2AFVB-L8500208Door Station

1. Door stations 1 Assistant door panel 1x8 Base + card reader L8 User’s manual (Door station Model No.8) 2. Technical specification Camera: Viewing angle: Lens: Resolution: Min. Illumination: Video Output: Audio SNR: Audio Distortion： Assistant door panel: System Capacity: Card and capacity: Standby Current: Working Current: Power supply: Environment Temperature: 1/3" CCD 92° F=3.6 420TV Lines 0.01 Lux 1V/75Ω P-P ≥25dB ≤7% Max.16pcs Max. 132 apartments/building ≤50,000pcs; ID card(Format:EM, 125Kh); IC card (Format: mifare 1 S50/S70, mifare Ultra Light, mifare Light, 13.56MHz) ≤116mA(direct-call) ≤450mA(direct-call) DC12V( -40°C~+45°C for audio); DC32V(for video) 3. Structure 1 2 3 4 5 Screw Microphone Camera LED Light sensor 6 7 8 9 10 Speaker Name tag Call button Card reader Panel 11 11 Guard button 1 2 3 4 5 6 9 10 7 8 10 Door station Assistant panel 1x8 a. Produce a recangle groove as the installation size (104x214x50mm) on a suitable position and then fix the box in it with cements or screws(①). b. Take off the screws and then the frame(②). c. Put the rubber seal on the back of door panel(③). d. Put the door panel into the box and fix it with the screws(③) after connection. e. Put the frame on the door panel and fix it with the screws(②). 4. Installation ① ② ③ Frame Panel Seal Box Screws 5. Operation 5.1 Call indoor phones Push a call button on the door station. 5.2 Call the guard unit (if there is) Push the guard button as the following figure. 5.3 Release door with registered card Move the registered card over the card reader as the following figure. 2 Product podel numbers Sizes: L x W x D (mm) Exclusive featureshotos Model names Series m Model No.8 6. Door station list 240X120X58 JB-5000 L8-5002MGLC-IP(8)-8 JB-5000 L8-5002MLC-IP(8)-8 JB-5000 L8-5002MGC(8)-8 With card reader or without. With card reader and 4 call buttons With 2~4 call buttons XIMAN LEELEN TECHNOLOGY CO.,LTD. 65, SUNBAN SOUTH ROAD, JIMEI, XIAMEN, 361021 CHINA This appliance shall not be disposed together with the normal waste. It must be recycled. Atitude during operation below 2km. FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

MET Laboratories TCB - Samples Agent Authorization Letter 2015-10-19 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Most Technology Service Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Haoye Chen Position: Manager Company Name: Xiamen Leelen Technology Co., Ltd Address: 65 Sunban South Road, Jimei Industrial Zone, Xiamen, Fujian, China E-Mail: [email protected]

MET Laboratories TCB - Samples Long Term Confidentiality Request Letter 2015-10-19 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Door Station / JB-5000 L8-5002MGLC-IP(8)-8) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - e.g. Block diagram - e.g. SCH - e.g. Operational Description required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Name: Haoye Chen Position: Manager Company Name: Xiamen Leelen Technology Co., Ltd Address: 65 Sunban South Road, Jimei Industrial Zone, Xiamen, Fujian, China E-Mail: [email protected]

Model difference letter Oct. 19, 2015 Dear MET Reviewer, This is a new Application from Xiamen Leelen Technology Co., Ltd JB-5000 L8-5002MGLC-IP(8)-8, JB-5000 L8-5002MLC-IP(8)-8 and JB-5000 L8-5002MGC(8)-8 are identical in interior structure, electrical circuits, components and appearance, Only different in model name. Thank you for your cooperation! Yours sincerely, Signatory: Name: Haoye Chen Position: Manager Company Name: Xiamen Leelen Technology Co., Ltd Address: 65 Sunban South Road, Jimei Industrial Zone, Xiamen, Fujian, China E-Mail: [email protected]

No.: JB-5000 L8-5002MGLC-IP(8)-8 FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE No.: JB-5000 L8-5002MGLC-IP(8)-8 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE No.: JB-5000 L8-5002MGLC-IP(8)-8 TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE No.: JB-5000 L8-5002MGLC-IP(8)-8 PHOTO OF THE ENTIRE SAMPLE PHOTO OF THE ENTIRE SAMPLE

Label Label location

No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 1 INTERNAL PHOTO OF SAMPLE – 2 No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 3 INTERNAL PHOTO OF SAMPLE – 4 No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 5 INTERNAL PHOTO OF SAMPLE – 6 No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 7 INTERNAL PHOTO OF SAMPLE – 8 No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 9 INTERNAL PHOTO OF SAMPLE – 10 No.: JB-5000 L8-5002MGLC-IP(8)-8 INTERNAL PHOTO OF SAMPLE – 11

Report No.: MTE/DYY/A15091145 Page 1 of 16 TEST REPORT For Applicant : XIAMEN LEELEN TECHNOLOGY CO.,LTD Address : 65 Sunban South Road, Jimei Industrial Zone, Xiamen, China Product Name : Door Station Model Name : JB-5000 L8-5002MGLC-IP(8)-8 Series Model Name: : JB-5000 L8-5002MLC-IP(8)-8, JB-5000 L8-5002MGC(8)-8 Remark : Only difference in the model name. Brand Name : FCC ID : 2AFVB-L8500208 Report No. : MTE/DYY/A15091145 Date o f Issue : Sept. 10, 2015 Issued by :Most Technology Service Co., Ltd. Address : No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China Tel : 86-755-8602 6850 Fax : 86-755-26013350 The report consists 16 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The clien t should not use it to claim product endorsement by MOST. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Report No.: MTE/DYY/A15091145 Page 2 of 16 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY............................................................... 3 2. GENERAL INFORMATION................................................................................. 4 2.1 Product Information ................................................................................................................ 4 2.2 Objective ................................................................................................................................ 4 2.3 Test Standards and Results .................................................................................................... 5 2.4 Environmental Conditions....................................................................................................... 5 3. TEST METHODOLOGY ..................................................................................... 6 3. 1TEST FACILITY...................................................................................................................... 6 4. SETUP OF EQUIPMENT UNDER TEST ............................................................ 7 4.1 SETUP CONFIGURATION OF EUT....................................................................................... 7 4.2 TEST EQUIPMENT LIST........................................................................................................7 5. 47 CFR Part 15 C Requirements ...................................................................... 8 5.1.1 Applicable Standard ............................................................................................................ 8 5.1.2 Evaluation Criteria ............................................................................................................... 8 5.1.3 Result: Compliance. ............................................................................................................ 8 5.2 CONDUCTED EMISSION TEST ............................................................................................ 9 5.2.1Requirement......................................................................................................................... 9 5.2.2 Block Diagram of Test Setup ...............................................................................................9 5.2.3 Test procedure..................................................................................................................... 9 5.2.4 Test Result........................................................................................................................... 9 5.3 Radiated Emission ............................................................................................................... 10 5.3.1Requirement....................................................................................................................... 10 5.4.2 Test Configuration.............................................................................................................. 10 5.4.3 Test Procedure: ..................................................................................................................11 5.4.4 Test Result......................................................................................................................... 12 APPENDIX 1............................................................................................................................................................15 PHOTOGRPHS OF TEST SET ...............................................................................................................................15 Report No.: MTE/DYY/A15091145 Page 3 of 16 1. VERIFICATION OF CONFORMITY Equipment Under Test: Door Station Brand Name: Model Number: JB-5000 L8-5002MGLC-IP(8)-8 FCC ID： 2AFVB-L8500208 XIAMEN LEELEN TECHNOLOGY CO.,LTD Applicant: 65 Sunban South Road,Jimei Industrial Zone,Xiamen,China XIAMEN LEELEN TECHNOLOGY CO.,LTD Manufacturer: 65 Sunban South Road,Jimei Industrial Zone,Xiamen,China Technical Standards: 47 CFR Part 15 Subpart C section 15.225 File Number: MTE/DYY/A15091145 Date of test: Aug. 12-Sept. 07, 2015 Deviation: None Condition of Test Sample: Normal Test Result: PASS The above equipment was tested by Most Technology Service Co., Ltd. for compliance with the requirements set forth in FCC rules and the Technical Standards mentioned above. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment and the level of the immunity endurance of the equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Tested by (+ signature): Daisy Yu Aug. 12-Sept. 07, 2015 Review by (+ signature): Henry Chen Sept . 10, 2015 Approved by (+ signature): Yvette Zhou(Manager) Sept . 10, 2015 Report No.: MTE/DYY/A15091…

Text truncated - open the document above for the full version.

No.: JB-5000 L8-5002MGLC-IP(8)-8 RE TEST SETUP RE TEST SETUP
