2AF3K-SPS1Square Register

1955 Broadway Ste 600, Oakland, CA 94612 PROJECT X2B Packaging DELIVERABLE GSG - 16pg - US INKS/COATING 1/1 + Matte AQ BLACK MATER IAL 128g text C2S - SUN SIZE Flat: 272mm x 136mm Folded: 136mm x 136mm VENDOR Veritiv China FINISHING diecut, fold, staple DESIGN Eric Manago PRODUCTION Mike O’Neal PRODUCTION NOTES Dieline _______ MODIFIED November 4, 2020 1:00 PM PROGRAM MANAGER Isabel Turnquist FILE NAME M-LIT-0239-03_X2_GSG_16-pages_US_M02 PART # M-LIT-0239 REV -03 MECHANICAL # M02 REV NOTES REV-02 (08/20): MP release REV-03 (10/20): MP rerelease with correction to images SUPPLIER NOTES Getting Started Square Register Customer display cable Mounting screws and thumb nuts (x4) Mounting platePower adapter WELCOME TO SQUARE Let’s get your Square Register up and running. Start by taking a quick look at what’s in the box. Square Register Customer display Power button Mounting plate cleat slot Customer display release latch Bottom view Micro USB ports Front viewBack view Power adapter cable Hub SETTING UP SQUARE REGISTER Start by connecting Square Register to the hardware hub and power adapter. A B C D E Square Register Customer display Customer display cable Hub Power adapterPower adapter cable Docking the customer display Register can be used in both docked and undocked configurations. To dock your customer display to Register, follow these two simple steps. 1. Line up the heel of the customer display with the corresponding dock on Register. 2. Gently press the customer display until you feel it click and lock into place. NOTE: If you need to undock the customer display, hold in the release latch located on the bottom of Register and lift out the customer display. A Connect Register to hub Connect the hub cable to the bottom of Register through any micro USB port. B Connect Register to customer display (undocked) Plug either end of the customer display cable into the customer display, then plug the other end into the bottom of Register. C Connect the power adapter to hub Plug the power adapter into the hub. D Plug into power outlet Plug the power adapter cable into the power adapter, then into a power outlet. E Power up Press the power button on the base of the Register display until the Square logo appears onscreen. HOW TO TAKE PAYMENTS (DOCKED) Position Register so customers can easily see the customer display and pay with their cards and devices. To take a payment, ring up the sale and tap Charge. HOW TO TAKE PAYMENTS (UNDOCKED) Make sure the customer display is correctly oriented so it’s sitting horizontally on your countertop. Position the customer display so your customers can easily see it and pay with their cards and devices. To take a payment, ring up the sale and tap Charge. Tap Ask your customer to hold a contactless device or card near the customer display to trigger payment. Dip Ask your customer to insert a chip card into the chip card slot on the customer display and leave it in place until the sale is complete. Swipe Ask your customer to swipe a magnetic-stripe card through the magstripe reader on the customer display. Tap Ask your customer to hold a contactless device or card near the customer display to trigger payment. Dip Ask your customer to insert a chip card into the chip card slot on the customer display and leave it in place until the sale is complete. Swipe Ask your customer to swipe a magnetic-stripe card through the magstripe reader on the customer display. MOUNT SQUARE REGISTER TO YOUR COUNTER WITH ADHESIVE 1. Prepare the adhesive strips Grab the mounting plate. Remove the backing from the adhesive strips located on the underside of the plate. 2. Position properly Make sure the raised cleat of the mounting plate is on your side of the counter, not the customer’s side. Adhere the plate to your counter in the desired position and press down firmly for 30 seconds. Wait 30 minutes for the adhesive to set. If you need to remove the plate, slowly pull the tabs on the adhesive strips until they release. 3. Twist and lock Place Register onto the mounting plate with the larger screen facing right. Make sure the cleat is positioned in its slot. Turn Register 90 degrees clockwise so it locks into place. 1 2 MOUNT SQUARE REGISTER TO YOUR COUNTER WITH SCREWS 1. Pick a spot Grab the mounting plate. Pick a spot on your counter for Register, position the plate, and use a pencil to mark the four screw holes on your counter. Make sure the raised cleat is on your side of the counter, not the customer’s side. Note: Maximum counter thickness is 2 inches (50 mm). 3. Position properly Position the mounting plate onto the holes you’ve drilled, then insert a screw into each hole. From the underside of your counter, place a thumb nut onto each screw and tighten until the thumb nut is flush against your counter. 2. Drill your counter carefully You need a drill, a 3/16" (5 mm) drill bit, and the included screws and thumb nuts. Use the drill and drill bit to make the four holes you’ve marked for the plate. 4. Twist and lock Place Register onto the mounting plate with the larger screen facing right. Make sure the cleat is positioned in its slot. Turn Register 90 degrees clockwise so it locks into place. 1 2 CONNECT TO THE INTERNET VIA ETHERNET OR CONNECT USB ACCESSORIES Ethernet: Plug one end of an Ethernet cable into the hub and the other into a modem or Ethernet port. USB accessories: Plug any USB accessories into the hub, such as a bar code scanner, receipt printer, or cash drawer. Note: The Ethernet port can only be used to connect Register to the internet. HELP AND SUPPORT Read our FAQs, learn more about compatible hardware, and get troubleshooting support at square.com/register-setup. HARDWARE WARRANTY You’re covere d from defects for up to two years under a limited warranty. See square.com/warranty. FREE 30-DAY RETURNS Square offers a 30-day, risk-free return policy for all purchases made from square.com/shop. Simply go to square.com/returns so we can make things right. After a return i…

