Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
M O T O R O L A W H O L E H O M E W I F I Quick Start Included in the Package Motorola Router Motorola Satellite Power Supply Ethernet Cable Let’s get started Download the MotoManage™ app from the App Store or Google Play. Open the app and follow the instructions to install your devices. The app will have you scan the QR code on the units and automatically configure the units for you. Positioning the units around your home When placing the unit labelled satellite, you should try and position it halfway between the router and the area you want to provide WiFi coverage. Note that the satellite must be within range of your router’s WiFi signal in order to sync with the router. The satellite will power up and attempt to sync with the router. While attempting to sync the Motorola logo will blink blue. If it continues to blink blue after a couple minutes your satellite is out of range, you must move the satellite closer to the router. After the satellite syncs with the router the Motorola logo will turn either green or amber. If the logo turns green, congratulations, the connection between the router and the satellite is good. If the logo turns amber, the connection to the router is weak. We recommend moving the satellite closer to the router to improve the signal. Wireless Router The MH7021 has a unique Wireless Network Name/SSID and Wireless Security Key/Password printed on the MH7021 back label. Set up your wireless devices to work with this SSID and security key, or with the SSID and security key you specified, if you changed them. Note that wireless performance depends on a number of factors. Please keep these things in mind: • Try to avoid interference from Bluetooth headsets and stereos, microwave ovens, WiFi-capable printers, and 2.4 GHz cordless phones and base stations. Try not to put the MH7021 close to these interfering devices. • Wireless range can be limited by a variety of issues, including weak wireless clients and challenging building configurations. Front Panel Light The Motorola Logo will change colors to indicate the status COLOR DESCRIPTION Solid Green Connected with a strong signal Blinking Green Unit is powering up. Blinking Blue Unit is trying to pair with another device. Solid Amber Connected with a weak signal. Blinking Amber WPS is active and in discovery mode. Troubleshooting Tips What if I can’t make an Internet connection right after installation? • First turn off the modem that provides your Internet connection for at least 8 seconds, then on, to see if that fixes the problem. • Check that the MH7021’s power supply is plugged into a live outlet, and that the Ethernet cable is connected securely. What if I am connected wirelessly but my connection seems slow or keeps dropping? Please re-read the Wireless Router section above. What if I don’t know my MH7021’s Wireless Network Name/SSID or Security Key/Password? The default values are printed on the bottom label of the MH7021. Use these unless you changed them. If you changed them, try to remember where you put the new values. If you have a device that connects wirelessly to the MH7021, it may show the Wireless Network Name/SSID and Password. You can also find this information in the MH7021 Configuration Manager. Information about using this is in the Configuration Manager section above. If all else fails, reset the device to factory defaults by holding the Reset button depressed for 10 seconds. (A paperclip helps.) You can then use the default values. Do you have any other questions? We have lots more information at www.motorolanetwork.com/mentor We like to help. Please visit our support Website or call our support specialists. Our Website has our Motorola Mentor information, and also provides returns and warranty information. www.motorolanetwork.com/support Email: [email protected] Phone: 800-753-0797 or 617-753-0562 Our full-length user manual is available at www.motorolanetwork.com/MH7021manual Limited Warranty MTRLC LLC warrants this product against defects in material and workmanship for a warranty period of 2 years. To read the full warranty, please go to www.motorolanetwork.com/warranty Safety Precautions These precautions help protect you and your MH7021. Do not put the MH7021 or its power supply in water, since this is a shock hazard. The MH7021 should normally be installed indoors. If you use it outdoors, protect it from moisture and be careful about temperature. Your MH7021 should be operated in an environment that’s between 32 and 104° Fahrenheit (0 to 40° Centigrade). Your MH7021 should not be in a confined space. There should be room for air flow around the top, front, and sides of the MH7021. Make sure to use your MH7021’s power supply and a compatible electrical outlet. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this eq…
Text truncated - open the document above for the full version.
