2AJ55HOLYSTONEW7quadcopter

D70 V 1.0 Instructions For Use Gebrauchsanweisungen +1(855)777-8866 [email protected] (USA)[email protected] (EU) [email protected] (JP) English01-33 Deutsch 日本語 34-59 60-90 Contents Disclaimer & Warning ................................................................................ Safety Guidelines ......................................................................................... Maintenance ................................................................................................. Package Contents ........................................................................................ Drone Details ................................................................................................ Transmitter Functions ................................................................................ Joystick Mode ............................................................................................... Preparation Before Flight Charging .................................................................................................. Download App ...................................................................................... Arms .......................................................................................................... Drone Battery ......................................................................................... Propellers ................................................................................................. Phone Holder ......................................................................................... Flight Pairing ....................................................................................................... Connect to Wi-Fi .................................................................................... One Key Takeoff/Landing .................................................................. Functions Details Take Photo/Record Video .................................................................. Camera Angle Adjustment ................................................................ High-Speed Rotation ............................................................................ Circle Fly ................................................................................................... Speed Switch .......................................................................................... 1 1 5 6 7 8 9 10 11 11 12 13 14 15 16 17 18 18 19 19 20 Emergency Stop .................................................................................... 360° Flip .................................................................................................. Altitude-Hold Function ....................................................................... Headless Mode ...................................................................................... Attitude Adjustment Trimmer ................................................................................................... Calibrate the Gyro................................................................................. Specification .................................................................................................. Contact Us ..................................................................................................... General Information ................................................................................... 20 21 21 22 24 25 26 27 28 -1- SAFETY GUIDELINES CHECK BEFORE USE DISCLAIMER & WARNING 1. Please read this Disclaimer & Warning and Safety Guidelines carefully before using our product. This product is not recommended for people under the age of 14. By using this product, you hereby agree to this disclaimer and signify that you have read it fully. You agree that you are responsible for your own conduct and any damage caused while using this product, and any consequence. You agree to only use this product for it's designed purposes and in accordance with the local laws, regulations and all applicable policies and guidelines that DEERC may provide. 2. When using this product, please be sure to strictly abide by the specification requirements and safety guidelines stated in this document. Any personal injury, property damage, legal disputes and all other adverse events caused by the violation of any of the safety instructions or due to any other factor, WILL NOT be DEERC’s responsi- bility. This product is a high precision drone that integrates various electronic stability and control mechanisms. Please be sure to configure this drone carefully and correctly to ensure safe, accident-free operation Ensure that the batteries of the drone and transmitter are clean, undamaged, and fully charged before every use. Ensure that all the propellers are undamaged and are installed in the correct orientation. -2- FLIGHT ENVIRONMENT Fly in Open Areas Maintain Line of Sight - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Fly Below 131 ft (40 m) Please perform a thorough check of the product before each use. Inspect the integrity of the parts, any signs of cracks and wear off on the propellers, battery power and effectiveness of the indicator, etc. If there is any problem found after checking the drone, please refrain from using it until the problem is resolved. Avoid flying over or near obstacles, crowds, high voltage power lines, trees, airports or bodies of water. DO NOT fly near strong electromagnetic sources such as power lines and base stations as it may affect the onboard compass. DO NOT use this drone in adverse weather conditions such as rain, snow, fog, and wind. SAFETY GUIDELINES -3- OPERATION REQUIREMENTS USE OF BATTERY ⑥ Stay away from the rotating propellers and motors. DO NOT fly in any spaces where drones are prohibited. Please respect people's right…

Text truncated - open the document above for the full version.

EUT EXTERNAL PHOTOGRAPHS ----------------The end----------------

EUT INTERNAL PHOTOGRAPHS

FPC antenna ----------------The end----------------

FCC ID : 2AJ55HOLYSTONEW7 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 1.1 Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1416 R= distance between observation point and center of the radiator in 20cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the nd total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 1.2 Measurement Result Mode Max Measured power (dBm) Max tune-up power (dBm) Antenna gain Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2 ) 2.4G WIF 17.27 18 2.44 1.75 0.02202 1 ----------------THE END OF REPORT---------------

