2AG7CSNAP11SBattery Camera

QUICK GUIDE ORIGINALITY DESIGN SMART - AND BEAUTIFUL BATTERY CAM Snap 11S 1 Snap 11S Screws(2 packages) User manual Bracket (B) Power adapter Please consult this checklist for all parts. What's in the box USB cable Bracket (A) 2 Reset SD card slot Power button Micro USB Charging indicator Microphone PIR Status light Lens Photosensitive Speaker Power port Power on/off Status light DC 5V±10% Press the button for 3 seconds to turn on/off the camera Solid red light on: the camera is turning on or malfunctional Blinking red light: awaiting WiFi connection (slowly blinking) connecting the WiFi (quickly blinking) Blinking blue light: currently connecting Solid blue light on: the camera runs correctly Support local SD card storage (Max.128G) Press and hold on for 5 seconds to reset the camera Reset SD card slot Solid red indicator on: battery is charging Solid blue indicator on: charging completed Charging indicator Battery capacity9000mAh (two 21700 lithium-ion batteries) 3 Mode 1 Bracket (A) Installation Mode 2 Bracket (B) Installation Install 2.Install the camera in the bracket and lock it with the screw 1.Fix the bracket on the wall 1.Fix the bracket on the wall with screws 2.Bring the camera closer to the bracket 0~90° 0~360° After ajusting your camera angle, please lock this screw 4 Download Smart Life is available for both iOS and Android OS. Rearch the name 'Smart Life'in App Store or Android Market, or scan the QR-Code to download the App. Set up router The router supports the 2.4GHz WiFi (doesn't support the 5GHz).Before connecting to the WiFi network,please set the parameters of the router, and record the SSID and password of your WiFi. Android IOS ·Support Download App(IOS&android) Connect 2.4GHz5GHz Please keep network available 5 Registration process Step 1 Open the Smart Life App, click "Register", read the "Privacy Policy" and click "Agree" . Step 2 Input a legal and valid Mobile number or Email address and click "Continue". Input Verification Code, then log in the app. 6 QR Code Configuration Open the Smart Life App, click "Create family", and you can customize the Family name and related settings. 1 Continue to click "Security & Sensor" >> "Smart Camera", and then choose" Add Device" or "+", ready to add camera. 2 7 In "Add Device" this interface,continue to click "next step", and then you should input your WiFi's passwords. 3 Note: 1) Camera only supports 2.4GHz WiFi network. 2) The number of bits in the ssid and passwords of the router should not exceed 24 digits. 8 In this interface, you should scan the QR code in your phone with the camera, when the camera comes out "dong dong dong". And you can complete the configuration about 30s. 4 9 When connecting, you should make sure your router, mobile,and camera are as close as possible. When camera added successffully, click " " you could also DIY the camera's name. 5 10 In "Smart Camera" interface,click " ",you can set the camera common functions. Settings 11 Q: Why is it still in the list of devices after reseting? A: The reset device only resets the network configuration of the camera, but cannot change the configuration on the App, remove the camera, and must be deleted by the App. Q: How to cut the camera network to another router? A: First remove and reset the device on the App and then configure the device again by the App. Q: Why doesn't the device identify the SD card? A: It is recommended to plug in SD card after power cut. Confirm whether the SD card is normally available and the format is FAT32. And the TF card can’t be identified when the internet environment is not good. Q: Why I can’t get the notifications with my cell phone App? A: Please confirm that the App has been running on the phone, and the relevant reminder function has been opened;Message notification and authority confirmation in the mobile phone system have been opened. Q: The device cannot be previewed properly? A: Check whether the network is normal, you can place the camera close to the router, and if not, it is recommended to reset the device and add it again. FAQ DaytimeNight 12 Functions Record Using SD card or opening the Cloud-Storage Service, to keep recording for every moment. Day & Night Powerful night vision means no interruptions, even in complete darkness. Full-duplex audio You can see and hear the vistor in your App from the camera. PIR When the camera detects someone stopping by, it sends an alarm message to your cell phone. Low battery alarm When the battery power is lower than your set, the App will send a notification to your mobile phone. Remote wake-up The camera will be in a sleep mode to save power; you can have a preview in App. FCCStatement ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice, pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates, usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewith theinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereis noguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor moreofthefollowingmeasures: —Reorientorrelocatethereceivingantenna. —Increasetheseparationbetweentheequipmentandreceiver. —Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris connected. —Consultthedealeroranexperiencedradio/TVtechnicianforhelp. FCCRadiationExposureStatement ThisdevicecomplieswithFCCradiationexposurelimitssetforthforanuncontrolled environmentanditalsocomplieswithPart15oftheFCCRFRules.Thisequipmentmustbe installedandoperatedinaccordancewithprovidedinstructionsandtheantenna(s)usedfor thistransmittermustbeinstalledtoprovideaseparationdistanceofatleast20cmfromall personsandmustnotbeco-locatedoroperatinginconjunctionwithanyo…
