2AFP2-MC05Qi2.0 Duo Wireless Charger

Qi 2.0 MAGNETIC WIRELESS CAR CHARGER 23 ENGLISH Specs Magnetic Wireless Car Charger •USB-C ™ Input: 5V/3A; 9V/2.22A; 12V/1.67A •Output: Up to 15W 20W Car Charger •Input: DC 12V-24V •Output: 5V/3A, 9V/2.22A, 12V/1.67A Caution DO NOT place any credit cards or other types of magnetic material near the charging pad. Do not attempt to disassemble the wireless charging pad as it may short circuit or damage the product. Keep at least 8” (20cm) distance between implantable medical devices such as pacemakers, cochlear implants, etc. Keep this product in a dry and ventilated space. Do not place in direct heat or use in high humidity environments. Do not use organic solvents to clean surface. 45 ENGLISH ENGLISH Instructions Attaching the VENT MOUNT: WARNING: Please do not text and drive. Do not place near an airbag. 1. Make sure the air vent is clean and free of dust. 2. Loosen the large socket nut on the back of the magnet mount and push the vent ball joint into the hole until it snaps into place. 3. Screw the socket nut tight – this secures the mount to the base. 4. Turn the smaller socket nut until the vent hook mechanism is at proper length. NOTE: Vent hook latch rotates for compatibility with vertical or horizontal vent mounts. Instructions Attaching the VENT MOUNT: 5. Attach by pushing and placing the vent hook mechanism onto a vent blade and then screwing the socket nut until tight. The vent pads should be against your dash and it should be stable and secure. Attaching the SUCTION MOUNT: 1. Unscrew the large socket nut and push vent clip ball joint into the hole until it snaps into place. 2. Screw the socket nut back on until tight –this locks the vent clip onto the wireless charging pad and holds the adjustable support base in place. 67 ENGLISH ENGLISH Instructions Using your Magnetic Wireless Car Charger : 1. Connect the USB-C to USB-C cable to the USB-C port of the Magnetic Wireless Car Charger. 2. Connect the USB-C connector into the included car charger and plug it in. 3. Place the back of your Apple iPhone ® MagSafe ® device against the Magnetic Wireless Car Charger until it automatically aligns and snaps into place. *‡ Charging will begin automatically. * Works with MagSafe cases. Non-MagSafe cases must be removed before charging. Limited Lifetime Warranty This product is fully warranted against defects in materials and workmanship for the lifetime of the product, so long as the manufacturer continues to make this product. If a product fails due to a manufacturing defect, we will replace it upon proper proof of purchase by the original purchaser. Replacement product will be subject to shipping and handling charges. Damages through normal wear and tear, alteration, misuse, neglect, accident, service by anyone other than the authorized service center, or act of God, are not covered by this warranty. For all warranty claims, the product must be returned in accordance with PureGear’s return policy. The “Qi2” symbol is a trademark of the Wireless Power Consortium. USB-C is a trademark of USB Implementers Forum. All trademarks and trade names are used for reference purposes only and are the property of their respective owners. 89 ENGLISH ENGLISH FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body. FCC Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. FCC Interference Statement (cont.) This equipment generates, uses and can radiate radio frequency energy; if not installed and used in accordance with the instructions, maybe cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into and outlet on a circuit different form that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CARGADOR INALÁMBRICO MAGNÉTICO PARA MONTAJE EN AUTO Qi 2.0 1213 ESPAÑOL Especificaciones Cargador inalámbrico •Entrada USB-C: 5Vc.c./3A; 9Vc.c./2.22A; 12Vc.c./1.67A •Salida: Hasta 15W Cargador de auto de 20W •Entrada: DC 12V-24V •Salida: 5Vc.c./3A, 9Vc.c./2.22A, 12Vc.c./1.67A Precaución NO coloque tarjetas de crédito u otros tipos de materiales magnéticos cerca de la base de carga. No intente desensamblar la base de carga inalámbrica pues esto podría causar un cortocircuito o dañar el producto. Mantenga a una distancia mínima de 20 cm (8”) entre dispositivos médicos implantables como marcapasos, implantes cocleares, etc. Mantenga este producto en un lugar seco y ventilado. No lo coloque cerca del calor directo ni lo use en ambientes con un nivel alto de humedad. No use solventes orgánicos para limpiar la superficie. 1415 ESPAÑOL ESPAÑOL Instrucciones: Instalar el SOPORTE PARA MONTAJE EN REJILLA DE VENTILACIÓN de su auto: ADVERTENCIA: Por favor no escriba textos cuan…

Text truncated - open the document above for the full version.

