2AFP2-MC20Qi2.0 Wireless Charger Ring Stand

128g哑粉纸单黑印刷风琴折 无线充说明书 MC20 73×55mm 1:1 2024.7.25 1.0 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radiofrequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The FCC certification of this device refers to RF exposure testing performed in typical operating conditions, where a person is no closer than 20 centimeters from the device surface at all times, except for non-repetitive patterns with transient time intervals in the order of a second. Only in the stated conditions, the device is shown to fully comply with the FCC RF Exposure requirements of KDB 447498.

- Shenzhen Powerqi Technology Co., Ltd. - Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/4/2024 U.S. Agent Designation Shenzhen Powerqi Technology Co., Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AFP2-MC20): Name and company of U.S. agent: UUX GROUP INC Physical U.S. address of agent: 36 South 18th Avenue, Suite A Brighton, CO USA 80601 FRN of U.S. agent: 0033701590 Email address of U.S. agent: [email protected] UUX GROUP INC acknowledges their obligation to accept service of process on behalf of Shenzhen Powerqi Technology Co., Ltd.. Shenzhen Powerqi Technology Co., Ltd. with the FRN 0024845463 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Tina Qu Sales Manager Shenzhen Powerqi Technology Co., Ltd. Signature Jack Fu Manager UUX GROUP INC 48_[model] US_Agent_2.911(d)(7) - U, V05

Page 1 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 ---The End---

Label Size: 550mm * W10mm 1. The label is silk-screen on the sample Qi2.0 Wireless Charger Ring Stand Model Name: MC20 FCC ID: 2AFP2-MC20 L W

Page 1 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 Page 2 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 4 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 Photo 8 ------End------

Page 1 of 12 Report No.: AiTSZ-240828005W2 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : Qi2.0 Wireless Charger Ring Stand Brand Name : POWERQI Model : MC20 Series Model : N/A FCC ID : 2AFP2-MC20 Applicant : Shenzhen Powerqi Technology Co., Ltd. Address : Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang Community, Longgang District, Shenzhen,China Manufacturer : Shenzhen Powerqi Technology Co., Ltd. Address : Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang Community, Longgang District, Shenzhen,China Standard(s) : FCC CFR 47 PART 1, § 1.1310 KDB 680106 D01 Wireless Power Transfer v04 Date of Receipt : Aug.28, 2024 Date of Test : Aug.28, 2024~ Sept.03, 2024 Issued Date : Sept.03, 2024 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Leon.yi Sean She Page 2 of 12 Report No.: AiTSZ-240828005W2 Report Revise Record Report Version Issued Date Notes M1 Sept.03, 2024 Initial Release Page 3 of 12 Report No.: AiTSZ-240828005W2 Contents 1 GENGENERAL INFORMATION ................................................................................................................................... 4 1.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 4 1.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2.1 DESCRIPTION OF THE TEST MODE ..................................................................................................................................... 6 2.2 SPECIAL ACCESSORIES ................................................................................................................................................... 6 2.3 EQUIPMENT LIST FOR THE TEST ....................................................................................................................................... 6 3 TEST CONDITIONS AND RESULTS .............................................................................................................................. 7 3.1 APPLICABLE STANDARD .................................................................................................................................................. 7 3.2 LIMIT ......................................................................................................................................................................... 7 3.3 TEST SETUP ................................................................................................................................................................. 7 3.4 MEASUREMENT PROCEDURE .......................................................................................................................................... 8 3.5 TEST RESULT OF E AND H FIELD STRENGTH ........................................................................................................................ 8 3.6 EQUIPMENT APPROVAL CONSIDERATIONS ......................................................................................................................... 9 3.7 CONCLUSION ............................................................................................................................................................... 9 4 TEST SETUP PHOTOGRAPHS OF EUT ....................................................................................................................... 10 Page 4 of 12 Report No.: AiTSZ-240828005W2 1 GENGENERAL INFORMATION 1.1 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Normal Temperature: 25°C Relative Humidity: 55 % Air Pressure: 101 kPa 1.2 General Description of EUT Product Name: Qi2.0 Wireless Charger Ring Stand Model/Type reference: MC20 Power Supply: Input: 5V⎓3A, 9V⎓2.22A, 12V⎓1.67A Output: 5W/7.5W/10W/15W Hardware version: N/A Software version: V1.0 Sample(s) Status: AiTSZ-240828005-01(Normal sample) AiTSZ-240828005-02(Engineer sample) Wireless Charger: Operation frequency: 113-205Khz, 360Khz Modulation Technology: ASK Antenna Type: Loop coil Antenna Antenna gain: 0dBi Remark: The above DUT's information was declared by manufacturer. For more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Page 5 of 12 Report No.: AiTSZ-240828005W2 1.3 Test Facility Test Laboratory: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Ju…

Text truncated - open the document above for the full version.

