITION........................................................................................................................... 64 13.2 GENERALLY TEST PROCEDURES .................................................................................................... 64 13.3 SAR SUMMARY TEST RESULT .......................................................................…

Text truncated - open the document above for the full version.

Reference No.: WTD24D06151713W008 Page 114 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 115 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 116 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 117 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 118 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 119 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 120 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 121 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 122 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 123 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 124 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 125 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 126 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 127 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 128 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 129 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 130 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 131 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 132 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 133 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 134 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 135 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 136 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 137 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 138 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 139 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 140 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 141 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 142 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 143 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn

Reference No.: WTD24D06151713W008 Page 144 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 145 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 146 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 147 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 148 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 149 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 150 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 151 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 152 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 153 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 154 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 155 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 156 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 157 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 158 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 159 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 160 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 161 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 162 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 163 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 164 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 165 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 166 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 167 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 168 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 169 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 170 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 171 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 172 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 173 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 174 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 175 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 176 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 177 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn

Reference No.: WTD24D06151713W008 Page 178 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 179 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 180 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 181 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 182 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 183 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 184 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 185 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 186 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 187 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 188 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 189 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 190 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 191 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 192 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 193 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 194 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 195 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 196 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 197 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Reference No.: WTD24D06151713W008 Page 198 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 16 SAR System Photos Liquid depth ≥ 15cm Reference No.: WTD24D06151713W008 Page 199 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 17 Setup Photos Right Head Cheek Right Head Tilt Left Head Cheek Left Head Tilt Reference No.: WTD24D06151713W008 Page 200 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Hotspot( Front Side ) Hotspot ( Back Side ) Hotspot(Right Edge) Hotspot(Left Edge) Hotspot(Top Edge) 10mm separation 10mm separation 10mm se paration 10mm se paration 10mm se paration Reference No.: WTD24D06151713W008 Page 201 of 201 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 18 EUT Photos Front Side Back Side ======End of Report======

品名 : WAG-F-LAG0-00-069工规 History List 版本 REV. 修訂者 EDITOR 修訂頁次 PAGE 修訂內容 ITEMS OF CHANGE 申請日期 DATE 生效日期 VALID DATE ECN 编号 ECN NO A0 Eason ALL 正式发行 2024/05/08 2024/05/08 N/A UNLESS OTHER SPECIFIED TOLERANCES ON： 佳邦科技股份有限公司 INPAQ TECHNOLOGY CO., LTD. X＝± X.X＝±0.15 X.XX＝±0.15 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： Eason CHECKED BY： 张冬冬 DESIGNED BY：Eason APPROVED BY： 张冬冬 TITLE：WAG-F-LAG0-00-069 Specification DOCUMENT ENS000195280 PAGE REV. NO. A0 PAGE 1 OF 5 WAG-F-LAG0-00-069 Specification 1. Explanation of part number : WAG _ F _ LAG0 _00_069 (1) (2) (3) (4)(5) (1) Product Type：Wireless Antenna (2) Material: FPC (3) Frequency : 1575.42/2400~2500 MHz (4) Coaxial Cable Type : 00 (5) Suffix : 069 2. Storage Condition: Temperature -40 to +85°C Humidity 20 to 65 %RH Recommended storage condition： Store in room condition as listed below: Temperature -20°C~+45ºC, Humidity 80% Max. 3. Operating Condition: Temperature -40 to +85°C Humidity 10 to 85 %RH 4. Electrical Specification : Those specifications were specially defined for WLAN model, and all characteristics were measured in the customer's machine. . 4-1. Frequency Band: Frequency Band MHz WBG 1575.42/2400~2500 MHz 4-2. Impedance 50 hm nominal 4-3. Matching circuit None UNLESS OTHER SPECIFIED TOLERANCES ON： 佳邦科技股份有限公司 INPAQ TECHNOLOGY CO., LTD. X＝± X.X＝±0.15 X.XX＝±0.15 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： Eason CHECKED BY： 张冬冬 DESIGNED BY：Eason APPROVED BY： 张冬冬 TITLE：WAG-F-LAG0-00-069 Specification DOCUMENT ENS000195280 PAGE REV. NO. A0 PAGE 2 OF 5 4-4. VSWR Frequency Band 1575.42MHz 2400 MHz 2500 MHz 4-4-1.Typical Value: ≦ 3.0 ≦ 3.0 ≦ 3.0 4-4-2.Measuring Method 1. A 50Ωcoaxial cable is connected to the pcb antenna. Then this cable is connected to a network analyzer to measure the VSWR. 2. Keeping this jig away from metal at least 20 cm. 4-4-3.Picture UNLESS OTHER SPECIFIED TOLERANCES ON： 佳邦科技股份有限公司 INPAQ TECHNOLOGY CO., LTD. X＝± X.X＝±0.15 X.XX＝±0.15 ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY： Eason CHECKED BY： 张冬冬 DESIGNED BY：Eason APPROVED BY： 张冬冬 TITLE：WAG-F-LAG0-00-069 Specification DOCUMENT ENS000195280 PAGE REV. NO. A0 PAGE 3 OF 5 4-5. Efficiency and Gain 4-5.1 Measuring equipment Measuring instrument： Microwave chamber, Network analyzer, and standard antenna. Instructions for microwave chamber： This is a microwave chamber set up by our company in Suzhou，This microwave chamber belongs to a set of near-field measurement system. The size of the chamber is 2.95M * 3M * 3M . The microware chamber, shown above, using a unique multi-probe technique，The aim is to reduce the measurement time of the whole measurement system. The measuring sy…

Text truncated - open the document above for the full version.
