2AEX3-SENSEPLUSAir cleaner

Blueair Sense+ ™ User Manual English | Deutsch | Español | Français | Polski 3 The intelligent, Wi-Fi enabled Blueair Sense+ cleans your indoor air completely five times in an hour, turning any room up to 18 square meters (194 square feet) into a healthy air zone. You can control it wirelessly with a smartphone – or automatically with the Blueair Aware air monitor that also gives air quality readings.Before using Blueair Sense+, please read this user manual carefully.ContentGeneral safety information 5 Get the most out of it 7 Place it 7Start it 7Connect i wirelessly to your smartphone 8 Control it 9Care for it 10Change filter 11Blueair filter subscription program 13 Help and support 13Warranty information 13Technical specifications 14 English SENSE+_EN-EU_UM_Rev00 5 4 The plug fits into a grounded outlet – do not alter the plug in any way.Plug Sense+ directly into an appropriate electrical outlet – please refer to the voltage label on your unit.This unit can be used by children aged from 8 years and above and persons with reduced phys-ical, sensory or mental capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning use of the unit in a safe way and understand the hazards involved. Children must not play with the appliance. Cleaning and maintenance must not be done by children without supervision Welcome to your new air purifierSense+ comes with Blueair’s patented HEPASilentPlus™ – the world’s most advanced and silent filter system. It’s a revolutionary combination of mechanical and electrostatic filtration. Air is drawn into the air purifier where large airborne particles and gaseous pollutants are captured in the first filter cassette. The air continues through an ion chamber where particles not captured mechanically are charged with negative ions, so they get attracted and caught by oppositely charged fibers in the second filter cassette. The purified air, virtually contaminant-free, is then re-circu-lated into the room. Active carbon filter sheet (2) HEPASilent- Plus™ filter (2) Kit box Blueair Sense+ Welcome cardUser manualCleaning cloth 1 2 3 4 5 Air intakeAir outlet LED (lit when Sense+™ is purifying air) Display (motion sensor controlled) 1234 5 Power cord General safety informationThe Blueair Sense+ air purifier is an electrical appliance. Please take the necessary precautions to reduce the risk of fire, electric shock or injury. 7 6 Warning : Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable pro-tection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip-ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.• Consult the dealer or an experienced radio/TV technician for help.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.This Class B digital apparatus complies with Canadian ICES-003. Get the most out of itMaximum speed is recommended for fast initial cleaning or for heavily polluted air. After a few minutes, the speed can be reduced. Minimum speed is generally recommended for nighttime use.For best results, run Sense+ 24/7. This ensures that clean, filtered air constantly circulates throughout the room. Sense+ uses as little as 7 W, less than a low-energy light bulb.Start itPlug Sense+ into a grounded electrical outlet with the supplied power cord. To turn it on for the first time, sweep your hand over the top display. A blue LED on the front side indicates that the unit is working.Place itSense+ should be placed in a location that allows air to circulate freely in, out and around the unit. Minimum distance from another object is 10 cm. Don’t place the unit: Directly on or against soft furnishings, such as bedding or curtains.Near sources of heat, such as radiators, fireplaces or ovens.Near wet areas, such as bathrooms or laundry rooms, where it may come into contact with water.Outdoors. FCC ID: 2AEX3-Sense+IC ID: 20267-Sense+ FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons 9 8 Connect it wirelessly to your smartphone1. Download the Blueair Friend™ app to your smartphone (available for iPhone and Android). 2. Activate Sense+ by sweeping your hand over the top display – when a Wi-Fi symbol and a circle are pulsing, Sense+ is ready to be connected to the Blueair app.3. Make sure you are connected to the Wi-Fi network you want Sense+ to be connected to. Start the app and follow setup instructions. For more information, tap on (Support) “FAQ”…

Text truncated - open the document above for the full version.

2AEX3-SENSEPLUS Global Product Marketing Manager

Model: Sense+ FCC ID: 2AEX3-SENSEPLUS IC:20267-SENSEPLUS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

