Cooper User Guide Thank you for choosing this Spreadtrum Platformphone. This device will offer you unprecedented surprise for it can support GSM cards and multiple cards standby. Meanwhile, this phone is equipped with a 3 megapixel HD digital camera, a MP3 Mobile Musicand a MP4 video player. Enjoy yourself ! Safety Please go through, and comply with, the following considerations before using this phone.   Please take earphone if making or Answer incoming call while driving or after you car is parked.   The phone may interfere with aircraft telecommunication. So please turn if off or switch to flight mode during the flight.   Anyphone may be susceptible to interference, which could affect performance.   Please turn off your phone near the medical equipment or in the medical facility where anyphone must be out of service.   Please use the original battery and accessories in order to have optimal performance and prevent phone damage. Please don’t use unmatched products.   Please turn off yourphone in the gas station or near fuel or chemicals to prevent explosion.   To avoid interference with blasting work, please turn off thephone on the site or where two-way radio must be switched off. Please observe the local rules.   Burning or disposing ofphone battery as usual is prohibited, or it may cause life risk or environmental pollution. Please dispose of and recycle it in compliance with the local environmental regulations.   If yourphone needs to be connected with other device, please read the User Guide of the latter.   Some small components (e.g. memory card, etc.) shall be out of children’s reach; otherwise it may be swallowed or cause other hazards.   Please copy or keep a written copy of the vital information stored in your phone.  SOS  Ensure the phone is turned on and within the service area. Enter the emergency number, press the talking key to tell your location. Please don’t end the call without permission. i Contents Introduction ........................................................................................................................................................ 9 Insert SIM card and battery ....................................................................................................................................9 Insert memory card .................................................................................................................................................9 Battery charging .....................................................................................................................................................9 Power on and off ..................................................................................................................................................10 Idle .................................................................................................................................................................... 11 Switch to Idle Page ............................................................................................................................................... 11 Wallpaper Settings ................................................................................................................................................ 11 Task Manager ....................................................................................................................................................... 11 Settings ................................................................................................................................................................. 11 Open Option Menu ............................................................................................................................................... 11 Main menu ....................................................................................................................................................... 12 Use Function Menu of Main Menu ......................................................................................................................12 Call .................................................................................................................................................................... 13 Dialpad .................................................................................................................................................................13 Making an overseas call. ......................................................................................................................................13 Dialing via Contacts .............................................................................................................................................13 Calling an extension number ................................................................................................................................13 Making an emergency phone ................................................................................................................................13 Answer or reject incoming calls ...........................................................................................................................13 Menu during a call ................................................................................................................................................13 Adjust volume ......................................................................................................................................................14 End a call ..............................................................................................................................................................14 Call logs ............................................................................................................................................................. 15 Set as a rejected call ................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 MOVEON TECHNOLOGY LIMITED 2015.10.14 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, MOVEON TECHNOLOGY LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: mobile phone model name: Cooper FCC ID: 2AFD9COOPER Sincerely, Client’s signature : Apple Chen Client’s name / title: Manager Applicant company: MOVEON TECHNOLOGY LIMITED address: World Trade Plaza-A block#3201-3202 Fuhong Road, Futian Shenzhen, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 MOVEON TECHNOLOGY LIMITED 2015.10.14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFD9COOPER We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Apple Chen Client’s name & title : Manager Contact information / address: World Trade Plaza-A block#3201-3202 Fuhong Road, Futian Shenzhen, China

Project No: STS1509130 Cooper APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1509130 Photo 3 Photo 4 Project No: STS1509130 Photo 5 Photo 6 Project No: STS1509130 Photo 7 Photo 8 Project No: STS1509130 Photo 9

Label mobile phone Model name: Cooper FCC ID: 2AFD9COOPER label

Project No: STS1509130 Cooper APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Project No: STS1509130 Photo 3 Photo 4 GSM ANTENNA Project No: STS1509130 Photo 5 Photo 6 BT ANTENNA Project No: STS1509130 Photo 7 Photo 8 Project No: STS1509130 Photo 9

