2AG7C-BABY7TBaby Monitor

QUICK GUIDE ORIGINALITY DESIGN SMART - AND BEAUTIFUL Baby Monitor 1 USB cable x 2 Camera Screws Manual Please consult this checklist for all parts. What's in the box Bracket Power adapter x 2 Display Reset pin 2 Description Microphone Status light of charging Status light of using Zoom in/out Menu Direction OK Call Back Speaker Microphone Type-C Status light Reset SD card slot Micro USB DC 5V/1A Capture sound for your video Support local SD Card storage (Max.128G) Long press the camera pairing button to pair with the display Microphone SD card slot Reset Pairing Status light Solid red light on: network is malfunctional Blinking red light: wait for network connection (slowly blinking) connecting the network (fast blinking) Solid blue light on: camera is working correctly Press and hold for 5 seconds with pin to reset the camera (if you have modified settings, they will return to factory defaults) Temperature and humidity sensor Pairing 3 Micro USB DC 5V/1A Orange light: Charging Green light: Fully charged Yellow light: The display is on No light: The display is off Capture sound for your video Adjust the angle to get better signals Long press 5 seconds to turn on and turn off the display Zoom the image in 1X, 2X or 4X On homepage, press to enter the menu interface; On homepage, long press to enter the setting interface Control the rotation directions; select the menu items Confirm Make a call after pressing the button Support local SD Card storage (Max.128G) Press with pin to reset the display Press to back up; On homepage, long press to stop playing music Microphone Antenna ON/OFF button Menu Description Speaker ON/OFF button Antenna Screen holder SD card slot Reset Type-C Status light of charging Status light of using Zoom in/out Direction OK Call SD card slot Reset Back 4 Installation 2 Put the camera on a clean and flat surface. 2 Use the included mounting bracket to fix the camera to a clean surface. Connect the camera to the App 5 Connection The camera can be connected both to the monitor and the App. Generally, it is connected to the monitor by default. Follow the steps below to connect the camera to the App: 1. Make sure the Wi-Fi network is a 2.4 GHz network, as the camera doesn't support 5 GHz Wi-Fi. 2. Download the corresponding App on your phone. Register a new account to log in or log in directly. 3. Reset the camera using a pin until the status light is red in fast blinking. (You have to connect the camera to the App within 2 minutes; otherwise, you have to reset the camera again.) (If you are using the monitor, the audio and video will be temporarily disconnected, and will automatically resume after the camera is successfully configured with the network. The maximum time is 2 minutes.） 4. Follow the step instructions on your smart phone to add the monitor, and scan the QR code with your camera. App Download The App is available for both iOS and Android OS. Scan the QR code or search "CloudEdge" at App Store and Google Play. Download and install the App at your phone. You can select the App according to needs. iPadAndroidiOS ·Support Download App(iOS&Android) Connect the camera to the monitor Disconnect the camera to the monitor: 1. Press Menu button on the monitor screen, and select > Camera Management. 2. Long press OK button on the monitor screen to release the binding. Reconnect the camera to the monitor: 1. Press Menu button on the monitor screen, and select > Camera Management. 2. Long press the camera pairing button until you hear the prompt tone. 3. Press OK button on the monitor screen to start pairing. Power on the camera and the monitor, and then the camera will connect to the monitor automatically. The connection is distance limited, so make the distance between the camera and the monitor is no more than 200m. UnbindBind Connection 2.4GHz5GHz 6 Set up router Please keep network available The router supports the 2.4GHz WiFi (doesn't support the 5GHz), and is connected to the WiFi network. Please set the parameters of the router before connecting the WiFi network, and record the SSID and password of your WiFi. 7 Photo & video Usage Take a photo: You can take a photo when you want to capture an interesting scene of baby. Press Menu button on the monitor screen, select and press OK to take a photo. Record a video: You can record a video when you want to capture a meaningful time of baby. Press Menu button on the monitor screen, select and press OK to record. View the taken photos and recorded videos: 1. Press Menu button on the monitor screen, select and press OK to enter the interface. 2. Select the camera and date, select the photo or video you want to view, and press OK to enter preview mode. * For a video, press OK to play or pause in the preview mode. * Press backup button to quit preview or return to main menu. Rotate the camera You can adjust the monitoring angle for a better vision. The direction buttons on the monitor screen are available when the camera is powered on. Press direction buttons to rotate the camera horizontally and vertically, for a better vision. 8 Play music Feeding reminder Remind you to feed your baby, when you are too busy, or when you want to give your baby a regular diet. Usage 1. Press Menu button on the monitor screen, and select > Feeding Reminder. 2. Press UP and DOWN direction buttons to select between 4 time options, and press OK to start time setting. 3. When start to set up one feeding time, press LEFT and RIGHT direction buttons to change options between hour, minute, second and on/off; and press UP and DOWN direction buttons to change values and select on or off. 4. Press OK to save settings. 5. Select on or off to open or close feeding reminders. You can set up to 4 feeding times one day. And when the set time is up, a feeding alarm will appear on the monitor screen. You can play music to sooth your baby when baby is crying or sleeping. There are various soft music to select. Press Menu button on the monitor screen, select an…

Text truncated - open the document above for the full version.

