Blueair HealthProtect™ User Manual Manuel utilisateur Manual del usuario 사용 설명서 使用手冊 5 EN Blueair HealthProtect™ 6 Safety instructions 8 Get started 10 Control panel 11 Filters 20 Move the air purifier 22 Cable winder 22 Care and maintenance 23 Troubleshooting 24 Disposal and recycling 25 Help and support 25 Warranty information 25 Specification 26 Regulatory information 27 Content Please read this user manual carefully and keep it for future reference. The latest version of this user manual can be found on www.blueair.com Note: There may be local variations of these models. Product name:Regulatory model number: Regulatory model number: 10-models100-127V220-240V 7410i74113710007421371000 7710i77113710007721371000 40-models 7440i74123710007422371000 7740i 77123710007722371000 70-models 7470i 74133520007423352000 7475i 74133520007423352000 7770i 77133520007723352000 7775i 77133520007723352000 Blueair HealthProtect™ 7400/7700 Series 7 6 Blueair HealthProtect™ Blueair HealthProtect™ air purifiers are available in three models, the 10-models, the 40-models and the 70-models. All models are Wi-Fi enabled, have a GermShield TM function to prevent bacterial growth, pre-filters and a main filter to purify air. All HealthProtect™ models have control functions and built in sensors. The 40-models and the 70-models have additional indications for air quality data. The 40-models have a display for particulate matter data. The 70-models have a dynamic screen control, with additional functions for particles, gases (tVOC), temperature, relative humidity and filter lifetime. You can change the air purifier settings at any time, using the control panel on the air purifier or remotely using the Blueair app. Additional functions are available for all models through the Blueair app. Recommendations for best performance • Use the air purifier in a room that does not exceed the room size recommendation. • Place the air purifier in a location where air can circulate freely in, out and around the air purifier. • Do not place the air purifier closer than 10cm/4” to another object. • During operation, keep doors and windows in the room with the air purifier closed. • Run the air purifier 24 hours per day with the GermShield TM function on. • Only use original Blueair filters. • Change the main filter when the filter replacement indicator appears on the control panel. • Follow the maintenance instructions in this user manual. Blueair air purifiers are mainly composed of a motor, a fan and a filter. The air purifier removes contaminants from the air in a room to improve indoor air quality. A I J H G B C E F D A Control panelG Pre-filters B HandleH Filter door C Air outletI Main filter D Air quality sensor inletsJ Fan and motor E Air inletK Power cable (not in picture) F Feet and wheelsL User Manual (not in picture) 9 8 Safety instructionsSafety instructions Blueair HealthProtect™ air purifiers are electrical appliances for indoor use only, take the necessary precautions to reduce the risk of fire, electric shock or injury. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • Children should be supervised to ensure that they do not play with the appliance. • Always disconnect the appliance from the power supply before maintenance. • Do not alter the power plug in any way and do not attempt to open or service the appliance yourself. Service must be done by the manufacturer, service agent or similarly qualified person using only original Blueair spare parts. • Ensure that the power cable and the power plug are not at risk of getting damaged. To avoid hazard, a damaged power cable must always be replaced by the manufacturer, service agent or similarly qualified person. • If the appliance is damaged or malfunctions, turn it off, disconnect it from the power supply and contact Blueair. • The power plug must be firmly inserted in the power socket. • When disconnecting the unit from the power supply, do not pull on the power cord, pull on the power plug. • Use the grounded power cable provided with your Blueair air purifier to plug directly and firmly into an appropriate, grounded electrical outlet. Refer to the rating label on your appliance. • Do not use an extension cord or a power strip. Refer to the rating label on your appliance. • Do not alter the power plug in any way. If the plug does not fit into the outlet, contact qualified personnel to install the proper outlet. • Do not use the included power cord for anything else but the appliance. • Do not allow objects to enter or block the air inlets and air outlets as this can cause electric shock or damage the appliance. • Do not place any objects on top of or directly against the appliance. • Do not sit on, stand, climb onto or hang from the appliance. • Keep the appliance, including the power cable, at a safe distance from heated surfaces and open fire. • Keep the appliance and power plug away from water and other liquids. • Keep the appliance and power plug away from chemicals such as pesticides and deodorants. • Place the appliance on the floor. The appliance must be placed on a stable surface. • Do not use the appliance outdoors or in wet environments such as bathrooms, laundry rooms or pool areas. • Cleaning and user maintenance shall not be made by children without supervision. 11 10 Get started Plug into the power supply Step 1 Open the filter door, pull out the main filter and remove the protective wrapping. Step 1 If your air purifier has a removable power cable, plug the cable firmly into the power cable socket on the air purifier. Connect to the Blueair app Step 1 Download the Blueair app from the App store or Google play. Step 2 Open the Blueair app and follow the instructions to connect it to the air purifier. Connecti…

Text truncated - open the document above for the full version.

