2AKCY-0028000021Wavelinx Pro Wireless Node

FCC StatementWaveLinx Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, GA 30269 P: 770-486-4800 www.cooperlighting.com Canada Sales 5925 McLaughlin Road Mississauga, Ontario L5R 1B8 P: 905-501-3000 F: 905-501-3172 © 2020 Cooper Lighting Solutions All Rights Reserved Tous droits réservés Todos los derechos reservados Publication No. 9850-000709-02 March 2020 Cooper Lighting Solutions is a registered trademark. All trademarks are property of their respective owners. Cooper Lighting Solutions est une marque de commerce déposée. Toutes les autres marques de commerce sont la propriété de leur propriétaire respectif. Cooper Lighting Solutions es una marca comercial registrada. Todas las marcas comerciales son propiedad de sus respectivos propietarios. Product availability, specifications, and compliances are subject to change without notice. La disponibilité du produit, les spécifications et les conformités peuvent être modifiées sans préavis. La disponibilidad de productos, las especificaciones y los cumplimientos están sujetos a cambio sin previo aviso. FCC Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Part 15 Clause 15.21 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Part 15.19a This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC 2.1091/RSS-102 In order to comply with FCC/ISED RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times. Declaración de la FCC Nota: El equipo ha sido probado y cumple con los límites para un dispositivo digital de Clase B, de conformidad con la parte 15 de las Normas de la FCC. Estos límites están diseñados para proporcionar una protección razonable contra las interferencias dañinas en una instalación residencial. Este equipo genera, usos y puede emitir energía de radiofrecuencia y, si no se instala y utiliza de acuerdo con las instrucciones, puede causar interferencia dañina en las comunicaciones de radio. Sin embargo, no se puede garantizar que dicha interferencia no ocurra en una instalación determinada. Si este equipo causa interferencia dañina en la recepción de radio o televisión, lo que puede determinarse apagando y encendiendo el equipo, se recomienda al usuario que intente corregir la interferencia mediante una o más de las siguientes medidas: • Reorientar o reubicar la antena receptora. • Aumentar la separación entre el equipo y el receptor. • Conectar el equipo a una toma de corriente en un circuito diferente al que está conectado el receptor • Consultar con el distribuidor o con un técnico de radio/TV experimentado para obtener ayuda. Declaración de la FCC parte 15 cláusula 15.21 Los cambios o modificaciones no aprobados expresamente por la parte responsable del cumplimiento podrían anular la autoridad del usuario para operar el equipo. Declaración de la FCC parte 15.19a Este dispositivo cumple con la parte 15 de las Reglas de la FCC. El funcionamiento está sujeto a las siguientes dos condiciones: (1) este dispositivo no puede causar interferencias perjudiciales, y (2) este dispositivo debe aceptar cualquier interferencia recibida, incluidas las interferencias que puedan causar un funcionamiento no deseado. FCC 2.1091/RSS-102 Para cumplir con los requisitos de exposición a RF de FCC / ISED, este dispositivo debe instalarse para proporcionar al menos 20 cm de separación de la cuerpo humano en todo momento. ISED RSS This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-3 (B)/NMB-3(B) ISED RSS Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) l’appareil ne doit pas produire de brouillage; 2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-005 (B)/NMB-005(B)

