2AJKE-L1001LLumos Kickstart Lite Helmet

Lumos Kickstart Lite User Guide Before using your Lumos Kickstart Lite, review the user guide at: lumoshelmet.co/support/kickstartlite Safety and Handling See “Safety, handling, and support” in the Lumos Kickstart Lite User Guide. Lumos One-Year Limited Warranty Lumos warrants all products sold by Lumos to be free of defects in material and workmanship for a period of one (1) year from the date of purchase unless otherwise specified on the product. If a product is found to be defective by Lumos, in its sole discretion, Lumos’ only responsibility will be to replace the defective product. Lumos will not be responsible for any costs, losses or damages incurred because of the loss or use of any of its products, and Lumos specifically disclaims all claims for consequential and incidental damages. This limited warranty is subject to several important restrictions: This limited warranty only applies to products purchased directly from Lumos or from a Lumos Authorized Reseller. This limited warranty is valid only for the original purchaser of a product, and it cannot be transferred to another person upon the sale, lease, or transfer of the product. This limited warranty does not cover normal wear and tear. This limited warranty does not apply to anything other than defects in the manufacturing and workmanship of the product. The limited warranty is waived if you seek to repair the product using anything other than approved Lumos products and services, or if you seek to combine the product with any third party product (like sealants, cameras, or custom helmet pads). If, upon its inspection, Lumos discovers that you have modified, changed, or altered the product in any way, this limited warranty is waived. Lumos gives no warranty regarding the life of the batteries used in its products. Actual battery life may vary depending on a number of factors, including, but not limited to, the configuration and usage of a product. Your use of our products is at your own discretion and risk. You will be solely responsible for (and Lumos disclaims) any and all loss, liability or damages resulting from your use of our products , including loss of life, personal injury, or the loss of or damage to computer, mobile device, and all other property. Lumos does not guarantee or promise any specific level of performance or battery life associated with the use of its products or any feature of them. All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are hereby limited to the duration of the limited warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. With the exception of any warranties implied by state law as hereby limited, the foregoing limited warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Company Information 25/F, Two Harbour Square 180 Wai Yip Street Kwun Tong, Hong Kong RF Warning Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Specification of Radio Transmission The above product is in conformity with the European Radio Equipment Directive (RED) (2014/53/EU) which is subject of EU certificate (ATSZAWW190419002) issued by: Shenzhen Anbotek Compliance Laboratory Limited. 1/F, Building D, Sogood Science and Technology Park, Sanwei community, Hangcheng Street, Bao’an District, Shenzhen, Guangdong, China 218102. Bluetooth LE Maximum Output Power: -5.22dBm EIRP Average (Calculated) Maximum Antenna Gain: 1dBi You can find the declaration of conformity at the following link: www.lumoshelmet.co/EU_DoC_MX Helmet Model: Lumos Kickstart Lite Helmet Model number: L1001L C.P.S.C. 16 CFR Part 1203 (Consumer Product Safety Commission) United States Federal Safety Standard for Bicycle Helmets CE, EN1078:2012 +A1:2012 ASTM F1492 - 15 - Standard Specification for Helmets Used in Skateboarding and Trick Roller Skating (European Safety Standard) Patent Pending This helmet is designed to protect impact cause by collision …

Text truncated - open the document above for the full version.

Lumen Labs(HK) Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2019/12/23 Subject; Request for Confidentiality FCC ID: 2AJKE-L1001L To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Haoran Chen Title: CEO

Lumen Labs(HK) Limited Agent Authorization Company: Lumen Labs(HK) Limited Address: 25/F, Two Harbour Square 180 Wai Yip Street, Kwun Tong Hong Kong Product Name: Lumos Kickstart Lite Helmet Model Number(s): L1001 L, L1001M We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2019/12/23 Name: Haoran Chen Title: CEO Company: Lumen Labs(HK) Limited

