2AFCB-LY138Wifi battery camera

Thanks for purchasing this Wire-Free battery camera.Please read this instruction manual carefully before using this product. Instruction Manual WOHOME Smart Camera PACKING LIST 1.Camera x1 2.Instruction Manual x1 3.USB cable x1 USB 4.Iron Ball Wall Mountx1 5.Screws x2 6.Battery x2 ①②③ ④⑤⑥ Manual 3 CAMERA STRUCTURE ⑥ ⑦ ⑧ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① ② ④ ⑤ ③ ① ② ④ ⑤ Lens Mic Light sensor LED Motion detection sensor Charge LED USB interface Speaker Resrt button Mirco-SD card Power button 18650 Battery Flip Switch 18650 ① ② ③ ④ ⑤ Charge LED: Charging in Red;Full in Green. Power button：Long press to turn on/off the camera. Note: The camera will turn on automatically when the battery is installed. 4 Inserting SD Card THE CAMERA OPERATING Please open the camera cover,and firstly insert the Mirco-SD card. Slide the SD card cover down ,then open the cover and inset the SD card. 18650 LOCKOPEN 18650 SD card 5 Loading batteries Resetting camera Please install 18650 battery. Note: Please notice the polarity of the battery. Press the Reset button long until you hear the "system reset" prompt from the camera speaker.After resetting camera, you’re ready to connect to the Tuya App. 18650 18650 18650 18650 18650 18650 6 + - + - + - + - NSTALL TUYA SMART APP The App is available for iOS,Android. Search “tuya smart” in App store or google play store,or scan below QR Code to download and install the App. 7 CONNECT THE CAMERA WITH APP 1.Account Registration and Login Please open Tuya App,and enter the App main interface. New users need to register by Email or Mobile number,click “Register”. Follow the steps to complete the registration of the account,and login. 8 United States +1 Please log in directly if you already have an account. To input your account and password ,click“Log in”. 2.Add Device Click the Add Device and enter next interface. Find the Security camera in the list and click 9 Pairing the camera. The camera lens is aimed at the QR code on the phone screen with a distance of 15cm. It will sound”bugu” after the camera recognize the QR code. Confirm the red indicator light rapidly blinks or a prompt tone is heard. Connect with your home Wi-Fi. 10 Please click “Hear a prompt” if you heard it ,then will start connecting. The camera added successfully ,and enter to the main interface. 11 FUNCTION OVERVIEW Settings Click to enter detailed settings of the camera. You can check more about it in the section of Settings on page 13. Signal The camera may be disconnected if the signal is lower than 50%. Please move your camera to be closer to your router for better signal. Battery capacity Please charge the camera timely if the power is less than 2 bars. Image quality Tap to switch the image quality between HD and SD. SD is recommended for a smoother streaming. Screenshot Tap to capture the current live picture and save it to your mobile device. Speak Hold and talk to people on the camera side. Image quality Camera settings Wi-Fi Signal Full screen option Battery capacity Sound on/off 12 SETTINGS Click enter to the Settings page. There are only a few settings to make,so the process is quick and easy. To start setting up your camera. Device name Allow you to set the name of the device . Share device Allow you to share the device with your family . Add your family’s account in App. Note: Firstly ensure family’s account already registered in Tuya App. Playback Tap to play the videos recorded in the MicroSD card. Record Tap to start recording the current live streaming. Tap again to end and save it to the internal storage of your mobile device. 13 Off Device Name Share Device Device lnformation Use Echo Power Management Settings Basic Function Settings PIR Purchase VAS FAQ & Feedback Firmware lnformation Wire-Free Smart Camera Power management settings This function is it will push a notification if the battery is low .You can set the low battery alarm threshold ( 0% to 30%). Note: Firstly please enable Tuya App notification in mobile setting . Basic function settings Flip screen setting. The function is to flip the screen angle. Talk mode setting .Select one-way communication or two-way talk you want. PIR OFF means you shut down the function. Also ,you can set the PIR sensitivity for Low,Medium,High. The camera will take pictures and videos automatically when it is triggered by the PIR sensor’s detection of activity in the area it covers. Meanwhile, it will push a notification to your phone when PIR is triggered. 1.Make sure the PIR sensor of the camera is not facing bright lights(including sunshine ,bright lamps, etc), mirror, windows or glass. 2.Do not mount the camera in a place with moving vehicles or streaming people. 3.Stay away from air vents of air conditioner or heating sources like stove, lights and refrigerator, etc. To avoid wireless interference. IMPORTANT Reducing the False Alarms 14 5.A mounting height of 2M is recommend to reduce false alarms caused by the movements of small animals on the ground. If it’s required, please mount the camera at a height around 1.5M. 6.When mounting the camera an appropriate angle between the PIR sensor and the monitoring area is recommended. 7.The effective distance between the PIR sensor of the camera and the moving objects id 2M to 8M. Please fix the iron ball bracket to the wall with screws ,and then magnetize the camera to the iron ball. It is very convenient and easy to adjust the angle. 4.Please do not scratch or squeeze the PIR sensor to avoid lowering its detection sensitivity. CAMERA INSTALLATION 15 Q1.The camera can’t connect to Wi-Fi. Make sure you select the right Wi-Fi network and enter the right password. Make sure your Wi-Fi is 2.4GHz. Make sure the camera and your mobile device are close to the router. Q2. How can I reset the camera? Please press the Reset button .There is beeping sound after a successful reset and the RED LED will flash slowly. Q3. Why can’t I receive the push notifications of the alarms? Make sure you have allowed Tuya App to push notificat…