FCC ID : 2AFD9COOPER RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID : 2AFD9COOPER Maximum measured transmitter power. BT The Worst Case frequency Maximum Peak Conducted Output Power Tune up tolerance Max Antenna Gain GHz dBm dBm dBi 2.402 4.400 4±1 1 2.441 3.924 4±1 1 2.480 4.189 4±1 1 Remark: The best case gain of the antenna is 1 dBi. 1 dBi logarithmic terms convert to numeric result is nearly 1.26 (2.402GHz) -5 dbm= 3.1623mw (2.441GHz) -5 dbm= 3.1623mw (2.480GHz) -5 dbm= 3.1623mw BT: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.1623/5*√2.402=0.9802≤3.0 [(mid. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.1623/5*√2.441=0.9881≤3.0 [(min. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.1623/5*√2.480=0.9960≤3.0 Threshold at which no SAR required is 0.9960 ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1509130F02 Issued for MOVEON TECHNOLOGY LIMITED World Trade Plaza-A block#3201-3202 Fuhong Road, Futian Shenzhen, China Product Name: mobile phone Brand Name: MYM Model No.: Cooper Series Model: N/A FCC ID: 2AFD9COOPER Test Standard: FCC Part 15.247 S T L A B S Page 2 of 73 Report No.: STS1509130F02 TEST RESULT CERTIFICATION Applicant’s Name............ MOVEON TECHNOLOGY LIMITED Address .................................. : World Trade Plaza-A block#3201-3202 Fuhong Road, Futian Shenzhen, China Manufacture's Name ............ : MOVEON TECHNOLOGY LIMITED Address .................................. : World Trade Plaza-A block#3201-3202 Fuhong Road, Futian Shenzhen, China Product description Product name ......................... : mobile phone Band name ............................. : MYM Model and/or type reference ................................................ : Cooper Ratings..................................... DC 5V/500mA Standards .............................. : FCC Part 15.247 Test procedure ............................. : ANSI C63.10-2013 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test............................................... : Date (s) of performance of tests .............. : 29 Sep. 2015 ~10 Oct. 2015 Date of Issue ............................................. : 12 Oct. 2015 Test Result ................................................. : Pass Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 73 Report No.: STS1509130F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 TEST SETUP 15 3.1.4 EUT OPERATING CONDITIONS 15 3.1.5 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 18 3.2.1 RADIATED EMISSION LIMITS 18 3.2.2 TEST PROCEDURE 19 3.2.3 DEVIATION FROM TEST STANDARD 19 3.2.4 TEST SETUP 20 3.2.5 EUT OPERATING CONDITIONS 21 3.2.6 TEST RESULTS 22 4. CONDUCTED SPURIOUS EMISSIONS 28 4.1 REQUIREMENT 28 4.2 TEST PROCEDURE 28 4.3 TEST SETUP 28 4.4 EUT OPERATION CONDITIONS 28 4.5 TEST RESULTS 29 5. NUMBER OF HOPPING CHANNEL 41 5.1 APPLIED PROCEDURES / LIMIT 41 5.2 TEST PROCEDURE 41 5.3 TEST SETUP 41 5.4 EUT OPERATION CONDITIONS 41 Page 4 of 73 Report No.: STS1509130F02 Table of Contents Page 5.5 TEST RESULTS 42 6. AVERAGE TIME OF OCCUPANCY 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.2 TEST PROCEDURE 43 6.3 TEST SETUP 43 6.4 EUT OPERATION CONDITIONS 43 6.5 TEST RESULTS 44 7. HOPPING CHANNEL SEPARATION MEASUREMEN 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.2 TEST PROCEDURE 50 7.3 TEST SETUP 50 7.4 EUT OPERATION CONDITIONS 50 7.5 TEST RESULTS 51 8. BANDWIDTH TEST 57 8.1 APPLIED PROCEDURES / LIMIT 57 8.2 TEST PROCEDURE 57 8.3 TEST SETUP 57 8.4 EUT OPERATION CONDITIONS 57 8.5 TEST RESULTS 58 9. PEAK OUTPUT POWER TEST 64 9.1 APPLIED PROCEDURES / LIMIT 64 9.2 TEST PROCEDURE 64 9.3 TEST SETUP 64 9.4 EUT OPERATION CONDITIONS 64 9.5 TEST RESULTS 65 10. ANTENNA REQUIREMENT 71 10.1 STANDARD REQUIREMENT 71 10.2 EUT ANTENNA 71 Page 5 of 73 Report No.: STS1509130F02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 12 Oct. 2015 STS1509130F02 ALL Initial Issue Page 6 of 73 Report No.: STS1509130F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(b)(1) Peak Output Power PASS -- 15.247(c) Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious Emission PASS -- 15.247(a)(iii) Number of Hopping Frequency PASS -- 15.247(a)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 7 of 73 Report No.: STS1509130F02 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% Page 8 of 73 Report No.: STS…
