Attn: TIMCO Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Confidentiality Request regarding application for certification of FCC ID: 2AFYS-KLK915LOI Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Schéma_LoRa_Board_915MHz_V2A.pdf Schematics Schematics_SoP_3G_V3A.pdf Schematics Schematics_Wirgrid_Carte_Antenne_V2A.pdf Schematics Schematics_Wirgrid_Carte_Mere_Schema_V4B.pdf Part List / tune Up BOM_Carte_Antenne_V2A.pdf Part List / tune Up BOM_LoRa_Board_915MHz_V2A.pdf Part List / tune Up BOM_SoP_3G_V3A.pdf Part List / tune Up BOM_Wirgrid_Carte_Mere_V4B.pdf Operational description OpDes_IoT_station_915.pdf Operational description Brief_Des_LoRa_IoT_StationFCC.pdf Block diagram LORA IOT station block diagrams.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Internal photos IntPho.pdf User’s manual KERLINK_INSTALL_LoRa_IoT_Station_v2.pdf Sincerely, October 28th, 2015 By Mathieu DUMESNIL, EMITECH Radio Technical Manager (On behalf of Mr Yannick DELIBIE, KERLINK CTO)

Page 2 out of 2

Internal pictures of the LORA IOT STATION 915MHz General view of the opened LORA IOT Station: Note: dimensions of the enclosure are 231 x 126 x 60 mm Detail of the inside front panel: Note: dimensions of the enclosure are 231 x 126 x 60 mm Detail of the sticker, on door rear side: Note: dimensions of the enclosure are 231 x 126 x 60 mm Internal view when the PCB are removed: Note: dimensions of the enclosure are 231 x 126 x 60 mm View of the top side of the antenna PCB (K-0120-02) : View of the bottom side of the antenna PCB (K-0120-02) : Note: dimensions of the PCB are 107 x 50 mm. View of the bottom side of the LORA PCB (K-0121-05) : Detail of the bottom side of the LORA PCB (K-0120-02) : Note: dimensions of the PCB are 159,7 x 106,5 mm. View of the top side of the LORA PCB (K-0121-05) : Detail of the top side of the LORA PCB (K-0121-05), CPU area : Note: dimensions of the PCB are 159,7 x 106,5 mm. Detail of the top side of the LORA PCB (K-0121-05), power area : Detail of the top side of the LORA PCB (K-0121-05), radio area : Note: dimensions of the PCB are 159,7 x 106,5 mm. Note: dimensions of the shield are 44 x 30 mm. Detail of the top side of the LORA PCB (K-0121-05), radio area without shield : Note: dimensions of the PCB are 159,7 x 106,5 mm. Note: dimensions of the shield are 44 x 30 mm. View of the bottom side of the MOTHER PCB (K-0117-04) : Detail of the bottom side of the MOTHER PCB (K-0117-04), USIM connector area : Note: dimensions of the PCB are 159,7 x 106,5 mm. Detail of the bottom side of the MOTHER PCB (K-0117-04), external power supply area : Note: dimensions of the PCB are 159,7 x 106,5 mm. View of the top side of the MOTHER PCB (K-0117-04) : Note: dimensions of the PCB are 159,7 x 106,5 mm. Detail of the top side of the SOP3G PCB (K-0115-05) mounted on MOTHER PCB (K-0117-04) : Note: dimensions of the K-0117-04 PCB are 159,7 x 106,5 mm. Note: dimensions of the K-0115-05 PCB are 66 x 58 mm. Detail of the top side of the MOTHER PCB (K-0117-04), power area : Detail of the top side of the MOTHER PCB (K-0117-04), power area without shield : Note: dimensions of the PCB are 159,7 x 106,5 mm. Note : dimensions of the shield are 29,36 x 18.5 mm.

APPENDIX 1: Photos of the equipment under test RR051-15-103539-1-A Ed. 0 Page 2 out of 6 RR051-15-103539-1-A Ed. 0 Page 3 out of 6 RR051-15-103539-1-A Ed. 0 Page 4 out of 6 APPENDIX 2: Test set up Indoor test site RR051-15-103539-1-A Ed. 0 Page 5 out of 6 Outdoor test site RR051-15-103539-1-A Ed. 0 Page 6 out of 6 Conducted measurements

