2AF62-MAAXBOARDRTMaaXBoard RT

Page 1 MaaXBoard RT Hardware User Guide v1.0 – Sept 21, 2021 GHz Real-Time NXP RT1176 SBC board Page 2 1 Document Control Document Version: v1.0 Document Date: 09/21/2021 Document Author: Peter Fenn Document Classification: Public Document Distribution: Public 2 Version History Version Date Comment 1.0 09/21/2021 Release version (for Rev.3 production PCB) Page 3 Contents 1 Document Control ................................................................................................. 2 2 Version History ..................................................................................................... 2 3 Hardware Checklist .............................................................................................. 7 4 Software Checklist ................................................................................................ 7 5 Introduction ........................................................................................................... 8 5.1 MaaXBoard RT Info ....................................................................................... 9 5.2 Items Included with MaaXBoard RT ............................................................... 9 5.3 Important Reference Documents ................................................................... 9 5.4 MCU-LINK Debugger/Programmer Probe (Required Option) ........................ 9 5.5 MCU-LINK-PRO Debugger/Programmer Probe (Optional) .......................... 10 5.6 MIPI DSI 7-inch Capacitive Touch LCD Display (Optional) .......................... 11 5.7 MIPI CSI 5 MP Camera (Optional) ............................................................... 11 5.8 Other SBCs and SOMs from Avnet Boards (Optional) ................................. 12 5.9 Hardware Setup for Application Development ............................................. 13 6 MaaXBoard RT Architecture & Features ............................................................ 14 6.1 Features ....................................................................................................... 14 6.2 Block Diagram – NXP RT1176 Processor .................................................... 15 6.3 Block Diagram – MaaXBoard RT (Rev.3 PCB) ............................................ 16 6.4 Location of Components on MaaXBoard RT ................................................ 17 6.5 Jumpers, LEDs, and Switches ..................................................................... 18 6.5.1 Boot Mode Configuration Jumper (J19) .......................................................................... 18 6.5.2 Button Switches .............................................................................................................. 18 6.5.3 Status LEDs .................................................................................................................... 18 6.6 Memory Resources ...................................................................................... 19 6.6.1 Memory Maps for Application Development ................................................................... 20 6.6.2 Internal ROM/RAM memory map ................................................................................... 20 6.6.3 HyperFlash Memory ........................................................................................................ 21 6.6.4 HyperFlash Programming using NXP MCUBootUtility Application................................. 23 6.6.5 HyperFlash Programming using MCUXpresso Secure Provisioning Tools .................... 25 6.6.6 On-chip TCM RAM and OCRAM .................................................................................... 26 6.6.7 SDRAM ........................................................................................................................... 26 6.7 Wireless Connectivity ................................................................................... 27 6.7.1 Wi-Fi SDIO Interface ....................................................................................................... 30 Page 4 6.7.2 BT/BLE UART Interface .................................................................................................. 30 6.7.3 BT PCM Audio Interface ................................................................................................. 30 6.7.4 Wi-Fi / BT antenna .......................................................................................................... 30 6.8 Peripheral Devices and Interfaces ............................................................... 31 6.8.1 USB 2.0 Host Interface ................................................................................................... 31 6.8.2 USB 2.0 Device Interface................................................................................................ 31 6.8.3 GbE Ethernet (with TSN time-sync.) ............................................................................... 31 6.8.4 10/100 Ethernet (with IEEE 1588 time-sync.) ................................................................. 31 6.8.5 CAN-FD........................................................................................................................... 31 6.8.6 MIPI-DSI Display and Touchscreen ................................................................................ 31 6.8.7 MIPI-CSI Camera ............................................................................................................ 32 6.8.8 Digital Microphones ........................................................................................................ 32 6.8.9 Audio Codec ................................................................................................................... 32 6.8.10 J9: Stereo Audio Jack ..................................................................................................... 32 6.8.11 J1: Pi-HAT compatible 40-pin header ............................................................................. 33 6.8.12 Pi HAT Expansion Bo…

Text truncated - open the document above for the full version.