This document is intended for installers, set-up technicians and IT professionals of the WaveLinx Connected Lighting System E ngage appropriate network security professionals to ensure all lighting control system hardware and servers are secure for access. Ensure IT professionals review the WaveLinx network architecture document found at the end of the WaveLinx User and Programming manual. Network security is an important issue. Typically, the IT organization must approve configurations that expose networks to the Internet. Be sure to fully read and understand customer IT Compliance documentation. DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind that may arise from the improper, careless, or negligent installation, handling or use of the products. IMPORTANT: This manual provides information on the installation and operation of WaveLinx Wireless Connected Lighting System. For proper operation it is important to follow the installation instructions for each product/component. ATTENTION User and Programming Manual WaveLinx PRELIMINARY WaveLinx User Manual 2 www.cooperlighting.com WaveLinx User Manual - Table of contents Becoming Familiar with WaveLinx System Components ......................................................................................................................... 10 WaveLinx Device Reference Sheets ...................................................................................................................................................... 12 WaveLinx Wireless Area Controller 2 (Gen 2) .................................................................................................................................. 13 WaveLinx Wireless Area Controller (Gen 1) ..................................................................................................................................... 20 Ambient Integrated Sensor Reference Sheet .................................................................................................................................. 26 Industrial Integrated Sensor Reference Sheet ................................................................................................................................. 28 Outdoor Integrated Sensor Reference Sheet ................................................................................................................................... 30 Outdoor Sensor Extender/Multiplier Reference Sheet .................................................................................................................... 32 Wireless Tilemount Sensor Reference Sheet .................................................................................................................................. 34 WaveLinx Outdoor Lighting Control Module .................................................................................................................................... 37 WaveLinx Wireless Fixture Reference Sheet ................................................................................................................................... 39 WaveLinx Universal Voltage Dimming Switchpack ......................................................................................................................... 40 WaveLinx Universal Voltage Dimming Switchpack with Emergency .............................................................................................. 42 WaveLinx Universal Voltage Dimming Switchpack with Dry Contact Input ................................................................................... 44 WaveLinx Low-Voltage Power Module............................................................................................................................................. 47 Low-Voltage Fixture with Integrated Sensor Reference Sheet ....................................................................................................... 52 Low-Voltage Fixture .......................................................................................................................................................................... 54 WaveLinx Receptacle ........................................................................................................................................................................ 55 WaveLinx Ceiling Sensor .................................................................................................................................................................. 57 WaveLinx Wallstation........................................................................................................................................................................ 59 WaveLinx Battery Powered Wallstation ........................................................................................................................................... 61 WaveLinx Touchscreen ..................................................................................................................................................................... 63 ISHH-01 Integrated Sensor Programming Remote ......................................................................................................................... 64 WaveLinx User Manual www.cooperlighting.com 3 WaveLinx User Manual 4 www.cooperlighting.com WaveLinx User Manual www.cooperlighting.com 5 WaveLinx User Manual 6 www.cooperlighting.com WaveLinx User Manual www.cooperlighting.com 7 WaveLinx User Manual 8 www.cooperlighting.com Welcome and Introduction The WaveLinx Wireless Connected Lighting System offers wireless, code-compliant control in a simple, easy to install and manage format. Designed with ease of use in mind, the WaveLinx wireless system installs and configures quickly to capture immediate energy and cost savings. The WaveLinx wireless system is fully scalable with options for smaller, stand-alone operation, and options for larger networked based syste…

Text truncated - open the document above for the full version.

Classified 28 June 2022 TUV SUD America Inc. 10 Centennial Drive Peabody, MA 01960, USA Dear Sir or Madam, We, Cooper Lighting Solutions, 1121 Hwy. 74 S. Pe achtree City, GA 30269, hereby authorize Kirby Munroe of TUV SUD America, 5945 Cabot Parkway, Alpharetta, GA 30005 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Yours sincerely, Name: Chad Ruhala Title: Compliance Manager

Classified (COOPER Lighting Soiut ions 8 July 2022 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID: 2AKCY-0028000021 Pursuant to Sections 0.457(d)(1 )(ii) and 0.459 of the Commission’s Rules, Cooper Lighting Solutions hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1 )(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Khaled Salah Title: Principal RF Engineer

TUV SUD America, 5945 Cabot Parkway, Suite 100, Alpharetta GA 30005 Document: 120780 v1 Page 1 of 1 Date: July 25, 2022 Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Re: FCC ID: 2AKCY-0028000021 To Whom It May Concern: The following application is submitted on behalf of our client, Cooper Lighting LLC, for evaluation of their model 0028-000021 for an original certification under FCC Part 15.247. Device is a wirelss adapter for use with lighting fixtures. I have reviewed the application and supporting documentation and have found them to comply with FCC requirements. I recommend this application for certification. Yours sincerely Kirby Munroe, Wireless EMC Technical and Certification Manager

