ReportNo.:JCF260617082-002 LOP-FTR0111.0 1 / 7 RFEXPOSUREREPORT Applicant:GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic &TechnologyDevelopmentDistrict,Guangzhou,China Manufacturer:GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic &TechnologyDevelopmentDistrict,Guangzhou,China ProductDescription:WirelessPTZCamera BrandName:MAXHUB TestedModel/HVIN:EP50 FCCID:2AFG6-EP50 ReportNo.:JCF260617082-002 ReceivedDate:Jun.17,2026 TestedDate:Jun.17,2026-Aug.07,2026 IssuedDate:Aug.07,2026 TestStandards:KDB447498D01GeneralRFExposureGuidancev06 TestResult:Pass PreparedBy: KennysZhang/EngineerDate:Aug.07,2026 ReviewedBy: RogerLi/EngineerDate:Aug.07,2026 ApprovedBy: TalentZhang/EngineerDate:Aug.07,2026 Note:Thetestresultsinthisreportapplyexclusivelytothetestedmodel/sample.Withoutwrittenapprovalof GuangzhouJingceTestingTechnologyCo.,Ltd.thetestreportshallnotbereproducedexceptinfull. ReportNo.:JCF260617082-002 LOP-FTR0111.0 2 / 7 ReportReviseRecord ReportVersionReviseTimeIssuedDateValidVersionNotes --/Aug.07,2026OriginalReport/ ReportNo.:JCF260617082-002 LOP-FTR0111.0 3 / 7 TableofContents 1.TestReportDeclare.............................................................................................................................4 2.EquipmentUnderTest.........................................................................................................................5 2.1.DescriptionofEUT...........................................................................................................................5 2.2.DescriptionofAvailableAntennas...................................................................................................5 3.TestLaboratory....................................................................................................................................5 4.RFExposureMeasurement................................................................................................................5 4.1.Requirement.....................................................................................................................................5 4.2.LimitsforMaximumPermissibleExposure(MPE)...........................................................................6 4.3.MPECalculationFormula.................................................................................................................6 4.4.Classification....................................................................................................................................7 5.RFExposureCalculation....................................................................................................................7 ReportNo.:JCF260617082-002 LOP-FTR0111.0 4 / 7 1.TestReportDeclare Applicant: GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic&Technology DevelopmentDistrict,Guangzhou,China Manufacturer: GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic&Technology DevelopmentDistrict,Guangzhou,China ProductName WirelessPTZCamera BrandName: MAXHUB ModelName: EP50,EP50***(*=0-9,orA-Zora-zor “ - ” orblank,formarketingpurpose useonly,notechnicaldifference) DifferenceDescription: Thedifferenceinmodelnamesisonlyforsalespurposes,whiletheEUT remainsunchanged. WeDeclare: TheequipmentdescribedaboveistestedbyGuangzhouJingceTestingTechnologyCo.,Ltd.andin theconfigurationtestedtheequipmentcompliedwiththestandardsspecifiedabove.Thetestresults arecontainedinthistestreportandGuangzhouJingceTestingTechnologyCo.,Ltd.isassumedoffull responsibilityfortheaccuracyandcompletenessofthesetestsexceptasprovidedinformationby clients. ReportNo.:JCF260617082-002 