C5266091_X24_Ed.1 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Avnet Inc Grantee code: 2AF62 FCC ID: 2AF62-MAAXBOARDRT Contact Name: Brandon Quintana Address: 2211 S 47th St Phoenix, AZ 85034 Telephone No: 480-643-8648 Fax No: / Email: [email protected] i. [Avnet Inc] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Avnet Inc] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Date: Nov. 02, 2022 Applicant’s Name: Avnet Inc Title: Director, Advanced Solutions Engineering Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Avnet Inc Address: 2211 S 47th St Phoenix, AZ 85034 Product Name: MaaXBoard RT Model Number: AES-MC-SBC-IMXRT1176-G FCC Identifier: 2AF62-MAAXBOARDRT We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Brandon Quintana Date: 2022.11.02 Title: Director, Advanced Solutions Engineering Signature of applicant:

C5266091_X10_Ed.1 1/1 Avnet Inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022.11.02 Subject: Request for Confidentiality FCC ID: 2AF62-MAAXBOARDRT To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.1 1/1 Sincerely, Signature: Name: Brandon Quintana Title: Director, Advanced Solutions Engineering

FCC ID: 2AF62-MAAXBOARDRT Page 1 of 5 IC: 21571-MAAXBOARDRT External Photos of EUT Antenna FCC ID: 2AF62-MAAXBOARDRT Page 2 of 5 IC: 21571-MAAXBOARDRT FCC ID: 2AF62-MAAXBOARDRT Page 3 of 5 IC: 21571-MAAXBOARDRT FCC ID: 2AF62-MAAXBOARDRT Page 4 of 5 IC: 21571-MAAXBOARDRT FCC ID: 2AF62-MAAXBOARDRT Page 5 of 5 IC: 21571-MAAXBOARDRT

FCC ID: 2AF62-MAAXBOARDRT Page 1 of 1 Report No.: CTL2205203012-WF FCC-ID Label Information 1. Label location: FCC ID: 2AF62-MAAXBOARDRT

FCC ID: 2AF62-MAAXBOARDRT Page 1 of 2 IC: 21571-MAAXBOARDRT Internal Photos of EUT FCC ID: 2AF62-MAAXBOARDRT Page 2 of 2 IC: 21571-MAAXBOARDRT

Report No.: CTL2205203012-WF FCC ID: 2AF62-MAAXBOARDRT FCC RF Exposure Evaluation 1. Product Information FCC ID 2AF62-MAAXBOARDRT Product Name MaaXBoard RT Test Model AES-MC-SBC-IMXRT1176-G Power Supply DC 5V power supply Input: 100-240V~, 50/60Hz, 2.5A Modulation Type Bluetooth: GFSK, π/4DQPSK, 8DPSK Bluetooth LE: GFSK 2.4G WIFI: 802.11b: DSSS 802.11g/802.11n(H20): OFDM 5G WIFI : IEEE 802.11a/ac/n: OFDM Antenna Type PIFA Antenna Antenna Gain Bluetooth: 3.20dBi 2.4G WIFI: 3.20dBi 5G WIFI : 4.25dBi Frequency Range 2402 – 2480MHz / 2412 – 2462MHz / 5180 – 5240MHz 5745 – 5825MHz/ 5260 – 5320MHz / 5500 – 5700MHz Exposure Category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Device 2. Evaluation Method and Limit Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. Report No.: CTL2205203012-WF FCC ID: 2AF62-MAAXBOARDRT 3. Limit 3.1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information AES-MC-SBC-IMXRT1176-G can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Note PIFA Antenna 2402 MHz – 2480 MHz 2412 MHz – 2462 MHz 5180MHz - 5240MHz 5260MHz-5320MHz 5500MHz-5700MHz 5745MHz -5825MHz Bluetooth: 3.20dBi 2.4G WIFI: 3.20dBi 5G WIFI : 4.25dBi Bluetooth & WLAN Antenna Report No.: CTL2205203012-WF FCC ID: 2AF62-MAAXBOARDRT 6.Conducted Power Results [BT] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 1.86 39 2441 2.14 78 2480 1.72 π/4DQPSK 0 2402 0.80 39 2441 1.05 78 2480 0.72 8DPSK 0 2402 1.12 39 2441 1.37 78 2480 1.04 [BLE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK(1M) 0 2402 1.72 19 2440 2.02 39 2480 1.54 GFSK(2M) 0 2402 1.71 19 2440 2.03 39 2480 1.57 [2.4GWIFI Max Conducted Power] Mode Channel Frequency(MHz) Max Conducted Power(dBm) IEEE 802.11b 1 2412 13.76 6 2437 14.88 11 2462 14.85 IEEE 802.11g 1 2412 13.58 6 2437 14.53 11 2462 14.48 IEEE 802.11n HT20 1 2412 13.64 6 2437 14.56 11 2462 14.61 Report No.: CTL2205203012-WF FCC ID: 2AF62-MAAXBOARDRT [5.2GWIFI Max Conducted Power] Mode Channel Frequency (MHz) Max Conducted Power(dBm) 11A 36 5180 10.27 40 5200 10.09 48 5240 10.10 11N20 SISO 36 5180 10.54 40 5200 10.35 48 5240 10.33 11N40 SISO 38 5190 10.62 46 5230 10.37 11AC20 SISO 36 5180 10.94 40 5200 10.28 48 5240 10.21 11AC40 SISO 38 5190 10.57 46 5230 10.47 11AC80 SISO 42 5210 10.73 [5.8WIFI Max Conducted Power] Mode Channel Frequency (MHz) Max Conducted Power(dBm) 11A 149 5745 11.28 157 5785 11.18 165 5825 10.69 11N20 SISO 149 5745 9.82 157 5785 9.77 165 5825 9.18 11N40 SISO 151 5755 9.68 159 5795 9.42 11AC20 SISO 149 5745 9.70 157 5785 9.67 165 5825 9.11 11AC40 SISO 151 5755 9.68 159 5795 11.31 11AC80 SISO 155 5775 11.13 Report No.: CTL2205203012-WF FCC ID: 2AF62-MAAXBOARDRT [5.3GWIFI Max Conducted Power] Mode Channel Frequency (MHz) Max Conducted Power(dBm) 11A 52 5260 10.09 60 5300 9.72…