Hangzhou Meari Technology Co., Ltd. Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both [TianHeng Consulting, LLC] (“Agent”) and [Hangzhou Meari Technology Co., Ltd.] (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I [Zhiyang Chai] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC if there is any change in the status identified above. Applicant Company Name : Hangzhou Meari Technology Co., Ltd. Contact Name : Zhiyang Chai Address : Room 604-605,Building 1,No.768 Jianghong Road,Changhe street,Binjiang District,Hangzhou,zhejiang,China Telephone No : +86 - 571 - 56565099 Email : [email protected] Signature: ____________________________________ Date: ___02/15/2023_______ I, Hualing Dong, HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to all certification applications to the FCC submitted by above applicant during the period of this agreement which ends at the specified date below. I agree to immediately notify the FCC if there is change in this representation. This current agreement term is one year. Agent Company Name : TianHeng Consulting, LLC FRN : 0033401258 Contact Name : Hualing Dong Address : 392 Andover Street, Wilmington, MA 01887, United States Telephone No : +1 617-997-4010 Email : [email protected] Signature: ____________________________________ Issue Date: February 15, 2023 Expiry Date: February 15, 2024 FRN 0025181900 :

HangzhouMeariTechnologyCo.,Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.5.16 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filling FCC ID: 2AG7C-BABY7T Hangzhou Meari Technology Co., Ltd. Certifies that, as of the date of the filling of the application, the applicantis notidentified on the Covered List as an entity producing “covered” equipment. Sincerely, Grantee Contact’s Signature Zhiyang Chai Printed name

HangzhouMeariTechnologyCo.,Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.5.16 Ref: Attestation Statements Part 2.911(d)(5)(i) Filling FCC ID: 2AG7C-BABY7T Hangzhou Meari Technology Co., Ltd. Certifies that the equipment for which authorization is soughtis not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Grantee Contact’s Signature Zhiyang Chai Printed name

Confidentiality Request Letter For Certification Service in the USA FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 Towhomitmayconcern PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)andSection §552(b)(4)oftheFreedomofInformationAct,werequestconfidentialityforthe documentationofthefollowingproducts: FCC ID 2AG7C-BABY7T Model name Baby 7S,Baby 7T, Baby 7Q, Speed 21S, Speed 21T Fortheproductslistedabove,werequestpermanentconfidentialityforallapplicable exhibitsasthereare:  theOperationalDescription  theBlockDiagram theSchematics Theabovelistedexhibitscontaintradesecretsandproprietaryinformationthatcouldbeof benefittoourcompetitors. Ifyouhaveanyquestions,pleasefeelfreetocontactusattheaddressshownbelow. Sincerely, Signature 2023-5-16 Date PrintedNameofSignee: Company:HangzhouMeariTechnologyCo.,Ltd. Address: Room604-605,Building1,No.768JianghongRoad,Changhestreet,Binjiang District,Hangzhou,zhejiang ， China Phone: +8615869048127 Email:[email protected]

ModelDeclarationLetter We,theundersigningcompany CompanyName:HangzhouMeariTechnologyCo.,Ltd. Address:Room604-605,Building1,No.768JianghongRoad,Changhestreet,Binjiang District,Hangzhou,zhejiang，China Herebyconfirmthatthefollowingproducts: Tha Product description: Baby Monitor Type designation:Baby 7S,Baby 7T, Baby 7Q, Speed 21S, Speed 21T t Date: 2023-5-16 Name: Zhiyang Chai Telephone: +8615869048127 E-mail: [email protected] PCB board,structure and internal of these model(s) are the same,Only the model name different, So no additional models were tested. Signature: FCC ID: 2AG7C-BABY7T

Report No.: GTS20230227015-1-15 Page 33 of 43 6. E X T E R N A L A N D I N T E R N A L P H O T O S O F T H E EUT Fig. 1 Fig. 2 Report No.: GTS20230227015-1-15 Page 34 of 43 Fig. 3 Fig. 4 Report No.: GTS20230227015-1-15 Page 35 of 43 Fig. 5 Fig. 6 Report No.: GTS20230227015-1-15 Page 36 of 43 Fig. 7 Fig. 8 Report No.: GTS20230227015-1-15 Page 37 of 43 Fig. 9 Fig. 10