Figure 1: Top View Figure 2: Bottom View

Figure 1: Sample Label Figure 2: Label Location

Figure 1: Top View Figure 2: Bottom View

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: 2AKCY-0028000021 FCC Rule Part: 47 CFR Part 2.1091 Project Number: 72177304 Manufacturer: COOPER LIGHTING SOLUTIONS Model Name / Number: WaveLinx Wireless Adapter / 0028-000021 RF Exposure Model Name / Number: WaveLinx Wireless Adapter / 0028-000021 FCC ID: 2AKCY-0028000021 Report: AT72177304-3C0 Page 2 General Information: Applicant: Cooper Lighting Solutions Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information (BLE) – “Device 1”: Frequency Range (MHz): 2402 - 2480 Antenna Type: Dipole Antenna Gains: 2.6 dBi Maximum Transmitter Conducted Power: 12.3 dBm, 16.98 mW Maximum System EIRP: 14.9 dBm, 30.90 mW Exposure Conditions: 20 centimeters Technical Information (Zigbee) – “Device 2”: Frequency Range (MHz): 2405 - 2480 Antenna Type: Dipole Antenna Gains: 2.6 dBi Maximum Transmitter Conducted Power: 12.2 dBm, 16.60 mW Maximum System EIRP: 14.8dBm, 30.20mW Exposure Conditions: 20 centimeters Note: The device does not support simultaneous transmissions RF Exposure Calculation Table 1: Device Characteristics (BLE & Zigbee) Technical Parameters Device 1 Device 2 Frequency (GHz) 2.402 2.405 Frequency (MHz) 2402 2405 Separation Distance (cm) 20.00 20.0 Separation Distance (m) 0.2000 0.200 Antenna Gain (dBi) 2.60 2.60 ERP Easily Determined YES YES 1-g body or 10-g extremity Body Body Conducted Power (dBm) 12.30 12.20 Conducted Power (mW) 16.98 16.60 Duty Factor (Source-Based) % 100.0 100.0 Maximum (Source-Based) Time-Averaged Conducted Power (mW) 16.98 16.60 Maximum (Source-Based) Time-Averaged ERP (mW) 18.84 18.41 Maximum (Source-Based) Time-Averaged EIRP (mW) 30.90 30.20 Maximum Output (mW) 18.84 18.41 Model Name / Number: WaveLinx Wireless Adapter / 0028-000021 FCC ID: 2AKCY-0028000021 Report: AT72177304-3C0 Page 3 Table 2: 47 CFR 1.1307(b)(3)(i)(c) MPE-Based Exemption ERP (W) – (BLE & Zigbee) Technical Parameters Device 1 Device 2 λ / 2π (m) 0.020 0.020 R≥ λ / 2π YES YES Maximum (Source-Based) Time-Averaged ERP (W) 0.0188 0.0184 ERP Threshold (W) 0.7680 0.7680 Exemption YES YES Contribution Ratio (ERP / ERP th ) 0.025 0.024 Distance to Limit (cm) 3.13 3.10