Text truncated - open the document above for the full version.

Square,Inc. Date:2020/11/24 FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Towhomitmayconcern: I,theundersigned,herebyauthorizeULVerificationServicesInc.toactonourbehalfinall mannersrelatingtoapplicationforequipmentauthorization,includingsigningofalldocuments relatingtothesematters.AnyandallactscarriedoutbyULVerificationServicesInc.onour behalfshallhavethesameeffectasactsofourown. I,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C. 853(a). InauthorizingULVerificationServicesInc . asourrepresentative,westillrecognizethatweare responsibleto: a)complywiththerelevantprovisionsofthecertificationprogram; b)makeallnecessaryarrangementsfortheconductoftheevaluation,including provisionforexaminingdocumentationandaccesstoallareas,records(including internalauditreports)andpersonnelforthepurposesofevaluation(e.g.testing, inspection,assessment,surveillance,reassessment)andresolutionofcomplaints; c)makeclaimsregardingcertificationonlyinrespectofthescopeforwhich certificationhasbeengranted; d)donotuseourproductcertificationinsuchamannerastobringtheCertification Divisionintodisreputeandnotmakeanystatementregardingourproduct certificationwhichtheCertificationDivisionmayconsidermisleadingor unauthorized; e)uponsuspensionorcancellationofcertification,discontinueuseofalladvertising matterthatcontainsanyreferencetheretoandreturnanycertificationdocuments asrequiredbytheCertificationDivision; f)usecertificationonlytoindicatetheproductsarecertifiedasbeinginconformity withspecifiedstandards; g)endeavortoensurethatnocertificateorreportnoranypartthereofisusedina misleadingmanner; h)ensurethatanyreferencetoourproductcertificationincommunicationmediasuchas documents,brochuresoradvertising,complieswiththerequirementsofthe CertificationDivision; i)keeparecordofallcomplaintsmadeknowntousrelatingtotheproduct’s compliancewithrequirementsoftherelevantstandardandtomaketheserecords availabletothewhenrequested; j)takeappropriateactionwithrespecttosuchcomplaintsandanydeficienciesfoundin productsorservicesthataffectcompliancewiththerequirementsforcertification; k)documenttheactionstaken. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signedby: CompanyName:Square,Inc. ContactName:MichaelLamfalusi TitleofPerson:EngineeringProgramManager Address:1455MarketSt.Suite600SanFrancisco,CA94103UnitedStates

Square,Inc. FederalCommunicationsCommission 7435OaklandMillsRoad ColumbiaMD21046 Subject:RequestforConfidentiality FCCID:2AF3K-SPS1 ToWhomItMayConcern: PursuanttotheprovisionsofSections0.457and0.459oftheCommission’srules(47CFR§§ 0.457,0.459),wearerequestingtheCommissiontowithholdthefollowingattachmentsas confidentialdocumentfrompublicdisclosureindefinitely. SchematicDiagram BlockDiagram TheoryofOperation Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionareconsidered asproprietaryinformationinoperationoftheequipment.Thepublicdisclosureofabove documentsmightbeharmfultoourcompanyandwouldgivecompetitoranunfairadvantagein themarket. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatandcorrespondent duringcertificationreviewprocesscannotbegrantedasconfidentialdocumentsandthose informationwillbeavailableforpublicreviewoncethegrantofequipmentauthorizationis issued. BestRegards CompanyName:Square,Inc. ContactName:MichaelLamfalusi TitleofPerson:EngineeringProgramManager Address:1455MarketSt.Suite600SanFrancisco,CA94103UnitedStates Date:2020/11/24