Labellocation

Report No.: GTS20230227015-1-15 Page 38 of 43 Fig. 11 Fig. 12 SRD Antenna Report No.: GTS20230227015-1-15 Page 39 of 43 Fig. 13 Fig. 14 Report No.: GTS20230227015-1-15 Page 40 of 43 Fig. 15 Fig. 16 Report No.: GTS20230227015-1-15 Page 41 of 43 Fig. 17 Fig. 18 WLAN Antenna Report No.: GTS20230227015-1-15 Page 42 of 43 Fig. 19 Fig. 20 Report No.: GTS20230227015-1-15 Page 43 of 43 Fig. 21 Fig. 22 .......................End of Report........................

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No...................... : FCC ID. ............................................ : GTS20230227015-1-17 2AG7C-BABY7T Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : May.16, 2023 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Hangzhou Meari Technology Co., Ltd. Address ............................................ : Room 604-605, Building 1, No.768 Jianghong Road, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Test specification ........................... : Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Baby Monitor Trade Mark ....................................... : N/A Manufacturer .................................... : Hangzhou Meari Technology Co., Ltd. Model/Type reference ...................... : Baby 7S Listed Models .................................. : Baby 7T, Baby 7Q, Speed 21S, Speed 21T Hardware Version ............................ : BABY7S-T3MB-GC1-REV1_1 Software Version .............................. : ppstrong-c92-m_general_baby_sta-5.5 Rating ............................................... : DC 5.0V/1.0A by Adapter Result ............................................... : PASS Report No.: GTS20230227015-1-17 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20230227015-1-17 May.16, 2023 ______________________________________________________________________________________________ Date of issue Equipment under Test : Baby Monitor Model /Type : Baby 7S Listed model : Baby 7T, Baby 7Q, Speed 21S, Speed 21T Applicant : Hangzhou Meari Technology Co., Ltd. Address : Room 604-605, Building 1, No.768 Jianghong Road, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Manufacturer : Hangzhou Meari Technology Co., Ltd. Address : 4F of Building 1 and 2-4F of Building 2, No. 91 Chutian Road, Xixing Street, Binjiang District, Hangzhou,Zhejiang,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20230227015-1-17 Page 3 of 11 Contents 1. SUMMARY ................................................................................................................................................................. 4 1.1 EUT CONFIGURATION ........................................................................................................................................................ 4 1.2 PRODUCT DESCRIPTION ..................................................................................................................................................... 4 2. TEST ENVIRONMENT ................................................................................................................................................. 5 2.1 ADDRESS OF THE TEST LABORATORY ..................................................................................................................................... 5 2.2 TEST FACILITY .................................................................................................................................................................. 5 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .................................................................................................................. 5 3. METHOD OF MEASUREMENT .................................................................................................................................... 6 3.1 APPLICABLE STANDARD ...................................................................................................................................................... 6 3.2 REQUIREMENT ................................................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ............................................................................................................................................. 7 3.5 ANTENNA INFORMATION .............................................................................................................................…

Text truncated - open the document above for the full version.