TÜV SÜD America 5945 Cabot Parkway, Suite 100 Alpharetta, GA 3005 Phone: 678-341-5900 www.tuv-sud-america.com TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Divya Adusumilli Senior Wireless Engineer TUV SUD America Inc. Authorized Signatory 5/31/2022 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD America, Inc. document control rules. FCC Accreditation Designation Number US1233 FCC Test Site Registration Number 967699 Innovation, Science, and Economic Development Canada Lab Code 23932 EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with the standards listed above. A2LA Cert. No. 2955.09 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD America with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD America. No part of this document may be reproduced without the prior written approval of TÜV SÜD America. © TÜV SÜD. ACCREDITATION Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. Report on the Testing of the Cooper Lighting Solutions WaveLinx Wireless Adapter 0028-000021 In accordance with: FCC 47 CFR part 15.247 ISED RSS-247 Issue 2, February 2017 Prepared for: Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, Georgia 30269 USA COMMERCIAL-IN-CONFIDENCE Document Number: AT72177304.1C0 Document Number: AT72177304.1C0 COMMERCIAL-IN-CONFIDENCE Page 2 of 42 Contents Report Summary .........................................................................................................................3 Report Modification Record ...........................................................................................................3 Introduction ....................................................................................................................................3 Brief Summary of Results .............................................................................................................5 Product Information .......................................................................................................................6 Deviations from the Standard ........................................................................................................8 EUT Modification Record ..............................................................................................................8 Test Location .................................................................................................................................9 Test Details ............................................................................................................................... 10 Antenna Requirement ................................................................................................................ 10 Power Line Conducted Emissions ............................................................................................. 11 Fundamental Emission Output Power ........................................................................................ 14 6dB / 99% Bandwidth ................................................................................................................. 17 Maximum Power Spectral Density in the Fundamental Emission ............................................. 22 Band-Edge Compliance of RF Conducted Emissions ............................................................... 25 RF Conducted Spurious Emissions ........................................................................................... 27 Radiated Spurious Emissions into Restricted Frequency Bands ............................................... 29 Test Equipment Used ................................................................................................................. 39 Diagram of Test Set-ups .......................................................................................................... 40 Accreditation, Disclaimers and Copyright............................................................................. 42 Document Number: AT72177304.1C0 COMMERCIAL-IN-CONFIDENCE Page 3 of 42 Report Summary Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Table 1.1-1 – Modification Record Issue Description of Change Date of Issue 0 First Issue 5/31/2022 Introduction The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations Section 15.247 and Innovation Science and Economic Development Canada’s Radio Standards Specification RSS-247 for the tests documented herein. Applicant Vrajesh Patel Manufacturer Cooper Lighting Solutions Applicant’s Email Address [email protected] Model Name WaveLinx Wireless Adapter 0028-000021 Model Number N/A Serial Number N/A FCC ID 2AKCY-0028000021 ISED Certification Number 4706A-0028000021 Hardware Version(s) EP2' Software Version(s) Mushroomsensor_fcc_railtest.s37 Number of Samples Tested 2 Test Specification/Issue/Date US Code of Federal REgulation (CFR): Title 47, Part 15, Subpart C: Radio Frequency Devices, Intentional Radiators, 2021 ISED Canada Radio Standards Specification: RSS-247 – Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and License-Exempt Local Area Network (LE-LAN) Devices, Issue 2, February 2017. Order Number 72177304 Date of Receipt of EUT 4/25/2022 Start of Test 4/25/2022 Finish of Test 5/12/2022 Document Number: AT72177304.1C0 COMMERCIAL-IN-CONFIDENCE Page 4 of 42 Related Document(s) ANSI C63.10-2013: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device. FCC OET KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hyb…

Text truncated - open the document above for the full version.

