2AH78-APTT2AINA PTT Voice Responder

AINA PTT Voice Responder QUICK GUIDE AINA Wireless DOC ID : IU0016 ver. 1.0 INCLUDED IN THE PACKAGE X 1 BUTTONS AND CONNECTIONS I. Power/ pairing A. Microphone B. Emergency C. PTT 1 C. Speaker D. LED indicator F. Le� arrow G. PTT 2 G. Charging (USB-C) J. Volume connector L. Right arrow N. Headset jack FIRST USE — CHARGING THE BATTERY EN ES 1. Charge the device for 1 hour before first use, either with AINA docking station or USB-C cable. NOTE! Wall charger / computer: min. 500mA Docking station: min. 700mA / Max. allowed: 2.8A. 1.Laden Sie das Gerät vor dem ersten Gebrauch 1 Stunde lang auf, entweder mit der AINA-Dockingstation oder dem USB-C- Kabel. HINWEIS! Ladegerät/Computer: min. 500 mA / Dockingsta�on: min. 700 mA/maximal zulässig:2,8 A. Chargez l'appareil pendant 1 heure avant la première utilisation, soit avec la station d'accueil AINA, soit avec un câble USB-C. ATTENTION! Chargeur mural / ordinateur: 500 mA min. / sta on d'accueil: 700 mA min. / maximum autorisé: 2,8 A. Cargue el dispositivo durante 1 hora antes del primer uso, ya sea con la estación de acoplamiento AINA o con el cable USB-C. ¡NOTA! Cargador de pared/ computadora: min. 500mA / Base de carga: min. 700mA / Max. permi do: 2.8A. DE FR POWER ON / OFF ON OFF 3 sec 3 sec Turn on by pressing button I for 3 seconds. Turn off by pressing button I for 3 seconds. Zum Einschalten die Taste I 3 Sekunden lang gedrückt halten. Zum Ausschalten die Taste I 3 Sekunden lang gedrückt halten. Pour allumer le dispositif, appuyez sur le bouton I pendant 3 secondes. Pour éteindre le dispositif, appuyez sur le bouton I pendant 3 secondes. Enciende el dispositivo presionando el botón I por 3 segundos. Apaga el dispositivo presionando el botón I por 3 segundos. EN DE FR ES EN For best result hold the device 15-20cm from your mouth when speaking. DE Halten Sie das Gerät 15–20 cm von Ihrem Mund entfernt, um ein optimales Ergebnis zu gewährleisten. FR Pour de meilleurs résultats, gardez le dispositif à 15–20 cm de votre bouche quand vous parlez. ES Para obtener los mejores resultados, mantén el dispositivo a 15- 20cm de tu boca al hablar. MICROPHONE PERFORMANCE TIP PAIRING 1 2 3 4 2 5 sec APTT123456 APTT123456 EN 1. Simultaneously turn on the device and put into pairing mode by pressing bu�on I for 5 seconds 2. The LED will display fast green blinks 3. Pair via Bluetooth to your phone 4. The device is paired when the LED blinks blue. NOTE! For security reasons, single pairing only. DE Kopplungsmodus zu setzen, Taste I 5 Sekunden lang gedrückt halten. 2. Die LED blinkt dann schnell grün. 3. Über Bluetooth mit Ihrem Telefon koppeln. 4. Blinkt die LED blau, ist das Gerät gekoppelt. HINWEIS: Aus Sicherheitsgründen ist nur eine Einfachkopplung möglich. FR ES 1. Pour allumer le dispositif et le mettre simultanément en mode couplage, appuyez sur le bouton I pendant 5 secondes. 2. Le voyant LED clignote rapidement en vert. 3. Couplez le dispositif à votre téléphone via Bluetooth. 4. Le voyant LED passe au bleu dès que le dispositif est bien couplé. ATTENTION: Pour des raisons de sécurité, seul le couplage simple est possible. 1. Simultáneamente enciende el dispositivo y ponlo en modo de emparejamiento presionando el botón I por 5 segundos 2. La luz LED parpadeara rápidamente en verd e 3. Conecta vía Bluetooth a tu teléfono 4. Cuando el LED cambia ha azul, el dispositivo está conectado. ¡NOTA! Por razones de seguridad, conexión a un teléfono a la vez. 1.Do not put the device near your ear. 2.Avoid contact with magnetic stripe cards. 3.Charging temperature: +10°C - + 45°C. 4.Operating frequency range: 2400 - 2483.5MHz. 5.Bluetooth power level: Class 2. For more detailed instructions on setting up and using your PTT Voice Responder, please refer to the User Manual, available online at www.ainaptt.com If any part of the equipment is damaged on arrival, contact the shipper to conduct an inspection and prepare a damage report. Save the shipping container and all packing materials until the inspection and the damage report are completed. In addition, contact the Customer Care to make arrangements for replacement equipment. Do not return any part of the shipment until you receive detailed instructions from an AINA Wireless representative. Contact Customer Care at: Phone Number: + 358 40 322 6717 E-mail:[email protected] ADDITIONAL SAFETY TIPS EN OPERATION CUSTOMER CARE 1.Halten Sie das Gerät nicht am Ohr. 2.Vermeiden Sie den Kontakt mit Magnetstreifenkarten. 3.Ladetemperatur: +10 °C – +45 °C. 4.Betriebsfrequenzbereich: 2400–2483,5 MHz. 5.Bluetooth-Leistung: Klasse 2. Detailliertere Anweisungen zur Einrichtung und Verwendung Ihres PTT Voice Responders finden Sie in der Online-Gebrauchsanweisung unter www.ainaptt.com Sollte ein Teil des Geräts bei Erhalt beschädigt sein, wenden Sie sich an das Versandunternehmen, um eine Untersuchung und die Erstellung eines Schadensberichts zu veranlassen. Bewahren Sie den Versandbehälter und alle Verpackungen auf, bis die Untersuchung und der Schadensbericht abgeschlossen sind. Setzen Sie sich darüber hinaus mit dem Kundenservice in Verbindung, um die Bereitstellung eines Ersatzgeräts zu vereinbaren. Senden Sie keinen Teil der Sendung zurück, bevor Sie detaillierte Anweisungen vonseiten eines Vertreters von AINA Wireless erhalten haben. Kontakt Kundenservice: Telefon: + 358 40 322 6717 E-Mail:[email protected] ZUSÄTZLICHE SICHERHEITSTIPPS DE OPERATION KUNDENDIENST 1.Ne positionnez pas le dispositif près de votre oreille. 2.Évitez le contact avec les cartes à bande magnétique. 3.Température de chargement : +10 °C – +45 °C. 4.Gamme de fréquences de fonctionnement: 2400–2483,5MHz. 5.Puissance Bluetooth : classe 2. Pour obtenir des informations plus détaillées sur la configuration et l'utilisation de votre PTT Voice Responder, veuillez consulter le manuel d'utilisation, disponible en ligne sur www.ainaptt.com Si une pièce de l'appareil est endommagée au moment de la réception, veuillez contacter l'expéditeur afin qu'il effectue un…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name AINA Wireless Finland Oy Address Joensuunkatu 7G, 24100 Salo, Finland Grantee Code 2AH78 FCC ID -APTT2 Authorized Contact Name Petri Numminen Contact Email [email protected] Contact Phone +358 40 322 6717 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List AINA Wireless Finland Oy (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. AINA Wireless Finland Oy (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: May 10, 2023 Print Name: Petri Numminen Title: Software Developer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

