FCC RF Exposure EUT Description: Smart glasses Model No.: GJ03A FCC ID: 2AKUO-GJ03A 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v06 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]ꞏ[√f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation Frequency (MHz) Output power (dBm) Tune Up Power (dBm) Max Tune Up power (mW) Min test separation distance (mm) Result Limit SAR Test Exclusion BLE 2480 1.15 1±1 1.585 5 0.499 3.0 Pass EDR 2480 1.69 1±1 1.585 5 0.499 3.0 Pass 2.4G WiFi 2437 4.89 4±1 3.162 5 0.987 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2511176181-1E/2E/3E, BT antenna gain=-1.75dBi, 2.4GWiFi antenna gain=2.3dBi. BT and 2.4GWiFi Simultaneous evaluation: 0.499 / 3+0.987 / 3 = 0.495<1, SAR testing is not required Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine RF Exposure test exclusion. The test exclusion threshold meets the requirements, SAR testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ꞏ[√f (GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

1376033455 Building 7, Building B1, Hangcheng Jincheng Industrial Park, Hangcheng Street Address： , Baoan District, Shenzhen Contact：Li Xue Cheng4 Page1of10 LetterofAcceptanceofShenzhen OnePlusWirelessCommunication TechnologyCo.,Ltd. CustomerName ProjectNam APPROVAL SHEET Shenzhen Smart Care Technology Limited e GJ03A CustomerP/N Specification WIFI/BTAntennas Antennamanufacturer ProductionDate 20251222 Approval OnePlusOne: RFCheckMECheckQCCheckConfirmBy Signature Date 2025122220251222 Customer: EECheckPMCheckQCCheckConfirmBy Signature Date 承认鉴章后请寄回承认书一份 Pleasereturntousonecopyof“APPROVALSHEET”withyourapprovedsignatures Pl Address： 1376033455 Building 7, Building B1, Hangcheng Jincheng Industrial Park, Hangcheng Street, Baoan District, Shenzhen Contact：Li Xue Cheng4 Page2of10 Contents 1天线说明ANTENNADESCRIPTION.................................................................3 1.1天线规格Partnumber........................................................................3 1.2 天线图片 Antennapictures................................................................3 2测试设备TESTINGEQUIPMENT......................................................................4 3测试数据TESTDATA........................................................................................4 3.1无源Passive..........................................................................................4 3.2 有源 Active...........................................................................................5 4匹配电路MATCHINGCIRCUITDESCRIPTION................................................7 5环境处理ENVIRONMENTALTREATMENT......................................................7 6可靠性报告RELIABILITYTESTREPORT........................................................8 7图纸DRAWING..................................................................................................9 7.1尺寸图纸Dimensionaldrawing.........................................................9 7.2 组装图 Assemblydrawing................................................................10 Address： 1376033455tact Building 7, Building B1, Hangcheng Jincheng Industrial Park, Hangcheng Street, Baoan District, Shenzhen ：Li Xue Cheng4 Page1-3of10 1天线说明Antennadescription MAIAntennaNDVIGPSWIFIBT ///2400-25002400-2500 Frequence Range (MHZ) Type ///PIFA Material Single Pole ///FPCFPC 1.1Partnumber MAINDIVWIFIBT size(MM) Antenna Antenna //38.30*12.5328.36*2.99 antenna screen printing //GJ03A-WIFI-V7.0GJ03A-BT-V7.0 1.2Antennapictures 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page3-4of10 2Testingequipment 3Testdata 3.1Passive LagMsg 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page3-5of10 3.2Active BT 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page3-6of10 WIFI 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page5-7of10 4MatchingCircuitDescription 5EnvironmentalTreatment 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page6-8of10 6ReliabilityTestReport TestDate August12,2025 SampleQty 1 Tester YANPEITIAN TestItemsRequirementTestEquipmentSample1Sample2SamplePASS/NG high temperature storage Exposureat+85°C for24hours,followed byrecoveryfor2 hourspriortotesting constant temperatureand humiditychamber OKOKOKPass cryogenic storage Exposureto-40°Cfor 24hours,followedby recoveryfor2hours priortotesting constant temperatureand humiditychamber OKOKOKPass high temperature work Operatingunder +60°Cfor24hours withpowersupply constant temperatureand humiditychamber OKOKOKPass cryogenic operation Operatedunder-20° Cfor24hourswith powersupply constant temperatureand humiditychamber OKOKOKPass SaltSpray Test (5±0.5)%sodium chloride,pH6.5-7.2, experimental chambertemperature (35±2)°Cfor48 hours constant temperatureand humiditychamber OKOKOKPass ConclusionsPass 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page7-9of10 7Drawing 7.1Dimensionaldrawing 公司地址： Building7,BuildingB1,HangchengJinchengIndustrialPark,HangchengStreet,BaoanDistrict,Shenzhen 联系方式：LiXueCheng13760334554 Page8-10of10 7.2Assemblydrawing 8Packagingspecifications Delivered way Whole Plate FP In bag C FP Antenna Type C FPC+ coaxial line LD Steel sheet S External Antenna Cable