上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 1 页共 12 页 1 客户承认书 SPECIFICATIONFORAPPROVAL CUSTOMER/PROJECT客户/机型：觅睿 CUSTOMERP.N./客户物料号： PRODUCTNAME./物料名称：内置天线 MODELNO./物料型号：26B009A SPECIFICATION/物料规格： VERSION 版本 DATE 日期 REVISIONDESCRIPTION 修订说明 T:A2022/3/21新增 CUSTOMERAUTHORIZEDSIGNATURE/客户承认签核 项目质量 Pleasereturntousonecopyof“SPECIFICATIONFORAPPROVAL”withyour approvedsignature.//客户确认签字，盖章后请回传一份承认书给我司. ADD:No.358LiuyuanRD.,BaoshanUrbanIndustrialDistrict.,Shanghai,PR.China. 地址：上海市宝山城市工业园区柳园路 358 号 2 号楼 1 楼 TEL:+86-21-66276925(26/29/35) － 615 SUPPLIERAUTHORIZEDSIGNATURE/供应商承认签核 制作/PREPARED审核/CHECKED批准/APPROVED 肖文珍 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 2 页共 12 页 2 目录 TUUTU目录U ...................................................................................................................................... 1 UTU 1 UUUT 名词解释 U .................................................................................................................................. TU 4 TUUTU 2 U 测试设备 .................................................................................................................................. TUTU 4 TUTU 3 UU 适用频段 TT .................................................................................................................................. 4 UTU 4 UUUUUU 基本测试项目 UUUUTTTTTTTT ...................................................................................................................... 5 TU 4.1 UTT 驻波比图 ....................................................................................................................... 5 TU4.2史密斯阻抗图U .............................................................................................................. 5 U4.3UTU辐射方向图UU ................................................................................................................... 5 4.4 TTTU 增益和效率 UUUTTTTTT ................................................................................................................. 5 5 UTT 测试指标和数据图表 UUUUTTTT ............................................................................................................ 5 UTU 5.1 UUTTTTT 驻波比 TTT .................................................................................................................. 5 UTU5.1.1UUUUUUUUT驻波比图UUUUUTTTTTTT ...................................................................................................... 5 U5.1.2UUUUUUUU驻波比数据UUUUUUUUTTTTTTTTTTTTTTTT ................................................................................................ 6 5.2UUU史密斯阻抗圆图UUUUTTTTT ......................................................................................................... 6 5.3UUT辐射方向图UUUTTT .................................................................................................................. 7 UTU 5.3.1 UUTU H-plane UUUTTTT ............................................................................................................. 7 5.3.2 UTUTU E-plane UUUUTTTT .......................................................................................................... 8-9 TU5.4TTU增益和效率UUUU ................................................................................................................ 10 TUTUTU6UUUUTTT环境处理建议UUT ..................................................................................................................... 10 TU7TTTT阻抗匹配要求UUUU ....................................................................................................................... TT10 UTUTUTU 8 UUTTTT 天线外形图 UUUT ......................................................................................................................... 11 TUTU 8.1 UUUUUUUU 天线尺寸图 UUUUUTTTTTTTT ........................................................................................................... 11 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 3 页共 12 页 3 UTU8.2UUUUUUUUT馈线尺寸图UUUUUUUUTTTTTTTTTTT .......................................................................................................... 11 8.3射频端尺寸图 UUUUUUUTTT .......................................................................................................... 11 9 UUUUTTT 天线安装指导 UUUUU ...................................................................................................................... 12 UTU 9.1 UUU 天线安装说明 UUUUUUUTTTT ......................................................................................................... 12 UTU 9.2 UUUUUUU 馈线走线说明 UUUUUTTTTTTTT ........................................................................................................ 12 10其它...........................................................................................................................................12 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 4 页共 12 页 4 1 名词解释 dBiDecibelrelativeisotropicantenna TxTransmitfrequency RxReceivefrequency TRPTotalRadiatedPower TISTotalIsotropicSensitivity VSWRVoltageStandingWaveRatio GSMGlobalServiceforMobilecommunication DCSDigitalCommunicationSystem CDMACodeDivisionMultipleAccess WCDMAWidebandCodeDivisionMultipleAccess 2测试设备 可根据实际情况自行增减 矢量网络分析仪 综合测试仪 SATIMO64位暗室 3适用频段 将适用的频段用其他颜色标出。 制式/band上行/uplink下行/downlink GSM800824MHz～896MHz824MHz～896MHz GSM900890MHz～915MHz935MHz～960MHz DCS18001710MHz～1785MHz1805MHz～1880MHz PCS19001850MHz～1910MHz1930MHz～1990MHz CDMA800825MHz～835MHz870MHz～880MHz WCDMA900880MHz～915MHz925MHz～960MHz WCDMA21001920MHz～1980MHz2110MHz～2170MHz NB-B5824MHz～896MHz824MHz～896MHz NB-B8890MHz～915MHz935MHz～960MHz 868M-915M868M-915M 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 5 页共 12 页 5 4 基本测试项目 4.1驻波比图 4.2史密斯阻抗图 4.3辐射方向图 4.4增益和效率 5 测试指标和数据图表 5.1驻波比 5.1.1驻波比图 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载 第 6 页共 12 页 6 5.1.2驻波比数据/VSWRdata Fre…

Text truncated - open the document above for the full version.

ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 1 / 14 SPECIFICATIONFORAPPROVAL CUSTOMER/PROJECT ： CUSTOMERP.N ： PRODUCTNAME ： WIFIANT MODELNO ： 26B007A-41 SPECIFICATION ： Pleasereturntousonecopyof“SPECIFICATIONFORAPPROVAL”withyour approvedsignature. ADD:No.358LiuyuanRD.,BaoshanUrbanIndustrial District.,Shanghai,PR.China. TEL:+86-21-66276925(26/29/35)－615 SUPPLIERAUTHORIZEDSIGNATURE PREPAREDCHECKEDAPPROVED WDH CUSTOMERAUTHORIZEDSIGNATURE PMQE ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 2 / 14 Content TUTUcontentUUTT.................................................................................................................................1 TUTU 1 UUTTU Nounexplanation.....................................................................................................................4 TUTU 2 UUTT Testequipment UUTT ........................................................................................................................4 TUTU 3 UUTT Workingfrequencyband UUT .....................................................................................................4 TUTU 4 UUTT Testproject...............................................................................................................................5 TUTU 4.1 UUTTTUTU VSWRplot UUTT ................................................................................................................5 TUTU4.2UUTTTUTUSimthplotUUTT..................................................................................................................5 TUTU4.3UUTUTURadiationpatternUUTT.......................................................................................................5 TUTU 4.4 UTUTU Gain&Efficiency.......................................................................................................5 TUTU 5 UUTT Antennaparameter...................................................................................................................5 TUTU 5.1 UUTTTUTU VSWR UUTT ......................................................................................................................5 TUTU5.1.1UUTTTUTUVSWRplotUUTT....................................................................................................5 TUTU5.1.2UUTTUTUVSWRdataUUTT.....................................................................................................6 TUTU5.2UUSimthplotUUTT..................................................................................................................6 TUTU5.3UUTTTUTURadiationpattern.......................................................................................................7 TUTU5.3.1UUTTTUTUH-planeUUTT...........................................................................................................7 TUTU5.3.2UUTTUTUE-planeUUTT......................................................................................................8-10 TUTU5.4UUTTUTUUGain&EfficiencyUUTT................................................................................................11 TUTU6UUTTEnvironmentaltreatmentsuggestionsU..................................................................................12 TUTU7UUTTImpedancematching..............................................................................................................12 TUTU 8 UUTTTUTU Antennaplan U ..........................................................................................................................13 TUTU 8.1 UUTTTUTU Antennadimensionaldrawing................................................................................13 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 3 / 14 TUTU8.2UUTTTUTUCoaxicalcablelengthdrawingUUTT................................................................................13 TUTU 8.3 UUTTTUTU Connecterdrawing...................................................................................................13 TUTU9UUTTAntennainstallationguide.....................................................................................................14 TUTU9.1UUTTAntennainstallationinstructions.................................................................................14 TUTU9.2UUTTTUTUCoaxicalroutingUUTT..........................................................................................................14 TUTU10UUTTUTUOther..............................................................................................................................14 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 4 / 14 1Nounexplanation dBiDecibelrelativeisotropicantenna TxTransmitfrequency RxReceivefrequency TRPTotalRadiatedPower TISTotalIsotropicSensitivity VSWRVoltageStandingWaveRatio GSMGlobalServiceforMobilecommunication DCSDigitalCommunicationSystem CDMACodeDivisionMultipleAccess WCDMAWidebandCodeDivisionMultipleAccess 2Testequipment networkanalyzer Agilent8960 SATIMO64chamber 3Workingfrequencyband TheyellowIdentificationistheusingband Band WIFI(2.4G)2412MHz～2483MHz ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 5 / 14 4Testproject 4.1VSWRplot 4.2Simthplot 4.3Radiationpattern 4.4Gain&Efficiency 4.5TRP&TIS 5Antennaparameter 5.1VSWR 5.1.1VSWRplot ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 6 / 14 5.1.2VSWRdata Freq/MHz24002500 VSWR1.41.5 5.2Simthplot ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 7 / 14 5.3Radiationpattern 5.3.1H-plane ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 8 / 14 5.3.2E-plane E1 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 9 / 14 E2 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 10 / 14 5.4UGain&Efficiency 频率(MHz)增益(dBi)效率(%) 23502.0956.76 23701.4450.93 23901.2551.13 24001.7454.60 24201.0854.33 24501.3658.65 24801.9463.92 25001.7059.85 25201.9159.95 25502.3962.31 WIFITRPTIS UL_ChannelDL_Channel 11b 116.011-77.24 615.836-81.43 1115.4111-81.52 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 11 …

Text truncated - open the document above for the full version.

FCCID: 2AG7C-BABY7T 1 Case No. : GTS20230227015-1-15 Ambient Condition: 24 °C, 49 %RH, Atmos100.1Kpa, Test Date: 2023.5.12 Test Engineer: Jenny zeng Appendix A.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.080 2406.960 2417.040 0.5 PASS 2437 10.040 2431.960 2442.000 0.5 PASS 2462 10.040 …