We, MTRLC LLC, declare that the device does not support chann - 13 in 2.4GHzband and any non-US channels in all the operational mode(p) for the fo g product. MTRLC LLC 225 Franklin St. 26th Floor Boston. MA 02110 Date:202012120 FCC lD: 2AF5PMH7021 Thank you! Andy Pollock / Director of Hardware Engineering MTRLC LLC Tel: 617-753-0663 Fax: 61 7-753-0663 E-mail: [email protected]
MTRLC LLC 225 Franklin St. 26th Floor Boston, MA 021 10 Date: 202012120 FCC lD:2AF5PMH7021 To the attention of FederaI Communi cations Commission Authorization and Evatuation Division Perrmanent Confidentialitv Req uest Pursuant to Sections 0.457 and 0.459 of the Commission's Rutes, the Appticant hereby requests confidential treatment of information accompanying this Apptication as outlined betow: Schematics Block Diagram Operational Descri ption Software Operational Description The above materiarts contain trade secrets and proprietary information not customarity reteas,ed to the pubtic. The pubtic disctosure of these matters might be harmful to the Appticant and provide unjustified benefits to its competitors. The Appticant undr:rstands that pursuant to Rute 0.457, disctosure of this Apptication and all, accompanying documentation wi[[ not be made before the date of the Grant for this application. Sincerely yours, Andy Pollock / Direrctor of Hardware Engineering MTRLC LLC Tel: 617-753-0663 Fax: 617-753-066:i E-mail: andvp@zo,om. net
MTRI.C LLC 225 Franklin St. 26th Florcr Boston, MA 02110 Date: 202012120 FCC lD:2AF5PMH7021 AUTHORIZATION LETTER To Whom lt May Concern: MTRLG tLC hereby authorizes Debby Lin/Senior Specialist of Bureau Veritas Consumer Products Services (H.1(.) Ltd., Taoyuan Branch ("BV CPS Taoyuan"), to act on its behalf in all matters relating to the Federal Communication Commission ("FCC') application for equiprnent authorization in connection with the FCC lD listed above, including signing of all docunnents relating to these matters. Any and all acts carried out by Debby Lin/Senior Speciialist of BV CPS Taoyuan on MTRLc LLc's behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. lf you have any questions regarding the authorization, please don't hesitate to contact us. Sincenely yours, MTRLC LLC Tel: 617-753-0663 Fax: €i17-753-0663 E-mail: andyp@zoom. net Andy Pollock / Director ol'Hardware Engineering
Reference No.: 191227E09-1 Page 1 Reference No.: xxxxxxxx CONSTRUCTION PHOTOS OF EUT Reference No.: 191227E09-1 Page 2 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 3 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 4 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 5 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 6 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 7 Reference No.: xxxxxxxx Reference No.: 191227E09-1 Page 8 Reference No.: xxxxxxxx Adapter Reference No.: 191227E09-1 Page 9 Reference No.: xxxxxxxx
FCC ID:2AF5PMH7021 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label Here
FCC ID:2AF5PMH7021 LABEL SAMPLE The label will be permanently affixed at a conspicuous location on the device.
Reference No.: 191227E09-2 Page 1 Reference No.: xxxxxxxx CONSTRUCTION PHOTOS OF EUT Reference No.: 191227E09-2 Page 2 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 3 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 4 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 5 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 6 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 7 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 8 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 9 Reference No.: xxxxxxxx Antenna 1 Reference No.: 191227E09-2 Page 10 Reference No.: xxxxxxxx Antenna 2 Reference No.: 191227E09-2 Page 11 Reference No.: xxxxxxxx Reference No.: 191227E09-2 Page 12 Reference No.: xxxxxxxx Antenna 3 Reference No.: 191227E09-2 Page 13 Reference No.: xxxxxxxx Antenna 4
Report No.: SA191227E09 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA191227E09 FCC ID: 2AF5PMH7021 Test Model: MH7021 Series Model: MH702XY (where X can be 0, 1, 2, 3, or 4, and Y can be A, B, C, D or blank) Received Date: Dec. 27, 2019 Test Date: Feb. 17, 2020 Issued Date: Mar. 11, 2020 Applicant: MTRLC LLC Address: 225 Franklin St. 26th Floor Boston, MA 02110 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. Report No.: SA191227E09 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result of Maximum Conducted Power ............................................................................. 7 Report No.: SA191227E09 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA191227E09 Original release. Mar. 11, 2020 Report No.: SA191227E09 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: AC2200 Tri-band Mesh WiFi Brand: Motorola Test Model: MH7021 Series Model: MH702XY (where X can be 0, 1, 2, 3, or 4, and Y can be A, B, C, D or blank) Sample Status: ENGINEERING SAMPLE Applicant: MTRLC LLC Test Date: Feb. 17, 2020 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: Mar. 11, 2020 Vivian Huang / Specialist Approved by : , Date: Mar. 11, 2020 Clark Lin / Technical Manager Report No.: SA191227E09 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 34cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA191227E09 Page No. 6 / 7 Report Format Version: 6.1.1 2.4 Antenna Gain Antenna No Brand Antenna Gain (dBi) Frequency range (GHz) Antenna Type Connector Type *Cable Length (mm) Cable Loss (dB) ANT 1 (2.4GHz/5GHz) WALSIN TECHNOLOGY CORPORATION 2.88 2.4~2.5 PCB I-pex 85±3 0.23 4.31 5.15~5.85 0.36 ANT 2 (2.4GHz/5GHz) 3 2.4~2.5 PCB I-pex 125±3 0.31 5.27 5.15~5.85 0.5 ANT 3(5GHz) 5.19 5.15~5.85 METAL TUBE I-pex 110±3 0.47 ANT 4(5GHz) 5.37 5.15~5.85 METAL TUBE I-pex 110±3 0.47 Report No.…
Text truncated - open the document above for the full version.
