2AFGF-PXN-9607XWireless Controller

第1页，总4页 Product use instructions 1.summarize： The bluetooth controller with vibration is specially designed for the SWITCH platform.Compatible with PC/ android platform。 2. Functional Characteristics： 2.1 bluetooth 5.0。 2.2 Compatible with SWITCH host platform, PC platform。 2.3 Low power mode (disconnect after sleep)。 2.4 SWITCH host platform has sensor induction function。 2.5 With double motor vibration function。 2.6 The linear transmission distance is over 10 meters。 2.7 Built-in lithium battery 3.7v, can be used for more than 20 hours。 2.8 It can be charged via TYPE-C USB。 3. Product diagram： 第2页，总4页 4. instructions： 4.1 The first step is to turn on the cable Settings in the host as shown below： 4.2 POWER ON/OFF ： 4.2.1 POWER ON： press the "HOME" button for 3 second to activate the controller, and the four LED racing flashes once per second。 4.2.2 POWER OFF：Press the "HOME" button for 1 seconds to close the controller。 4.3 connect： 4.3.1 SWITCH host press and hold the "Y" button and then press the "HOME" button to start up the pairing, four LED racing flashing,1 second 2 times, connected to the current LED light long bright.(LED1 is bright if it is the first machine connection, and LED2 is bright if it is the second, and so on)。 4.3.2 The android platform, press A and press HOME again. LED2+LED3 Quick flashing, LED2+LED3 lights up after successful connection。 4.3.3 Connect the gamepad to the computer with the USB Micro data cable, which is the x-input key value gamepad。 4.4 Low power prompt： 4.4.1 The current connection light flashes twice per second。 4.4.2 Shutdown voltage：3.2V 。 4.5 Charging tips： 4.5.1 Charging in the connected state of the handle: the light in the current mode of the charging line 第3页，总4页 will flash slowly for 1 second and light up normally when fully charged。 4.5.2 DisConnect charging：Insert the charging cable, four LED lights flash once every 1 second, and four LED lights go out when full。 4.6 Controller sleep function ： 4.6.1 Press the "HOME" button to start up the handle in the reconnect state, and no signal will be received for 10 seconds to enter sleep。 4.6.2 After connecting the Controller, there will be no keystroke or axis movement for 5 minutes to sleep。 4.7 Calibration of the Controller： When the Controlle is off, press the -button, B button and HOME button at the same time. The four leds of the Controlle are divided into two groups to shine alternately. The Controlle is placed on the horizontal desktop, and then press the + button。 5. Other parameters： Search for current：18-26MA Working current：26MA Low power alarm：3.5V Shutdown voltage：3.2V Sleep current：Less than 50uA NO. button SWITCH code PC X-INPUT code Android code 1 A A B 97 2 B B A 96 3 X X Y 100 4 Y Y X 99 5 L L LB 102 6 R R RB 103 7 - - BACK 109 8 + + START 108 9 0 screenshots NO NO 10 3D press L 3D press L Thumb L 106 11 3D press R 3D press R Thumb R 107 12 Z L Z L LT 104 13 Z R Z R RT 105 第4页，总4页 14 ML-> X (3D VR) ML-> X (3D VR) ML-> X (3D VR) ML-> X (3D VR) 15 ML-> Y (3D VR) ML-> Y (3D VR) ML-> Y (3D VR) ML-> Y (3D VR) 16 MR- >X (3D VR) MR- >X (3D VR) MR- >X (3D VR) MR- >X (3D VR) 17 MR ->Y (3D VR) MR ->Y (3D VR) MR ->Y (3D VR) MR ->Y (3D VR) 18 D-PAD-UP D-PAD- UP D-PAD- UP 19 19 D-PAD-DOWN D-PAD- DOWN D-PAD- DOWN 20 20 D-PAD-LEFT D-PAD- LEFT D-PAD- LEFT 21 21 D-PAD-RIGHT D-PAD- RIGHT D-PAD- RIGHT 22 FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant t o part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferenc e in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not inst alled and used in accordance with the instructions, may cause harmful interference to radio communications. How ever, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and o n, the user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help important announcement Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Shen Zhen PXN Electronics Technology Co., Ltd. Fenghuanggang Xixiang, Baoan, Shenzhen, China Date: Nov. 02, 2020 Dear Sir/Madam, We, Shen Zhen PXN Electronics Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Model No.: PXN-9607X, PXN-9607,PXN-9607S,PXN-9628,PXN-9607PRO,PXN-9607PROB, PXN-9607PROG,PXN-9607PROY,PXN-9607T,PXN-9607X,PXN-9607XB,PXN- 9607XT,PXN-9607XY,PXN-9617,PXN-9627,PXN-9615,PXN-9608,PXN- 9618,PXN-9609,PXN-9619,PXN-007,PXN-008,PXN-009,SWITCH-0007 FCC ID: 2AFGF-PXN-9607X Sincerely, Name/Title： Pinghui Chen/ Manager Company: Shen Zhen PXN Electronics Technology Co., Ltd. Address: Fenghuanggang Xixiang, Baoan, Shenzhen, China Phone: 0755-29703896 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/11/02 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: Model No PXN-9607X FCC ID 2AFGF-PXN-9607X For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Pinghui Chen/ RD/engineer Company: Shen Zhen PXN Electronics Technology Co., Ltd. Address: Fenghuanggang Xixiang, Baoan, Shenzhen, China Phone: +86 0755-29703896 E-Mail: [email protected]

