Blueair HealthProtect™ User Manual Manuel utilisateur Manual del usuario 사용 설명서 使用手冊 5 EN Blueair HealthProtect™ 6 Safety instructions 8 Get started 10 Control panel 11 Filters 20 Move the air purifier 22 Cable winder 22 Care and maintenance 23 Troubleshooting 24 Disposal and recycling 25 Help and support 25 Warranty information 25 Specification 26 Regulatory information 27 Content Please read this user manual carefully and keep it for future reference. The latest version of this user manual can be found on www.blueair.com Note: There may be local variations of these models. Product name:Regulatory model number: Regulatory model number: 10-models100-127V220-240V 7410i74113710007421371000 7710i77113710007721371000 40-models 7440i74123710007422371000 7740i 77123710007722371000 70-models 7470i 74133520007423352000 7475i 74133520007423352000 7770i 77133520007723352000 7775i 77133520007723352000 Blueair HealthProtect™ 7400/7700 Series 7 6 Blueair HealthProtect™ Blueair HealthProtect™ air purifiers are available in three models, the 10-models, the 40-models and the 70-models. All models are Wi-Fi enabled, have a GermShield TM function to prevent bacterial growth, pre-filters and a main filter to purify air. All HealthProtect™ models have control functions and built in sensors. The 40-models and the 70-models have additional indications for air quality data. The 40-models have a display for particulate matter data. The 70-models have a dynamic screen control, with additional functions for particles, gases (tVOC), temperature, relative humidity and filter lifetime. You can change the air purifier settings at any time, using the control panel on the air purifier or remotely using the Blueair app. Additional functions are available for all models through the Blueair app. Recommendations for best performance • Use the air purifier in a room that does not exceed the room size recommendation. • Place the air purifier in a location where air can circulate freely in, out and around the air purifier. • Do not place the air purifier closer than 10cm/4” to another object. • During operation, keep doors and windows in the room with the air purifier closed. • Run the air purifier 24 hours per day with the GermShield TM function on. • Only use original Blueair filters. • Change the main filter when the filter replacement indicator appears on the control panel. • Follow the maintenance instructions in this user manual. Blueair air purifiers are mainly composed of a motor, a fan and a filter. The air purifier removes contaminants from the air in a room to improve indoor air quality. A I J H G B C D E F A Control panelG Pre-filters B HandleH Filter door C Air outletI Main filter D Air quality sensor inletJ Fan and motor E Air inletK Power cable (not in picture) F Feet and wheelsL User Manual (not in picture) 9 8 Safety instructionsSafety instructions Blueair HealthProtect™ air purifiers are electrical appliances for indoor use only, take the necessary precautions to reduce the risk of fire, electric shock or injury. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • Children should be supervised to ensure that they do not play with the appliance. • Always disconnect the appliance from the power supply before maintenance. • Do not alter the power plug in any way and do not attempt to open or service the appliance yourself. Service must be done by the manufacturer, service agent or similarly qualified person using only original Blueair spare parts. • Ensure that the power cable and the power plug are not at risk of getting damaged. To avoid hazard, a damaged power cable must always be replaced by the manufacturer, service agent or similarly qualified person. • If the appliance is damaged or malfunctions, turn it off, disconnect it from the power supply and contact Blueair. • The power plug must be firmly inserted in the power socket. • When disconnecting the unit from the power supply, do not pull on the power cord, pull on the power plug. • Use the grounded power cable provided with your Blueair air purifier to plug directly and firmly into an appropriate, grounded electrical outlet. Refer to the rating label on your appliance. • Do not use an extension cord or a power strip. Refer to the rating label on your appliance. • Do not alter the power plug in any way. If the plug does not fit into the outlet, contact qualified personnel to install the proper outlet. • Do not use the included power cord for anything else but the appliance. • Do not allow objects to enter or block the air inlets and air outlets as this can cause electric shock or damage the appliance. • Do not place any objects on top of or directly against the appliance. • Do not sit on, stand, climb onto or hang from the appliance. • Keep the appliance, including the power cable, at a safe distance from heated surfaces and open fire. • Keep the appliance and power plug away from water and other liquids. • Keep the appliance and power plug away from chemicals such as pesticides and deodorants. • Place the appliance on the floor. The appliance must be placed on a stable surface. • Do not use the appliance outdoors or in wet environments such as bathrooms, laundry rooms or pool areas. • Children shall not play with the appliance. • Cleaning and user maintenance shall not be made by children without supervision. 11 10 Get started Plug into the power supply Step 1 Open the filter door, pull out the main filter and remove the protective wrapping. Step 1 If your air purifier has a removable power cable, plug the cable firmly into the power cable socket on the air purifier. Connect to the Blueair app Step 1 Download the Blueair app from the App store or Google play. Step 2 Open the Blueair app and follow the instruction…