Text truncated - open the document above for the full version.

2020-07-01 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFCB-LY138 Product Name: Wifi battery camera Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Long-term confidential Block diagram Long-term confidential Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Wangxing Yu Position Manager Company Name Shenzhen Longzhiyuan Technology Co., Ltd. Address 2F & 5F, Bldg #2, Zhuangbian 2nd Industrial Park, Hezhou Community, Hangcheng, Bao’an, Shenzhen City, China Tel 0755-27948826-830 Fax 0755-27948676 Email [email protected] Shenzhen Longzhiyuan Technology Co., Ltd.

Differences Description We Shenzhen Longzhiyuan Technology Co., Ltd state: Product name: Wifi battery camera Model: LY-138, LY-138B All model’s the function, software and electric circuit are the same, except the apperance and model numbers difference. 2020-06-30 Signature: Name Wangxing Yu Position Manager Company Name Shenzhen Longzhiyuan Technology Co., Ltd. Address 2F & 5F, Bldg #2, Zhuangbian 2nd Industrial Park, Hezhou Community, Hangcheng, Bao’an, Shenzhen City, China Tel 0755-27948826-830 Fax 0755-27948676 Email [email protected] FCC ID: 2AFCB-LY138

FCC ID: 2AFCB-LY138

Label Size: 1.5x1.0cm FCC ID: 2AFCB-LY138 Shenzhen Longzhiyuan Technology Co., Ltd. Model name: Wifi battery camera Model No.: LY-138B Location

FCC ID: 2AFCB-LY138 ANT

FCC ID: 2AFCB-LY138 Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) 2. Test Procedure Equation from page 18 of OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna FCC ID: 2AFCB-LY138 3. Result For Worst case Mode: 2.4G WIFI 2412-2462MHz Maximum peak output power at antenna input terminal: 16.422 (dBm) Maximum peak output power at antenna input terminal: 43.87 (mW) Antenna gain(typical): 2 (dBi) Maximum antenna gain: 1.58 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 2442 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.01384 (mW /cm^2) Power density at prediction frequency: 0.00138 (W/m^2) Power density at a given distance is 0.01384<1 mW/cm^2 Some radios transmit simultaneously, and the max evaluated ratio value are as below： For Worst case Mode 2.4G WiFi Ratio: MPE 2.4G WiFi /Limit above 1500 = 0.01384 (mW/cm^2) <1 (mW/cm^2)

