2AG2K-BV-031TXVIBRATING JEWEL PLUG

VIBRATING JEWEL PLUG USER GUIDE 23 GETTING STARTED 1. Before first use, charge your wand for approximately 1.5 - 2 hours. The USB charging cable can be plugged into any USB port or USB/ AC power adapter (not included). • Flashing Light = Charging. • Solid Light = Fully Charged. • Rapid Flashing Light = Low battery, charge is needed. 2. Wash your plug with soap and water or toy cleaner suitable for use with silicone items. 3. Lubricate your plug with a water based, silicone compatible lubricant. ENGLISH OVERVIEW b-Vibe TM products are made with silky smooth, body-safe silicone. Our products are phthalate-free and latex-free. The easy to use interface allows users to easily reach their desired stimulation and intensity level. Get ready for sensual satisfaction and exploration that will have you craving for more. Decrease Intensity Power Button Vibration Function Button Increase Intensity Pleasure Tip VIBRATING JEWEL PLUG S / M VIBRATING JEWEL PLUG M / L WIRELESS REMOTE CONTROL TOY CLEANER A A AA LUBE 4. Turn ON your plug by pressing A quickly at the bottom of your plug. The light will flash, indicating the power is on and in standby mode. Push A again to use the manual mode, or push A on the remote to pair the remote & plug. Once in use, the base light will change from flashing to solid. 5. To change the vibration pattern via the base control, press the A. Vibration intensity can only be increased via use of the remote control. 6. To change the vibration intensity via the remote control, press and release A (Increase Intensity) and A (Decrease Intensity). Press and release A to change the vibration pattern. Powerful Motor Power Button & LED Indicator Magnetic Charging Contact 45 1 2 MANUAL CONTROL 1. To turn the item ON quickly press A. The A will flash to indicate the power is on. Push again to change the vibration pattern. There are a total of 15 modes using the manual control. Vibration intensity can only be increased via use of the remote control. 2. To power OFF your plug press and hold A for 2 seconds. LED will turn off to indicate the power is OFF. REMOTE CONTROL 1. First turn your plug on in standby mode by quickly pressing A on your plug. 2. While the base light is flashing, power on your remote to pair the remote and plug. 3. Once the item is paired the base light will become solid and you can control your plug by remote. 4. Press and release A to increase vibration intensity. 5. Press and release A to decrease vibration intensity. 6. The vibration modes can be changed by pressing and releasing A. 7. To turn the item ON/OFF press and release A on the remote. 8. To completely turn off your plug, you must press and hold A on your plug. 1 2 3 1 2 3 4 5 TRAVEL LOCK All b-Vibe items include travel lock for safe and convenient travel. Via the remote: Simultaneously press and hold the A and A buttons for 3 seconds. Flashing light on the remote will indicate the item is locked. To unlock simply press and hold A and A again for 3 seconds. Flashing light will indicate lock is disabled. Via the plug: Hold A for 5 seconds, flashing light on the base of the plug will indicate the item is locked. For unlocking, hold A again for 5 seconds, flashing light will indicate the item is unlocked. Flashing light = Charging Solid light = Fully Charged CHARGING YOUR PLUG Attach the magnetic charging plug to the designated charging area on the base of the product. • Flashing light indicates item is charging. • Solid light indicates item is fully charged. • Rapid flashing indicates charging is required. 67 CHANGING YOUR REMOTE CONTROL BATTERY 1. Slide open the remote control battery compartment as shown. 2. Button cell CR 2032 has been preinstalled into the remote control. 3. Remove the paper slip inside the battery compartment to activate the power in the remote control. 4. Store the remote control and the battery separately to prolong the battery life. WARNING • Do not expose this product to fire or water. • Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. • Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas. • A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. • Do not attempt to disassemble the product yourself. Please contact after-sales service if there is an issue. • The battery used in this product is a non-chargeable battery. Do not try to charge it. • This product contains small parts such as battery, battery cover. The small parts are not toys, do not allow children to play with them to prevent the risk of suffocation. • Risk of safety issue if the battery is replaced by an incorrect type. • Replacement of a battery with an incorrect type that can defeat a safeguard. • Dispose of used batteries according to instructions. • Do not ingest battery. Chemical Burn Hazard! • This product contains a coin/ button battery. If the coin/ button cell is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. • Keep new and used batteries away from children. • If the battery compartment does not close securely, stop using the product and keep it away from children. SPECIFICATIONS ModelVibrating Jewel Plug S / M Vibrating Jewel Plug M / L MaterialBody Safe Silicone Height98 mm106 mm Diameter37 mm40 mm Weight68 g85 g Battery200 mAh350 mAh Charging Time90 mins120 mins Usage Time90 mins90 mins Interface Single Button & Manual Control 4 Button Remote Control 89 VIBRATING MODES • There are 6 vibration intensities. • There are 15 vibration modes, explained below: Vibration Intensity Vibration Pattern Vibration Pattern 1 Vibration Pattern 8 Vibration Pattern 7 Vibration Pattern 6 Vibration Pattern 5 Vibration Pattern 4 Vibration Pattern 3 Vibration Pattern 2 Vibration Pattern 9 Vibration Pattern 15 Vibration Pattern 14 Vibration Pattern 13…

Text truncated - open the document above for the full version.