Lumen Labs(HK) Limited Model Difference 2019-12-23 Product Name: Lumos Kickstart Lite Helmet Trademark: N/A Model Number(s): L1001 L, L1001M FCC ID: 2AJKE-L1001L All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature: Client’s name / title : Haoran Chen /CEO Contact information / address: 25/F, Two Harbour Square 180 Wai Yip Street, Kwun Tong Hong Kong

External Photos

Size:50*25mm Multimedia player FCC ID: 2AJKE-L1001L IC: 21853-L1001L This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. FCC ID: 2AJKE-L1001L Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402-0.280.940±11.001.26<50.390233.00YES 2.440-0.520.890±11.001.26<50.393303.00YES 2.480-0.860.820±11.001.26<50.396513.00YES GFSK Conclusion: Pass For the max result : 0.39651W/Kg ≤ FCC Limit 3.0 for 1g SAR.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 41 Test Report FCC: 2AJKE-L1001L Product Name: Lumos Kickstart Lite Helmet Trademark: N/A Model Name : L1001 L L1001M Prepared For : Lumen Labs(HK) Limited Address : 25/F, Two Harbour Square 180 Wai Yip Street, Kwun Tong Hong Kong Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 09, 2019 to Dec. 16, 2019 Date of Report : Dec. 17, 2019 Report No.: BCTC1912000779E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 41 TEST RESULT CERTIFICATION Applicant’s name ................. : Lumen Labs(HK) Limited Address ................................. : 25/F, Two Harbour Square 180 Wai Yip Street, Kwun Tong Hong Kong Manufacture's Name ............ : Lumen Labs(HK) Limited Address ................................. : 25/F, Two Harbour Square 180 Wai Yip Street, Kwun Tong Hong Kong Product description Product name ........................... : Lumos Kickstart Lite Helmet Trademark ................................. : N/A Model and/or type reference : L1001 L, L1001M Standards ............................. : FCC Part15.247 ANSI C63.10:2013 KDB558074 D01 15.247 Meas Guidance v05r02 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 41 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 DEVIATION FROM TEST STANDARD 17 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 21 3.3 RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION 24 3.3.1 TEST REQUIREMENT: 24 3.3.2 TEST PROCEDURE 24 3.3.3 DEVIATION FROM TEST STANDARD 25 3.3.4 TEST SETUP 25 3.3.5 EUT OPERATING CONDITIONS 25 4 . POWER SPECTRAL DENSITY TEST 27 4.1 APPLIED PROCEDURES / LIMIT 27 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 41 Table of Contents Page 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . BANDWIDTH TEST 30 5.1 APPLIED PROCEDURES / LIMIT 30 5.1.1 TEST PROCEDURE 30 5.1.2 DEVIATION FROM STANDARD 30 5.1.3 TEST SETUP 30 5.1.4 EUT OPERATION CONDITIONS 30 5.1.5 TEST RESULTS 31 6 . PEAK OUTPUT POWER TEST 33 6.1 APPLIED PROCEDURES / LIMIT 33 6.1.1 TEST PROCEDURE 33 6.1.2 DEVIATION FROM STANDARD 33 6.1.3 TEST SETUP 33 6.1.4 EUT OPERATION CONDITIONS 33 6.1.5 TEST RESULTS 34 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 35 7.1 APPLICABLE STANDARD 35 7.2 TEST PROCEDURE 35 7.3 DEVIATION FROM STANDARD 35 7.4 TEST SETUP 35 7.5 EUT OPERATION CONDITIONS 35 8 . ANTENNA REQUIREMENT 38 8.1 STANDARD REQUIREMENT 38 8.2 EUT ANTENNA 38 9 . EUT TEST PHOTO 39 10 . EUT PHOTO 41 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 41 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.205, 15.209 Radiated Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Restricted Band of Operation PASS 15.247(d) Band Edge (Out of Band Emissions) PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000779E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 41 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add.: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Conducted emissions Shenzhen BCTC Testing Co., Ltd. Radiated Measurement Photos
