2AG2K-OUT271Remote control rose butt plug

A&H Design Group, Ltd. 2.911 (d)(7)USA Agentv1.3 Section 2.911(d)(7) USA Agent for Service of Process Company name: A&H Design Group, Ltd. Address: Suite 608, Tower One, Harbour Centre1 Hok Cheung Street, Hung Hom, Kowloon Hong Kong, China Product Name: Remote control rose butt plug FCC ID: 2AG2K-OUT271 Model(s): OUT271 2.911(d)(7) USA Designated Agent for Service of Process We, [A&H Design Group, Ltd.] (“the applicant”) designate [Electric EEL Inc] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later.

FCC ID LABEL: Ca. 3mm x 10mm Label Location FCC ID: 2AG2K-OUT271

FCC RF Exposure EUT Description: Remote control rose butt plug Model No.: OUT271 FCC ID: 2AG2K-OUT271 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]·[√ f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation 2477MHz: EIRP(dBm)=100.29dBuV/m)-95.2=5.09dBm) Frequency (MHz) Output power (dBm) Tune Up Power (dBm) Max Tune Up power dBm/mW Min test separatio n distance mm Result Limit (mW/cm 2 ) SAR Test Exclusion 2477 5.09 4.5±1 5.5/3.55 5 1.11685 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2406123071-E, antenna gain= 0dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine RF Exposure test exclusion. The test exclusion threshold is 1.11685 which is<= 3, RF Exposure testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f (GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

1 ITEM Model Name Center Frequency MAX.GAIN Polarization Azimuth Beam Pattern Impedance Antenna Length Omni-directional 42.835mm Tested Products. Antenna 1:PCB antenna. Frequency=2407MHz - 2477MHZ Manufacturer:Quanfengtechnologyco.Ltd. Product:PCB antenna SPEC. PCB antenna 2440 MHz 0dbi Linear, Vertical QF-156天线规格

Page 1 of 27 Report No.: HK2406123071-E FCC Test Report Test report On Behalf of A&H Design Group, Ltd. For Remote control rose butt plug Model No.: OUT271 FCC ID: 2AG2K-OUT271 Prepared For : A&H Design Group, Ltd. Suite 608, Tower One, Harbour Centre1 Hok Cheung Street, Hung Hom, Kowloon Hong Kong, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Jun. 12, 2024 ~Jul. 19, 2024 Date of Report: Jul. 19, 2024 Report Number: HK2406123071-E Page 2 of 27 Report No.: HK2406123071-E Test Result Certification Applicant’s name ................. : A&H Design Group, Ltd. Address ................................. : Suite 608, Tower One, Harbour Centre1 Hok Cheung Street, Hung Hom, Kowloon Hong Kong, China Manufacture's Name ............ : A&H Design Group, Ltd. Address ................................. : Suite 608, Tower One, Harbour Centre1 Hok Cheung Street, Hung Hom, Kowloon Hong Kong, China Product description Trade Mark: N/A Product name ........................... : Remote control rose butt plug Model and/or type reference : OUT271 Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Jun. 12, 2024 ~Jul. 19, 2024 Date of Issue ........................................... : Jul. 19, 2024 Test Result .............................................. : Pass Testing Engineer : (Len Liao) Technical Manager : (Sliver Wan) Authorized Signatory : (Jason Zhou) Page 3 of 27 Report No.: HK2406123071-E Table of Contents Page 1 . Test Summary 5 1.1 . Test Procedures and Results 5 1.2 . Information of the Test Laboratory 5 1.3 . Measurement Uncertainty 5 2 . General Information 6 2.1 . General Description of EUT 6 2.2 . Operation of EUT During Testing 7 2.3 . Description of Test Setup 8 2.4. Description of Support Units 9 3 . Conducted Emissions Test 11 3.1. Conducted Power Line Emission Limit 11 3.2. Test Setup 11 3.3. Test Procedure 11 3.4. Test Result 12 4. Radiated Emission Test 13 4.1. Radiation Limit 13 4.2. Test Setup 13 4.3. Test Procedure 14 4.4. Test Result 14 5. Band Edge 20 5.1. Limits 20 5.2. Test Procedure 20 5.3. Test Result 21 6. Occupied Bandwidth Measurement 23 6.1. Test Setup 23 6.2. Test Procedure 23 6.3. Measurement Equipment Used 23 6.4. Test Result 23 7. Antenna Requirement 25 8. Photograph of Test 26 9. Photos of the EUT 27 Page 4 of 27 Report No.: HK2406123071-E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Jul. 19, 2024 Jason Zhou Page 5 of 27 Report No.: HK2406123071-E 1. Test Summary 1.1. Test Procedures and Results DESCRIPTION OF TEST SECTION NUMBER RESULT CONDUCTED EMISSIONS TEST 15.207 N/A RADIATED EMISSION TEST 15.249(a)/15.209 COMPLIANT BAND EDGE 15.249(d)/15.205 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT 15.215（c） COMPLIANT ANTENNA REQUIREMENT 15.203 COMPLIANT 1.2. Information of the Test Laboratory Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 27 Report No.: HK2406123071-E 2. General Information 2.1. General Description of EUT Equipment: Remote control rose butt plug Model Name: OUT271 Series Model: N/A Model Difference: N/A FCC ID: 2AG2K-OUT271 Antenna Type: PCB Antenna Antenna Gain: 0dBi Operation frequency: 2407-2477MHz Number of Channels: 27CH Modulation Type: GFSK Power Source: DC 3V From Battery Power Rating: DC 3V From Battery Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Antenna gain Refer to the antenna specifications. 3. The cable loss data is obtained from the supplier. 4. The test results in the report only apply to the tested sample. Page 7 of 27 Report No.: HK2406123071-E 2.1.1. Carrier Frequency of Channels Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 1 2407 10 2435 19 2467 2 2408 11 2436 20 2468 3 2409 12 2437 21 2469 4 2410 13 2438 22 2470 5 2411 14 2439 23 2471 6 2412 15 2440 24 2472 7 2413 16 2441 25 2473 8 2414 17 2442 26 2474 9 2421 18 2447 27 2477 2.2. Operation of EUT During Testing Operating Mode The mode is used: Transmitting mode Low Channel: 2407MHz Middle Channel: 2440MHz High Channel: 2477MHz Page 8 of 27 Report No.: HK2406123071-E 2.3. Description of Test Setup Operation of EUT during testing: The sample was placed (0.8m below 1GHz, 1.5m above 1GHz) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying an…
