2AHNM-WIS130Window Sensor

ba <5mm Frame Window/ Door a. b. c. d. e. f. 3. Release the button while the LED is flashing numerous times in a row. 4. After you release the button, the LED shows one long flash, and the reset is completed. eng Modes ACTIVATION MODE A single green flash means that the sensor and the magnet are moving either away from or to- wards each other. SEARCHING GATEWAY MODE Red flashes every second for a longer period, means that the device is searching for a gate- way. LOST CONNECTION MODE When the red LED flashes 3 times, it means that the device has failed to connect to a gateway. LOW-BATTERY MODE Two consecutive red LED flashes every 60 seconds, means that the battery should be replaced. • There are many ways to mount the sensor and magnet, as windows and doors vary greatly. The most important consideration is for the magnet to be placed as near to the point on the sensor indicated by the grey arrow. • The sensor and magnet may be placed on separate three dimensional planes, though this does affect the maximum distance allowed. The magnet may also be placed either facing the side of the sensor or sitting parallel to it. Other information Note local regulations about information to your insurance company regarding installed Window Sensors. Resetting Resetting is needed if you want to connect your Window Sensor to another gateway or if you need to perform a factory reset to eliminate ab- normal behavior. STEPS FOR RESETTING 1. Press and hold down the reset button for approximately 8-10 seconds. 2. While you are holding the button down, the LED first flashes once, then two times in a row, and finally numerous times in a row. Mounting • Clean the surface before mounting. • The Window Sensor (a) should be mounted to the frame using the double stick tape, already applied on the back of the sensor and magnet. Press firmly to secure sensor. Testing You can test if the positioning of the sensor and magnet are correct by checking whether the green light on the Window Sensor is flashing when you open or close the window/door. Placement • Place the sensor indoors at a temperature between 0-50°C. • The magnet has to be placed on that side of the sensor which is marked with a small triangle. • The magnet and sensor also have to be aligned/centered thickness-wise on as similar level as possible. • In case of a weak or a bad signal, change the location of the Window Sensor or strengthen the signal with a smart plug. SEE PAGE 2 FOR ILLUSTRATIONS • When removing cover for battery change - electrostatic discharge can harm electronic components inside. • Always mount indoors as sensor is not waterproof. • Do not place the sensor close to magnetic or electromagnetic fields. This device includes a magnet. The magnet creates a magnetic field that may cause damage to computer hard drives, magnetic cards, data storage devices, hearing aids and speakers e.g. Therefore, we strongly advise you to never position the magnet close to electronic devices. Getting started 1. Open the casing of the device by pushing the fastening on top of the device to remove the front panel from the back cover. Product description The Window Sensor detects and reports open- ing and closing of doors and windows. Easily installed on any door or window, the sensor trig- gers a signal when parted. This lets you know when a room is entered, if a window or a door has been left open, etc. Window Sensor Fault finding • If the Window Sensor does not work when the window or door is parted, the probable cause is a faulty battery. Replace the batteries if they are worn out. • In case of a bad or weak signal, change the location of the Window Sensor. Otherwise you can relocate your gateway or strengthen the signal with a smart plug. • If the search for a gateway has timed out, a short press on the button will restart it. Battery replacement CAUTION: RISK OF EXPLOSION IF BATTER- IES ARE REPLACED BY AN INCORRECT TYPE. DISPOSE OF THE BATTERIES IN ACCORD- ANCE WITH INSTRUCTIONS. 2. Insert the enclosed batteries into the device, respecting the polarities 3. Close the casing 4. The Window Sensor will now start searching (up to 15 minutes) for a Zigbee network to join. 5. Make sure that the Zigbee network is open for joining devices and will accept the Window Sensor. 6. While the Window Sensor is searching for a Zigbee network to join, the red LED is flashing. Disposal Dispose the product and battery properly at the end of life. This is electronic waste which should be recycled. Precautions • The magnet (b) should be mounted on the door or window no further than 5mm away from the arrow on the sensor. 7. When the red LED stops flashing, the Window Sensor has successfully joined the Zigbee network. CAUTION: When removing cover for battery change - Electrostatic Discharge (ESD) can harm electronic components inside 1. Open the casing of the device by pushing the fastening on top of the device to remove the front panel from the back cover. 2. Replace the batteries respecting the polarities. The Window Sensor uses 2xAAA batteries. 3. Close the casing. 4. Test the Window Sensor. INSTALLATION MANUAL Version 4.2 The reset button is marked with the small ring on the front of the sensor. Placement Examples - Top View • The most beneficial distance between the sensor and the magnet is 0.2-0.5 cm. • Be aware that on magnetic surface (e.g. metal door), the distance between the sensor and the magnet has to be 0.1-0.3 cm. Sensor (a) Magnet (b) Sensor (a) Magnet (b) Sensor (a) Magnet (b) Sensor (a) Magnet (b) Sensor (a) Magnet (b) Sensor (a) Magnet (b) Sliding Door Sensor (a) Magnet (b) g. h. i. Placement Examples - Doors • Be sure to mount the sensor on the frame, to protect the electronics from heavy vibrations. • The sensor and magnet should be mounted on the side opposite from the hinge/pivot point. • Pay careful attention to the arrow printed on the sensor. This should be oriented to face the magnet. The distance between the two should not exceed 5mm. Placement Examples …
