2AFXA-BT01Bluetooth Speaker

SoundBox V6 Dear valued customers thank you for choosing this product In order to better understand its performance and use it safely please read this user manual carefully before using. 1.Product Features 1.1 Support iPhone, iPad,HTCˈSamsung,laptops and other devices with Bluetooth function,easy to pair , Support the TF card MP3 format etc,easy to play music. 1.2 Built-in microphone for clear voice call. 1.3 Built-in (3.7V/1500mAh) lithium battery, Can be charged by connecting to PC via USB cable. 1.4 Built-in high quality loudspeaker to guarantee the perfect sound of playing music 1.5 Up to 8 hours of music play (Medium Sound Volume). 1.7 AUX in 3.5mm audio jack, ( Connected to other devices with the same 3.5mm audio output jack for music play). 1.8 NFC Fast matching ( Optional ) 1.9 APP for Andriod Phone ( BluetoothBox.apk ) download from Google Playstore 2.0 When the unit is connected to PC( off mode) and mp3 files could be downloaded into the unit. 2.1 Auto-off after disconnect 5 minute to any unnecessary energy loss 2.2 Low battery warning ( red led flash ) 2.Supplied Accessories 3.5mm stereo audio cable x1pc USB cable x1pc User Manual x1pc Backpack buckle x1pc 3.Technical Specifications Bluetooth Version: ATS2805B V4.0 Operation Range :10M Output Power˖3W+3W Frequency respond: 100Hz-20KHz Speaker system : 2 full range (40mm ) speakers + Passive low frequency radiator ( 95 x 30 mm) Battery Type: 3.7V 1500mAh Lithium(built in) Power Supply : DC5.0V USB Connecting Cable: 3.5mm Stereo Audio Cable Net Weight : 0.28kg Product Size: 65 x 50 x 160mm 4.Product Description 4.1 Power/MShort pause – Mode setting/Long pause –Power ON/OFF 4.2ُُ
Short pause – Next/Long pause – Volume increase 4.3
ඔٙShort pause – Previous/ Long pause – Volume reduce 4.4 Rotate volume Clockwise Volume increase/ Anti clockwise – Volume reduce 4.5ඖ

hand-freeShort pause – Play/pause (mp3 status) Short pause – Answer call / hang up (hand-free status) 5.Trouble Shooting 5.1 Cannot pair with Bluetooth Pls make sure the Bluetooth speaker is fully charged and can be searched 5.2 No Sound Pls check and make if it is fully charged and volume is not at the lowest. 5.3 Bluetooth speaker cannot be turned on Make sure the Bluetooth speaker is with Battery, Check the status of indicator light Audio Output Power 3W+3W FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - END-

FengShun Peiying Electro-Acoustic Co., Ltd No.8, Fengda Road, Tangkeng Town Ind. Area, Fengshun County, Guangdong, China DATE :2015-9 -11 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Hank Yan of Global United Technology Services Co., Ltd. 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District Shenzhen Guangdong (Name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with FengShun Peiying Electro-Acoustic Co., Ltd and No.8, Fengda Road, Tangkeng Town Ind. Area, Fengshun County, Guangdong, China Dated this / Day of 9/11/2015 / Agency agreement expiration date: 9/11/2016 By: Yiu Sang Li Signature Printed Title: Manager On behalf of : FengShun Peiying Electro-Acoustic Co., Ltd Telephone: +86-755-29799787

Differences Declaration To whom concern, We company FengShun Peiying Electro-Acoustic Co., Ltd hereby declares: The product model(s) V6, V7, V9, V10, V12 is identical in the same PCB layout, interior structure and electrical circuits with the model V1 which tested in Global Unit Technology Co., Ltd., the only differences are the model name for commercial purpose. Authorized signature: Date: 2015-9- 11

FengShun Peiying Electro-Acoustic Co., Ltd No.8, Fengda Road, Tangkeng Town Ind. Area, Fengshun County, Guangdong, China DATE 2015-9 -11 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFXA-BT01 Product Name: Bluetooth Speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this / Day of 9/11/2015 / By: Yiu Sang Li Signature Printed Title: Manager On behalf of : FengShun Peiying Electro-Acoustic Co., Ltd Telephone: +86-755-29799787

Label location

FengShun Peiying Bluetooth Speaker Model: V1 FCC ID: 2AFXA-BT01

FCC ID: 2AFXA-BT01 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) --- 3m So pt = (EXd) 2 /30 x gt Field strength = 95.42dBuV/m @3m Ant gain =2dBi, so Ant numeric gain= 1.58 So pt={ [10 (95.42/20) /10 6 x 3] 2 /30x1.58 }x1000 mW = 0.659mW So (0.659mW /5mm)x √2.480 = 0.208<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15090173601 FCC REPORT Applicant: FengShun Peiying Electro-Acoustic Co., Ltd Address of Applicant: No.8, Fengda Road, Tangkeng Town Ind. Area, Fengshun County, Guangdong, China Equipment Under Test (EUT) Product Name: Bluetooth Speaker Model No.: V1, V6, V7, V9, V10, V12 FCC ID: 2AFXA-BT01 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: September 02, 2015 Date of Test: September 06-10, 2015 Date of report issued: September 11, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. g RbiL Report No.: GTSE15090173601 2Version Version No.DateDescription 00September 11, 2015Original Prepared By: Date: September 11, 2015 Project Engineer Check By:Date: September 11, 2015 Reviewer Global United Technology Services Co., Ltd.Project No.: GTSE150901736RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 31 Report No.: GTSE15090173601 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 4.1 MEASUREMENT UNCERTAINTY............................................................................................................ 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................25 Global United Technology Services Co., Ltd.Project No.: GTSE150901736RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building…
