t name: PoC mobile radio Model name: TM-9, FCC ID:2AIV6-TM9 The chipset MT6739 supports GSM,WCDMA,LTE Band, But only GSM850 ,PCS1900,WCDMA Band 2/5,LTE Band 2/4/5 /7/12/17/38/66 were active, The other were disable by software. Sincerely, Signature: Wenshun Zhang Manager Shenzhen Inrico Electronics Co.,Ltd ADD: 3/F, Bu ilding No.118, High Tech Industrial Park, 72 Guowei Road, Luohu District, Shenzhen China TEL: 07 55-83273589 FAX: 0755-82689912 E-mail: 2850399099@q q.com Date: 2020-12-18 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, Shenzhen Inrico Electronics Co.,Ltd , hereby authorize Bay Area Compliance Laboratories Corp. to act as a laboratory for testing and test rep ort generation for the following project(s): Produc

QA-FR-171-A Shenzhen Inrico Electronics Co.,Ltd ADD: 3/F, Building NO.118, High Tech Industrial Park, 72 Guowei Road, Luohu District, Shenzhen China TEL:0755-83273589 FAX: 0755-82689912 E-mail:[email protected] FCC Confidential Authorization Date: 2020-12-08 FEDERAL COMMUNICATIONS COMMISSIONS Autho rization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confid entiality Request regarding application for certification of FCC ID:2AIV6-TM9 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Shenzhen Inrico Electronics Co.,Ltd hereby requests lon g-term confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operation Description Parts List/Tune up procedure (for licensed devices) The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Wenshun Zhang Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS 3G/4G Main Antenna GPS Antenna

SHENZHEN INRICO ELECTRONICS CO.,LTD Model: TM-9 20 NETWORK MOBILE RADIO IMEI:XXX000000000000 IMEI:XXX000000000000 S/N:XTMX9A0001 FCC ID:2AIV6-TM9

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Aux Antenna

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 10 of 189 FCC §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculation formula: Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 11 of 189 Calculated Data: Mode Frequency (MHz) Antenna Gain Conducted output power including Tune- up Tolerance Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric)(dBm)(mW) GPRS/EDGE 850 824-849 0.5 1.12 32.1 1621.8120.00 0.362 0.55 GPRS/EDGE 1900 1850-1910 0.5 1.12 29.5 891.2520.00 0.199 1.0 WCDMA Band 2 1850-1910 0.5 1.12 23 199.5320.00 0.045 1.0 WCDMA Band 5 824-849 0.5 1.12 22.5 177.8320.00 0.040 0.55 LTE Band 2 1850-1910 0.5 1.1223199.5320.000.045 1.0 LTE Band 4 1710-1755 0.5 1.1222.5177.8320.000.040 1.0 LTE Band 5 824-849 0.5 1.1223199.5320.000.045 0.55 LTE Band 7 2500-2570 0.5 1.1223199.5320.000.045 1.0 LTE Band 12 699-716 0.5 1.1223199.5320.000.045 0.47 LTE Band 17 704-716 0.5 1.1223199.5320.000.045 0.47 LTE Band 38 2570-2620 0.5 1.1223199.5320.000.045 1.0 LTE Band 66 1710-1780 0.5 1.1222.5177.8320.000.040 1.0 Result: The device meet FCC MPE at 20 cm distance

FCC PART 22H, PART 24E,PART 27 MEASUREMENT AND TEST REPORT For Shenzhen Inrico Electronics Co.,Ltd 3/F, Building No.118, High Tech Industrial Park, 72 Guowei Road, Luohu District, Shenzhen Report Type: Original Report Product Type: PoC mobile radio Report Number: RDG200407007-00B Report Date: 2021-01-30 Reviewed By: Ivan Cao Assistant Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industry Area, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn FCC ID: 2AIV6-TM9 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 2 of 189 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 DECLARATIONS ............................................................................................................................................................ 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 JUSTIFICATION ............................................................................................................................................................. 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 8 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 CONFIGURATION OF TEST SETUP ................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................... 9 FCC §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ............................................................ 10 APPLICABLE STANDARD ............................................................................................................................................ 