LOP-FTR0111.0 5 / 7 2.EquipmentUnderTest 2.1.DescriptionofEUT EUT*Name:WirelessPTZCamera ModelNumber:EP50 EUTFunctionDescription:Pleaserefertousermanualofthisdevice PowerSupply:12Vdc,3.0A SampleNo.260617082-01-01 HardwareVersion:N/A SoftwareVersion:N/A RadioSpecification:IEEE802.11a/n OperationFrequency: IEEE802.11a:5150MHz—5250MHz,5745MHz—5825MHz IEEE802.11nHT20:5150MHz—5250MHz,5745MHz—5825MHz IEEE802.11nHT40:5150MHz—5250MHz,5745MHz—5825MHz Modulation: IEEE802.11a:OFDM(64QAM,16QAM,QPSK,BPSK) IEEE802.11nHT20,HT40:OFDM(64QAM,16QAM,QPSK,BPSK) AntennaType: ExternalAntenna,MAX.Gain:5.63dBi ExternalAntenna,MAX.DirectionalGain:8.64dBi ProductType: ☐ Portabledevice☑Mobiledevice ☐ Fixeddevice Note1:EUTistheab.ofequipmentundertest. Note2:Theantennagainisdeclaredbythecustomerandthelaboratoryisnotresponsibleforthe accuracyoftheantennagain. 2.2.DescriptionofAvailableAntennas TestMode Transmitand ReceiveMode Description 5GWIFI2TX,2RXANT1andANT2canbeusedastransmitting/receivingantenna. 3.TestLaboratory GuangzhouJingceTestingTechnologyCo.,Ltd. Add.:No.10,HefengNo.1street,HuangpuDistrict,Guangzhou,Guangdong,People’sRepublicof China AssociationforLaboratoryAccreditation(A2LA).CertificateNumber:6594.03 FCCDesignationNumber:CN1381.TestFirmRegistrationNumber:486550 ICTestFirmRegistrationNumber:31808 ConformityAssessmentBodyidentifier:CN0173 4.RFExposureMeasurement 4.1.Requirement SystemsoperatingundertheprovisionsofFCC47CFRsectionshallbeoperatedinamanner thatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeendefined asmobiledevicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuserand thedevice,andbelowRFPermissibleExposurelimitshallcomplywith. ReportNo.:JCF260617082-002 LOP-FTR0111.0 6 / 7 4.2.LimitsforMaximumPermissibleExposure(MPE) FrequencyRange (MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm 2 ) AverageTime (Minutes) LimitsForGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F=FrequencyinMHz *=Plane-waveequivalentpowerdensity. 4.3.MPECalculationFormula Pd=(Pout*G)/(4*pi*R 2…

Text truncated - open the document above for the full version.

ReportNo.:JCF260617082-001 LOP-FTR0141.0 1/115 FCCCERTIFICATIONTESTREPORT Applicant:GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic &TechnologyDevelopmentDistrict,Guangzhou,China Manufacturer:GuangzhouShiruiElectronicsCo.,Ltd. Address: 192KezhuRoad,ScientechPark,GuangzhouEconomic &TechnologyDevelopmentDistrict,Guangzhou,China ProductDescription:WirelessPTZCamera BrandName:MAXHUB TestedModel:EP50 FCCID:2AFG6-EP50 ReportNo.:JCF260617082-001 ReceivedDate:Jun.17,2026 TestedDate:Jun.17,2026-Aug.07,2026 IssuedDate:Aug.07,2026 TestStandards:FCCRulesandRegulationsPart15SubpartE, TestProcedure: ANSIC63.10-2020 789033D02GeneralU-NIITestProceduresNewRulesv02r01, 662911D01MultipleTransmitterOutputv02r01, TestResult:Pass PreparedBy: KennysZhang/EngineerDate:Aug.07,2026 ReviewedBy: RogerLi/EngineerDate:Aug.07,2026 ApprovedBy: TalentZhang/EngineerDate:Aug.07,2026 Note:Thetestresultsinthisreportapplyexclusivelytothetestedmodel/sample.Withoutwrittenapprovalof GuangzhouJingceTestingTechnologyCo.,Ltd.thetestreportshallnotbereproducedexceptinfull. ReportNo.:JCF260617082-001 LOP-FTR0141.0 2 / 115 ReportReviseRecord ReportVersionReviseTimeIssuedDateValidVersionNotes --/Aug.07,2026OriginalReport/ ReportNo.:JCF260617082-001 LOP-FTR0141.03/115 TableofContents 1.TestReportDeclare...............................................................................................................................5 2.Summaryoftestresults........................................................................................................................6 