Text truncated - open the document above for the full version.

FCC ID: 2AF62-MAAXBOARDRT Page 1 of 52 IC: 21571-MAAXBOARDRT Test Data for Bluetooth Product Name: MaaXBoard RT Test Model: AES-MC-SBC-IMXRT1176-G 1. Bandwidth 1.1 OBW 1.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type ANT 99% Occupied Bandwidth (MHz) Verdict Result GFSK SISO 2402 DH5 1 0.869 Pass 2441 DH5 1 0.873 Pass 2480 DH5 1 0.869 Pass Pi/4DQPSK SISO 2402 2DH5 1 1.173 Pass 2441 2DH5 1 1.174 Pass 2480 2DH5 1 1.173 Pass 8DPSK SISO 2402 3DH5 1 1.182 Pass 2441 3DH5 1 1.180 Pass 2480 3DH5 1 1.182 Pass FCC ID: 2AF62-MAAXBOARDRT Page 2 of 52 IC: 21571-MAAXBOARDRT 1.1.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 3 of 52 IC: 21571-MAAXBOARDRT GFSK_DH5_HCH_2480MHz_Ant1_NTNV Pi/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 4 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV Pi/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 5 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 6 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 7 of 52 IC: 21571-MAAXBOARDRT 1.2 20dB BW 1.2.1 Test Result Mode TX Type Frequency (MHz) Packet Type ANT 20dB Bandwidth (MHz) Verdict Result GFSK SISO 2402 DH5 1 0.962 Pass 2441 DH5 1 0.963 Pass 2480 DH5 1 0.962 Pass Pi/4DQPSK SISO 2402 2DH5 1 1.341 Pass 2441 2DH5 1 1.342 Pass 2480 2DH5 1 1.342 Pass 8DPSK SISO 2402 3DH5 1 1.314 Pass 2441 3DH5 1 1.315 Pass 2480 3DH5 1 1.315 Pass FCC ID: 2AF62-MAAXBOARDRT Page 8 of 52 IC: 21571-MAAXBOARDRT 1.2.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 9 of 52 IC: 21571-MAAXBOARDRT GFSK_DH5_HCH_2480MHz_Ant1_NTNV Pi/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 10 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV Pi/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 11 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 12 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 13 of 52 IC: 21571-MAAXBOARDRT 2. Maximum Conducted Output Power 2.1 Power 2.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit EIRP Limit GFSK SISO 2402 DH5 1.86 <=30 5.06 <=36 Pass 2441 DH5 2.14 <=30 5.34 <=36 Pass 2480 DH5 1.72 <=30 4.92 <=36 Pass Pi/4DQPSK SISO 2402 2DH5 0.80 <=20.97 4.00 <=36 Pass 2441 2DH5 1.05 <=20.97 4.25 <=36 Pass 2480 2DH5 0.72 <=20.97 3.92 <=36 Pass 8DPSK SISO 2402 3DH5 1.12 <=20.97 4.32 <=36 Pass 2441 3DH5 1.37 <=20.97 4.57 <=36 Pass 2480 3DH5 1.04 <=20.97 4.24 <=36 Pass Note1: Antenna Gain: Ant1: 3.20dBi; FCC ID: 2AF62-MAAXBOARDRT Page 14 of 52 IC: 21571-MAAXBOARDRT 2.1.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 15 of 52 IC: 21571-MAAXBOARDRT GFSK_DH5_HCH_2480MHz_Ant1_NTNV Pi/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 16 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV Pi/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 17 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 18 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 19 of 52 IC: 21571-MAAXBOARDRT 3. Carrier Frequency Separation 3.1 Ant1 3.