Page 1 of 43 Report No.: HK2511176181-1E FCC Test Report Test Report On Behalf of Shenzhen Smart Care Technology Limited For Smart glasses Model No.: GJ03A, Y1, Y2, Y3, Y4, Y5, Y6, Y7, Y8, Y9, Y10, Y11, Y12, VK2048, Fansee Glasses, S1, S2, S3, S4, S5 FCC ID: 2AKUO-GJ03A Prepared For: Shenzhen Smart Care Technology Limited The 6rd Floor,Block 2, An’da Industrial Park, Heping Road,Heping Community, Fuhai Street, Bao’an District, Shenzhen, 518000, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Nov. 17, 2025 ~ Dec. 15, 2025 Date of Report: Dec. 15, 2025 Report Number: HK2511176181-1E Page 2 of 43 Report No.: HK2511176181-1E Test Result Certification Applicant’s Name ................... : Shenzhen Smart Care Technology Limited Address .................................... : The 6rd Floor,Block 2, An’da Industrial Park, Heping Road,Heping Community, Fuhai Street, Bao’an District, Shenzhen, 518000, China Manufacturer's Name ............. : Shenzhen Smart Care Technology Limited Address .................................... : The 6rd Floor,Block 2, An’da Industrial Park, Heping Road,Heping Community, Fuhai Street, Bao’an District, Shenzhen, 518000, China Product Description Trade Mark ................................. : FancyView Product Name ............................ : Smart glasses Model and/or Type Reference .. : GJ03A, Y1, Y2, Y3, Y4, Y5, Y6, Y7, Y8, Y9, Y10, Y11, Y12, VK2048, Fansee Glasses, S1, S2, S3, S4, S5 Standards ................................ : 47 CFR FCC Part 15 Subpart C 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10: 2020 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .............................................. : Date (s) of Performance of Tests ............... : Nov. 17, 2025 ~ Dec. 15, 2025 Date of Issue ............................................. : Dec. 15, 2025 Test Result ................................................. : Pass Testing Engineer Len Liao Technical Manager Sliver Wan Authorized Signatory Jason Zhou Page 3 of 43 Report No.: HK2511176181-1E Contents Page 1 Summary ......................................................................................................................................................... 5 1.1 Test Procedures and Results .................................................................................................................... 5 1.2 Measurement Uncertainty ......................................................................................................................... 6 1.3 Information of the Test Laboratory ............................................................................................................ 6 2 General Information ....................................................................................................................................... 7 2.1 General Description of EUT ...................................................................................................................... 7 2.2 Description of Test Conditions .................................................................................................................. 9 2.3 Description of Test Setup ........................................................................................................................ 10 2.4 Description of Support Units .................................................................................................................... 11 3 Equipments List for All Test Items ............................................................................................................. 12 4 Test Result .................................................................................................................................................... 13 4.1 Antenna Requirement.............................................................................................................................. 13 4.2 AC Conduction Emissions Measurement ................................................................................................ 14 4.3 Radiated Emissions Measurement .......................................................................................................... 18 4.4 Maximum Peak Output Power Measurement ......................................................................................... 27 4.5 Power Spectral Density ........................................................................................................................... 28 4.6 6dB Bandwidth ........................................................................................................................................ 31 4.7 Occupied Bandwidth ................................................................................................................................ 34 4.8 Band Edge ............................................................................................................................................... 35 4.9 Conducted Spurious Emissions .............................................................................................................. 37 5 Test Setup Photos of the EUT .................................................................................................................... 41 6 Photos of the EUT ........................................................................................................................................ 43 Page 4 of 43 Report No.: HK2511176181-1E ** Issued …

Text truncated - open the document above for the full version.