1 H Hanyi Electronic Technology Co., LTD Specification custome Project Name Part Name Wifi Antenna frequency range 2.4-2.5GHz Part Number edition R:A Sample type built-in Issue Date 2022-12-10 Prepared by Reviewed by Approve Product picture 2 Content 1、Cover. ................................................................................................. 1 2、Content. ..................................................................................................... 2 3、Product Picture. .......................................................................... 3 4、Electricity test report. .............................................................. 4- 5 3 3. Product Picture 4 4. Electricity test report 4.1 █Electrical Specifications FrequencyRange(MHz) 2400-2500 Gain(dBi) 2.44 VSWR ≤2.0 Input Impedance（Ω） 50 Maximum input power(W) 2 4.2 Voltage Standing Wave Ratio 5 4.3 Gain and Efficiency 4.4 Directional Diagram 2.4G directional diagram Frequency（MHz） Gain(dBi) Efficiency(%) 2400 1.5 28.80 2410 1.73 31.42 2420 1.91 32.26 2430 2.01 35.56 2440 2.13 35.28 2450 2.31 37.34 2460 2.32 38.39 2470 2.41 39.68 2480 2.44 41.49 2490 2.35 40.80 2500 2.33 39.42

Report No. ENS2212130001W00301R Page 1 of 57 Ver.1.0 TEST REPORT Product Name ： quadcopter Model Number ： D70, D70S, D70E, D70R, D70G, D60, D60S, D60E, D60G, HS120S, HS270D, HS270S, F7, D65, D75, D80, D85, D90, D11, D33, D100, D200, HT40, HT50, HT60, HT65, HT70, HT300, HS290, HS320, HS390, HS410, HS460, HS480, HS490, HS520, HS530, HS540, HS560, HS570, HS580, HS590, HS610, HS620, HS630, HS640, HS650, HS660, HS670, HS680, HS690, HS730, HS740, HS750, HS760, HS770, HS780, HS790, HS810, HS820, HS900, HS176, HS101, HS155, HS176, D89, DC10, DC11, DC12, HS210F, JY08, JY03, JY01, 1812, Z6pro FCC ID ： 2AJ55HOLYSTONEW7 Prepared for : Xiamen Huoshiquan Import & Export CO., LTD Address : Unit 1, Room 501, Hongxiang Building, No.258 Hubin Nan Road, Siming District, Xiamen, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone,Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2212130001W00301R Date(s) of Tests : December 13, 2022 to December 27, 2022 Date of issue : December 27, 2022 $二维码$ Report No. ENS2212130001W00301R Page 2 of 57 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ........................................................................................................ 3 2 EUT TECHNICAL DESCRIPTION ...................................................................................................... 5 3 SUMMARY OF TEST RESULT ........................................................................................................... 6 4 TEST METHODOLOGY ...................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................... 8 5 FACILITIES AND ACCREDITATIONS ................................................................................................ 9 5.1 FACILITIES .................................................................................................................................. 9 5.2 EQUIPMENT ................................................................................................................................ 9 5.3 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................... 9 6 TEST SYSTEM UNCERTAINTY ....................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................... 14 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................... 15 7.5 SUPPORT EQUIPMENT ............................................................................................................ 15 8 TEST REQUIREMENTS .................................................................................................................... 16 8.1 DTS 6DB BANDWIDTH .............................................................................................................. 16 8.2 DTS 99% BANDWIDTH ............................................................................................................. 21 8.3 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................. 26 8.4 MAXIMUM POWER SPECTRAL DENSITY ............................................................................... 31 8.5 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ............................... 36 8.6 RADIATED SPURIOUS EMISSION ........................................................................................... 43 8.7 CONDUCTED EMISSION TEST ................................................................................................ 56 8.8 ANTENNA APPLICATION .......................................................................................................... 57 Report No. ENS2212130001W00301R Page 3 of 57 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Xiamen Huoshiquan Import & Export CO., LTD Address : Unit 1, Room 501, Hongxiang Building, No.258 Hubin Nan Road, Siming District, Xiamen, China Manufacturer : Xiamen Huoshiquan Import & Export CO., LTD Address : Unit 1, Room 501, Hongxiang Building, No.258 Hubin Nan Road, Siming District, Xiamen, China EUT : quadcopter Model Name : D70, D70S, D70E, D70R, D70G, D60, D60S, D60E, D60G, HS120S, HS270D, HS270S, F7, D65, D75, D80, D85, D90, D11, D33, D100, D200, HT40, HT50, HT60, HT65, HT70, HT300, HS290, HS320, HS390, HS410, HS460, HS480, HS490, HS520, HS530, HS540, HS560, HS570, HS580, HS590, HS610, HS620, HS630, HS640, HS650, HS660, HS670, HS680, HS690, HS730, HS740, HS750, HS760, HS770, HS780, HS790, HS810, HS820, HS900, HS176, HS101, HS155, HS176, D89, DC10, DC11, DC12, HS210F, JY08, JY03, JY01, 1812, Z6pro Trademark : Holy Stone Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS IC RSS-GEN, Issue 5(04-2018)+A1(03-2019)+A2(02-2021) IC RSS-247 Issue 2(02-2017) PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by th…

Text truncated - open the document above for the full version.

Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz) ----------------The end----------------