10 FCC §2.1047 - MODULATION CHARACTERISTIC ............................................................................................ 12 FCC § 2.1046, § 22.913 (A) & § 24.232 (C) & § 27.50- RF OUTPUT POWER ...................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 TEST PROCEDURE ...................................................................................................................................................... 14 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 19 TEST DATA ................................................................................................................................................................ 19 FCC §2.1049, §22.917, §22.905 & §24.238 & §27.53- OCCUPIED BANDWIDTH ............................................... 41 APPLICABLE STANDARD ............................................................................................................................................ 41 TEST PROCEDURE ...................................................................................................................................................... 41 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 41 TEST DATA ................................................................................................................................................................ 41 FCC §2.1051, §22.917(A) & §24.238(A) & §27.53- SPURIOUS EMISSIONS AT ANTENNA TERMINALS ... 86 APPLICABLE STANDARD ............................................................................................................................................ 86 TEST PROCEDURE ...................................................................................................................................................... 86 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 86 TEST DATA ................................................................................................................................................................ 86 FCC §2.1053, §22.917 & §24.238 & §27.53- SPURIOUS RADIATED EMISSIONS .......................................... 133 APPLICABLE STANDARD ............…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 81 of 189 3M, QPSK, Low Channel 3M, 16QAM, Low Channel 3M, QPSK, Middle Channel 3M, 16QAM, Middle Channel 3M, QPSK, High Channel 3M, 16QAM, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 82 of 189 5M, QPSK, Low Channel 5M, 16QAM, Low Channel 5M, QPSK, Middle Channel 5M, 16QAM, Middle Channel 5M, QPSK, High Channel 5M, 16QAM, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 83 of 189 10M, QPSK, Low Channel 10M, 16QAM, Low Channel 10M, QPSK, Middle Channel 10M, 16QAM, Middle Channel 10M, QPSK, High Channel 10M, 16QAM, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 84 of 189 15M, QPSK, Low Channel 15M, 16QAM, Low Channel 15M, QPSK, Middle Channel 15M, 16QAM, Middle Channel 15M, QPSK, High Channel 15M, 16QAM, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 85 of 189 20M, QPSK, Low Channel 20M, 16QAM, Low Channel 20M, QPSK, Middle Channel 20M, 16QAM, Middle Channel 20M, QPSK, High Channel 20M, 16QAM, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 86 of 189 FCC §2.1051, §22.917(a) & §24.238(a) & §27.53- SPURIOUS EMISSIONS AT ANTENNA TERMINALS Applicable Standard FCC §2.1051, §22.917(a) , §24.238(a) and §27.53. The spectrum was to be investigated to the tenth harmonics of the highest fundamental frequency as specified in § 2.1051. Test Procedure The RF output of the transceiver was connected to a spectrum analyzer and simulator through appropriate attenuation. Sufficient scans were taken to show any out of band emissions up to 10 th harmonic. Test Equipment List and Details Manufacturer Description Model Serial Number Calibration Date Calibration Due Date R&S Spectrum Analyzer FSU 26 200256 2020-07-07 2021-07-07 R&S Spectrum Analyzer FSV40 101474 2020-07-07 2021-07-07 Unknown Coaxial Cable C-SJ00-0010 C0010/04 Each time N/A E-Microwave Blocking Control EMDCB- 00036 0E01201048 Each time N/A E-Microwave Coaxial Attenuators EMCA10- 5RN-6 OE01203239 Each time N/A E-Microwave Two-way Spliter ODP-1-6-2S OE0120142 Each time N/A * Statement of Traceability: Bay Area Compliance Laboratories Corp. (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data Environmental