- Shenzhen Powerqi Technology Co., Ltd. - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/12/2024 U.S. Agent Designation Shenzhen Powerqi Technology Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AFP2-MC05): Name and company of U.S. agent: UUX GROUP INC Physical U.S. address of agent: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 FRN of U.S. agent: 0033701590 Email address of U.S. agent: [email protected] UUX GROUP INC acknowledges their obligation to accept service of process on behalf of Shenzhen Powerqi Technology Co., Ltd.. Shenzhen Powerqi Technology Co., Ltd. with the FRN 0024845463 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Tina Qu Sales Manager Shenzhen Powerqi Technology Co., Ltd. Signature Jack Fu Manager UUX GROUP INC 48_[model] US_Agent_2.911(d)(7) - U, V05

Page 1 of 3 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 3 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 3 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 ---The End---

Label Size: L45mm * W10mm 1. The label is silk-screen on the sample Qi2.0 Duo Wireless Charger Model Name: MC05 FCC ID: 2AFP2-MC05 L W

Page 1 of 5 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 Coil Antenna Page 2 of 5 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 5 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 5 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 Photo 8 Page 5 of 5 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 9 ------End------

Page 1 of 14 Report No.: AITSZ24061416W2 RF Exposure Evaluation Client Information: Applicant: Shenzhen Powerqi Technology Co.,Ltd. Applicant add.: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Manufacturer: Shenzhen Powerqi Technology Co.,Ltd. Manufacturer add.: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Product Information: Product Name: Qi2.0 Duo Wireless Charger Model No.: MC05 Brand Name: POWERQI Test samples.: AITSZ24061416001 FCC ID: 2AFP2-MC05 Applicable standards: FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 Prepared By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Date of Receipt: Jun. 14, 2024 Date of Test: Jun. 14, 2024 ~ July 04, 2024 Date of Issue: July 04, 2024 Test Result: Pass This device described above has been tested by Guangdong Asia Hongke Test Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited, this document may be altered or revised by Guangdong Asia Hongke Test Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Leon.yi Sean She Page 2 of 14 Report No.: AITSZ24061416W2 1 CONTENTS COVER PAGE Page 1 CONTENTS 2 2 TEST FACILITY 4 2.1 Deviation from standard 4 2.2 Abnormalities from standard conditions 4 2.3 Test Location 4 3 GENERAL INFORMATION 5 4 TEST METHODOLOGY 6 4.1 Measuring Standard 6 4.2 Requirements 6 4.3 Limits 6 4.4 Test Setup 7 4.5 Test Procedure 7 5 Equipment Approval Considerations 8 5.1 Description of the test mode 9 5.2 Peripheral List 9 5.3 Test Instruments list 9 5.4 Duty Cycle 10 5.5 Test Result 11 1.1 Test Setup photo 12 Page 3 of 14 Report No.: AITSZ24061416W2 Revision History Revision Issue Date Revisions Revised By 00 July 04, 2024 Initial Issue Sean She Page 4 of 14 Report No.: AITSZ24061416W2 2 TEST FACILITY The test facility is recognized, certified or accredited by the following organizations: FCC-Registration No.: 251906 Designation Number: CN1376 Guangdong Asia Hongke Test Technology Limited has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. IC —Registration No.: 31737 CAB identifier: CN0165 The 3m Semi-anechoic chamber of Guangdong Asia Hongke Test Technology Limited has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 31737 A2LA-Lab Cert. No.: 7133.01 Guangdong Asia Hongke Test Technology Limited has been accredited by A2LA for technical competence in the field of electrical testing, and proved to be in compliance with ISO/IEC 17025: 2017 General Requirements for the Competence of Testing and Calibration Laboratories and any additional program requirements in the identified field of testing. 2.1 Deviation from standard None 2.2 Abnormalities from standard conditions None 2.3 Test Location Guangdong Asia Hongke Test Technology Limited Address: B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Page 5 of 14 Report No.: AITSZ24061416W2 3 GENERAL INFORMATION EUT Name: Qi2.0 Wireless Car Charger Model No: MC05 Serial Model: N/A Test sample(s) ID: AITSZ24061416001 Sample(s) Status: Engineer sample Operation frequency: 113kHz-205kHz,360KHz Modulation Technology: ASK Antenna Type: Loop coil Antenna Antenna gain: 0dBi Hardware version.: N/A Software version.: N/A Power supply: Input: 5V⎓2A,9V⎓2.22A,12V⎓1.67A Output: 5W/7.5W/10W/15W Model different: N/A Note: For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 6 of 14 Report No.: AITSZ24061416W2 4 TEST METHODOLOGY 4.1 Measuring Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: KDB 680106 D01 Wireless Power Transfer v04. 4.2 Requirements According to the item 3 of KDB 680106 D01v04: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Mobile Device and Portable Device Configurations (2) Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz (3) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the top surface. 4.3 Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Page 7 of 14 Report No.: AITSZ24061416W2 4.4 Test Setup 4.5 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, …

Text truncated - open the document above for the full version.