A I N A W I R E L E S S F I N L A ND O Y Salo IoT Campus, Joensuunkatu 7G 24100 Salo, Finland www.ainaptt.com • +358 40 322 6717 • [email protected] VAT-ID: FI23956662 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 19 th of April 2023 Ref: Attestation Statement Part 2.911(d)(7) Filing FCC ID: 2AH78-APTT2 AINA Wireless Finland Oy certifies that, as of the dates of this application, Americas Compliance Consulting LLC dba iCertifi “iCertifi” is our designated U.S. agent for service of process for the above referenced FCC ID. AINA Wireless Finland Oy accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission-related proceeding involving the equipment. iCertifi accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Americas Compliance consulting, LLC dba iCertifi FCC FRN: 0033399411 Address: 1001 SW Disk Drive, Suite 250, Bend, Oregon 97702 Contact Person: Paul Preston Tel: 866-885-4575 Email: [email protected] Sincerely, AINA Wireless Finland Oy Americas Compliance Consulting LLC dba iCertifi Petri Numminen Paul Preston

A I N A W I R E L E S S F I N L A ND O Y Salo IoT Campus, Joensuunkatu 7G 24100 Salo, Finland www.ainaptt.com • +358 40 322 6717 • [email protected] VAT-ID: FI23956662 To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: AINA Wireless Finland Oy Joensuunkatu 7G 24100 Salo Finland Regarding: Confidentiality Request regarding application for FCC ID 2AH78-APTT2 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic and layout Block Diagrams Operational Descriptions Parts List / BOM The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Petri Numminen Software Developer AINA Wireless Finland Oy

A I N A W I R E L E S S F I N L A N D O Y Maximum permissible emission (MPE) ver.1.0 As PTT Voice Responder has one Bluetooth Class 2 devices with maximum EIRP transmit power +4dBm (2.51mW), conducted maximum RF power +3.5dBm (2.24mW) due to antenna peak gain 0.5dBi. 1. European standard EN 50663 defines maximum power levels called P MAX exclusion levels. The standard EN 50663 has defined a maximum low-power exclusion level to be 20 mW over the 10 MHz to 300 GHz frequency range for the general public exposure. Thus, if a device has lower or equal power levels as exclusion level (20 mW), the device is considered as a low power equipment and deemed to comply with the basic restrictions. P MAX = 2.51mW ≤ 20mW limit, Conclusion: No SAR test required 2. Calculation from FCC document “RF Exposure Procedures and Equipment Authorization Policies For Mobile and Portable Devices” attached. 4.3. General SAR test reduction and exclusion guidance 4.3.1. Standalone SAR test exclusion considerations a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. A I N A W I R E L E S S F I N L A N D O Y Calculation: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] Power = 2.51mW => rounded to 3mW Distance = (if distance <5mm, use value 5mm) = 5mm Frequency = 2.45GHz [(3mW)/(5mm)] ·[√2.45GHz] = 0.94 ≤ 3.0 (1g SAR limit) => SAR test excluded for 1g SAR tests. [(3mW)/(5mm)] ·[√2.45GHz] = 0.94 ≤ 7.5 (10g SAR limit) => SAR test excluded for 10g SAR tests. 3. Canada RSS-102 P MAX = 2.51mW ≤ 4mW limit, Conclusion: No SAR test required