Conditions Temperature: 22.5~28.7 C Relative Humidity: 47~57% ATM Pressure: 100.8~101.4kPa Tester: Theshy Xie Test Date: 2020-11-20~2021-01-21 Test Result: Compliance. Please refer to the following plots. EUT Spectrum Analyzer Splitter CMU200/CMW500 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 87 of 189 GSM 850, Low Channel GSM 850, Middle Channel GSM 850, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 88 of 189 PCS 1900, Low Channel PCS 1900, Middle Channel PCS 1900, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 89 of 189 WCDMA Band II, R99, Low Channel WCDMA Band II, R99, Middle Channel WCDMA Band II, R99, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 90 of 189 WCDMA Band V, R99, Low Channel WCDMA Band V, R99, Middle Channel WCDMA Band V, R99, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 91 of 189 LTE Band 2: 1.4M, QPSK, Low Channel 1.4M, QPSK, Middle Channel A * 3DB RBW 100 kHz SWT 100 ms * VBW 300 kHz Att 30 dB * Offset 7.5 dB LVL Ref 20 dBm Start 30 MHzStop 1 GHz97 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -44.13 dBm 111.480000000 MHz D1 -13 dBm Date: 20.NOV.2020 14:21:15 Att 30 dB * A * 3DB RBW 100 kHz SWT 100 ms * VBW 300 kHz Ref 20 dBm Offset 7.5 dB LVL Start 30 MHzStop 1 GHz97 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -42.54 dBm 142.520000000 MHz D1 -13 dBm Date: 20.NOV.2020 14:22:01 A * 3DB RBW 1 MHz SWT 250 ms * VBW 3 MHz Att 40 dB * Offset 7.5 dB LVL Ref 30 dBm Start 1 GHzStop 13.5 GHz1.25 GHz/ 1 PK MAXH -70 -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -23.44 dBm 11.025000000 GHz D1 -13 dBm Date: 20.NOV.2020 14:21:28 A * 3DB RBW 1 MHz SWT 250 ms * VBW 3 MHz Att 40 dB * Offset 7.5 dB LVL Ref 30 dBm Start 1 GHzStop 13.5 GHz1.25 GHz/ 1 PK MAXH -70 -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -22.50 dBm 3.100000000 GHz D1 -13 dBm Date: 20.NOV.2020 14:22:14 A * 3DB RBW 1 MHz SWT 130 ms * VBW 3 MHz Att 30 dB * Offset 7.5 dB LVL Ref 20 dBm Start 13.5 GHzStop 20 GHz650 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -16.03 dBm 16.750000000 GHz D1 -13 dBm Date: 20.NOV.2020 14:21:41 A * 3DB RBW 1 MHz SWT 130 ms * VBW 3 MHz Att 30 dB * Offset 7.5 dB LVL Ref 20 dBm Start 13.5 GHzStop 20 GHz650 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -15.85 dBm 14.800000000 GHz D1 -13 dBm Date: 20.NOV.2020 14:22:27 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 92 of 189 1.4M, QPSK, High Channel 3M, QPSK, Low Channel Att 30 dB * A * 3DB RBW 100 kHz SWT 100 ms * VBW 300 kHz Ref 20 dBm Offset 7.5 dB LVL Start 30 MHzStop 1 GHz97 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -40.04 dBm 171.620000000 MHz D1 -13 dBm Date: 20.NOV.2020 14:22:44 Att 30 dB * A * 3DB RBW 100 kHz SWT 100 ms * VBW 300 kHz Ref 20 dBm Offset 7.5 dB LVL Start 30 MHzStop 1 GHz97 MHz/ 1 PK MAXH -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 1 Marker 1 [T1 ] -47.53 dBm 227.880000000 MHz D1 -13 dBm Date: 20.NOV.2020 14:23:34 A * 3DB RBW 1 MHz SWT 250 ms * VBW 3 MHz Att 40 dB * Offset 7.5 dB LVL Ref 30 dBm Start 1 GHzStop 13.5 GHz1.25 GHz/ 1 PK MAXH -70 -60 -50 -40 -30 -20 -10 0 10 20 30 1 Marker 1 [T1 ] -23.72 dBm 11.875000000 GHz D1 -13 dBm Date: 20.NOV.2…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 127 of 189 LTE Band 66: 1.4M, QPSK, Low Channel 1.4M, QPSK, Middle Channel 1.4M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 128 of 189 3M, QPSK, Low Channel 3M, QPSK, Middle Channel 3M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 129 of 189 5M, QPSK, Low Channel 5M, QPSK, Middle Channel 5M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 130 of 189 10M, QPSK, Low Channel 10M, QPSK, Middle Channel 10M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 131 of 189 15M, QPSK, Low Channel 15M, QPSK, Middle Channel 15M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 132 of 189 20M, QPSK, Low Channel 20M, QPSK, Middle Channel 20M, QPSK, High Channel Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 133 of 189 FCC §2.1053, §22.917 & §24.238 & §27.53- SPURIOUS RADIATED EMISSIONS Applicable Standard FCC § 2.1053, §22.917, § 24.238 and § 27.53; Test Procedure The transmitter was placed on a wooden turntable, and it was transmitting into a non-radiating load which was also placed on the turntable. The measurement antenna was placed at a distance of 3 meters from the EUT. During the tests, the antenna