Page 1 of 25 Report No.: AITSZ24061416W1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. FCC TEST REPORT Client Information: Applicant: Shenzhen Powerqi Technology Co.,Ltd. Applicant add.: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Manufacturer: Shenzhen Powerqi Technology Co.,Ltd. Manufacturer add.: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China Product Information: Product Name: Qi2.0 Duo Wireless Charger Brand Name: POWERQI Model No.: MC05 FCC ID: 2AFP2-MC05 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Prepared By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Date of Receipt: Jun. 14, 2024 Date of Test: Jun. 14, 2024 ~ July 04, 2024 Date of Issue: July 04, 2024 Test Result: Pass This device described above has been tested by Guangdong Asia Hongke Test Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited, this document may be altered or revised by Guangdong Asia Hongke Test Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Leon.yi Sean She Page 2 of 25 Report No.: AITSZ24061416W1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ........................................................................................................................................................... 2 2 TEST SUMMARY .................................................................................................................................................. 5 2.1 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 5 2.2 MEASUREMENT UNCERTAINTY ............................................................................................................................ 5 3 TEST FACILITY ..................................................................................................................................................... 6 3.1 DEVIATION FROM STANDARD ............................................................................................................................... 6 3.2 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 6 3.3 TEST LOCATION ................................................................................................................................................. 6 4 GENERAL INFORMATION ................................................................................................................................... 7 4.1 EUT TEST MODE ............................................................................................................................................... 8 4.2 DESCRIPTION OF TEST SETUP............................................................................................................................. 8 4.3 PERIPHERAL LIST ............................................................................................................................................... 9 4.4 EUT PERIPHERAL LIST ....................................................................................................................................... 9 5 EQUIPMENTS LIST FOR ALL TEST ITEMS ..................................................................................................... 10 6 CONDUCTED EMISSION TEST ......................................................................................................................... 11 6.1 CONDUCTED EMISSION MEASUREMENT ................................................................................................ 11 6.2 POWER LINE CONDUCTED EMISSION LIMITS ........................................................................................... 11 6.3 TEST PROCEDURE ...................................................................................................................................... 11 6.4 DEVIATION FROM TEST STANDARD ......................................................................................................... 11 6.5 TEST SETUP ................................................................................................................................................. 12 6.6 EUT OPERATING CONDITIONS .................................................................................................................. 12 6.7 TEST RESULT .................................................................................................................................................. 13 7 RADIATED EMISSION MEASUREMENT .......................................................................................................... 15 7.1 RADIATED EMISSION LIMITS .............................................................................................................................. 15 7.2 ANECHOIC CHAMBER TEST SETUP DIAGRAM ..............................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 批准 APPROVEDBY 严慧琳 客户：深圳市倍力奇科技有限公司 CUSTOMER:____________________________________________________________________ 客户料号： CUSTP/N:____________________________________________________________________ 金赞料号：J30-000226-001 KCP/N:____________________________________________________________________ 产品型号：20.5*39.5*0.08*80P*11TS*20MM DESE: 日期：2024.6.24 DATE:____________________________________________________________________ 版本：A.0 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*11TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2024/6/24严慧琳 Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*11TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) 圈数 Turn s 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste 11TS 0.08*80P热风绞线 （Strandedwire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/-Paste） 所有材料要求合格ROHS标准 ABCDEFGH 15±0.520.5±0.539.5±0.543.5±0.53±120±10.95±0.052.15±0.2 Black heat shrink tubing 3M double-sided tape PS: 1. (F) The length of the outer magnetic lead; 2. (H) Includes incoming wire, not release paper; 3. First, thread the thin black heat shrink sleeve, and then press the wire with a stop machine. Then, thread the wire through the sleeve to the bend and to the end. All materials are required to be ROHS compliant Operation frequency: 113kHz-205kHz,360KHz Antenna Type: Loop coil Antenna Antenna gain: 0dBi Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 20.5*39.5*0.08*80P*11TS*20M M 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 4 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F ：7.7uH±10% 100kHz/1VLCZMETER1062 2DCRS-F ：65mΩMAX /LCZMETER1062 3Q值S-F ：60MIN 100kHz/1VLCZMETER1062 3. 材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 / / 2 GCP-T-00298HYT 3 GCP-T-00305 LX 4 SMJ-3M-00079 HWD 5 SMJ-T-0082HWD 6 3mm JRM 7 E7202WHZY 8 XC 9 9MM*Ф1.5 // Coil and disc Resistance Q value Wire rod 0.08*80P hot air stranded cable Large diskette minicycle Hard magnetic circle 15*0.7H without holes or slots G43.5±0.5*5.3*0.8H with double groove with hole, the middle small groove 3MM 3M double-sided tape 42*5.3*0.12H 3M9448A with hole and hand tear Small double-sided tape Round ordinary double-sided tape 13*0.08H with hand tear Gold finger tape High temperature adhesive paper 3MM glue JS-E7202 (thickened) white glue Tin bar Environmentally friendly lead-free solder bar Lead-free high Black heat shrink tubing thin temperature tin strip

Page 1 of 2 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Test Setup Photo DCD Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2AFP2-MC05 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Radiation (30MHz-1000MHz) ------End------
