2AHCR-R29CV3Door Phone

AboutThisManual ThankyouforchoosingAkuvoxR29Cdoorphone.Thismanualisintended fortheadministratorswhoneedtoproperlyconfigurethedoorphone.This manualappliesto29.30.2.907version,anditprovidesalltheconfigurations forthefunctionsandfeaturesofR29Cdoorphone.PleasevisitAkuvox forumorconsulttechnicalsupportforanynewinformationorthelatest firmwares. IntroductionofIconsandSymbols Warning: Alwaysabidebythisinformationinordertopreventthepersons frominjury. Caution: Alwaysabidebythisinformationinordertopreventthedamagesto thedevice. Note: Informativeinformationandadvicefromtheefficientuseofthe device. RelatedDocumentation Youareadvisedtorefertotherelateddocumentsformoretechnical informationviathelinkbelow: https://knowledge.akuvox.com TableofContents 1.ProductOverview..................................................................................1 2.ChangeLog...........................................................................................1 3.ModelDifferences.................................................................................2 4.IntroductiontoConfigurationMenu........................................................4 5.AccesstheDevice..................................................................................7 6.LanguageandTimeSetting..................................................................10 6.1.LanguageSetting.......................................................................10 6.1.1.LanguageSettingontheDevice........................................10 6.1.2.LanguageSettingontheDeviceWebInterface...................10 6.2.TimeSetting..............................................................................11 6.2.1.TimeSettingontheDevice...............................................11 6.2.2.TimeSettingontheDeviceWebInterface..........................12 7.LED&LCDSetting.................................................................................13 7.1.InfraredLEDSettingontheDevice..............................................13 7.2.InfraredLEDSettingontheWebInterface...................................15 7.3.LEDSettingonCardReaderArea................................................16 7.4.LCDScreenBrightnessSetting...................................................17 7.5.LCDHeatControl.......................................................................18 7.6.LEDWhiteLightSetting..............................................................18 7.7.ScreenDisplayconfiguration......................................................19 7.7.1.HomeScreenDisplaySetting............................................19 7.7.2.AwaitScreenSetting........................................................20 7.7.2.1.AwaitScreenSettingontheDevice..........................20 7.7.2.2.AwaitScreenSettingontheWebInterface...............22 7.7.3.UploadScreenSaver.........................................................22 7.7.4.UploadHomeScreenBackgroundPictures........................23 7.7.5.UploadBackgroundPictureintheTime-displayingArea.....24 7.8.UploadDeviceBootingImage.....................................................25 7.9.UploadDeviceLogo...................................................................26 7.10.ConfigurationforScenario-basedScreenDisplayMode.............26 7.10.1.BuildingModeHomeScreenConfiguration......................28 7.10.2.VillaModeHomeScreenConfiguration............................30 7.10.3.AlphanumericModeHomeScreenConfiguration..............32 7.11.VolumeandToneConfiguration................................................34 7.11.1.VolumeConfiguration.....................................................34 7.11.2.OpenDoorToneConfiguration........................................36 7.11.3.ContactListGuidingToneConfiguration..........................37 7.12.UploadTones...........................................................................37 8.NetworkSetting...................................................................................39 8.1.DeviceNetworkConnectionSetting............................................39 8.2.DeviceLocalRTPconfiguration..................................................41 8.3.DeviceDeploymentinNetwork...................................................42 8.4.NATSetting...............................................................................43 9.IntercomCallConfiguration.................................................................44 9.1.IPcall&IPCallConfiguration.....................................................44 9.2.SIPCall&SIPCallConfiguration.................................................44 9.2.1.SIPAccountRegistration..................................................45 9.2.2.SIPCallDND&ReturnCodeConfiguration..........................46 9.2.3.SIPServerConfiguration...................................................47 9.2.4.OutboundProxyServerconfiguration................................48 9.2.5.DataTransmissionTypeConfiguration..............................49 9.2.6.SIPHackingProtection.....................................................50 9.3.DialOptionsConfiguration.........................................................51 9.3.1.QuickDialBynumberReplacement...................................51 9.3.2.QuickDialUsingConfiguredDialName.............................53 9.3.3.Import/ExporttheSpeedDialContacts..............................54 9.3.4.SpeedDialontheHomeScreen.........................................54 9.4.GroupSpeedDial.......................................................................57 9.5.DialKeyOrder............................................................................58 9.6.CallAuto-answerConfiguration..................................................58 9.7.SequenceCallConfiguration.......................................................59 9.8.WebCallConfiguration...............................................................60 9.9.CallSettings..............................................................................61 9.9.1.MaximumCallDurationSetting.......................…

Text truncated - open the document above for the full version.

AKUVOX (XIAMEN) NETWORKS CO., LTD. Add: 10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China Tel: 086-0591-83057798 Fax: 086-0591-83057798 Email: [email protected] Date:2023-11-24 Attestation To: FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, AKUVOX (XIAMEN) NETWORKS CO., LTD., hereby authorize China Certification ICT Co., Ltd (Dongguan) to act as a laboratory for testing and test report generation for the following project(s): (Product Name:Door Phone, Model Name: R29C FCC ID:2AHCR-R29CV3 The chip support 2.4G Wi-Fi (802.11b/g/n20/n40 modes). But for the product, it only activates 802.11b/g/n20 (2412-2462MHz). Other mode and frequencies were disabled by software, the end user has no capability to activate it. Please contact me if you have any question. Signature: Printed Name: Bo Yang Title: Manager