height and polarization as well as EUT azimuth were varied in order to identify the maximum level of emissions from the EUT. The test was performed by placing the EUT on 3-orthogonal axis. The frequency range up to tenth harmonic of the fundamental frequency was investigated. Remove the EUT and replace it with substitution antenna. A signal generator was connected to the substitution antenna by a non-radiating cable. The absolute levels of the spurious emissions were measured by the substitution. Spurious emissions in dB = 10 lg (TXpwr in Watts/0.001) – the absolute level Spurious attenuation limit in dB = 43 + 10 Log 10 (power out in Watts) Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 134 of 189 Test Equipment List and Details Manufacturer Description Model Serial Number Calibration Date Calibration Due Date Sunol Sciences Antenna JB3 A060611-2 2020-08-25 2023-08-25 R&S EMI Test ReceiverESCI 100224 2020-09-12 2021-09-12 Unknown Coaxial Cable C-NJNJ-50 C-1000-01 2020-09-05 2021-09-05 Unknown Coaxial Cable C-NJNJ-50 C-0400-02 2020-09-05 2021-09-05 Unknown Coaxial Cable C-NJNJ-50 C-0530-01 2020-09-24 2021-09-24 Sonoma Amplifier 310N 185914 2020-10-13 2021-10-13 ETS-Lindgren Horn Antenna 3115 000 527 35 2018-10-12 2021-10-12 TDK RF Horn Antenna HRN-0118 130 084 2018-10-12 2021-10-12 Ducommun Technolagies Horn Antenna ARH-4223-02 1007726-01 1304 2018-12-06 2021-12-05 Ducommun Technola gies Horn Antenna ARH-4223-02 1007726-02 1304 2018-12-06 2021-12-05 Agilent Spectrum AnalyzerE4440A SG43360054 2020-07-07 2021-07-07 Unknown Coaxial Cable C-SJSJ-50 C-0800-01 2020-09-05 2021-09-05 Unknown Coaxial Cable C-2.4J2.4J-50 C-0700-02 2020-06-27 2021-06-27 Mini-Circuit Amplifier ZVA-213-S+ 54201245 2020-09-05 2021-09-05 Quinstar Amplifier QLW-18405536- JO 15964001001 2020-06-27 2021-06-27 Sinoscite Band-stop filter BSF1850- 1910MS-0935V2 0935V2 2020-06-16 2021-06-16 Sinoscite Band-stop filter BSF2500- 2750MS-1439-001 1437001 2020-06-16 2021-06-16 Micro-tronics High Pass Filter HPM50111 S/N-G217 2020-06-16 2021-06-16 Agilent Signal Generator E8247C MY43321350 2019-12-10 2020-12-10 2020-12-09 2021-12-08 Unknown Coaxial Cable C-NJNJ-50 C-0200-02 2020-09-05 2021-09-05 EMCO Adjustable Dipole Antenna 3121C 9109-753 N/A N/A * Statement of Traceability: Bay Area Compliance Laboratories Corp. (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data Environmental Conditions Test Items Radiation Below 1GHz Radiation Above 1GHz Temperature: 17.8~27.5 o C 18.1~25.3 o C Relative Humidity: 29~60% 29~46% ATM Pressure: 101.2~102.1kPa 100.9~101.2kPa Tester: Jalon Liu Felix Wang Test Date: 2020-11-22~2020-01-11 2020-11-24~2021-01-14 Test Result: Compliance. EUT Operation Mode: Transmitting Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RDG200407007-00B Page 135 of 189 Cellular Band (PART 22H) 30 MHz-10 GHz: Frequency (MHz) Polar (H/V) Receiver Reading (dBμV) Substituted Method Absolute Level (dBm) Limit (dBm) Margin (dB) Substituted Level (dBm) Antenna Gain (dBd/dBi) Cable Loss (dB) GSM850 Frequency:824.2MHz 1648.40 H 43.52 -60.66 10.44 0.71 -50.93 -13.00 37.93 1648.40 V 44.96 -59.82 10.44 0.71 -50.09 -13.00 37.09 2472.60 H 41.19 -61.59 12.88 1.25 -49.96 -13.00 36.96 2472.60 V 44.19 -58.64 12.88 1.25 -47.01 -13.00 34.01 3296.80 H 37.23 -62.55 13.60 1.59 -50.54 -13.00 37.54 3296.80 V 37.27 -62.52 13.60 1.59 -50.51 -13.00 37.51 597.80 H 54.28 -47.90 0.00 0.76 -48.66 -13.00 35.66 597.80 V 60.07 -45.36 0.00 0.76 -46.12 -13.00 33.12 GSM850 Frequency:836.6MHz 1673.20 H 42.30 -61.64 10.61 0.73 -51.76 -13.00 38.76 1673.20 V 44.63 -59.91 10.61 0.73 -50.03 -13.00 37.03 2509.80 H 43.89 -59.02 13.11 1.25 -47.16 -13.00 34.16 2509.80 V 49.11 -53.83 13.11 1.25 -41.97 -13.00 28.97 3346.40 H 37.22 -62.46 13.83 1.61 -50.24 -13.00 37.24 3346.40 V 37.51 -62.21 13.83 1.61 -49.99 -13.00 36.99 597.80 H 53.82 -48.36 0.00 0.76 -49.12 -13.00 36.12 597.80 V 58.49 -46.94 0.00 0.76 -47.70 -13.00 34.70 GSM850 Frequency:848.8MHz 1697.60 H 46.17 -57.53 10.78 0.75 -47.50 -13.00 34.50 1697.60 V 44.06 -60.24 10.78 0.75 -50.21 -13.00 37.21 2546.40 H 42.40 -60.55 13.15 1.27 -48.67 -13.00 35.67 2546.40 V 45.73 -57.36 13.15 1.27 -45.48 -13.00 32.48 3395.20 H 36.72 -62.80 14.08 1.64 -50.36 -13.00 37.36 3395.20 V 36.83 -62.79 14.08 1.64 -50.35 -13.00 37.35 597.80 H 54.59 -47.59 0.00 0.76 -48.35 -13.00 35.35 597.80 V 60.19 -45.24 0.00 0.76…
