2AIHD2046AG46

Unpowered Asset Tracker AG46 Datasheet OVERVIEW The AG46 Unpowered Asset Tracker is a wallet-sized tracker ideal for monitoring assets like intermodal containers, construction equipment, dumpsters, light towers and other mobile assets etc. It features customizable GPS check-ins, a lithium battery that lasts up to 5 years and a waterproof and ruggedized enclosure. The AG46 enables increased asset utilization, theft recovery and optimized pool inventory management. It is part of Samsara’s complete sensor system that combines asset tracking, fleet management, safety, and compliance solutions in a single platform. CONNECTIVITY Cellular LTE-M Connectivity Offline Storage Built-in flash memory logs data when Internet connectivity is unavailable Security All Internet connectivity secured via SSL with 256-bit AES encryption (military-grade) LOCATION GPS Advanced positioning system simultaneously reads from multiple independent satellite systems including GPS and GLONASS global navigation satellite systems. Internal antenna for discreet installation. Industry leading -146 dBm sensitivity with 1 second time-to-fix (hot start). Default Check-in Twice per day POWER Battery • 4 lithium batteries • Typical battery life 4-5 years (2 check-ins/day) • Actual battery life may be affected by extreme cold or cellular signal strength ENCLOSURE Material Polycarbonate Dimensions 70x112x29 mm Weight 180 gms Operating Temperature -20°C to 65°C IP Rating IP67 Certified (weatherproof and water resistant up to 1m submerged) SAMSARA CLOUD Features • Map-based location tracking • Ability to customize ping rates and switch to real-time for theft detection • Developer APIs • Alerts • Geofence INSTALL ACCESSORIES What’s Included • Anti-theft machine screws • Anti-theft self taping screws • Anti-theft screw bit • VHB strip • Alcohol wipes LITHIUM BATTERY PRECAUTIONS Customers should NOT manually replace batteries in the AG46. Improper handling or installation of lithium batteries can cause significant heat and/or bursting. If AG46 batteries are low or dead, contact Samsara for replacement. For questions about the safe use of lithium battery powered devices, please consult your company’s safety department. IC REGULATIONS This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with Innovation, Science and Economic Development Canada RF exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated to ensure a minimum of 20 cm spacing to any person at all times. CAN ICES-3(B)/NMB-3(B) IC Radiation Exposure Statement: This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Déclaration d’exposition aux radiations: Cet équipement est conforme Canada limites d’exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 4

Letter of Authorization Date: June 23, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize the following person to act on our behalf in all matters relating to application for Federal Communication Commision radio equipment authorization. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager E-mail : [email protected] We further certify that neither the applicant nor any party to this application, as defined in 47 C.F.R. 1.2002(b), is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862. This appointment also includes authority to complete FCC Form 731 on our behalf and sign as an authorized agent for the purposes of this application. FCC ID: 2AIHD2046 Product(s): AG46 Signature: Benjamin Calderon Executive Vice President, Hardware Operations Samsara Network, Inc. 1990 Alameda Street, San Francisco, CA 94103 Tel: +1 (415) 985-2400 Email: [email protected] DocuSign Envelope ID: B832E672-561C-4981-834A-1432470A9545

Date: July 14, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Confidentiality FCC ID: 2AIHD2046 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s rules, we hereby request confidential treatment for the following attachments to this application as outlined below: ☒ Block Diagram ☒ Schematics ☒ Theory of Operation ☒ Bill of Materials ☒ Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Further, pursuant to DA 04-1705 of the Commission’s public notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204 while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we are requesting the commission to grant short-term confidentiality request on the following attachments until 90 days after the grant date: ☒ Internal Photographs ☒ External Photographs ☒ User Manual ☒ Test Setup Photographs The applicant understands that pursuant to Section 0.457 of the rules, disclosure of this application and all accompanying documentation will not be made prior to the grant of equipment authorization. DocuSign Envelope ID: 1E761F32-7AD9-44C5-8154-5EB4187DE2AA Signature: Benjamin Calderon Executive Vice President, Hardware Operations Samsara Network, Inc. 1990 Alameda Street, San Francisco, CA 94103 Tel: +1 (415) 985-2400 Email: [email protected] DocuSign Envelope ID: 1E761F32-7AD9-44C5-8154-5EB4187DE2AA

Declaration Letter Date: June 23, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom it May Concern: We, Samsara Networks Inc., declare that this equipment (AG46, FCC ID: 2AIHD2046) does not support any non-US channels or country code selection in any operational mode(s). 1. Wi-Fi function for the Samsara asset gateway is limited by firmware to receive signal only. 2. There is no method to activate transmission function after shipment. Should you have any questions or comments regarding this matter, please contact us. Signature: Benjamin Calderon Executive Vice President, Hardware Operations Samsara Network, Inc. 1990 Alameda Street, San Francisco, CA 94103 Tel: +1 (415) 985-2400 Email: [email protected] DocuSign Envelope ID: B832E672-561C-4981-834A-1432470A9545

Project No.: 050802 Page No. : 1 of 11 Photographs of EUT Project No.: 050802 Page No. : 2 of 11 Project No.: 050802 Page No. : 3 of 11 Project No.: 050802 Page No. : 4 of 11 Project No.: 050802 Page No. : 5 of 11

Barcode reads serial number “1234-567-890” Serial number and 128b barcode are variable all other information is static Font is Nitti Grotesk Normal. Laser Etch Power: Laser Etch Speed: Frequency: 22% 400 mm/s 40 hz AG46_Laser_Artwork_03 Location 1 45.5mm 3.5mm (Barcode dimensions: 27mm x 3.5mm) Total Height: 27.7mm 3 mm

Project No.: 050802 Page No. : 6 of 11 Project No.: 050802 Page No. : 7 of 11 Project No.: 050802 Page No. : 8 of 11 Project No.: 050802 Page No. : 9 of 11 Project No.: 050802 Page No. : 10 of 11 Project No.: 050802 Page No. : 11 of 11

Report No.: FA050802 Page : 1 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. FCC RF Exposure Report FCC ID : 2AIHD2046 Equipment : AG46 Model No. : 010-2046 Brand Name : Samsara Applicant : Samsara Networks Inc. Address : 444 De Haro Street, San Francisco, CA 94107, U.S.A. Standard : 47 CFR FCC Part 2.1091 Received Date : May 08, 2020 Tested Date : Jun. 04 ~ Jun. 18, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA050802 Page : 2 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.5 MPE EVALUATION RESULTS .............................................................................................................. 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA050802 Page : 3 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Release Record Report No. Version Description Issued Date FA050802 Rev. 01 Initial issue Jul. 01, 2020 FA050802 Rev. 02 Model name changed. Jul. 07, 2020 FA050802 Rev. 03 Model / product name changed. Jul. 09, 2020 Report No.: FA050802 Page : 4 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA050802 Page : 5 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. 1.5 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Ratio* Pass / Fail Band 2: 1850-1910 21.15 21.5 3.51 20 0.063 1 0.063 Pass Band 4: 1710-1755 21.21 21.5 3.52 20 0.063 1 0.063 Pass Band 12: 699-716 20.81 21.0 0.82 20 0.030 0.466 0.065 Pass Band 13: 777-787 20.45 20.5 3.79 20 0.053 0.518 0.103 Pass *Ratio = Power density / Limit Report No.: FA050802 Page : 6 of 6 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan District, Tao Yuan City 333, Taiwan, R.O.C.. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FG050802P24 Page : 1 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. FCC Test Report FCC ID : 2AIHD2046 Equipment : AG46 Model No. : 010-2046 Brand Name : Samsara Applicant : Samsara Networks Inc. Address : 444 De Haro Street, San Francisco, CA 94107, U.S.A. Standard : 47 CFR FCC Part 24 Subpart E Received Date : May 08, 2020 Tested Date : Jun. 04 ~ Jun. 18, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FG050802P24 Page : 2 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Test Standards ..................................................................................................................................... 10 1.6 Reference Guidance ............................................................................................................................ 10 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 10 1.8 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION ..................................................................................................................... 11 2.1 Testing Condition and Location Information ......................................................................................... 11 2.2 Testing Facility...................................................................................................................................... 11 2.3 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TEST RESULTS................................................................................................................................... 13 3.1 Equivalent Isotropically Radiated Power .............................................................................................. 13 3.2 Radiated Emissions .............................................................................................................................. 25 3.3 Conducted Emissions & Band Edge .................................................................................................... 36 3.4 Occupied and 26 dB Bandwidth ........................................................................................................... 81 3.5 Peak to Average Ratio ....................................................................................................................... 103 3.6 Frequency Stability ............................................................................................................................. 119 4 TEST LABORATORY INFORMATION ............................................................................................. 126 Report No.: FG050802P24 Page : 3 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Release Record Report No. Version Description Issued Date FG050802P24 Rev. 01 Initial issue Jul. 01, 2020 FG050802P24 Rev. 02 Model name changed. Jul. 07, 2020 FG050802P24 Rev. 03 Model / product name changed. Jul. 09, 2020 Report No.: FG050802P24 Page : 4 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Summary of Test Results FCC Rules Test Items Measured Result 2.1046 / 24.232(c) Equivalent Isotropically Radiated Power Power[dBm]: 24.66 Pass 2.1053 / 24.238(a) Radiated Emissions Meet the requirement of limit Pass 2.1051 / 24.238(a) Conducted Emissions Meet the requirement of limit Pass 2.1051 / 24.238(a) Band Edge Meet the requirement of limit Pass 2.1049 Occupied Bandwidth Meet the requirement of limit Pass 24.232(d) Peak to Average Ratio Meet the requirement of limit Pass 2.1055 / 24.235 Frequency Stability Meet the requirement of limit Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FG050802P24 Page : 5 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. 1 General Description 1.1 Informat…

