2AIV9-AC1C360 Smart Camera little drop AI version

Correct Demonstration Avoid to be blocked the view of camera, please put the camera in the right way when on the table (pic 1) or on the wall (pic 2) Important Statement 2)Description of Hazardous material Contents 1)Personal information security To protect the information for you and your family, please make sure that the product you purchased was not bound by others without your permission. 360 Company always take strict measures to guard and protect the information safety of you and your family. Note: A small patch of electronic components for special purposes is marked with "X" in the table (such as high voltage resistors, ceramic resistors, diodes), in which the lead content may exceed 0.1% . As the screws and the core in the data cables using alloy with better performance, the lead content may also be exceed 0.1%. These components are in accordance with the requirements of the exemption clause of the EU RoHs directive. Limited by the current global technology development, there are no other alternative technologies and components. The external lead contents of these components are in accordance with enviornmental protection requirements. AppearancePacking list After login, click “+”button which on the right-top corner of screen. Click on “connect to my camera” and follow the voice prompts to complete. After adding successfully, start your discovery. Picture 1Picture 2 Note: The issues mentioned below may cause the network disconnection problem, suggest to avoid those items. • During acoustic matching,please keep away from noisy environment • Please turn off MAC Address Filter function in WiFi router, otherwise the camera may not be connected successfully. • Make sure the camera connect to 2.4GHz WiFi • The camera temporally not supports WPA/WPA2 enterprise-class WiFi, please select other options. • Suggest connecting nonbridging contact WiFi. 2) Download 360 Smart Camera APP Scan the QR code below, click the “ Download the APP” and install on your phone. USER GUIDE 1) Connect with power 3)Add camera Open 360 Smart Camera APP, click “register” button and start register an account. If you already have an account, login directly. Note: You can also purchase wall-mounting accessories or extension power cords at 360 Mall to customize the mounting. Method 1: The camera can be used directly on a horizontal table. Method 2: The camera base is magnetic, which can be adsorbed on the surface of iron-containing objects (such as refrigerator and iron window). Do not place it near the computer host or hard disk. Method 3: The camera can be attached on the surface of smooth objects such as glass, tile, and wall coated with latex paint using the delivery-attached 3M double-sided tap. (4) Fixing the camera 3M double-sided tape Base Smooth wall Product Description Resolution: 1080P (1920*1080) super HD resolution, transparent and exquisite screen, clear and bright, outstanding in both close-up view and full view. Color quality of picture: clear, beautiful, delicate, and realistic, comparable to screen display capability of mainstream smartphones, rich in color. Field of view angle: 130° ultra-wide-angle lens, ultra-clear customization, wide field of view, excellent full view effect. Voice: Real-time two-way synchronous conversation, stable and clear, free chat like a phone call, immersed in intimate communication. Night vision: The camera can automatically turn on the night vision mode according to the ambient light. In this mode, the picture is black and white and clearly visible within 7 m in the indoor environment. The internal filter is switched when night vision is turned on or off. The switching is accompanied by a slight "click" sound, which is normal. It will cause no light pollution, thereby protecting your eyes. FAQ Low level of heat is a normal phenomenon during working status. Working temperature may ranges from -0 to 40. 2) Is it normal for the camera to run hot? In order to get a better night vision imaging results, please don't put the camera in front of or close to the glass, white walls or other reflective objects, or you will see the picture bright in the vicinity and dark in the distance or white full of the screen. 3) Announcements AC1C Camera x1 Adapter x1 USB cable x1 3M double-sided tape x1 User Manual x1 Insert Power Line into Power interface which behind the camera. When the status indicator lamp turns green, shows the camera start working. Please make sure your phone has connected to the available WiFi network. Please make sure to hang up on the wall after finishing connecting the camera. Status indicator Lens MIC Magnetic adsorbable base Configuration Button Speaker Micro SD Slot Power socket 360o rotatable stand Please confirm if the camera and its accessories are in good condition after opening the package. Constant Green Camera activated flashing Green Configuring Wi-Fi networks or offline Constant Blue Camera on-line Flashing Blue Video being viewed 1) How many modes does the indicator have? Wrong The night vision imaging effect Right The night vision imaging effect Right The night vision imaging effect Wrong The night vision imaging effect Toxic and Harmful Substances and Elementst Lead（Pb） Mercury（Hg） Cadmium（Cd） Hexavalent Chromium （Cr(VI)） Polybrominsted Biphenyls（PBB） Polybrominsted DiphenylEthers（PBDE） Component :Indicates that for each item in this produce ,said hazardous substance id below the requirements set forth by the standard GB/T26572. This form is prepared in accordance with SJ/T11364. : It indicates that the hazardous substance in at least one homogeneous material of this part exceeds the limit specified in GB/T26572. However, it satisfies limit requirements specified in the List of Exempt Applications of Hazardous Substances Identified in the Management Catalog. Plastic enclosure Circuit board components Power cableAdapterLens After-Sales Service 1) Warranty policy of 360 Smart Camera 2) Non warranty policy of 360 Smart Camera This product comes with …

Text truncated - open the document above for the full version.

Differences Declaration To whom concern, We company Beijing Visual World Technology Co.,Ltd. Here by declares: The product model AC1CAS51, AC1CEU00, AC1CNA19, AC1CAS11, AC1CAS18, AC1COC10, AC1CAS12, AC1CAS14, AC1CAS15, AC1CAS16, AC1CAT00 are the same PCB layout, electronic schematic and Antenna with AC1C, which tested in Shenzhen Huatongwei International Inspection Co., Ltd., the only difference between them are the model name, different colors and does not have any effect on any other functions. Sincerely yours, Name (in print): Liling Ge Company name: Beijing Visual World Technology Co.,Ltd. Company address: 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing Tel：010-52447808 E-Mail: [email protected]

2020-03-30 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd./ 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China / Hans Hu,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Beijing Visual World Technology Co.,Ltd. / 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing. Agency agreement expiration date: Mar.30, 2021 By: Liling Ge Signature Printed Title: PM On behalf of : Beijing Visual World Technology Co.,Ltd. Telephone: 010-52447808

2020-03-30 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AIV9-AC1C Product Name: 360 Smart Camera little drop AI version Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. By: Liling Ge Signature Printed Title: PM On behalf of : Beijing Visual World Technology Co.,Ltd. Telephone: 010-52447808

External Photos Adapter 1: Adapter 2:

Label&Label location

Internal Photos RF ANT

Page: 1 of 21 TEST REPORT Report No. .......................................: CHTEW20030098 Report verification : Project No. ..................................: SHT2002002920EW FCC ID ............................................. : 2AIV9-AC1C Applicant’s name ........................... : Beijing Visual World Technology Co.,Ltd. Address ............................................. : 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing Manufacturer.....................................: Beijing Visual World Technology Co.,Ltd. Address.............................................: 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing Test item description .................... : 360 Smart Camera little drop AI version Trade Mark ....................................... : +360 Model/Type reference ....................... : AC1C Listed Model(s) ................................. : AC1CAS51, AC1CEU00, AC1CNA19, AC1CAS11, AC1CAS18, AC1COC10, AC1CAS12, AC1CAS14, AC1CAS15, AC1CAS16, AC1CAT00 Standard ......................................... : 47 CFR FCC Part 15 Subpart B Date of receipt of test sample...........: Mar.04, 2020 Date of testing..............................: Mar.04, 2020- Mar.18, 2020 Date of issue.................................: Mar.19, 2020 Result .................. ........................: Pass Compiled by ( position+printed name+signature) .. : File administrators Echo Wei Supervised by ( position+printed name+signature) .. : Project Engineer Edward Pan Approved by ( position+printed name+signature) .. : RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely corresponds to the test sample. Report No : CHTEW20030098 Page 2 of 21 Issued: 2020-03-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) Contents 1. TEST STANDARDS AND REPORT VERSION ............................................ 3 1.1. Test Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION ..................................................................... 4 3. SUMMARY ............................................................................... 5 3.1. Client Information 5 3.2. Product Description 5 3.3. EUT operation mode 5 3.4. Configuration of Tested System 5 3.5. Support unit used in test configuration 5 4. TEST ENVIRONMENT .................................................................... 6 4.1. Address of the test laboratory 6 4.2. Test Facility 6 4.3. Environmental conditions 7 4.4. Statement of the measurement uncertainty 7 4.5. Equipments Used during the Test 8 5. TEST CONDITIONS AND RESULTS ..................................................... 9 5.1. Conducted Emissions Test 9 5.2. Radiated Emissions Test 14 6. TEST SETUP PHOTOS OF THE EUT ................................................... 20 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ................................... 21 Report No : CHTEW20030098 Page 3 of 21 Issued: 2020-03-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2014 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz 1.2. Report version information Revision No. Date of issue Description N/A 2020-03-19 Original Report No : CHTEW20030098 Page 4 of 21 Issued: 2020-03-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 2. TEST DESCRIPTION Test Item Section in CFR 47 Result Test Engineer Conducted Emissions 15.107(a) PASS Jianquan Wu Radiated Emissions 15.109(a) PASS Pan Xie Note: The measurement uncertainty is not included in the test result. Report No : CHTEW20030098 Page 5 of 21 Issued: 2020-03-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V01 (2018-01) 3. SUMMARY 3.1. Client Information Applicant: Beijing Visual World Technology Co.,Ltd. Address: 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing Manufacturer: Beijing Visual World Technology Co.,Ltd. Address: 501 & 5F,102 No, Building No. 2, No 6 Jiuxianqiao Rd, Chaoyang District, Beijing 3.2. Product Description Name of EUT: 360 Smart Camera little drop AI version Trade Mark: +360 Model No.: AC1C Listed Model(s) AC1CAS51, AC1CEU00, AC1CNA19, AC1CAS11, AC1CAS18, AC1COC10, AC1CAS12, AC1CAS14, AC1CAS15, AC1CAS16, AC1CAT00 Power supply: DC 5V from adapter Adapter Information 1: Model: A18A-050100U-US2 Input: 100-240Va.c.,50/60Hz 0.2A Output: 5Vd.c.,1.0A Adapter Information 2: Model: TEKA006-0501000UK Input: 100-240Va.c.,50/60Hz 0.3A MAX Output: 5Vd.c.,1000mA Hardware version: HI3518EV300_V360P6_GC2053_D903 Software version: AC1CA1_B_20200302.7.2.1 3.3. EUT operation mode Test mode Describe Camera recording mode The EUT works at video recording status 3.4. Configuration of Tested System N/A. 3.5. Support unit used in test configuration N/A. Report No : CHTEW20030098 Page 6 of 21 Issued: 2020-03-19 Shenzhen Huatongwei International Inspection Co., …

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS OF THE EUT Conducted Emissions (AC Mains) Radiated Emissions
