FCC ID : 2AJ55HOLYSTONE5W RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) KDB 447498 D01 General RF Exposure Guidance v06 Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 11.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in 20cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 11.2 Measurement Result 5G WIIF Mode Max Measured power (dBm) Max tune-up power (dBm) Antenna gain Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) Ant. 1 12.70 14 2 1.58 0.007924 1 Ant. 2 13.07 14 2 1.58 0.007924 1 Ant. 1+ Ant. 2 15.85 16 2 1.58 0.012559 1

Report No. ES210329076W Page 1 of 58 Ver.1.0 TEST REPORT Product Name ： quadcopter Model Number ： HS175D, HS175, HS175E, HS175G, HS800, HS820, HS830, HS850, HS710, HS730, HS740, HS750, HS760, HS770, HS600, HS610, HS620, HS630, HS660, HS670, HS690, HS500, HS520, HS530, HS560, HS570, HS400, HS410, HS420, HS430, HS440, HS450, HS300, HS320, HS360, HS380, HS390, HS250, HS260, HS280, HS290, HS130, HS176, HS115, HS125, HS135, HS155, HS225, HT01, HT02, HT03, HT04, HT05, HT06, HT07, HT08, HS900, HS920, HS930, D11, D15, D22, D25, D33, D35, D55, D23, D40, D60, D65, DE23, DE28, DE29, HT15, HT20, HT25, HT30, HT35, HT50, HT45, HT55, HT60, HT65 FCC ID ： 2AJ55HOLYSTONE5W Prepared for : Xiamen Huoshiquan Import & Export CO., LTD Address : Room 703, No. 813-2 Xiahe Road, Siming District, XIAMEN China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES210329076W Date(s) of Tests : Apr. 1, 2021 to Apr. 28, 2021 Date of issue : Apr. 28, 2021 Report No. ES210329076W Page 2 of 58 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Xiamen Huoshiquan Import & Export CO., LTD Address： Room 703, No. 813-2 Xiahe Road, Siming District, XIAMEN China Manufacturer : Xiamen Huoshiquan Import & Export CO., LTD Address： Room 703, No. 813-2 Xiahe Road, Siming District, XIAMEN China EUT : quadcopter Model Name : HS175D, HS175, HS175E, HS175G, HS800, HS820, HS830, HS850, HS710, HS730, HS740, HS750, HS760, HS770, HS600, HS610, HS620, HS630, HS660, HS670, HS690, HS500, HS520, HS530, HS560, HS570, HS400, HS410, HS420, HS430, HS440, HS450, HS300, HS320, HS360, HS380, HS390, HS250, HS260, HS280, HS290, HS130, HS176, HS115, HS125, HS135, HS155, HS225, HT01, HT02, HT03, HT04, HT05, HT06, HT07, HT08, HS900, HS920, HS930, D11, D15, D22, D25, D33, D35, D55, D23, D40, D60, D65, DE23, DE28, DE29, HT15, HT20, HT25, HT30, HT35, HT50, HT45, HT55, HT60, HT65 Trademark : Holy Stone Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart E PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.407 The test results of this report relate only to the tested sample identified in this report. Date of Test : Apr. 1, 2021 to Apr. 28, 2021 Prepared by : Qiang Wang/Editor Reviewer : Sewen Guo/Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ES210329076W Page 3 of 58 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................................................... 2 2 EUT TECHNICAL DESCRIPTION ............................................................................................................. 4 3 SUMMARY OF TEST RESULT .................................................................................................................... 5 4 TEST METHODOLOGY ............................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED ................................................................................................. 6 4.3 DESCRIPTION OF TEST MODES .......................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 FACILITIES.............................................................................................................................................. 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS .......................................................................... 8 6 TEST SYSTEM UNCERTAINTY ................................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST .................................................................................................. 10 7.1 RADIO FREQUENCY TEST SETUP .................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP .................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP ............................................................................................. 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM .............................................................. 13 7.5 SUPPORT EQUIPMENT........................................................................................................................ 13 8 TEST REQUIREMENTS ............................................................................................................................. 14 8.1 BANDWIDTH MEASUREMENT ......................................................................................................... 14 8.2 MAXIMUM CONDUCTED OUTPUT POWER.................................................................................... 22 8.3 MAXIMUM PEAK POWER DENSITY ................................................................................................ 26 8.4 FREQUENCY STABILITY .................................................................................................................... 37 8.5 UNDESIRABLE RADIATED SPURIOUS EMISSION ......................................................................... 39 8.6 POWER LINE CONDUCTED EMISSIONS ......................…
