2AJN9-DBL9000WLink Me Watch

Welcome Guide Link Me Watch Paid service:customer will incur a repair charge as follows: -No valid warranty card or warranty card incompatible. -No S/N or S/N incompatible with warranty card -Malfunction caused by artificial damages(like external impact or submerging product into water,ect.) -Misuse of the product.User has not followed the instructions in the manual. -Product disassembled or repaired by individual or unauthorized service center. -Damages caused by storing the product in a hot or humid environment. -Defects or malfunctions due to force majeure. Thank you for purchasing the iWALK product. Our product’s warranty period is 12 months starting from the date of purchase.Within the warranty period, free service will be provided to the consumer. if the product has any quality problems(requiring warranty card with distributor’s official stamp and valid S/N). Carte de garantie | Garantiekarte | Scheda di garanzia Hoja de garantía | 製品パラメータ Warranty card Dealer’s Information (Please complete warranty card and use for any future warranty service) User’s Information Dealer Name: Product Type: Tel: Sales Date: Model No.: Product Name: User’s Name: E-mail: Tel: ADD: Warranty Content: Made in China PA1127 使用说明书 | user's manual | Manuel d'utilisation Bedienungsanleitung | Manuale d’istruzione Manual de instrucciones | 取扱説明書 1）为保证电池寿命，请每 4个月至少使用并给产品充电一次。 2）使用原装或者通过认证的线材。 3）请勿接触液体。 4）请勿拆卸。 5）避免跌落产品。 6）避免在过低或过高温度下使用。 1）Pour assurer la durée de vie de la batterie, veuillez utiliser et charger le produit au moins une fois tous les 4 mois. 2）Utilisez du câble d'origine ou certifié. 3）Ne le laisser pas toucher du liquide. 4）Veuillez ne pas démonter. 5）Évitez la chute du produit. 6）Évitez de l'utiliser à des températures trop faibles ou trop élevées. 产品参数/Specifications/Paramètre produit/Produktparameter Parametri del prodotto/Parámetros del producto/製品パラメータ 安全注意事项 1）To preserve battery lifespan, use and recharge at least once every 4 mouths. 2）Use original or certified cables. 3）Do not expose to liquids. 4）Do not disassemble. 5）Avoid dropping. 6）Avoid extreme temperatures. Safety Precautions 1）Verwenden und laden Sie das Produkt mindestens alle 4 Monate auf, um die Lebensdauer der Batterie zu gewährleisten. 2）Verwenden Sie Original- oder zertifizierte Drähte. 3）Berühren Sie keine Flüssigkeiten. 4）Zerlegen Sie das Gerät nicht. 5）Vermeiden Sie das Produkt fallen zu lassen. 6）Vermeiden Sie die Verwendung bei zu niedrigen oder zu hohen Temperaturen. Sicherheitsvorkehrungen Précautions de sécurité 1）Para garantizar la duración de la batería, debe usar y cargar al producto al menos una vez por cada 4 meses. 2）Utilizar los alambres originales o homologados. 3）No tocar con el líquido. 4）No lo desmonte. 5）Evitar la caída del producto. 6）Evite el uso del presente a temperaturas demasiado bajas o demasiado altas. Precauciones de seguridad 1）Per assicurare la vita della batteria, Le preghiamo di utilizzare e ricaricare il prodotto almeno una volta per ogni 4 mesi. 2）Utilizzare la confezione originale o il cavo certificato. 3）Non toccare il liquido. 4）Non smantellare il prodotto. 5）Evitare la caduta del prodotto. 6）Evitare l’utilizzo alla temperatura troppo bassa o alta. Precauzioni di sicurezza 1）電池の寿命を保証するために、最低でも4ヶ月おきに本製品に充電してください。 2）オリジナルまたは認証された線材を使ってください。 3）液体との接触を避けてください。 4）無断に解体しないでください。 6）度が低すぎまたは高すぎな環境での使用を避けてください。 安全注意事項 产品名称: 小飞象移动电源 产品型号: DBL9000W 额定能量: 33.3Wh 转换率: 60% 额定容量: 9000mAh 输入: USB-C口 5V 2A Lightning 口5V 1.5A 输出 1: USB-C口 5V 2A 输出 2: Lightning口 5V 2A 输出 3: Lightning线 5V 2A 产品尺寸: 100x50x30mm 产品重量: 401g Product Name:Link Me Watch Model No.: DBL9000W Capacity: 9000mAh 3.7V/33.3Wh Input: USB-C Port 5V 2A,Lightning Port 5V 1.5A Output 1: USB-C Port 5V 2A Output 2: Lightning Port 5V 2A Output 3: Lightning Cable 5V 2A Output 4: Apple Watch Wireless Charging 3W Size: 144x76.5x32mm Weight: 401g -Support up to 3 devices to charge at the same time. - Supporta fino a 3 dispositivi da caricare contemporaneamente. - Admite hasta 3 dispositivos para cargar al mismo tiempo. 允许本产品与一台设备同时进行充电，为了最好的给本产品充电，请使用至少 5V/2.0A以上输出充电器进行充电。 - 本产品最多可支持3个设备同时充电。 - Prend en charge jusqu'à 3 appareils pour charger en même temps. 边充边放功能 You can plug it into a USB socket to recharge and have your phone plugged into it at the same time,for recharging better,please use at least 5V/2.0A adapter for charging. Pass-through Charging - 同時に充電する最大3台のデバイスをサポート. - Unterstützt bis zu 3 Geräte zum gleichzeitigen Laden. Permita al producto a cargar simultáneamente con otro dispositivo. Para una carga mejor al producto, use un cargador de salida superior 5V/2.0A para la carga. Función de carga y descarga al mismo tiempo Dieses Produkt darf gleichzeitig mit einem anderen Gerät aufgeladen werden. Um dieses Produkt am besten aufzuladen, verwenden Sie bitte ein Ladegerät mit einer Ausgangsspannung von mindestens 5 V/2,0 A. Funktion der gleichzeitigen Ladung und Entladung Ce produit peut être chargé simultanément avec un appareil, pour charger le produit au mieux, veuillez utiliser un chargeur de sortie d'au moins 5V/2.0A. Fonction de charge et de décharge simultanée Il prodotto può essere ricaricato contestualmente all’altro dispositivo. Per l’ottima ricarica, Le preghiamo di utilizzare il caricabatterie con uscita di almeno 5V/2.0A. Funzione di contestuale ricarica e riproduzione I本製品と一台の設備が同 時に充電することができます。本製品によ りよく充電できるように、5V/2.0A以上の出力充電器を使って充電し てください。 充電しながら放電機能 输出 4: Apple Watch Wireless Charging 3W Link Me Watch DBL9000W FCC Notice: This device complies with Part 15 of the FCC rules. Operation is subject to the following twoconditions: 1) this device may not cause harmful interference, and 2) this device must acceptany interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digitaldevice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonableprotection against harmful interference in a reside…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/11/12 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AJN9-DBL9000W DBL9000W For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Zhide Wu Company: U2O GLOBAL CO.,LTD. Address: Huanzhu Road No.385, 4 Floor, Jimei District ,Xiamen, China Phone: +860592-5743537 Fax: +860592-5753736 E-Mail: [email protected]