2020-07-24 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Blueair AB FCC ID: 2AEX3-77XX Company name: Blueair AB Title: Global Certification Specialist Date: 2020-07-24 2020-10-13 To Whom It May Concern: We, Blueair AB. hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for 2AEX3-77XX under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 2020-07-24. The Limited Agency Agreement expires on 2021-03- 01, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are i n full compliance wit h the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant t o Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that s ection. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Sign: Marc Gottlieb Global Director of Compliance 2020-10-13 2020-10-13

Attention: Application Examiner RE: Request for Confidentiality Applicant: Blueair AB FCC ID: 2AEX3-77XX To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request is hereby submitted by Blueair AB to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block Diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: Blueair AB has invested considerable time and materials in research and development to produce the referenced product. [Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.] [For FCC certification; delete for TCB certification: The fee for confidentiality has been submitted along with the fee for certification.] If you have questions or need further information, please contact the undersigned. Sincerely, Sign: Monica Sommarvinge on behalf of Blueair AB Email: [email protected] Title: Global Certification Specialist Tel: +46 70-268 38 50 Marc Gottlieb Global Director of Compliance [email protected] +46 70-268 38 49

Model: 7713352000 Model 7711371000 Model 7712371000

Model/Modèle: 7711371000 Input/Tension d’entrée: 120VAC 60Hz Power Consumption/ Consommation d’énergie: 76W 1.1A Motor Voltage, Current/ Tension, Courant du moteur: 310VDC, 0.282A Article No./Numéro de l’article: 105830 Filter Type/Type de filtre: SmartFilter Contains/Contient FCC ID: 2AC7Z-ESP32WROVERE Contains/Contient IC: 21098-ESPWROVERE FCC ID: 2AEX3-77XX IC: 20267-77XX Serial No./Numéro de série: Manufacturing date (YYWW): XXXX Designed in Sweden. Made in China. Conçu en Suède. Fabriqué en Chine. UPC/EAN: 689122015033 Conforms to UL STD.867 Certified to: CSA STD E60335-2-65 CSA STD C22.2 No. 60335-1 5018494 CAUTION: HIGH VOLTAGE INSIDE CAUTION: THIS EQUIPMENT SHOULD BE INSPECTED FREQUENTLY AND COLLECTED DIRT REMOVED FROM IT REGULARLY TO PREVENT EXCESSIVE ACCUMULATION THAT MAY RESULT IN FLASHOVER OR A RISK OF FIRE. ATTENTION: HAUTE TENSION ATTENTION: CET APPAREIL DEVRAIT FAIRE L’OBJET D’UNE INSPECTION ET LES FILTRES DEVRAIENT ÊTRE NETTOYÉS CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT, DE FAÇON RÉGULIÉRE, AFIN D’EMPÊCHER UNE ACCUMULATION EXCESSIVE DE POUSSIÉRE POUVANT PROVOQUER UN EMBRASEMENT ÉCLAIR OU CAUSER UN RISQUE D’INCENDIE. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 0105577000

