Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 26 | 27 | 1.72 GHz - 1.77 GHz | 192.30 mW | 18M0W7D | 2.5
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesRF output power is conducted at the antenna terminal. Single modular approval.
This device is certified for mobile and fixed application. Co-location of this module with other transmitters would require the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. OEM integrators must ensure that the end user has no manual instructions to remove or install this module. For mobile operating configurations the antenna gain, including cable loss, must not exceed the gains documented in this filing for satisfying RF exposure compliance, as defined in 2.1091. Under no conditions may an antenna gain be used that would exceed the ERP and/or EIRP power limits as specified in Parts 22/24/27. The Grantee is responsible for providing the documentation required for modular use and this module can only be used with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. For mobile and fixed operating configurations the antenna gain, including cable loss, must not exceed 2 dBi at GSM 850/ WCDMA Band 5/LTE Band 5, 3 dBi at GSM 1900/WCDMA Band 2/LTE Band 2, 6 dBi at LTE Band 4, 66 and 9 dBi at LTE Band 41, as defined in 2.1091 for satisfying RF exposure compliance.