Report No.: RF191227E09 Page No. 1 / 58 Report Format Version: 6.1.2 FCC Test Report Report No.: RF191227E09 FCC ID: 2AF5PMH7021 Test Model: MH7021 Series Model: MH702XY (Where X can be 0, 1, 2, 3, or 4, and Y can be A, B, C, D or blank.) Received Date: Dec. 27, 2019 Test Date: Feb. 11 to 12, 2020 Issued Date: Mar. 11, 2020 Applicant: MTRLC LLC Address: 225 Franklin St. 26th Floor Boston, MA 02110 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF191227E09 Page No. 2 / 58 Report Format Version: 6.1.2 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 14 3.5 General Description of Applied Standards ........................................................................................ 15 4 Test Types and Results ...................................................................................................................... 16 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 16 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 16 4.1.2 Test Instruments ................................................................................................................................ 17 4.1.3 Test Procedures ................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 19 4.1.5 Test Setup .......................................................................................................................................... 19 4.1.6 EUT Operating Conditions ................................................................................................................. 20 4.1.7 Test Results ....................................................................................................................................... 21 4.2 Conducted Emission Measurement .................................................................................................. 35 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 35 4.2.2 Test Instruments ................................................................................................................................ 35 4.2.3 Test Procedures ......................................................................................................…
Text truncated - open the document above for the full version.
Report No.: RF191227E09-2 Page No. 1 / 27 Report Format Version: 6.1.1 Reference No.: Supplemental “Transmit Simultaneously” Test Report Report No.: RF191227E09-2 FCC ID: 2AF5PMH7021 Test Model: MH7021 Series Model: MH702XY (where X can be 0, 1, 2, 3, or 4, and Y can be A, B, C, D or blank) Received Date: Dec. 27, 2019 Test Date: Feb. 11 to 13, 2020 Issued Date: Mar. 11, 2020 Applicant: MTRLC LLC Address: 225 Franklin St. 26th Floor Boston, MA 02110 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwa. Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan. FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF191227E09-2 Page No. 2 / 27 Report Format Version: 6.1.1 Reference No.: Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 Summary of Test Results ..................................................................................................................... 5 2.1 Measurement Uncertainty ................................................................................................................... 5 2.2 Modification Record ............................................................................................................................ 5 3 General Information .............................................................................................................................. 6 3.1 General Description of EUT ................................................................................................................ 6 3.1.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 8 3.2 Description of Support Units ............................................................................................................. 10 3.2.1 Configuration of System under Test ................................................................................................... 11 4 Test Types and Results ...................................................................................................................... 12 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 12 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 12 4.1.2 Test Instruments ................................................................................................................................ 13 4.1.3 Test Procedures ................................................................................................................................. 14 4.1.4 Deviation from Test Standard ............................................................................................................ 14 4.1.5 Test Setup .......................................................................................................................................... 15 4.1.6 EUT Operating Conditions ................................................................................................................. 16 4.1.7 Test Results ....................................................................................................................................... 17 4.2 Conducted Emission Measurement .................................................................................................. 20 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 20 4.2.2 Test Instruments ................................................................................................................................ 20 4.2.3 Test Procedures ................................................................................................................................. 21 4.2.4 Deviation from Test Standard ............................................................................................................ 21 4.2.5 Test Setup .......................................................................................................................................... 21 4.2.6 EUT Operating …
Text truncated - open the document above for the full version.
Reference No.: 191227E09 Page No. 1 / 4 Reference No.: PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Reference No.: 191227E09 Page No. 2 / 4 Reference No.: RADIATED EMISSION TEST (Below 1GHz) Reference No.: 191227E09 Page No. 3 / 4 Reference No.: RADIATED EMISSION TEST (Above 1GHz) Reference No.: 191227E09 Page No. 4 / 4 Reference No.:
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 897.00 mW |