Serial No./Numéro de série: Designed in Sweden. Made in China. Conçu en Suède. Fabriqué en Chine. UPC/EAN: 689122015088 CAUTION: HIGH VOLTAGE INSIDE CAUTION: THIS EQUIPMENT SHOULD BE INSPECTED FREQUENTLY AND COLLECTED DIRT REMOVED FROM IT REGULARLY TO PREVENT EXCESSIVE ACCUMULATION THAT MAY RESULT IN FLASHOVER OR A RISK OF FIRE. ATTENTION: HAUTE TENSION ATTENTION: CET APPAREIL DEVRAIT FAIRE L’OBJET D’UNE INSPECTION ET LES FILTRES DEVRAIENT ÊTRE NETTOYÉS CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT, DE FAÇON RÉGULIÉRE, AFIN D’EMPÊCHER UNE ACCUMULATION EXCESSIVE DE POUSSIÉRE POUVANT PROVOQUER UN EMBRASEMENT ÉCLAIR OU CAUSER UN RISQUE D’INCENDIE. 0105578000 Model/Modèle: 7712371000 Input/Tension d’entrée: 120VAC 60Hz Power Consumption/ Consommation d’énergie: 76W 1.1A Motor Voltage, Current/ Tension, Courant du moteur: 310VDC, 0.282A Article No./Numéro de l’article: 105835 Filter Type/Type de filtre: SmartFilter Contains/Contient FCC ID: 2AC7Z-ESP32WROVERE Contains/Contient IC: 21098-ESPWROVERE FCC ID: 2AEX3-77XX IC: 20267-77XX Manufacturing date (YYWW): XXXX 5018494 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Conforms to UL STD.867 Certified to: CSA STD E60335-2-65 CSA STD C22.2 No. 60335-1

Serial No./Numéro de série: Designed in Sweden. Made in China. Conçu en Suède. Fabriqué en Chine. UPC/EAN: 689122015132 CAUTION: HIGH VOLTAGE INSIDE CAUTION: THIS EQUIPMENT SHOULD BE INSPECTED FREQUENTLY AND COLLECTED DIRT REMOVED FROM IT REGULARLY TO PREVENT EXCESSIVE ACCUMULATION THAT MAY RESULT IN FLASHOVER OR A RISK OF FIRE. ATTENTION: HAUTE TENSION ATTENTION: CET APPAREIL DEVRAIT FAIRE L’OBJET D’UNE INSPECTION ET LES FILTRES DEVRAIENT ÊTRE NETTOYÉS CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT, DE FAÇON RÉGULIÉRE, AFIN D’EMPÊCHER UNE ACCUMULATION EXCESSIVE DE POUSSIÉRE POUVANT PROVOQUER UN EMBRASEMENT ÉCLAIR OU CAUSER UN RISQUE D’INCENDIE. 0105579000 Model/Modèle: 7713352000 Input/Tension d’entrée: 120VAC 60Hz Power Consumption/ Consommation d’énergie: 76W 1.1A Motor Voltage, Current/ Tension, Courant du moteur: 310VDC, 0.282A Article No./Numéro de l’article: 105840 Filter Type/Type de filtre: SmartFilter Contains/Contient FCC ID: 2AC7Z-ESP32WROVERE Contains/Contient IC: 21098-ESPWROVERE FCC ID: 2AEX3-77XX IC: 20267-77XX Manufacturing date (YYWW): XXXX 5018494 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Conforms to UL STD.867 Certified to: CSA STD E60335-2-65 CSA STD C22.2 No. 60335-1

Model: 7713352000 Control PCB of model 7711371000 Control PCB of model 7712371000

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 200720006GZU FCC ID: 2AEX3-77XX Page: 1 of 2 RF Exposure Compliance Requirement Calculation formula： E (V/m) = (30*P*G) 0.5 /d E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between EUT and antenna (m) Remark: P=(E*d) 2 /30G in the formula above, d=3m, field strength= 51.4dBuV/m (max described by client), G=1.0 (Antenna gain=0 dBi) so P=0.00004mW The worst case test separation distance is 5mm. The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequency of the device is below 100 MHz. In KDB 447498 D01 v06: 4.3.1 c)2) Standalone SAR test exclusion considerations: The SAR Test Exclusion Threshold is calculated from: 0.5 x [1+log(100/f (MHz) )] mW = 0.93mW The Max Conducted Output Power and SAR Test Exclusion Threshold (mW) are listed below: Transmit Frequency (MHz) Output power (mW) SAR Test Exclusion Threshold (mW) 13.56 0.00004 0.93 RFID MPE Ratio: 0.00004/0.93=0.00004 According to SAR Exclusion Threshold in KDB 447498 (D01) General RF Exposure Guidance D01 v06, the SAR report is not required. WIFI/BT module’s MPE ratio: WIFI: 0.2183/1 = 0.2183 BT: 0.0035/1 =0.0035 Sum of the MPE ratio for all simultaneously transmitting antennas: 0.00004+0.2183+0.0035<1 Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Job No.: 200720006GZU FCC ID: 2AEX3-77XX Page: 2 of 2 Test Location: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch All tests were performed at: Room102/104, No 203, KeZhu Road, Science City, GETDD Guangzhou, China