Text truncated - open the document above for the full version.

Report No.: FG050802P27 Page : 1 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. FCC Test Report FCC ID : 2AIHD2046 Equipment : AG46 Model No. : 010-2046 Brand Name : Samsara Applicant : Samsara Networks Inc. Address : 444 De Haro Street, San Francisco, CA 94107, U.S.A. Standard : 47 CFR FCC Part 27 Received Date : May 08, 2020 Tested Date : Jun. 04 ~ Jun. 18, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FG050802P27 Page : 2 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Test Standards ..................................................................................................................................... 10 1.6 Reference Guidance ............................................................................................................................ 10 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 10 1.8 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION ..................................................................................................................... 11 2.1 Testing Condition and Location Information ......................................................................................... 11 2.2 Testing Facility...................................................................................................................................... 11 2.3 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TEST RESULTS................................................................................................................................... 13 3.1 Equivalent Isotropically Radiated Power .............................................................................................. 13 3.2 Radiated Emissions .............................................................................................................................. 25 3.3 Conducted Emissions & Band Edge .................................................................................................... 36 3.4 Occupied and 26 dB Bandwidth ........................................................................................................... 81 3.5 Peak to Average Ratio ....................................................................................................................... 103 3.6 Frequency Stability ............................................................................................................................. 119 4 TEST LABORATORY INFORMATION ............................................................................................. 126 Report No.: FG050802P27 Page : 3 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Release Record Report No. Version Description Issued Date FG050802P27 Rev. 01 Initial issue Jul. 01, 2020 FG050802P27 Rev. 02 Model name changed. Jul. 07, 2020 FG050802P27 Rev. 03 Model / product name changed. Jul. 09, 2020 Report No.: FG050802P27 Page : 4 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Summary of Test Results FCC Rules Test Items Measured Result 2.1046 / 27.50(d)(4) Equivalent Isotropically Radiated Power Power[dBm]: 24.73 Pass 2.1053 / 27.53(h) Radiated Emissions Meet the requirement of limit Pass 2.1051 / 27.53(h) Conducted Emissions Meet the requirement of limit Pass 27.53(h) Band Edge Measurement Meet the requirement of limit Pass 2.1049 / 27.53(h) Occupied Bandwidth Meet the requirement of limit Pass 27.50(d)(5) Peak to Average Ratio Meet the requirement of limit Pass 2.1055 / 27.54 Frequency Stability Meet the requirement of limit Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FG050802P27 Page : 5 of 126 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. 1 General Description 1.1 Info…

Text truncated - open the document above for the full version.

Report No.: FG050802P27-1 Page : 1 of 133 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. FCC Test Report FCC ID : 2AIHD2046 Equipment : AG46 Model No. : 010-2046 Brand Name : Samsara Applicant : Samsara Networks Inc. Address : 444 De Haro Street, San Francisco, CA 94107, U.S.A. Standard : 47 CFR FCC Part 27 Received Date : May 08, 2020 Tested Date : Jun. 04 ~ Jun. 18, 2020 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any agency of government. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FG050802P27-1 Page : 2 of 133 Report Version: Rev. 03 The previous version of the test report has been cancelled and replaced by new version. Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Test Standards ...................................................................................…

Text truncated - open the document above for the full version.