U2O GLOBAL CO.,LTD. Huanzhu Road No.385, 4 Floor, Jimei District ,Xiamen, China Tel: +860592-5743537 Fax: +860592-5753736 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 11/12/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID:2AJN9-DBL9000W including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Zhide Wu Company: U2O GLOBAL CO.,LTD. Address: Huanzhu Road No.385, 4 Floor, Jimei District ,Xiamen, China Phone: +860592-5743537 Fax: +860592-5753736 E-Mail: [email protected]

FCC ID: 2AJN9-DBL9000W FCC ID: 2AJN9-DBL9000W

FCC ID:2AJN9-DBL9000W FCC ID:2AJN9-DBL9000W

FCC ID: 2AJN9-DBL9000W Antenna FCC ID: 2AJN9-DBL9000W

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20201103029-1-1-2 2AJN9-DBL9000W Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Nov. 05, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : U2O GLOBAL CO.,LTD. Address ............................................ : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Link Me Watch Trade Mark ....................................... : iWALK Manufacturer .................................... : U2O GLOBAL CO.,LTD. Model/Type reference....................... : DBL9000W Listed Models .................................. : N/A Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : Capacity:9000mAh 3.7V/33.3Wh Input:USB-C Port 5V2A, Lighting port 5V1.5A Output:USB-C Port 5V2A, Lightning Cable 5V2A Apple Watch Wireless Charging 3W Result................................................ : PASS Report No.: GTS20201103029-1-1-2 Page 2 of 12 T E S T R E P O R T Test Report No. : GTS20201103029-1-1-2 Nov. 05, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Link Me Watch Model /Type : DBL9000W Listed Models : N/A Applicant : U2O GLOBAL CO.,LTD. Address : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Manufacturer : U2O GLOBAL CO.,LTD. Address : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201103029-1-1-2 Page 3 of 12 Contents 1 S U M M A RY ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 5 1.5 Modifications 5 2 T E S T E N V I R O N M E N T .............................................................. 6 2.1 Address of the test laboratory 6 2.2 Test Facility 6 2.3 Environmental conditions 6 2.4 Summary of measurement results 7 2.5 Statement of the measurement uncertainty 7 2.6 Equipments Used during the Test 7 3 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 8 3.1 Applicable Standard 8 3.2 Limit 8 3.3 Test Setup 8 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 3.5.1 For mobile exposure ....................................................................................................... 9 3.5.2 For portable exposure .................................................................................................. 10 3.6 Equipment Approval Considerations 11 3.7 Conclusion 11 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 12 Report No.: GTS20201103029-1-1-2 Page 4 of 12 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : Oct. 28, 2020 Testing commenced on : Oct. 28, 2020 Testing concluded on : Nov. 04, 2020 1.2 Product Description Product Name: Link Me Watch Model/Type reference: DBL9000W Hardware version: DBL9000W V1.3 Software version: V1.0 Test samples ID: GTS20201103029-1-1# Power supply: DC 3.7V from battery Operation frequency: 110KHz-205KHz Modulation type: ASK Antenna type: Loop coil antenna 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Conditions Description Exposure conditions TM1 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch(Battery Status: <1%) Mobile Portable Record TM2 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch (Battery Status: <50%) Mobile Portable Record TM3 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch (Battery Status: 100%) Mobile Portable Record TM4 AC/DC Adapter (5V/1.5A Lightning Port) + EUT + iwatch (Battery Status: <1%) Mobile Portable Pre-tested TM5 AC/DC Adapter (5V/1.5A Lightning Port) + EUT + iwatch (Battery Status: <50%) Mobile Portable Pre-tested TM6 AC/DC Adapter (5V/1.5A Lightning Port) + EUT + iwatch (Battery Status: 100%) Mobile Portable Pre-tested TM7 EUT + iwatch (Battery Status: <1%) Mobile Portable Record TM8 EUT + iwatch (Battery Status: <50%) Mobile Portable Record TM9 EUT + iwatch (B…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20201103029-1-1 2AJN9-DBL9000W Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Nov. 05, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : U2O GLOBAL CO.,LTD. Address ............................................ : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Test specification ...........................: Standard ........................................... : FCC Rules and Regulations Part 15 Subpart C (Section 15.209), ANSI C63.10: 2013 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Link Me Watch Trade Mark ....................................... : iWALK Manufacturer .................................... : U2O GLOBAL CO.,LTD. Model/Type reference....................... : DBL9000W Listed Models .................................. : N/A Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : Capacity:9000mAh 3.7V/33.3Wh Input:USB-C Port 5V2A, Lighting port 5V1.5A Output:USB-C Port 5V2A, Lightning Cable 5V2A Apple Watch Wireless Charging 3W Result................................................ : PASS Report No.: GTS20201103029-1-1 Page 2 of 22 T E S T R E P O R T Test Report No. : GTS20201103029-1-1 Nov. 05, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Link Me Watch Model /Type : DBL9000W Listed Models : N/A Applicant : U2O GLOBAL CO.,LTD. Address : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Manufacturer : U2O GLOBAL CO.,LTD. Address : Huanzhu Road No.385, 4 Floor,Jimei District, Xiamen, China. Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20201103029-1-1 Page 3 of 22 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Description of the test mode 5 2.4 Special Accessories 5 2.5 Modifications 5 3 T E S T E N V I R O N M E N T .............................................................. 6 3.1 Address of the test laboratory 6 3.2 Test Facility 6 3.3 Environmental conditions 6 3.4 Summary of measurement results 7 3.5 Statement of the measurement uncertainty 7 3.6 Equipments Used during the Test 7 4 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 9 4.1 AC Power Conducted Emission 9 4.2 Radiated Emission 12 4.3 Occupied Bandwidth 16 4.4 Antenna Requirement 17 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 18 6 PH O T O S O F T H E E U T ........................................................... 19 Report No.: GTS20201103029-1-1 Page 4 of 22 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15 Subpart C (Section 15.207): Conducted limits. FCC Rules and Regulations Part 15 Subpart C (Section 15.209): Radiated emission limits; general requirements. ANSI C63.10: 2013: American National Standard for Testing Unlicensed Wireless Devices Report No.: GTS20201103029-1-1 Page 5 of 22 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Oct. 28, 2020 Testing commenced on : Oct. 28, 2020 Testing concluded on : Nov. 04, 2020 2.2 Product Description Product Name: Link Me Watch Model/Type reference: DBL9000W Hardware version: DBL9000W V1.3 Software version: V1.0 Test samples ID: GTS20201103029-1-1# Power supply: DC 3.7V from battery Operation frequency: 110KHz-205KHz Modulation type: ASK Antenna type: Loop coil antenna 2.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Conditions Description TM1 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch(Battery Status: <1%) Record TM2 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch (Battery Status: <50%) Pre-tested TM3 AC/DC Adapter (5V/2A Type-C port) + EUT + iwatch (Battery Status: 100%) Pre-tested TM4 AC/DC Adapter (5V/1.5A Lightning Port) + EUT + iwatch (Battery Status: <1%) Pre-tested TM5 AC/DC Adapter (5V/1.5A Lightning Port) + EUT + iwatch (Battery Status: <50%) Pre-tested TM6 AC/DC Adapter (5V/1.5A Lightning Port) + EU…

Text truncated - open the document above for the full version.

FCC ID: 2AJN9-DBL9000W