Blueair AB TEST REPORT SCOPE OF WORK EMC TESTING–7711371000, 7712371000, 7713352000 REPORT NUMBER 200720006GZU-001 ISSUE DATE [REVISED DATE] 25-September-2020 [---------------------] PAGES 30 DOCUMENT CONTROL NUMBER FCC Part 15.225-b © 2017 INTERTEK TEST REPORT Room 02, & 101/E201/E301/ E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Telephone: +86 20 8213 9688 Facsimile: +86 20 3205 7538 www.intertek.com.cn This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Room 02, & 101/E201/E301/E401/E501/E601/E701/E801 of Room 01 1-8/F., No. 7-2. Caipin Road, Science City, GETDD, Guangzhou, Guangdong, China Version: 10 June 2019 Page 2 of 30 FCC Part 15.225-b Applicant Name & Address : Blueair AB Karlavägen 108, 11526, Stockholm, Sweden Manufacturing Site : Dongguan JingNuo Environment Science and Technology Inc. #2, Limin Road, Jinxiaotang ,Zhutang Village, Fenggang Town, Dongguan City, Guangdong Intertek Report No: FCC ID: 200720006GZU-001 2AEX3-77XX Test standards 47 CFR PART 15 Subpart C: 2019 section 15.225 Sample Description Product : air purifier Model No. : 7711371000, 7712371000, 7713352000 Electrical Rating : 120V~, 60Hz, 76W Serial No. Not Labeled Date Received : 20 July 2020 Date Test Conducted : 29 July 2020-01 September 2020 Prepared and Checked By Oscar Gao Project Engineer Approved By: Helen Ma Team Leader TEST REPORT Intertek Report No.: 200720006GZU-001 Version: 10 June 2019 Page 3 of 30 FCC Part 15.225-b CONTENT TEST REPORT ........................................................................................................................... 1 CONTENT ............................................................................................................................. 3 1.0 TEST RESULT SUMMARY ............................................................................................ 4 2.0 GENERAL DESCRIPTION ............................................................................................. 5 2.1 P RODUCT DESCRIPTION ........................................................................................................ 5 2.2 R ELATED SUBMITTAL(S) GRANTS ........................................................................................... 5 2.3 T EST METHODOLOGY .......................................................................................................... 5 2.4 T EST FACILITY ..................................................................................................................... 5 3.0 SYSTEM TEST CONFIGURATION ................................................................................. 6 3.1 J USTIFICATION .................................................................................................................... 6 3.2 EUT EXERCISING SOFTWARE ................................................................................................. 7 3.3 S PECIAL ACCESSORIES .......................................................................................................... 7 3.4 M EASUREMENT UNCERTAINTY .............................................................................................. 7 3.5 E QUIPMENT MODIFICATION ................................................................................................. 8 3.6 S UPPORT EQUIPMENT LIST AND DESCRIPTION .......................................................................... 8 4.0 MEASUREMENT RESULTS .......................................................................................... 9 4.1 A NTENNA REQUIREMENT ..................................................................................................... 9 4.2 O CCUPIED BANDWIDTH ..................................................................................................... 10 4.3 R ADIATED EMISSION .......................................................................................................... 12 4.4 F REQUENCY STABILITY ....................................................................................................... 23 4.5 C ONDUCTED EMISSION TEST ............................................................................................... 25 5.0 TEST EQUIPMENT LIST ............................................................................................. 30 TEST REPORT Intertek Report No.: 200720006GZU-001 Version: 10 June 2019 Page 4 of 30 FCC Part 15.225-b 1.0 TEST RESULT SUMMARY Test ItemTest RequirementTest MethodResult Antenna Requirement FCC PART 15 C Section 15.203 FCC PART 15 C Section 15.203 PASS Occupied Bandwidth FCC PART 15 C section 15.215(c) ANSI C63.10: Clause 6.9 PASS Radiated Emission FCC PART 15 C section 15.225 (a), (b), (c), (d) ANSI C63.10: Clause 6.4 & 6.5 PASS Frequency Stability FCC PART 15 C section 15.225 (e) ANSI C63.10: Clause 6.8 PASS Conducted Emissions at Mains Terminals FCC PART 15 C section 15.207 ANSI C63.10: Clause 6.2 PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In t…