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) Packet Type Channel Separation (MHz) 20dB Bandwidth (MHz) Limit (MHz) Verdict GFSK SISO HOPP DH5 1.000 0.963 >=0.963 Pass Pi/4DQPSK SISO HOPP 2DH5 1.015 1.342 >=0.895 Pass 8DPSK SISO HOPP 3DH5 0.998 1.315 >=0.877 Pass FCC ID: 2AF62-MAAXBOARDRT Page 20 of 52 IC: 21571-MAAXBOARDRT 3.1.2 Test Graph GFSK_DH5_HOPP_Ant1_NTNV Pi/4DQPSK_2DH5_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 21 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 22 of 52 IC: 21571-MAAXBOARDRT 4. Number of Hopping Frequencies 4.1 HoppNum 4.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type Num of Hopping Frequencies Verdict ANT1 Limit GFSK SISO HOPP DH5 79 >=15 Pass Pi/4DQPSK SISO HOPP 2DH5 79 >=15 Pass 8DPSK SISO HOPP 3DH5 79 >=15 Pass FCC ID: 2AF62-MAAXBOARDRT Page 23 of 52 IC: 21571-MAAXBOARDRT 4.1.2 Test Graph GFSK_DH5_HOPP_Ant1_NTNV Pi/4DQPSK_2DH5_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 24 of 52 IC: 21571-MAAXBOARDRT 8DPSK_3DH5_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 25 of 52 IC: 21571-MAAXBOARDRT 5. Time of Occupancy (Dwell Time) 5.1 Ant1 5.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) Packet Type Duration of Single Pulse (ms) Observation Period (s) Num of Pulse in Observation Period Dwell Time (ms) Limit (ms) Verdict GFSK SISO HOPP DH1 0.396 31.600 320 126.720 <=400 Pass DH3 1.650 31.600 165 272.250 <=400 Pass DH5 2.900 31.600 108 313.200 <=400 Pass Pi/4DQPSK SISO HOPP 2DH1 0.398 31.600 320 127.360 <=400 Pass 2DH3 1.648 31.600 164 270.272 <=400 Pass 2DH5 2.898 31.600 108 312.984 <=400 Pass 8DPSK SISO HOPP 3DH1 0.392 31.600 320 125.440 <=400 Pass 3DH3 1.646 31.600 156 256.776 <=400 Pass 3DH5 2.898 31.600 103 298.494 <=400 Pass FCC ID: 2AF62-MAAXBOARDRT Page 26 of 52 IC: 21571-MAAXBOARDRT 5.1.2 Test Graph GFSK_DH1_HOPP_Ant1_NTNV GFSK_DH1_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 27 of 52 IC: 21571-MAAXBOARDRT GFSK_DH3_HOPP_Ant1_NTNV GFSK_DH3_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 28 of 52 IC: 21571-MAAXBOARDRT GFSK_DH5_HOPP_Ant1_NTNV GFSK_DH5_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 29 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH1_HOPP_Ant1_NTNV Pi/4DQPSK_2DH1_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 30 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH3_HOPP_Ant1_NTNV Pi/4DQPSK_2DH3_HOPP_Ant1_NTNV FCC ID: 2AF62-MAAXBOARDRT Page 31 of 52 IC: 21571-MAAXBOARDRT Pi/4DQPSK_2DH5_HOPP_Ant1_NTNV Pi/4DQPSK_2DH5_HOPP_Ant1_NTN…

Text truncated - open the document above for the full version.

