2AEUS-D013D01789IP Camera

TM Wi-Fi/IP Video Surveillance For home, baby, pets and business CL-4000 CAMERA MANUAL.indd 17/2/2015 4:27:09 PM Surveillance made simple. INTRODUCTION TECHNICAL SPECIFICATIONS Note: Your GuardCam syst em will allow you to connect unlimited amount of cameras to your GuardCam app. However , keep in mind, you can only allow 4 users to be registered per camera. Also available is the GuardCam 360°. It’s a Wi-Fi/IP Video Surveillance camera that can rotate 360° via the App. Night vision (30ft) Microphone 360° Rotatable Lens Str eam Live with Your Phone/TabletQuick and Easy Setup 360° Rotatable LensWi-Fi Connection Night vision (30ft)Unlimited Camera Connections Two Way Audio Communication CL-4000 CAMERA MANUAL.indd 27/2/2015 4:27:10 PM 3 Surveillance made simple. TECHNICAL SPECIFICATIONS 720p High Definition Resolution Night vision (30ft) Microphone 360° Rotatable Lens Enabled CL-4000 CAMERA MANUAL.indd 37/2/2015 4:27:11 PM 4 Surveillance made simple. INSTALLING THE GUARDCAM MOBILE APP GETTING STARTED The IP Home Camera works with iPhone, iPad and Android devices. Install the Pilot GuardCam mobile app and turn your mobile devices into a monitoring center for your camera. The Pilot GuardCam mobile app is free to download and is available from the respective Apple App Store and Google Play Store. To install Pilot GuardCam on Android: 1. Open Google Play Store 2. Search for “GuardCam” 3. Tap INSTALL 4. Review the App’s permissions, then tap ACCEPT to download. To install GuardCam on iPhone/iPad: 1. Open the App Store 2. Search for “Pilot GuardCam” 3. Tap INSTALL App to download After installing Pilot GuardCam app on your mobile device, just locate the GuardCam app and tap the icon to run. The app will load and take you directly to the Login screen. (See image 1) Image 1 CL-4000 CAMERA MANUAL.indd 47/2/2015 4:27:14 PM 5 Surveillance made simple. PAIRING NEW CAMERA RUNNING THE APP You will need to know the Wi-Fi network name (SSID) and password (security key) for your Wi-Fi network. You will need these details when setting up Wi-Fi connection for the camera on the mobile app. Make sure the mobile device that you are using to configure access to the camera is on the same Wi-Fi network prior to setting up your camera for the first time. Locate the Pilot GuardCam app and tap the icon to run. The app will load and take you directly to the login screen. You must register on the App to continue. Tap the “Register an Account” button to create an account. Enter details for “Email”, “Password” and “confirm Password”, then tap Registration when you’re finished. Please make sure there is no empty spaces after your email or you will receive an ERROR. You can now use your newly created account to log in. SET UP CL-4000 CAMERA MANUAL.indd 57/2/2015 4:27:14 PM 6 Surveillance made simple. SET UP CONNECTING TO WI-FI When you have a new camera that needs to be connected to your Wi-Fi Network, please make sure the mobile device that you are using to configure access to the camera is on the same Wi-Fi network. Follow these steps: Note: IP camera default user name: admin and Password: admin 1. Open the Pilot GuardCam App from your mobile phone Then log into your Account 2. Click to enter in the MENU navigation. 3. Open the “Camera Setup” (See Image 2) You can type in the GID code or just simply scan the barcode in the bottom of the camera that you are going to setup by simply pressing on the barcode icon (See Image 3) Then click NEXT STEP. Image 2Image 3 CL-4000 CAMERA MANUAL.indd 67/2/2015 4:27:15 PM 7 Surveillance made simple. 4. Make sure the name of the wireless network you want your camera to use is shown. Enter the correct password to the Wi-Fi network you want the camera to use, then click START. (See Image 4) The camera will start to connect the Wi-Fi automatically. This process will take about 40 seconds. 5. Name your camera. (i.e. Bedroom, Kitchen, etc.) Please leave the user name and password as default: user: admin and password: admin You can choose your user name and password in the next step. When finished, select “YES” at top right corner (See Image 5) Image 4 Image 5 CONNECTING TO WI-FI (CONT) SET UP CL-4000 CAMERA MANUAL.indd 77/2/2015 4:27:15 PM 8 Surveillance made simple. 1. If you want to setup your camera on another Wi-Fi network, you must reset your camera and follow the “CONNECTING TO WI-FI” instructions again. (Page 6) 1. With the supplied resetting tool, PRESS the reset button for 10 seconds while the camera is powered on. (See Image 7) SET UP CONNECTING TO WI-FI (CONT) REGISTERING A CAMERA ON DIFFERENT NETWORK RESETTING YOUR CAMERA 6. Creating a unique name and password for your camera. 1. Go to camera management 2. Select camera 3. Choose EDIT 4. Modify Device’s Password (See image 6) 7. Your camera is now set up. Image 6 Image 7 CL-4000 CAMERA MANUAL.indd 87/2/2015 4:27:17 PM 9 Surveillance made simple. ADD A REGISTERED CAMERA APP ICONS USING THE APP When you need to add a registered camera to your Pilot GuardCam account, or allow anyone with the Pilot GuardCam App to add your camera, please follow the following steps below: 1. On the main screen, tap Settings on the right corner. 2. Tap Device Management from the menu. 3. Tap the Add on the right corner. 4. Enter a Name for your Pilot GuardCam camera. (Name must match camera’s name you want to add. 5. Enter the GID (there are two ways to enter the GID) a. Type the GID from the bottom of device. b. Tap the QR code icon and scan the QR code from the bottom of device. 6. Enter correct user name and password. Start / Stop Recording Change Video QualityTake Snapshots Allows Users to Hear Via Camera’s Microphone Rotates Camera View on a Mobile Device Allows Users to Speak through the camera CL-4000 CAMERA MANUAL.indd 97/2/2015 4:27:17 PM Surveillance made simple. CL-4000 CAMERA MANUAL.indd 107/2/2015 4:27:17 PM This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause …
