2AFVB-L85002152nd-confirm door station

2. Technical specification 6.4.3 Structure Camera: Viewing angle: Lens: Resolution: Min. illumination: Video output: Audio SNR: Audio distortion: Standby current: Working current: Working voltage: Environment temperature: 1/3" CCD or CMOS 92° F=3.6 420TV Line 0.01 LUX 1Vp-p/75Ω ≥25dB ≤7% ≤60mA ≤230mA DC12V (for audio); DC32V (for video) -40°C～+45°C B) Model No.15 (Flush mount): LEDs Camera Light sensor Cast aluminium panel Speaker Name tag Call button Microphone Screw Screw Card reader inside Flush mount box A) Model No.15 (Surface mount): Rain shield(Surface mount bracket) LEDs Camera Light sensor Cast aluminium panel Speaker Name tag Call button Microphone Screw Card reader inside Surface mount bracket 1 L8 User’s Manual (2nd-confirm door stations) 1. Door stations Model No.15A surface mount 79X148X45(mm) Model No.15C flush mount 93X168X52(mm) Model No.15B surface mount, card reader. 79X148X45(mm) Model No.15D flush mount, card reader. 93X168X52(mm) 4. Installation A) Surface mount a. Take off the door panel from the bracket with the enclosed screw driver(). b. Fix the bracket on the wall with two screws and expansion plugs(). c. Put the door panel on the bracket and fix it after connect the cable(). ① ② ③ ① ② Bracket(rain shield) Door panel expansion plugs ③ Model No.15 B) Flush mount a. Produce a groove (75x150x50mm) on a proper position of the wall(). b. Take off the door panel from the box with the enclosed screw driver(). c. Fix the box in the groove with screws and expansion plugs(). d. Fix the door panel in the box with the screws(). ① ②③ ① ④ Door panel Box expansion plugs ② ① ③ 2 B. Use cards to release doors 5. Operation on door stations A. Call residents 6. 2nd-confirm door station list Product podel numbers Sizes: L x W x D (mm) Exclusive featureshotos Model names Series m 102X175X39 CALL MIC Model No.15A Model No.15B Model No.15C Model No.15D Model No.15E Model No.18 JB-5000 L8-5002MBGCW(8)-S15 JB-5000 L8-5002MBGCQ(8)-S15 JB-5000 L8-5002MBCNW(8)-S15 JB-5000 L8-5002MBCNQ(8)-S15 With name tag and surface mount With card reader and surface mount With card reader and flush mount With card reader and flush mount With name tag and flush mount 93X168X52 93X168X52 79X148X45 79X148X45 With keypad With keypad and card reader JB-5000 L8-5002MBCQ(8)-S18A JB-5000 L8-5002MBGCQ(8)-S18A 93×168×32 JB-5000 L8-5002MBCQ(8)-S15E XIMAN LEELEN TECHNOLOGY CO.,LTD. 65, SUNBAN SOUTH ROAD, JIMEI, XIAMEN, 361021 CHINA This appliance shall not be disposed together with the normal waste. It must be recycled. Atitude during operation below 2km. FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