FCC&IC TEST REPORT FCC ID: 2AFCB-LY138 On Behalf of Shenzhen Longzhiyuan Technology Co., Ltd. Wifi battery camera Model No.: LY-138, LY-138B Prepared for : Shenzhen Longzhiyuan Technology Co., Ltd. Address : 2F & 5F, Bldg #2, Zhuangbian 2nd Industrial Park, Hezhou Community, Hangcheng, Bao’an, Shenzhen City, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Report Number : A2006097-C02-R06 Date of Receipt : June 12, 2020 Date of Test : June 14-22, 2020 Date of Report : June 23, 2020 Version Number : V0 Page 2 of 58 Report No.: A2006097-C02-R06 TABLE OF CONTENTS Description Page 1. Summary of Standards And Results ------------------------------------------------------------------- 6 1.1. Description of Standards and Results ------------------------------------------------------------ 6 2. General Information -------------------------------------------------------------------------------------- 7 2.1. Description of Device (EUT) ---------------------------------------------------------------------- 7 2.2. Accessories of Device (EUT) --------------------------------------------------------------------- 8 2.3. Tested Supporting System Details ---------------------------------------------------------------- 8 2.4. Block Diagram of connection between EUT and simulators --------------------------------- 8 2.5. Test Mode Description ----------------------------------------------------------------------------- 8 2.6. Test Conditions -------------------------------------------------------------------------------------- 9 2.7. Test Facility ------------------------------------------------------------------------------------------ 9 2.8. Measurement Uncertainty ----------------------------------------------------------------------- 10 2.9. Test Equipment List ------------------------------------------------------------------------------ 11 3. Spurious Emission --------------------------------------------------------------------------------------- 12 3.1. Test Limits ----------------------------------------------------------------------------------------- 12 3.2. Test Procedure ------------------------------------------------------------------------------------- 15 3.3. Test Setup ------------------------------------------------------------------------------------------ 15 3.4. Test Results ---------------------------------------------------------------------------------------- 16 4. Power line Conducted Emission ---------------------------------------------------------------------- 22 4.1. Test Limits ----------------------------------------------------------------------------------------- 22 4.2. Test Procedure ------------------------------------------------------------------------------------- 22 4.3. Test Setup ------------------------------------------------------------------------------------------ 22 4.4. Test Results ---------------------------------------------------------------------------------------- 22 5. Conducted Maximum Output Power --------------------------------------------------------------- 24 5.1. Test limits ------------------------------------------------------------------------------------------ 24 5.2. Test Procedure ------------------------------------------------------------------------------------- 24 5.3. Test Setup ------------------------------------------------------------------------------------------ 24 5.4. Test Results ---------------------------------------------------------------------------------------- 24 6. Peak Power Spectral Density -------------------------------------------------------------------------- 26 6.1. Test limits ------------------------------------------------------------------------------------------ 26 6.2. Test Procedure ------------------------------------------------------------------------------------- 26 6.3. Test Setup ------------------------------------------------------------------------------------------ 26 6.4. Test Results ---------------------------------------------------------------------------------------- 27 7. Bandwidth ------------------------------------------------------------------------------------------------- 34 7.1. Test limits ------------------------------------------------------------------------------------------ 34 7.2. Test Procedure ------------------------------------------------------------------------------------- 34 7.3. Test Setup ------------------------------------------------------------------------------------------ 34 7.4. Test Results ---------------------------------------------------------------------------------------- 34 8. Band Edge Check ---------------------------------------------------------------------------------------- 47 8.1. Test limits ------------------------------------------------------------------------------------------ 47 8.2. Test Procedure ------------------------------------------------------------------------------------- 47 8.3. Test Setup ------------------------------------------------------------------------------------------ 47 8.4. Test Results ---------------------------------------------------------------------------------------- 47 9. Frequency stability -------------------------------------------------------------------------------------- 54 9.1. Test limit ------------------------------------------------------------------------------------------- 54 9.2. Test Procedure ------------------------------------------------------------------------------------- 54 9.3. Test Setup ------------------------------------------------------------------------------------------ 54 9.4. Test Results ---------------------------------------------------------------------------------------- 54 Page 3 of 58 Report No.: A2006097-C02-R06 10. Antenna Requirement ---------------------------------------------------------------------------------- 55 10.1. Standard Requiremen…