Siège Social : Emitech - 3, rue des Coudriers - Z.A. de l’Observatoire - 78180 MONTIGNY LE BX - France Siret : 344 545 645 00022 - Tél. : 33 (0)1 30 57 55 55 - Fax : 33 (0)1 30 43 74 48 - E-mail : [email protected] - URL : www.emitech.fr S.A. au capital de 1 560 000 € - R.C.S. VERSAILLES 344 545 645 - APE 7112B RR051-15-103539-1-A Ed. 0 Certification Radio test report According to the standard: CFR 47 FCC PART 15 Equipment under test: LoRa IoT Station 915MHz FCC ID: 2AFYS-KLK915LOI Company: KERLINK DISTRIBUTION: Mr GILBERT (Company: KERLINK) Number of pages: 87 with 7 appendixes Technical Verification and Ed. Date Modified Written by Quality Approval pages Name Visa Name Visa 0 22-SEPT-2015 Creation S. LOUIS T.LEDRESSEUR Duplication of this test report is only permitted for an integral photographic facsimile. It includes the number of pages referenced here above. This document is the result of testing a specimen or a sample of the product submitted. It does not imply an assessment of the conformity of the whole manufactured products of the tested sample. RR051-15-103539-1-A Ed. 0 Page 2 out of 87 DESIGNATION OF PRODUCT: LoRa IoT Station 915MHz Serial number (S/N): 0x8080011 Reference / model (P/N): LoRa IoT STATION 915 Software version: PROD_FW=wirmaV2_wirgrid_v2.1 MANUFACTURER: KERLINK COMPANY SUBMITTING THE PRODUCT: Company: KERLINK Address: 1, RUE JACQUELINE AURIOL 35235 THORIGNE-FOUILLARD FRANCE Responsible: Mr GILBERT DATES OF TEST: From 14 September 2015 to 23 September 2015 TESTING LOCATION: EMITECH ANGERS laboratory at JUIGNE SUR LOIRE (49) FRANCE 21 rue de la Fuye 49610 Juigne sur Loire France FCC Accredited under US-EU MRA Designation Number: FR0009 Test Firm Registration Number: 873677 TESTED BY: S. LOUIS / M.DUMESNIL RR051-15-103539-1-A Ed. 0 Page 3 out of 87 CONTENTS TITLE PAGE 1. INTRODUCTION ________________________________________________________________ 4 2. PRODUCT DESCRIPTION ________________________________________________________ 4 3. NORMATIVE REFERENCE ________________________________________________________ 5 4. TEST METHODOLOGY ___________________________________________________________ 5 5. TEST EQUIPMENT CALIBRATION DATES ____________________________________________ 6 6. TESTS AND CONCLUSIONS ______________________________________________________ 8 7. MEASUREMENT OF THE CONDUCTED DISTURBANCES ________________________________ 12 8. RADIATED EMISSION LIMITS ____________________________________________________ 16 9. MEASUREMENT OF THE CONDUCTED DISTURBANCES ________________________________ 18 10. ADDITIONAL PROVISIONS TO THE GENERAL RADIATED EMISSION LIMITATIONS __________ 33 11. MAXIMUM PEAK OUTPUT POWER _______________________________________________ 36 12. INTENTIONAL RADIATOR ______________________________________________________ 39 13. PEAK POWER DENSITY ________________________________________________________ 48 APPENDIX 1: Photos of the equipment under test APPENDIX 2: Test set up APPENDIX 3: Test equipment list APPENDIX 4: 6 dB bandwidth APPENDIX 5: 20 dB bandwidth APPENDIX 6: Band edge APPENDIX 7: Spectral density RR051-15-103539-1-A Ed. 0 Page 4 out of 87 1. INTRODUCTION This document presents the result of RADIO test carried out on the following equipment: LoRa IoT Station 915MHz in accordance with normative reference. The device under test integrates:  a multifrequencies wireless transceiver LoRa.  A GPS module already certified FCC and IC.  A 2G / 3G module (HUAWEII MU509c) already certified FCC and IC (FCCID: QISMU509C and IC Number: 6369A-MU509C). The applicant declares that the distance between the whip antenna for LoRa mode and integral antenna for GSM mode will be superior to 20cm. So collocation tests are limited: only measurement of the conducted disturbances are necessary and performed. The host device of certified modules shall be properly labeled to identify the module within. 2. PRODUCT DESCRIPTION Class: A Utilization: Tele transmission Antenna type and gain: External antenna 6dBi Operating frequency range: from 923.3MHz to 927.5MHz Number of channels: 8 Channel spacing: 600 kHz Modulation: LoRa Power source: 48Vdc via POE or solar panel (range 11Vdc to 30Vdc) The modulation plan in transmission (Downlink) is the following: SF BW (KHz) Débit (kbps) 7 500 21875 8 500 12500 9 500 7031 10 500 3906 11 500 2148 12 500 1172 The rates evaluated at the request of the applicant are: SF7 and SF12. Power level, frequency range and channels characteristics are not user adjustable. The details pictures of the product and the circuit boards are joined with this file. RR051-15-103539-1-A Ed. 0 Page 5 out of 87 3. NORMATIVE REFERENCE The standards and testing methods related throughout this report are those listed below. They are applied on the whole test report even though the extensions (version, date and amendment) are not repeated. CFR 47 FCC Part 15 (2015) Radio Frequency Devices ANSI C63.4 2009 Methods of measurement of Radio-Noise Emissions from low-voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C63.10 2009 Testing Unlicensed Wireless Devices. 558074 D01 DTS v03r02 Guidance for Performing Compliance on Digital Transmission Systems Operating under §15.247 4. TEST METHODOLOGY Radio performance tests procedures given in CFR 47 part 15: Subpart A –General Paragraph 19: labelling requirements Paragraph 21: information to user Subpart B –Unintentional Radiators Paragraph 105: information to the user Paragraph 107: Conducted limits Paragraph 109: Radiated emission limits Paragraph 111: Antenna power conduction limits for receivers Subpart C – Intentional Radiators Paragraph 203: Antenna requirement Paragraph 205: Restricted bands of operation Paragraph 207: Conducted limits Paragraph 209: Radiated emission limits; general requirements Paragraph 215: Additional provisions to the general radiated emission limitations Paragraph 247: Operation within the bands 902-928 MHZ, 2400-2483.5 MHz and 5725-5850 MHz RR051-15-10353…