3.TestLaboratory.....................................................................................................................................6 4.EquipmentUnderTest..........................................................................................................................7 4.1.DescriptionofEUT...........................................................................................................................7 4.2.ChannelList......................................................................................................................................7 4.3.TestChannelConfiguration..............................................................................................................8 4.4.TestEnvironmentConditions...........................................................................................................8 4.5.TheWorseCasePowerSettingParameter.....................................................................................8 4.6.DescriptionofAvailableAntennas...................................................................................................9 5.DescriptionofTestSetup.....................................................................................................................9 5.1.Accessory.........................................................................................................................................9 5.2.SupportEquipment...........................................................................................................................9 5.3.TestSetup........................................................................................................................................9 5.4.SetupDiagramforTests..................................................................................................................9 6.Measurementuncertainty...................................................................................................................10 7.MeasuringInstrumentandSoftwareUsed.......................................................................................10 8.DutyCycle............................................................................................................................................13 8.1.BlockDiagramofTestSetup.........................................................................................................13 8.2.Limits..............................................................................................................................................13 8.3.Procedure.......................................................................................................................................13 8.4.Results............................................................................................................................................13 8.5.OriginalTestData..........................................................................................................................14 9.26dBBandwidth,6dBBandwidthand99%Bandwidth...................................................................25 9.1.BlockDiagramofTestSetup.........................................................................................................25 9.2.Limits..............................................................................................................................................25 9.3.TestProcedure...............................................................................................................................25 