A&H Design Group, Ltd. Family models declaration letter. 2021-04-12 We A&H Design Group, Ltd. Of 6/F, Room 601, Liby Center, Liwan District, No.2 Luju Road, Guangzhou, Guangdong, China Product: VIBRATING JEWEL PLUG Model Name: BV-031 BLK Serial Model: BV-030 FUC, BV-030 TL, BV-031 GRN All the model are the same circuit and RF module, except the model No. and colour. Sincerely, Signature 2021-04-12 Name: Moms Liu Title:Manager

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 (TX) Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

Transmitter label： A&H Design Group, Ltd. Model No.: BV-031 BLK Rated: 3.0V (Use CR2030 button cell 1× ) FCC ID: 2AG2K-BV-031TX Made in China

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 TX ANT

Report No.: S21020302203001 ` Page 1 of 28 RADIO TEST REPORT FCC ID: 2AG2K-BV-031TX Product: VIBRATING JEWEL PLUG Trade Mark: N/A Model No.: BV-031 BLK Family Model: BV-030 FUC, BV-030 TL, BV-031 GRN Report No.: S21020302203001 Issue Date: 10 Mar. 2021 Prepared for A&H Design Group, Ltd. 6/F, Room 601, Liby Center, Liwan District, No.2 Luju Road, Guangzhou, Guangdong, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel.: +86-755-6115 6588 Fax.: +86-755-6115 6599 Website:http://www.ntek.org.cn Report No.: S21020302203001 ` Page 2 of 28 Table of Contents Page 1. TEST RESULT CERTIFICATION 4 2. SUMMARY OF TEST RESULTS 5 3. FACILITIES AND ACCREDITATIONS 6 3.1 FACILITIES 6 3.2 LABORATORY ACCREDITATIONS AND LISTINGS 6 3.3 MEASUREMENT UNCERTAINTY 6 4. GENERAL DESCRIPTION OF EUT 7 5. DESCRIPTION OF TEST MODES 9 6. SETUP OF EQUIPMENT UNDER TEST 10 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM 10 6.2 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 7. ANTENNA REQUIREMENT 13 7.1 STANDARD REQUIREMENT 13 7.2 EUT ANTENNA 13 8. CONDUCTED EMISSION MEASUREMENT 14 8.1 APPLICABLE STANDARD 14 8.2 CONFORMANCE LIMIT 14 8.3 MEASURING INSTRUMENTS 14 8.4 TEST CONFIGURATION 14 8.5 TEST PROCEDURE 14 8.6 TEST RESULTS 15 9. RADIATED EMISSION MEASUREMENT 16 9.1 APPLICABLE STANDARD 16 9.2 RADIATED EMISSION LIMITS ( FCC 15.209 ) 16 9.3 TEST PROCEDURE 18 9.4 TEST SETUP 20 9.5 TEST RESULTS 21 10. BANDWIDTH TEST 26 10.1 TEST PROCEDURE 26 10.2 DEVIATION FROM STANDARD 26 10.3 TEST SETUP 26 10.4 TEST RESULTS 27 Report No.: S21020302203001 ` Page 3 of 28 Table of Contents Page 11. TRANSMITTER TIMEOUT 28 11.1 REQUIREMENTS 28 Report No.: S21020302203001 ` Page 4 of 28 1. TEST RESULT CERTIFICATION Applicant’s name ......................... : A&H Design Group, Ltd. Address ....................................... : 6/F, Room 601, Liby Center, Liwan District, No.2 Luju Road, Guangzhou, Guangdong, China Manufacturer's Name .................. : TOPARC TECHNOLOGY (SHENZHEN) CO.,LTD. Address ....................................... : 101 And 1-4 Floors Of Workshop No. 23-1 Longteng Road, Baoan Community, Yuanshan Street, Longgang Shenzhen, CHINA Product description Product name .............................. : VIBRATING JEWEL PLUG Model and/or type reference ..... : BV-031 BLK Family Model ............................... : BV-030 FUC, BV-030 TL, BV-031 GRN Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 15, Subpart C ANSI C63.10-2013 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test : 04 Feb. 2021 ~ 08 Mar. 2021 Testing Engineer : (Allen Liu) Technical Manager : (Jason Chen) Authorized Signatory : (Alex Li) Report No.: S21020302203001 ` Page 5 of 28 2. SUMMARY OF TEST RESULTS FCC Part15 (15.231), Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.231(b) 15.209 15.205 Radiated Spurious Emission Pass 15.231(c) Occupied Bandwidth Pass 15.231(a)(1) Transmitter Timeout Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. (2) The EUT is using a new battery Report No.: S21020302203001 ` Page 6 of 28 3. FACILITIES AND ACCREDITATIONS 3.1 FACILITIES All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 3.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Certificate Registration Number is L5516. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Test Firm Registration Number: 463705. Designation Number: CN1184 A2LA-Lab. The Certificate Registration Number is 4298.01 Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 3.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.80dB 2 RF power, conducted ±0.16dB 3 Spurious emissions, conducted ±0.21dB 4 All emissions, radiated(30MHz~1GHz) ±2.64dB 5 All emissions, radiated(1GHz~6GHz) ±2.40dB 6 All emissions, radiated(＞6GHz) ±2.52dB 7 Temperature ±0.5°C 8 Humidity ±2% Report No.: S21020302203001 ` Page 7 of 28 4. GENERAL DESCRIPTION OF EUT Equipment VIBRATING JEWEL PLUG Trade Name N/A Model Name BV-031 BLK Family Model BV-030 FUC, BV-030 TL, BV-031 GRN Model Difference All the model are the same circuit and RF module, except the model No. and colour. Product Description The EUT is a VIBRATING JEWEL PLUG Operation Frequency: 433.92MHz Modulation Type: ASK Number Of Channel 1CH Antenna Designation: PCB Antenna Antenna Gain: 1dBi Field Strength: 73.62dBuV/m Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of…

Text truncated - open the document above for the full version.

Radiated Measurement Photos