Reference number: HELEM2301000056-2 Page 1 of 40 These test results are valid for the tested unit only. This report shall not be reproduced, except in full, without a written permission of SGS Fimko. Test Report HELEM2301000056-2 INTENTIONAL RADIATOR TESTS ACCORDING TO FCC PART 15 C AND ISED CANADA REQUIREMENTS Equipment Under Test: PTT Voice Responder Model: APTT2 Type: APTT2-0001-00 Trademark: AINA Manufacturer/Customer: AINA Wireless Finland Oy Joensuunkatu 7 G FI-24100, Salo Finland FCC Rule Part: §15.247 IC Rule Part: RSS-247, Issue 2, 2017 RSS-GEN Issue 5 Amendment 2, 2021 KDB: 558074 D01 15.247 Meas Guidance v05r02 Guidance for Compliance Measurements on Digital Transmission Systems, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating Under §15.247 of the FCC rules (April 2, 2019) Date: 28 March 2023 Date: 28 March 2023 Issued by: Checked by: Henri Mäki Rauno Repo Testing Engineer Senior EMC Specialist Reference number: HELEM2301000056-2 Page 2 of 40 Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS ................................................................................................................................. 2 GENERAL REMARKS ................................................................................................................................... 3 Disclaimer ................................................................................................................................................. 3 RELEASE HISTORY...................................................................................................................................... 4 PRODUCT DESCRIPTION ............................................................................................................................ 5 Equipment Under Test .............................................................................................................................. 5 General Description .................................................................................................................................. 5 Samples and Modifications........................................................................................................................ 5 Ratings and declarations ........................................................................................................................... 5 Ports and Cables ...................................................................................................................................... 6 Peripherals ............................................................................................................................................... 6 SUMMARY OF TESTING .............................................................................................................................. 7 EUT Test Conditions during Testing .......................................................................................................... 8 Test Facility............................................................................................................................................... 9 TEST RESULTS ............................................................................................................................................ 10 Antenna Requirement ............................................................................................................................... 10 AC Power-Line Conducted Emissions ....................................................................................................... 11 6 dB Bandwidth ......................................................................................................................................... 13 Occupied Bandwidth 99% ......................................................................................................................... 16 Maximum Peak Conducted Output Power ................................................................................................. 19 Unwanted Emissions (conducted) ............................................................................................................. 22 Unwanted Emissions (radiated) ................................................................................................................. 27 Power Spectral Density ............................................................................................................................. 37 TEST EQUIPMENT ....................................................................................................................................... 40 AC Power-Line Conducted Emissions ....................................................................................................... 40 Conducted RF Tests ................................................................................................................................. 40 Unwanted Emissions (radiated) ................................................................................................................. 40 Reference number: HELEM2301000056-2 Page 3 of 40 Disclaimer GENERAL REMARKS Disclaimer This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the …

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS Page 1 of 3 Project number: HELEM2301000056-2 SGS Fimko Ltd. Takomotie 8, FI-00380 Helsinki Finland t +358 9 6963 361 f +358 9 692 5474 www.sgs.fi Member of SGS Group (Société Générale de Surveillance) Photograph 1. Test setup for conducted RF tests Photograph 2. Test setup for AC Power-Line Conducted Emissions TEST SETUP PHOTOGRAPHS Page 2 of 3 Project number: HELEM2301000056-2 SGS Fimko Ltd. Takomotie 8, FI-00380 Helsinki Finland t +358 9 6963 361 f +358 9 692 5474 www.sgs.fi Member of SGS Group (Société Générale de Surveillance) Photograph 3. Test setup for radiated emissions (9 kHz – 30 MHz) Photograph 4. Test setup for radiated emissions (30 – 1000 MHz) TEST SETUP PHOTOGRAPHS Page 3 of 3 Project number: HELEM2301000056-2 SGS Fimko Ltd. Takomotie 8, FI-00380 Helsinki Finland t +358 9 6963 361 f +358 9 692 5474 www.sgs.fi Member of SGS Group (Société Générale de Surveillance) Photograph 5. Test setup for radiated emissions (1 – 18 GHz) Photograph 6. Test setup for radiated emissions (18 – 25 GHz)