9.4.TestResult.....................................................................................................................................25 9.5.OriginalTestData..........................................................................................................................27 10.MaximumOutputPower...................................................................................................................54 10.1.BlockDiagramofTestSetup.......................................................................................................54 10.2.Limits............................................................................................................................................54 10.3.TestProcedure.....................................................................................................…

Text truncated - open the document above for the full version.

ReportNo.:JCF260617082-001 LOP-FTR0141.025/115 9.26dBBandwidth,6dBBandwidthand99%Bandwidth 9.1.BlockDiagramofTestSetup Sameassection8.1 9.2.Limits FCCPart15,SubpartE TestItemLimit FrequencyRange (MHz) Bandwidth 26dBBandwidth5150-5250 26dBBandwidth5250-5350 26dBBandwidth5470-5725 Minimum500kHz6dBBandwidth5725-5850 Forreportingpurposesonly.5150~5825 9.3.TestProcedure (1)ConnectEUT’santennaoutputtospectrumanalyzerbyRFcable. CenterFrequencyThecentrefrequencyofthechannelundertest DetectorPeak RBW For6dBBandwidth:RBW=100kHz For26dBBandwidth:approximately1%oftheemissionbandwidth. For99%OccupiedBandwidth:approximately1%~5%oftheOBW. VBW For6dBBandwidth:VBW=300kHz For26dBBandwidth:>3*RBW For99%Bandwidth:>3*RBW TraceMaxhold SweepAutocouple (2)Allowthetracetostabilize,measurethemaximumwidthoftheemissionthatisconstrainedbythe frequenciesassociatedwiththetwooutermostamplitudepoints(upperandlowerfrequencies)thatare attenuatedby26dBand6dBrelativetothemaximumlevelmeasuredinthefundamentalemission. (3)Usethe99%powerbandwidthfunctionoftheinstrument,allowthetracetostabilizeandreport themeasuredbandwidth. 9.4.TestResult Test Mode Ant. Freq. (MHz) OCB (MHz) FL (MHz) FH (MHz) Limit (MHz) Verdict 11A Ant1518017.0695171.42265188.4916------ Ant2518017.0785171.40935188.4873------ Ant1520016.9295191.53065208.4596------ Ant2520017.1555191.34075208.4957------ Ant1524016.9055231.55405248.4590------ Ant2524017.0005231.47145248.4714------ Ant1574516.9355736.35705753.2920------ Ant2574516.9025736.45875753.3607------ Ant1578517.0535776.38775793.4407------ Ant2578516.9565776.44285793.3988------ Ant1582517.0155816.42405833.4390------ Ant2582516.9985816.40765833.4056------ 11N20MIMO Ant1518018.1285170.97255189.1005------ Ant2518018.0815170.87785188.9588------ Ant1520017.9065190.95935208.8653------ Ant2520018.0445190.92055208.9645------ Ant1524018.0945230.91415249.0081------ Ant2524018.0315230.94365248.9746------ Ant1574516.9875736.37955753.3665------ Ant2574516.7485736.57605753.3240------ ReportNo.:JCF260617082-001 LOP-FTR0141.026/115 Ant1578516.9785776.41565793.3936------ Ant2578516.7415776.54585793.2868------ Ant1582516.8605816.47425833.3342------ Ant2582516.9585816.39745833.3554------ 11N40MIMO Ant1519036.8255171.53725208.3622------ Ant2519036.9555171.41215208.3671------ Ant1523036.7905211.66645248.4564------ Ant2523036.9075211.47795248.3849------ Ant1575536.6315736.36995773.0009------ Ant2575536.9785736.33435773.3123------ Ant1579536.9615776.38085813.3418------ Ant2579536.5735776.53275813.1057------ Note:Offset=cableloss+Testsysteminsertionloss TestModeAnt. Freq. (MHz) 26dB EBW(MHz) FL (MHz) FH (MHz) Limit (MHz) Verdict 11A Ant1518021.9605168.6805190.640------ Ant2518021.0405169.4405190.480------ Ant1520020.9605189.7605210.720------ Ant2520022.2805188.5605210.840------ Ant1524021.4805229.3205250.800------ Ant2524021.2005228.8805250.080------ Ant1574521.6805733.9205755.600------ Ant2574522.5605733.2805755.840------ Ant1578522.2405773.5605795.800------ Ant2578522.7605773.7205796.480------ Ant1582521.2005814.2005835.400------ Ant2582521.3605813.8805835.240------ 11N20MIMO Ant1518022.7605168.8405191.600------ Ant2518021.7205168.9205190.640------ Ant1520022.5205188.8405211.360------ Ant2520021.4005189.3205210.720------ Ant1524022.3605228.7605251.120------ Ant2524022.5205229.0805251.600------ Ant1574521.4005734.3205755.720------ Ant2574520.4005734.8405755.240------ Ant1578521.1205774.0405795.160------ Ant2578521.6005774.0405795.640------ Ant1582522.0005814.3205836.320------ Ant2582521.6005814.2405835.840------ 11N40MIMO Ant1519045.2005167.5205212.720------ Ant2519045.5205166.4805212.000------ Ant1523044.8805207.8405252.720------ Ant2523044.8005208.1605252.960------ Ant1575544.7205731.9605776.680------ Ant2575545.9205730.4405776.360------ Ant1579545.6805771.9605817.640------ Ant2579547.2005771.0805818.280------ Note:Offset=cableloss+Testsysteminsertionloss TestModeAnt. Freq. (MHz) 6dB EBW(MHz) FL (MHz) FH (MHz) Limit (MHz) Verdict 11A Ant1574516.3605736.7605753.1200.5PASS Ant2574516.2805736.8005753.0800.5PASS Ant1578516.3205776.8005793.1200.5PASS Ant2578516.4405776.6805793.1200.5PASS Ant1582516.4405816.7205833.1600.5PASS Ant2582516.4005816.7205833.1200.5PASS 11N20MIMO Ant1574516.3205736.8005753.1200.5PASS Ant2574516.3205736.8005753.1200.5PASS Ant1578516.5205776.6405793.1600.5PASS Ant2578516.3205776.8005793.1200.5PASS Ant1582516.3605816.7605833.1200.5PASS Ant2582515.7205816.7605832.4800.5PASS 11N40MIMO Ant1575535.7605736.7605772.5200.5PASS Ant2575535.9205736.7605772.6800.5PASS ReportNo.:JCF260617082-001 LOP-FTR0141.027/115 Ant1579535.3605777.1605812.5200.5PASS Ant2579534.4005776.8405811.2400.5PASS Note:Offset=cableloss+Testsysteminsertionloss 9.5.OriginalTestData 99%Bandwidth: 11A_Ant1_5180 11A_Ant2_5180 11A_Ant1_5200 ReportNo.:JCF260617082-001 LOP-FTR0141.028/115 11A_Ant2_5200 11A_Ant1_5240 11A_Ant2_5240 ReportNo.:JCF260617082-001 LOP-FTR0141.029/115 11A_Ant1_5745 11A_Ant2_5745 11A_Ant1_5785 ReportNo.:JCF260617082-001 LOP-FTR0141.030/115 11A_Ant2_5785 11A_Ant1_5825 11A_Ant2_5825 ReportNo.:JCF260617082-001 LOP-FTR0141.031/115 11N20MIMO_Ant1_5180 11N20MIMO_Ant2_5180 11N20MIMO_Ant1_5200 ReportNo.:JCF260617082-001 LOP-FTR0141.032/115 11N20MIMO_Ant2_5200 11N20MIMO_Ant1_5240 11N20MIMO_Ant2_5240 ReportNo.:JCF260617082-001 LOP-FTR0141.033/115 11N20MIMO_Ant1_5745 11N20MIMO_Ant2_5745 11N20MIMO_Ant1_5785 ReportNo.:JCF260617082-001 LOP-FTR0141.034/115 11N20MIMO_Ant2_5785 11N20MIMO_Ant1_5825 11N20MIMO_Ant2_5825 ReportNo.:JCF260617082-001 LOP-FTR0141.035/115 11N40MIMO_Ant1_5190 11N40MIMO_Ant2_5190 11N40MIMO_Ant1_5230 ReportNo.:JCF260617082-001 LOP-FTR0141.036/115 11N40MIMO_Ant2_5230 11N40MIMO_Ant1_5755 11N40MIMO_Ant2_5755 ReportNo.:JCF260617082-001 LOP-FTR0141.037/115 11N40MIMO_Ant1_5795 11N40MIMO_Ant2_5795 ReportNo.:JCF260617082-001 LOP-FTR0141.038/115 26dBBandwidth: 11A_Ant1_5180 11A_Ant2_5180 11A_Ant1_5200 11A_Ant2_5200 ReportNo.:JCF260617082-001 LOP-FTR0141.039/115 11A_Ant1_5240 11A_Ant2_5240 11A_Ant1_5745