ATTESTATION STATEMENT Applicant:AKUVOX (XIAMEN) NETWORKS CO., LTD. Add:10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China Tel:086-0591-83057798 Email:[email protected] Date: 2023-11-24 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(i), (ii) Filing FCC ID:2AHCR-R29CV3 AKUVOX (XIAMEN) NETWORKS CO., LTD.(“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. And AKUVOX (XIAMEN) NETWORKS CO., LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signed by (printed name):Bo Yang Signature:Manager

U.S. AGENT LETTER OF ATTESTATION Date: 2023-11-24 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2AHCR-R29CV3 AKUVOX (XIAMEN) NETWORKS CO., LTD. ( “the Applicant”) certifies that, as of the date of the filing of the application, Iconsigh Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. AKUVOX (XIAMEN) NETWORKS CO., LTD. (“the Applicant”) a ccepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Iconsigh Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Iconsigh Inc. Address: 2310 Homestead Road, Suite C1, Los Altos, CA, 94024, USA FRN: 0033398652 Tel.: +1 (408) 320-9867 Email: [email protected] Signed by (printed name): Benjamin Kaur Signature: Applicant: AKUVOX (XIAMEN) NETWORKS CO., LTD. Address: 10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China FRN: 0025226762 Tel: 086-0591-83057798 Email: [email protected] Signed by (printed name): Bo Yang Signature:

QA-FR-170-B Company: AKUVOX (XIAMEN) NETWORKS CO., LTD. Add: 10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China Tel: 086-0591-83057798 Fax: 086-0591-83057798 Email: [email protected] FCC Authorization Date: 2023-11-24 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , AKUVOX (XIAMEN) NETWORKS CO., LTD., Hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Printed Name: Bo Yang Title: Manager

QA-FR-171-A AKUVOX (XIAMEN) NETWORKS CO., LTD. Add: 10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China Tel: 086-0591-83057798 Fax: 086-0591-83057798 Email: [email protected] FCC Confidential Authorization Date: 2023-11-24 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2AHCR-R29CV3 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, AKUVOX (XIAMEN) NETWORKS CO., LTD. hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Bo Yang Title: Manager

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-EXP Page 1 of 3 UT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-EXP Page 2 of 3 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-EXP Page 3 of 3

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 1 of 15 EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 2 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 3 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 4 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 5 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 6 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 7 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 8 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 9 of 15 Buletooth&Wifi Antenna China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 10 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 11 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 12 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 13 of 15 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 14 of 15 NFC Antenna China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-INP Page 15 of 15 125kHz Antenna

RF EXPOSURE EVALUATION Applicant: AKUVOX (XIAMEN) NETWORKS CO., LTD. Address: 10/F, No.56 Guanri Road, Software Park II, Xiamen 361009, China FCC ID: 2AHCR-R29CV3 Product Name: Door Phone Standard(s): 47 CFR §1.1310, 47 CFR §2.1091 447498 D01 General RF Exposure Guidance v06 The above device has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230740683-00F Date Of Issue: 2023/12/11 Reviewed By: Julie Tan Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-00F Page 2 of 8 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-00F Page 3 of 8 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 CR230740683-00F Original Report 2023/12/11 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-00F Page 4 of 8 1.1 Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (Mw/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. 1.2 Block Diagram of Test Setup For RFID Test Procedure: H-Field &E-Field Probe instrument was used to test and record magnetic and electric fields in five directions A, B, C, D and E at a distance of 20cm from EUT. 20cm China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-00F Page 5 of 8 1.3Calculation formula For Power Density: Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); 1.4 Test Data For 128kHz RFID: Serial Number: 28EX-1 Test Date: 2023/12/11 Test Site: RF Test Mode: Transmitting Tester: Vic Du Test Result: Pass Environmental Conditions: Temperature: (°C) 25.2 Relative Humidity: (%) 50 ATM Pressure: (kPa) 100.9 Test Equipment List and Details: Manufacturer Description Model Serial Number Calibration Date Calibration Due Date Narda Electric and Magnetic Field Probe-Analyzer EHP-200AC 180ZX102042021/06/07 2024/06/06 * Statement of Traceability: China Certification ICT Co., Ltd (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data: H-Field Strength: Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) Limit (A/m) 128 0.164 0.169 0.1645 0.17 0.1583 1.63 Note: Test with 15cm distance from the center of the probe(s) to the edge of the device, 20 cm for top test. E-Field Strength: Frequency Range (kHz) Position A (V/m) Position B (V/m) Position C (V/m) Position D (V/m) Position E (V/m) Limit (V/m) 128 0.5557 0.4598 0.4436 0.509 0.4793 614 Note: Test with 15cm distance from the center of the probe(s) to the edge of the device, 20 cm for top test. Note: according to KDB 680106 D01 Wireless Power Transfer v04 clause 3.2, for all RF devices, the MPE limits between 100 kHz to 300 kHz are to be considered the same as those at 300 kHz in Table 1 of$ 1.1310, that is, 614V/m and 1.63 A/m, for the electric field and magnetic field, respectively. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230740683-00F Page 6 of 8 1.5 Power Density Calculation: Operation Modes Frequency (MHz) Antenna Gain Conducted output power including Tune-up Tolerance Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) Bluetooth BDR/EDR 2402-2480 -2.3 0.59 0 1.00 20.00 0.0001 1.0 Bluetooth LE 2402-2480 -2.3 0.59 -1.50.71 20.00 0.0001 1.0 2.4G Wifi 2412-2462 -2.3 0.59 15.031.62 20.000.0037 1…