Page 1 of 96 Report No.: HK2511176181-3E FCC Test Report Test Report On Behalf of Shenzhen Smart Care Technology Limited For Smart glasses Model No.: GJ03A, Y1, Y2, Y3, Y4, Y5, Y6, Y7, Y8, Y9, Y10, Y11, Y12, VK2048, Fansee Glasses, S1, S2, S3, S4, S5 FCC ID: 2AKUO-GJ03A Prepared For: Shenzhen Smart Care Technology Limited The 6rd Floor,Block 2, An’da Industrial Park, Heping Road,Heping Community, Fuhai Street, Bao’an District, Shenzhen, 518000, China Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Nov. 17, 2025 ~ Dec. 15, 2025 Date of Report: Dec. 15, 2025 Report Number: HK2511176181-3E Applican Address . Manufac t Address . Product D Trade Ma Product N Model and Standard This publi the Shenz source of and will n o reproduce Date of Te Date (s) o Date of Is Test Resu t’s Name ... .................. turer's Nam .................. Description rk ................ Name ........... d/or Type R ds ............... ication may zhen HUAK the materia ot assume ed material est ............. of performan ssue ............ ult ................ T T A ............... : ............... : me ........... : ............... : n ................. : ................. : Reference : ............... : be reprod u K Testing Te al. Shenzhe liability for d due to its p .................. nce of tests .................. .................. Testing Eng Technical M Authorized S Pag Test Re Shenzhen The 6rd F Road,Hep Shenzhen Shenzhen The 6rd F Road,Hep Shenzhen FancyVie w Smart gla GJ03A, Y VK2048, FCC Rul e ANSI C63 uced in who chnology C en HUAK Te damages re placement a ............. : ............. : ............. : ............. : inee r Manager Signatory ge 2 of 96 sult Cert n Smart Car Floor,Block 2 ping Comm n, 518000, C n Smart Car Floor,Block 2 ping Comm n, 518000, C w asses Y1, Y2, Y3, Fansee Gla es and Regu 3.10: 2020 ole or in part Co., Ltd. is a esting Techn esulting from and context. Nov. 17, 202 Dec. 15, 202 Pass tification re Technolo 2, An’da Ind unity, Fuha China re Technolo 2, An’da Ind unity, Fuha China , Y4, Y5, Y asses, S1, S ulations Par t for non-co acknowledge nology Co., m the reade 25 ~ Dec. 15 25 Len Liao Sliver Wa Jason Zh o Report n ogy Limited dustrial Park i Street, Ba ogy Limited dustrial Park i Street, Ba Y6, Y7, Y8 S2, S3, S4, rt 15 Subpar ommercial p ed as copyr Ltd. takes er's interpret 5, 2025 o an ou No.: HK251 k, Heping o’an Distri c k, Heping o’an Distri c , Y9, Y10, S5 rt C Section purposes as right owner no respons tation of the 1176181-3E ct, ct, Y11, Y12, n 15.247 s long as and ibility for e Page 3 of 96 Report No.: HK2511176181-3E Table of Contents 1. Summary ................................................................................................... 5 1.1 Test Procedures and Results ........................................................................................................... 5 1.2 Information of the Test Laboratory ................................................................................................. 5 1.3 Measurement Uncertainty ................................................................................................................ 6 2. EUT Description ........................................................................................ 7 2.1 General Description of EUT ............................................................................................................. 7 2.2 Carrier Frequency of Channels ........................................................................................................ 8 2.3 Operation of EUT during Testing ..................................................................................................... 8 2.4 Description of Test Setup ................................................................................................................. 