INTERTEK TESTING SERVICES FCC ID: 2AEX3-SENSEPLUS RF Exposure report The Equipment Under Test (EUT) is an Air Cleaner with WiFi function operating at 2412-2462MHz for 802.11b/g/n-HT20, 11 channels with 5MHz channel spacing and 2422-2452MHz for 802.11n-HT40, 9 channels with 5MHz channel spacing. The EUT was powered by AC120V/60Hz. For more detailed features description, please refer to the user’s manual. Modulation Type: BPSK, QPSK, 16QAM, 64QAM for OFDM. CCK, DQPSK, DBPSK for DSSS. Antenna Type: Integral antenna Antenna Gain: 2.18dBi The nominal conducted output power specified: 17dBm (Tolerance: +/-5dB) The maximum conducted output power for the EUT is 21.86 dBm in the frequency 2.422GHz 802.11n-HT40 mode which is within the production variation. The minimum conducted output power for the EUT is 13.81dBm in the frequency 2.412GHz 802.11b mode which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting devices is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use For Maximum Permissible Exposure (MPE) evaluation of the product, the maximum power density at 20 cm from this transmitter shall be less than the General Population / Uncontrolled MPE limit in FCC Part 1.1310. The maximum EIRP= 17+5+2.18=24.18dBm=261.8mW The source-based time averaged maximum radiated power = 261.8 x Duty Cycle = 261.8mW From above data, the exposed power density at a distance (R) of 20cm from the center of radiation of the antenna can be calculated as follow: = PG/4πR^2 = EIRP/4πR^2 = 261.8/ 4πR^2 = 0.05 mW/cm^2 INTERTEK TESTING SERVICES FCC ID: 2AEX3-SENSEPLUS The MPE limit is 1.0 mWcm-2 for general population and uncontrolled exposure in the WiFi frequency range according to FCC Part 1.1310. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. Transmitter Duty Cycle Calculation The EUT transmit continuously during the test, the duty cycle is 1. The following RF exposure statement or similar sentence is proposed to be included in the user manual: “FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a separation distance of at least 20 cm from all persons.”

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. TRF no.: FCC 15C_Tx_b Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, D Block, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Website: www.china.intertek-etlsemko.com Blueair AB Application For Certification FCC ID: 2AEX3-SENSEPLUS Air Cleaner Model: Sense+ 2.4GHz WiFi Transceiver Report No.: 150508008SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [ 10-1-13] Prepared and Checked by: Approved by: Sign on file William Chen Senior Project Engineer Andy Yan Senior Project Engineer Date: July 05, 2015 INTERTEK TESTING SERVICE TRF no.: FCC 15C_TX_b FCC ID: 2AEX3-SENSEPLUS Report No.: 150508008SZN-001 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: Summary of Tests EXHIBIT 2: General Description EXHIBIT 3: System Test Configuration EXHIBIT 4: Measurement Results EXHIBIT 5: Equipment Photographs EXHIBIT 6: Product Labeling EXHIBIT 7: Technical Specifications EXHIBIT 8: Instruction Manual EXHIBIT 9: Confidentiality Request EXHIBIT 10: Miscellaneous Information EXHIBIT 11: Test Equipment List INTERTEK TESTING SERVICES TRF no.: FCC 15C_TX_b FCC ID: 2AEX3-SENSEPLUS Report No.: 150508008SZN-001 ii MEASUREMENT/TECHNICAL REPORT Air Cleaner Model: Sense+ FCC ID: 2AEX3-SENSEPLUS This report concerns (check one) Original Grant X Class II Change Equipment Type: DTS - Part 15 Digital Transmission Systems (WiFi transmitter portion) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01-13] Edition] provision. Report prepared by: William Chen Intertek Testing Services Shenzhen Ltd. Kejiyuan Branch 6F, Block D, Huahan Building, Langshan Road, Nanshan District, Shenzhen, P. R. China Phone: (86 755) 8614 0627 Fax: (86 755) 8614 6751 INTERTEK TESTING SERVICES TRF no.: FCC 15C_TX_b FCC ID: 2AEX3-SENSEPLUS Report No.: 150508008SZN-001 iii Table of Contents 1.0 Summary of Test results ............................................................................................................................. 2 2.0 General Description ...................................................................................................................................... 4 2.1 Product Description ..................................................................................................................................... 4 2.2 Related Submittal(s) Grants ....................................................................................................................... 5 2.3 Test Methodology ........................................................................................................................................ 5 2.4 Test Facility .................................................................................................................................................. 5 3.0 System Test Configuration ......................................................................................................................... 7 3.1 Justification .................................................................................................................................................. 7 3.2 EUT Exercising Software............................................................................................................................ 7 3.3 Special Accessories .................................................................................................................................... 7 3.4 Measurement Uncertainty .......................................................................................................................... 8 3.5 Equipment Modification .............................................................................................................................. 8 3.6 Support Equipment List and Description ................................................................................................ 8 4.0 Measurement Results................................................................................................................................. 10 4.1 Maximum Conducted Output Power at Antenna Terminals ..................................................................... 10 4.2 Minimum 6 dB RF Bandwidth ..................................................................................................................…

Text truncated - open the document above for the full version.