TÜV SÜD America 5945 Cabot Parkway, Suite 100 Alpharetta, GA 30005 Phone: 678-341-5900 www.tuv-sud-america.com TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Divya Adusumilli Senior Wireless Engineer TUV SUD America Inc. Authorized Signatory 5/31/2022 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD America, Inc. document control rules. FCC Accreditation Designation Number US1233 FCC Test Site Registration Number 967699 Innovation, Science, and Economic Development Canada Lab Code 23932 EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with the standards listed above. A2LA Cert. No. 2955.09 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD America with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD America. No part of this document may be reproduced without the prior written approval of TÜV SÜD America. © TÜV SÜD. ACCREDITATION Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. Report on the Testing of the Cooper Lighting Solutions WaveLinx Wireless Adapter 0028-000021 In accordance with: FCC 47 CFR part 15.247 ISED RSS-247 Issue 2, February 2017 Prepared for: Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, Georgia 30269 USA COMMERCIAL-IN-CONFIDENCE Document Number: AT72177304.2C0 Document Number: AT72177304.2C0 COMMERCIAL-IN-CONFIDENCE Page 2 of 47 Contents Report Summary .........................................................................................................................3 Report Modification Record ...........................................................................................................3 Introduction ....................................................................................................................................3 Brief Summary of Results .............................................................................................................5 Product Information .......................................................................................................................6 Deviations from the Standard ........................................................................................................8 EUT Modification Record ..............................................................................................................8 Test Location .................................................................................................................................9 Test Details ............................................................................................................................... 10 Antenna Requirement ................................................................................................................ 10 Power Line Conducted Emissions ............................................................................................. 11 Fundamental Emission Output Power ........................................................................................ 14 6dB / 99% Bandwidth ................................................................................................................. 18 Maximum Power Spectral Density in the Fundamental Emission ............................................. 23 Band-Edge Compliance of RF Conducted Emissions ............................................................... 27 RF Conducted Spurious Emissions ........................................................................................... 30 Radiated Spurious Emissions into Restricted Frequency Bands ............................................... 32 Test Equipment Used ................................................................................................................. 44 Diagram of Test Set-ups .......................................................................................................... 45 Accreditation, Disclaimers and Copyright............................................................................. 47 Document Number: AT72177304.2C0 COMMERCIAL-IN-CONFIDENCE Page 3 of 47 Report Summary Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Table 1.1-1 – Modification Record Issue Description of Change Date of Issue 0 First Issue 5/31/2022 Introduction The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations Section 15.247 and Innovation Science and Economic Development Canada’s Radio Standards Specification RSS-247 for the tests documented herein. Applicant Vrajesh Patel Manufacturer Cooper Lighting Solutions Applicant’s Email Address [email protected] Model Name WaveLinx Wireless Adapter 0028-000021 Model Number N/A Serial Number N/A FCC ID 2AKCY-0028000021 ISED Certification Number 4706A-0028000021 Hardware Version(s) EP2' Software Version(s) Mushroomsensor_fcc_railtest.s37 Number of Samples Tested 2 Test Specification/Issue/Date US Code of Federal REgulation (CFR): Title 47, Part 15, Subpart C: Radio Frequency Devices, Intentional Radiators, 2021 ISED Canada Radio Standards Specification: RSS-247 – Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and License-Exempt Local Area Network (LE-LAN) Devices, Issue 2, February 2017. Order Number 72177304 Date of Receipt of EUT 4/25/2022 Start of Test 4/25/2022 Finish of Test 5/12/2022 Document Number: AT72177304.2C0 COMMERCIAL-IN-CONFIDENCE Page 4 of 47 Related Document(s) ANSI C63.10-2013: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device. FCC OET KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hy…

Text truncated - open the document above for the full version.

Model(s) Name / Number: WaveLinx Wireless adapter / 0028-000021 FCC ID: 2AKCY-0028000021 IC: 4706A-0028000021 Project: 72177304 Page 1 Certification Exhibit FCC ID: 2AKCY-002800021 IC: 4706A-0028000021 FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Project Number: 72177304 Manufacturer: Cooper Lightning Solutions Model Name / Number: WaveLinx Wireless Adapter / 0028-000021 Test Setup Photos Model(s) Name / Number: WaveLinx Wireless adapter / 0028-000021 FCC ID: 2AKCY-0028000021 IC: 4706A-0028000021 Project: 72177304 Page 2 Figure 1: Test Setup – Radiated Emissions <30MHz Figure 2: Test Setup – Radiated Emissions <1GHz Model(s) Name / Number: WaveLinx Wireless adapter / 0028-000021 FCC ID: 2AKCY-0028000021 IC: 4706A-0028000021 Project: 72177304 Page 3 Figure 3: Test Setup – Radiated Emissions >1GHz Figure 4: Test Setup – Radiated Emissions >10GHz Model(s) Name / Number: WaveLinx Wireless adapter / 0028-000021 FCC ID: 2AKCY-0028000021 IC: 4706A-0028000021 Project: 72177304 Page 4 Figure 5: Test Setup – Radiated Emissions >18GHz Figure 6: Test Setup – Conducted Emissions Model(s) Name / Number: WaveLinx Wireless adapter / 0028-000021 FCC ID: 2AKCY-0028000021 IC: 4706A-0028000021 Project: 72177304 Page 5 Figure 7: Test Setup – Conducted Emissions Figure 8: Test Setup – Antenna Port Measurement