Appendix I External Photographs Page 2 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-1 View of EUT-2 Page 3 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-3 View of EUT-4 Page 4 of 4 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. View of EUT-5

FCC E-Labelling Model: SPS1-01 FCC ID: 2AF3K-SPS1 IC: 21827-SPS1 A. Information to be displayed 1. The i nformation that will be displayed on the e-label a nd information that wil l remain in the user manual i s shown below: Information On E-label In Manual Packaging label FCC ID number Yes No Yes 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”) Yes Yes No Class A / B Digital Device user manual statements Yes No No Caution to the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Yes No No Describe any other FCC regulatory information included in e-label No Yes No Model name Yes No Yes Images of the e-label screen are provided below: User can be able to access the regulatory information without requiring special access codes or permissions B.Access to the required information on the e-label 1. Users are able to access the information in no more than three steps in a device’s menu. The actual steps are: STEP 1: User clicks on detailed Settings entry STEP2: User clicks on detailed General entry After step 3, the user can access the FCC information: STEP3: User clicks on detailed Regulatory entry Users are able to access the information in no more than three steps in a device’s menu. go to Support > Legal > Hardware Disclaimer.

Appendix II Internal Photographs Page 2 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-1 Internal View of EUT-2 Page 3 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-3 Internal View of EUT-4 Page 4 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-5 Internal View of EUT-6 Page 5 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-7 Detail View of Antenna Antenna 1 WIFI/BT*BLE Antenna 2 WIFI Page 6 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Detail View of Antenna Hub: SHF3-01 Internal View of EUT-8 Page 7 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-9 Internal View of EUT-10 Page 8 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-11 Internal View of EUT-12 Page 9 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Hub: SHB3-01 Internal View of EUT-13 Internal View of EUT-14 Page 10 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-15 Internal View of EUT-16 Page 11 of 11 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Internal View of EUT-17

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. FCC RF EXPOSURE REPORT CERTIFICATION TEST REPORT For Square Register MODEL NUMBER: SPS1-01 FCC ID: 2AF3K-SPS1 REPORT NUMBER: 4789598114.1-5 ISSUE DATE: October 15, 2020 Prepared for Square, Inc. 1455 Market St, Suite 600, San Francisco, California, United States 94103 Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi- Tech Development Zone Dongguan, 523808, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT NO.: 4789598114.1-2 Page 2 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Issue Date Revisions Revised By V0 10/15/2020 Initial Issue REPORT NO.: 4789598114.1-2 Page 3 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. REQUIREMENT ................................................................................................................. 6 REPORT NO.: 4789598114.1-2 Page 4 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Square, Inc. Address: 1455 Market St, Suite 600, San Francisco, California, United States 94103 Manufacturer Information Company Name: Square, Inc. Address: 1455 Market St, Suite 600, San Francisco, California, United States 94103 EUT Information EUT Name: Square Register Model: Square Register Model: SPS1-01 Brand: SQUARE Sample Received Date: August 17, 2020 Sample Status: Normal Sample ID: 2809002 Date of Tested: August 17~ September 15, 2020 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47CFR§2.1091 PASS Prepared By: Checked By: Kebo Zhang Shawn Wen Project Engineer Laboratory Leader Approved By: Stephen Guo Laboratory Manager REPORT NO.: 4789598114.1-2 Page 5 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 2. TEST METHODOLOGY The tests documented in this report were performed in accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091. 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 4102.01) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1187) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. Has been recognized to perform compliance testing on equipment subject to the Commission's Declaration of Conformity (DoC) and Certification rules ISED (Company No.: 21320) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been registered and fully described in a report filed with Industry Canada. The Company Number is 21320. VCCI (Registration No.: G-20019, R-20004, C-20012 and T-20011) UL Verification Services (Guangzhou) Co., Ltd. Song Shan Lake Branch. has been assessed and proved to be in compliance with VCCI, the Membership No. is 3793. Facility Name: Chamber D, the VCCI registration No. is G-20019 and R-20004 Shielding Room B, the VCCI registration No. is C-20012 and T-20011 Note: All tests measurement facilities use to collect the measurement data are located at Building 10, Innovation Technology Park, Song Shan Lake Hi tech Development Zone, Dongguan, 523808, China. REPORT NO.: 4789598114.1-2 Page 6 of 7 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM No.: 10-SL-F0112 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. 4. REQUIREMENT LIMIT AND CALCULATION METHOD Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. Limits for General Population/Uncontrolled Exposure RF EXPOSURE LIMIT Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 CALCULATION METHOD S=PG/4πR² Where: S=power density P=power input to ante…