9 2.5 Description of Support Units ......................................................................................................... 10 3. General Information ................................................................................ 11 3.1 Test Environment and Mode .......................................................................................................... 11 4. Test Results and Measurement Data .................................................... 14 4.1 AC Power Line Conducted Emission ............................................................................................ 14 4.2 Maximum Peak Conducted Output Power .................................................................................... 18 4.3 Emission Bandwidth ....................................................................................................................... 20 4.4 Power Spectral Density .................................................................................................................. 28 4.5 Conducted Band Edge and Spurious Emission Measurement .................................................. 37 4.6 Radiated Spurious Emission Measurement ................................................................................. 57 4.7 Antenna Requirement ..................................................................................................................... 93 5. Test Setup Photos of the EUT ............................................................... 94 6. Photos of the EUT ................................................................................... 96 Page 4 of 96 Report No.: HK2511176181-3E ** Issued history ** Revision Description Issued Date Remark Revision 1.0 Initial Test Report Release Dec. 15, 2025 Jason Zhou Page 5 of 96 Report No.: HK2511176181-3E 1. Summary 1.1 Test Procedures and Results Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247(b)(4) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak …

Text truncated - open the document above for the full version.

Page 49 of 96 Report No.: HK2511176181-3E Pag Mi Spu e 50 of 96 iddle Chan urious Emis nnel ssion Report No.: HK2511176181-3E 802.11ax ( HE20) Mod Lowes Ban Spuriou ulation st Channel nd Edge us Emissio Pag l on e 51 of 96 S Report Highest C Band E Spurious E No.: HK251 Channel Edge Emission 1176181-3E Page 52 of 96 Report No.: HK2511176181-3E Pag Mi Spu e 53 of 96 iddle Chan urious Emis nnel ssion Report No.: HK2511176181-3E 802.11ax ( HE40) Mod Lowes Ban Spuriou ulation st Channel nd Edge us Emissio Pag l on e 54 of 96 S Report Highest C Band E Spurious E No.: HK251 Channel Edge Emission 1176181-3E Page 55 of 96 Report No.: HK2511176181-3E Pag Mi Spu e 56 of 96 iddle Chan urious Emis nnel ssion Report No.: HK2511176181-3E Page 57 of 96 Report No.: HK2511176181-3E 4.6 Radiated Spurious Emission Measurement 4.6.1 Test Specification Test Requirement: FCC Part15 C Section 15.209 Test Method: ANSI C63.10: 2020 Frequency Range: 9 kHz to 25 GHz Measurement Distance: 3 m Antenna Polarization: Horizontal & Vertical Operation mode: Transmitting mode with modulation Receiver Setup: Frequency Detector RBW VBW Remark 9kHz- 150kHz Quasi-peak 200Hz 1kHz Quasi-peak Value 150kHz- 30MHz Quasi-peak 9kHz 30kHz Quasi-peak Value 30MHz-1GHz Quasi-peak 120KHz 300KHz Quasi-peak Value Above 1GHz Peak 1MHz 3MHz Peak Value Peak 1MHz 10Hz Average Value Limit: Frequency Field Strength (microvolts/meter) Measurement Distance (meters) 0.009-0.490 2400/F(KHz) 300 0.490-1.705 24000/F(KHz) 30 1.705-30 30 30 30-88 100 3 88-216 150 3 216-960 200 3 Above 960 500 3 Frequency Field Strength (microvolts/meter) Measurement Distance (meters) Detector Above 1GHz 500 3 Average 5000 3 Peak Page 58 of 96 Report No.: HK2511176181-3E Test setup: For radiated emissions below 30MHz 30MHz to 1GHz Above 1GHz Page 59 of 96 Report No.: HK2511176181-3E Test Procedure: 1. For the radiated emission test below 1GHz: The EUT was placed on a turntable with 0.8 meter above ground. The EUT was set 3 meters from the interference receiving antenna, which was mounted on the top of a variable height antenna tower. The EUT was arranged to its worst case and then tune the antenna tower (from 1 m to 4 m) and turntable (from 0 degree to 360 degrees) to find the maximum reading. A pre-amp and a high PASS filter are used for the test in order to get better signal level. 2. For the radiated emission test above 1GHz: Place the measurement antenna on a turntable with 1.5 meter above ground, which is away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m above the ground or reference ground plane. 3. Corrected Reading: Antenna Factor + Cable Loss + Read Level - Preamp Factor = Level 4. For measurement below 1GHz, If the emission level of the EUT measured by the peak detector is 3 dB lower than the applicable limit, the peak emission level will be reported. Otherwise, the emission measurement will be repeated using the quasi-peak detector and reported. 5. Use the following spectrum analyzer settings: (1) Span shall wide enough to fully capture the emission being measured; (2) Set RBW=120 kHz for f < 1 GHz; VBW ≥RBW; Sweep = auto; Detector function = peak; Trace = max hold; (3) Set RBW = 1 MHz, VBW= 3MHz for f > 1 GHz for peak measurement. 6.For average measurement: VBW = 10 Hz, when duty cycle is no less than 98 percent.VBW ≥ 1/T, when duty cycle is less than 98 percent where T is the minimum transmission duration over which the transmitter is on and is transmitting at its maximum power control level for the tested mode of operation. Test Results: PASS Page 60 of 96 Report No.: HK2511176181-3E 4.6.2 Test Instruments Radiated Emission Test Site (966) Name of Equipment Manufacturer Model Serial Number Calibration Date Calibration Due Spectrum analyzer Agilent N9020A HKE-025 Feb. 19, 2025 Feb. 18, 2026 Spectrum analyzer Agilent N9020A HKE-117 Feb. 19, 2025 Feb. 18, 2026 Spectrum analyzer R&S FSV3044 HKE-126 Feb. 19, 2025 Feb. 18, 2026 Preamplifier EMCI EMC051845S HKE-006 Feb. 19, 2025 Feb. 18, 2026 Preamplifier Schwarzbeck BBV 9743 HKE-016 Feb. 19, 2025 Feb. 18, 2026 Preamplifier A.H. Systems SAS-574 HKE-182 Feb. 19, 2025 Feb. 18, 2026 6dB Attenuator Pasternack 6db HKE-184 Feb. 19, 2025 Feb. 18, 2026 EMI Test Receiver Rohde & Schwarz ESR-7 HKE-010 Feb. 19, 2025 Feb. 18, 2026 Broadband Antenna Schwarzbeck VULB9168 HKE-167 Feb. 21, 2024 Feb. 20, 2026 Loop Antenna COM-POWER AL-130R HKE-014 Feb. 21, 2024 Feb. 20, 2026 Horn Antenna Schwarzbeck 9120D HKE-013 Feb. 21, 2024 Feb. 20, 2026 EMI Test Software Tonscend JS32-RE 5.0.0 HKE-082 N/A N/A RSE Test Software Tonscend JS36-RSE 5.0.0 HKE-184 N/A N/A Page 61 of 96 Report No.: HK2511176181-3E 4.6.3 Test Data All the test modes completed for test. Only the worst result of reported as below: Below 1GHz Test Results: Antenna polarity: Horizontal Remark: Factor = Cable loss + Antenna factor + Attenuator – Preamplifier; Level = Reading + Factor; Margin = Limit – Level Page 62 of 96 Report No.: HK2511176181-3E Antenna polarity: Vertical Remark: Factor = Cable loss + Antenna factor + Attenuator – Preamplifier; Level = Reading + Factor; Margin = Limit – Level Harmonics and Spurious Emissions Frequency Range (9kHz-30MHz) Frequency (MHz) Level@3m (dBμV/m) Limit@3m (dBμV/m) -- -- -- -- -- -- -- -- -- -- -- -- Note: 1.Emission Level=Reading+ Cable loss-Antenna factor-Amp factor. 2. The emission levels are 20 dB below the limit value…

Text truncated - open the document above for the full version.

Test Model：GJ03A Radiated Emission AC Conducted Emission RF Conducted Emission BT WiFi