Shen Zhen PXN Electronics Technology Co., Ltd. Fenghuanggang Xixiang, Baoan, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/02/2020 To whom it may concern: We, Shen Zhen PXN Electronics Technology Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AFGF-PXN-9607X including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Pinghui Chen/ RD/engineer Company: Shen Zhen PXN Electronics Technology Co., Ltd. Address: Fenghuanggang Xixiang, Baoan, Shenzhen, China Phone: +86 0755-29703896 E-Mail: [email protected]

FCC ID: 2AFGF-PXN-9607X FCC ID: 2AFGF-PXN-9607X FCC ID: 2AFGF-PXN-9607X

FCC ID: 2AFGF-PXN-9607X

FCC ID: 2AFGF-PXN-9607X FCC ID: 2AFGF-PXN-9607X FCC ID: 2AFGF-PXN-9607X

RF Exposure evaluation FCC ID: 2AFGF-PXN-9607X 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK(Peak) Channel Channel 00 Channel 19 Channel 39 Target (dBm) -7.0 -7.0 -7.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.480 5 -6.0 0.2512 0.079<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20201022013-1-1 2AFGF-PXN-9607X Compiled by ( position+printed name+signature) .............................. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .............................. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .............................. : Manager Jason Hu Date of issue ..................................... : Oct.29,2020 Testing Laboratory Name ..............: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shen Zhen PXN Electronics Technology Co., Ltd. Address ............................................ : Fenghuanggang Xixiang, Baoan, Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Controller Trade Mark ....................................... : N/A Manufacturer .................................... : LITE STAR ELECTRONICS TECHNOLOGY Co.,Ltd. Model/Type reference....................... : PXN-9607X Listed Models .................................. : PXN-9607,PXN-9607S,PXN-9628,PXN-9607PRO,PXN-9607PROB, PXN-9607PROG,PXN-9607PROY,PXN-9607T,PXN-9607X,PXN-9607XB, PXN-9607XT,PXN-9607XY,PXN-9617,PXN-9627,PXN-9615,PXN-9608, PXN-9618,PXN-9609,PXN-9619,PXN-007,PXN-008,PXN-009,SWITCH- 0007 Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Rating ............................................... : DC 3.7V From Battery and DC5V From Adapter Result................................................ : PASS Report No.: GTS20201022013-1-1 Page 2 of 34 T E S T R E P O R T Test Report No. : GTS20201022013-1-1 Oct.29,2020 ______________________________________________________________________________________________ Date of issue Equipment under Test : Wireless Controller Model /Type : PXN-9607X Listed Models : PXN-9607,PXN-9607S,PXN-9628,PXN-9607PRO,PXN-9607PROB, PXN-9607PROG,PXN-9607PROY,PXN-9607T,PXN-9607X,PXN- 9607XB,PXN-9607XT,PXN-9607XY,PXN-9617,PXN-9627,PXN- 9615,PXN-9608,PXN-9618,PXN-9609,PXN-9619,PXN-007,PXN- 008,PXN-009,SWITCH-0007 Applicant : Shen Zhen PXN Electronics Technology Co., Ltd. Address : Fenghuanggang Xixiang, Baoan, Shenzhen, China Manufacturer : LITE STAR ELECTRONICS TECHNOLOGY Co.,Ltd. Address : Xingchen Science park Lianbi Road,Wulian Industry Area,Fenggang Town,Dongguan City,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201022013-1-1 Page 3 of 34 Contents 1. T E S T S T A N D A R D S ................................................................. 4 2. S U M M A R Y ............................................................................ 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Block Diagram of Test Setup 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. EUT configuration 6 2.9. Modifications 6 3. T E S T E N V I R O N M E N T .............................................................. 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Test Description 8 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4. T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1. AC Power Conducted Emission ................................................................................... 10 4.2. Radiated Emission ........................................................................................................ 13 4.3. Maximum Peak Output Power ...................................................................................... 19 4.4. Power Spectral Density ................................................................................................ 20 4.5. 6dB Bandwidth ............................................................................................................. 22 4.6. Band Edge Compliance of RF Emission ...................................................................... 24 4.7. Spurious RF Conducted Emission ............................................................................... 27 4.8. Antenna Requirement ................................................................................................... 29 5. T E S T S E T U P P H O T O S O F T H E E U T ......................................... 30 6. E X T E RN A L A N D I N T E R N AL P H O T O S O F T HE E U T ...................... 31 Report No.: GTS20201022013-1-1 Page 4 of 34 1. T E S T S T A N D A R D S The tests were …

Text truncated - open the document above for the full version.

FCC ID: 2AFGF-PXN-9607X _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2AFGF-PXN-9607X _______________________________________________________________________________________________ 1.2. Photo of conducted Emissions Measurement Fig. 3