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No.: CTL2205203012-WF01 Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Gray Gao (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : MaaXBoard RT Model/Type reference ................ : AES-MC-SBC-IMXRT1176-G List Model(s) ............................... : N/A Trade Mark .................................. : AVNET FCC ID ......................................... : 2AF62-MAAXBOARDRT Applicant’s name ....................... : Avnet Inc Address of applicant ................. : 2211 S 47th St Phoenix, AZ 85034 Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : July.04, 2022 Date of Test Date ........................ : July.04, 2022-Sep.19, 2022 Date of Issue .............................. : Sep.20, 2022 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 38 Report No.: CTL2205203012-WF01 TEST REPORT Test Report No. : CTL2205203012-WF01 Sep.20, 2022 Date of issue Equipment under Test : MaaXBoard RT Sample No : CTL220520301-1-S001 Model /Type : AES-MC-SBC-IMXRT1176-G Listed Models : N/A Applicant : Avnet Inc Address : 2211 S 47th St Phoenix, AZ 85034 Manufacturer : Avnet Inc Address : 2211 S 47th St Phoenix, AZ 85034 Test result Pass * *In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 38 Report No.: CTL2205203012-WF01 ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2022-09-20 CTL2205203012-WF01 Tracy Qi V1.0 Page 4 of 38 Report No.: CTL2205203012-WF01 Table of Contents Page 1. SUMMARY ............................................................................................................................................................... 5 1.1. TEST STANDARDS ..................................................................................................................................................... 5 1.2. TEST DESCRIPTION ........................................................................................................................................................ 5 1.3. TEST FACILITY .............................................................................................................................................................. 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. GENERAL INFORMATION .......................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 9 2.4. EQUIPMENTS USED DURING THE TEST ............................................................................................................................ 10 2.5. RELATED SUBMITTAL(S) / GRANT (S) .............................................................................................................................. 10 2.6. MODIFICATIONS ......................................................................................................................................................... 10 3. TEST CONDITIONS AND RESULTS ............................................................................................................................ 11 3.1. CONDUCTED EMISSIONS TEST ....................................................................................................................................... 11 3.2. RADIATED EMISSIONS AND BAND EDGE .......................................................................................................................... 14 3.3. MAXIMUM PEAK OUTPUT POWER ................................................................................................................................ 22 3.4. 20DB BANDWIDTH ..................................................................................................................................................... 23 3.5. FREQUENCY SEPARATION ....................................................................…

Text truncated - open the document above for the full version.

APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E PCB Cabled Balanced Antenna Application Specification SHEET No. F EC No: 641299 1 of 22 DATE: 2020/05/27 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461870100 Liu Hai 2020/05/27 Cheng Kang 2020/05/27 Andy Zhang 2020/05/27 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC TITLE WIFI 6E PCB CABLED BALANCED ANTENNA TABLE OF CONTENTS 1.0 SCOPE 2.0 PRODUCT DESCRIPTION 3.0 APPLICABLE DOCUMENTS 4.0 ANTENNA PERFORMANCE 5.0 ASSEMBLY GUIDELINE 6.0 RF PERFORMANCE AS A FUNCTION OF IMPLEMENTATION 7.0 THE ANTENNA PERFORMANCE VARIATION WITH CABLE LENGTH 8.0 CHANGE HISTORY Mole x CVS Dabendorf GmbH Mae rkische Strasse 72, Zossen, 15806, Germany APPLICATION SPECIFICATION REVISION: ECR/ECN INFORMATION: TITLE: WIFI 6E PCB Cabled Balanced Antenna Application Specification SHEET No. F EC No: 641299 2 of 22 DATE: 2020/05/27 DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY: AS-1461870100 Liu Hai 2020/05/27 Cheng Kang 2020/05/27 Andy Zhang 2020/05/27 TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC WIFI 6E PCB CABLED BALANCED ANTENNA 1.0 SCOPE This specification…