Page 1 of 21 Report No.: AiTSZ-240828005W1 Note: This device has been tested and found to comply with the standard(s) listed, this test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited. If there is a need to alter or revise this document, the right belongs to Guangdong Asia Hongke Test Technology Limited, and it should give a prior written notice of the revision document. This test report must not be used by the client to claim product endorsement. Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. TEST REPORT Product Name : Qi2.0 Wireless Charger Ring Stand Brand Name : POWERQI Model : MC20 Series Model : N/A FCC ID : 2AFP2-MC20 Applicant : Shenzhen Powerqi Technology Co., Ltd. Address : Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang Community, Longgang District, Shenzhen,China Manufacturer : Shenzhen Powerqi Technology Co., Ltd. Address : Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang Community, Longgang District, Shenzhen,China Standard(s) : FCC CFR Title 47 Part 15 Subpart C Date of Receipt : Aug.28, 2024 Date of Test : Aug.28, 2024~ Sept.03, 2024 Issued Date : Sept.03, 2024 Issued By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Reviewed by: Approved by: Leon.yi Sean She Page 2 of 21 Report No.: AiTSZ-240828005W1 Report Revise Record Report Version Issued Date Notes M1 Sept.03, 2024 Initial Release Page 3 of 21 Report No.: AiTSZ-240828005W1 Contents 1 TEST SUMMARY ....................................................................................................................................................... 4 1.1 TEST STANDARDS.......................................................................................................................................................... 4 1.2 TEST SUMMARY ........................................................................................................................................................... 4 1.3 TEST FACILITY .............................................................................................................................................................. 5 1.4 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2 GENGENERAL INFORMATION ................................................................................................................................... 6 2.1 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 6 2.2 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 6 2.3 DESCRIPTION OF THE TEST MODE ..................................................................................................................................... 7 2.4 SPECIAL ACCESSORIES ................................................................................................................................................... 7 2.5 EQUIPMENT LIST FOR THE TEST ....................................................................................................................................... 7 3 TEST CONDITIONS AND RESULTS .............................................................................................................................. 9 3.1 CONDUCTED EMISSIONS TEST ......................................................................................................................................... 9 3.2 RADIATED EMISSIONS .................................................................................................................................................. 12 3.3 20DB BANDWIDTH ..................................................................................................................................................... 18 3.4 ANTENNA REQUIREMENT ............................................................................................................................................. 20 4 TEST SETUP PHOTOGRAPHS OF EUT ....................................................................................................................... 21 5 EXTERNAL PHOTOGRAPHS OF EUT ......................................................................................................................... 21 6 INTERNAL PHOTOGRAPHS OF EUT .......................................................................................................................... 21 Page 4 of 21 Report No.: AiTSZ-240828005W1 1 TEST SUMMARY 1.1 Test Standards The tests were performed according to following standards: FCC Rules Part 15.207,15.209, 15.215(c) ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices 1.2 Test Summary Test Item Section in CFR 47 Test Result Electric Field Radiated Emissions FCC Part 15 C (Section15.209) PASS 20dB Bandwidth/99% Bandwidth FCC Part 15 C (Section15.215(c)) PASS AC Power Line Conducted Emission FCC Part 15 C (Section15.207) PASS Antenna Requirement FCC Part 15 C (Section15.203 PASS Page 5 of 21 Report No.: AiTSZ-240828005W1 1.3 Test Facility Test Laboratory: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chon…

Text truncated - open the document above for the full version.

Page 1 of 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 批准 APPROVEDBY 严慧琳 客户：深圳市倍力奇科技有限公司 CUSTOMER:____________________________________________________________________ 客户料号： CUSTP/N:____________________________________________________________________ 金赞料号：J30-000143-001 KCP/N:____________________________________________________________________ 产品型号：20.5*39*0.08*80P*11TS-7.7uH±10% DESE: 日期：2024.6.4 DATE:____________________________________________________________________ 版本：A.2 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-094 20.5*39*0.08*80P*11TS-7.7uH ± 10% 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2024/4/26严慧琳 A.142*0.08H双面胶3M9448A双面胶：42*0.12H2024/4/26严慧琳 A.2 --新增9*11MM蓝色胶布 2024/6/4严慧琳--新增阻值：65mΩMAX --新增Q值：60MIN Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-094 20.5*39*0.08*80P*11TS-7.7uH ± 10% 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) 圈数 Turns 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste 11TS 0.08*80P热风绞线 （Strandedwire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/Paste） ABCDEFG 15±120.5±0.539±0.543.5±0.510±13±12.0-2.3MAX Ps: 1.(E) The length of the magnetic outer lead; 2.(G) Includes incoming wire, does not include release paper; 3.Attach 9*11MM blue tape and 5MM gold finger tape to the back of the cable All materials are required to be ROHS compliant Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-094 20.5*39*0.08*80P*11TS-7.7uH ± 10% 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 4 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F100kHz/VLCZMETER1062 2DCRS-F 65mΩMAX 100kHz/VLCZMETER1062 3Q值S-F100kHz/VLCZMETER1062 3.材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 线材0.08*80P JX-2U-F-0008 CX 2 大磁片G43.5±0.5*5.3*0.8（带孔，带双L槽， 中间小槽3mm） GCP-T-00298HYT 3小磁片硬磁圆形15*0.7H无孔无槽 GCP-T-00305LX 4大双面胶3M双面胶9448A42*0.12H带手撕 SMJ-3M-00077 HWD 5 小双面胶圆形普通双面胶13*0.08H带手撕 SMJ-T-0082HWD 6 胶水JS-E7202（加稠）白胶 E7202WHZY 7 锡条环保无铅焊锡条 无铅高温锡条XC 8金手指胶布5mm 高温胶纸5MMJRM 9蓝色胶布9*11MM蓝色胶布 // Coil plus disc: 7.7uH±10% Resistance: Q value: 60MIN Strandedwire

Page 1 of 2 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Test Setup Photo DCD Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2AFP2-MC20 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Radiation (30MHz-1000MHz) ------End------