ReportNo.:JCF260617082-001 LOP-FTR0141.040/115 11A_Ant2_5745 11A_Ant1_5785 11A_Ant2_5785 ReportNo.:JCF260617082-001 LOP-FTR0141.041/115 11A_Ant1_5825 11A_Ant2_5825 11N20MIMO_Ant1_5180 ReportNo.:JCF260617082-001 LOP-FTR0141.042/115 11N20MIMO_Ant2_5180 11N20MIMO_Ant1_5200 11N20MIMO_Ant2_5200 ReportNo.:JCF260617082-001 LOP-FTR0141.043/115 11N20MIMO_Ant1_5240 11N20MIMO_Ant2_5240 11N20MIMO_Ant1_5745 ReportNo.:JCF260617082-001 LOP-FTR0141.044/115 11N20MIMO_Ant2_5745 11N20MIMO_Ant1_5785 11N20MIMO_Ant2_5785 ReportNo.:JCF260617082-001 LOP-FTR0141.045/115 11N20MIMO_Ant1_5825 11N20MIMO_Ant2_5825 11N40MIMO_Ant1_5190 ReportNo.:JCF260617082-001 LOP-FTR0141.046/115 11N40MIMO_Ant2_5190 11N40MIMO_Ant1_5230 11N40MIMO_Ant2_5230 ReportNo.:JCF260617082-001 LOP-FTR0141.047/115 11N40MIMO_Ant1_5755 11N40MIMO_Ant2_5755 11N40MIMO_Ant1_5795 ReportNo.:JCF260617082-001 LOP-FTR0141.048/115 11N40MIMO_Ant2_5795 6dBBandwidth: 11A_Ant1_5745 11A_Ant2_5745 ReportNo.:JCF260617082-001 LOP-FTR0141.049/115 11A_Ant1_5785 11A_Ant2_5785 11A_Ant1_5825 ReportNo.:JCF260617082-001 LOP-FTR0141.050/115 11A_Ant2_5825 11N20MIMO_Ant1_5745 11N20MIMO_Ant2_5745

ReportNo.:JCF260617082-001 LOP-FTR0141.051/115 11N20MIMO_Ant1_5785 11N20MIMO_Ant2_5785 11N20MIMO_Ant1_5825 ReportNo.:JCF260617082-001 LOP-FTR0141.052/115 11N20MIMO_Ant2_5825 11N40MIMO_Ant1_5755 11N40MIMO_Ant2_5755 ReportNo.:JCF260617082-001 LOP-FTR0141.053/115 11N40MIMO_Ant1_5795 11N40MIMO_Ant2_5795 ReportNo.:JCF260617082-001 LOP-FTR0141.054/115 10.MaximumOutputPower 10.1.BlockDiagramofTestSetup Sameassection8.1 10.2.Limits FCCPart15,SubpartE TestItemLimit FrequencyRange (MHz) Conducted OutputPower OutdoorAccessPoint:1W(30dBm) 5150-5250 IndoorAccessPoint:1W(30dBm) FixedPoint-To-PointAccessPoints:1W(30dBm) ClientDevices:250mW(24dBm) Shallnotexceedthelesserof250mW(24dBm)or 11dBm+10logB,whereBisthe26dBemission bandwidthinmegahertz. 5250-5350 5470-5725 Shallnotexceed1Watt(30dBm). 5725-5850 Note:For802.11n,theEUTincorporatesaMIMOfunction.TheAntennadirectionalgainis8.64dBi. TheMaximumOutputPowerlimitistheabovelimits-(8.64-6) Note:Theabovelimitsarebaseduponthemaximumantennagaindoesnotexceed6dBi.If transmittingantennasofdirectionalgaingreaterthan6dBiareused,themaximumconductedoutput powershallbereducedbytheamountindBthatthedirectionalgainoftheantennaexceeds6dBi. 10.3.TestProcedure MethodPMisMeasurementusinganRFaveragepowermeter.Theprocedureforthismethodisas follows: (1)MeasurementsmaybeperformedusingawidebandRFpowermeterwithathermocouple detectororequivalentifallofthefollowingconditionsaresatisfied: a)TheEUTisconfiguredtotransmitcontinuously,ortotransmitwithaconstantdutycycle. b)AtalltimeswhentheEUTistransmitting,itshallbetransmittingatitsmaximumpowercontrol level. c)Theintegrationperiodofthepowermeterexceedstherepetitionperiodofthetransmittedsignal byatleastafactoroffive. (2)Ifthetransmitterdoesnottransmitcontinuously,measurethedutycycleDofthetransmitter outputsignalasdescribedin12.2. (3)Measuretheaveragepowerofthetransmitter.ThismeasurementisanaverageoverboththeON andOFFperiodsofthetransmitter. (4)CorrectthemeasurementindBmbyadding[10log(1/D)],whereDisthedutycycle{e.g.,[10log (1/0.25)],ifthedutycycleis25%}. 10.4.TestResult Test Mode Ant. Freq. (MHz) Channel Power (dBm) DC Factor (dBm) Result (dBm) Limit (dBm) Verdict 11A Ant151800.440.130.57≤23.98PASS Ant25180-2.200.16-2.04≤23.98PASS Ant152001.440.161.60≤23.98PASS Ant25200-2.430.16-2.27≤23.98PASS Ant152402.180.162.34≤23.98PASS Ant25240-2.390.16-2.23≤23.98PASS Ant157454.610.134.74≤30.00PASS Ant257452.640.162.80≤30.00PASS Ant157853.780.163.94≤30.00PASS Ant257851.370.131.50≤30.00PASS Ant158252.180.162.34≤30.00PASS Ant258250.640.160.80≤30.00PASS ReportNo.:JCF260617082-001 LOP-FTR0141.055/115 11N20MIMO Ant15180-0.180.17-0.01≤23.98PASS Ant25180-2.260.17-2.09≤23.98PASS total5180------2.08≤21.34PASS Ant152000.620.170.79≤23.98PASS Ant25200-2.320.17-2.15≤23.98PASS total5200------2.57≤21.34PASS Ant152401.190.131.32≤23.98PASS Ant25240-2.680.17-2.51≤23.98PASS total5240------2.82≤2…
