2AKWY-FBP207SE3 Wi-Fi 6 Radio Module

To: Federal Communications Commission Date: 2026/08/13 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Certification designating a U.S. Agent for Service of Process Section 2.911(d)(7) (KDB 986446 D01 Covered Equipment) DynaScan Technology Corp.as required by section 2.911(d)(7), designate below for service of process. The applicant also acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Type of Equipment subject to FCC Certification: FCC ID: 2AKWY-FBP207 Sincerely yours, Applicant/GranteeUS Agent FRN: 0026170399FRN: (The US Agent does not have a FRN because This Person does not do business with the FCC) ____________________________________ (Signature)(Signature) Office: +1 949.421.0348 SE3 Wi-Fi 6 Radio Module

To: Federal Communications Commission Date: 2026/07/28 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) DynaScan Technology Corp. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> The applicant also certifies that the device does not have cybersecurity and/or anti- virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Section 2.911(d)(5)(ii) DynaScan Technology Corp. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: FCC ID: 2AKWY-FBP207 If you have any questions, please feel free to contact me DynaScan Technology Corp. [ Asson Ko, Director ] gy p SE3 Wi-Fi 6 Radio Module

Declaration of Authorization We Name: DynaScan Technology Corp. Address: 6F, No.88, Wenmao Rd., Guishan Dist., Taoyuan City 333001,Taiwan Declare that: Name Representative of agent: Chenz Ker Agent Company name: MRT Technology (Taiwan) Co., Ltd Address: No. 38, Fuxing Second Rd., Guishan Dist., City: Taoyuan Country Taiwan is authorized to apply for Certification of the following product(s): Product description: SE3 Wi-Fi 6 Radio Module Trademark: DynaScan Type designation: SKI.WB800D80U.5 FCC ID: 2AKWY-FBP207 IC: 35225-FBP207 on our behalf. Date: 2026/07/28 City: Taoyuan City Name: Asson Ko Function: Director Signature:

Long/Short-term Confidentiality Request NMi TESTLAB GmbH Date: 21 August 2026 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: 2AKWY-FBP207 To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics ☐ Parts List ☒ Block Diagram ☐ Tune-Up Info ☒ Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☐ for an initial period of days ☐ until: ☒ not applicable ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Signatory Printed Name: Asson Ko Position: Director

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 13.06.2014 Datum: 00.00.00 Seite 1 von 1 NMi TESTLAB GmbH Date: 18 August 2026 Product Certification Königswinkel 10 D 32825 Blomberg Subject: Declaration Operating Channel Limitation FCC ID: 2AKWY-FBP207 IC: 35225-FBP207 To Whom it may concern, Our devices don't operate on Channels 12 and 13, when a master transmits on these channels. This information is programmed into the EEPROM and is not accessible and cannot be changed by the end user. Signatory -------------------------------------------- Printed Name: Asson Ko Position: Director

NMi TESTLAB GmbH Date: 18 August 2026 Product Certification Königswinkel 10 D 32825 Blomberg Attn: Reviewing Engineer Subject: PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL To Whom It May Concern: We, DynaScan Technology Corp., hereby requests for part 15 unlicensed modular transmitter approval of our device, described as follows: Brand name: DynaScan Model name: SKI.WB800D80U.5 FCC ID: 2AKWY-FBP207 In FCC Public Notice DA 00-1407 released June 26, 2000 there are eight numbered requirements that our device complies with: 1. The modular transmitter must have its own shielding. Ans: Yes, Module transmitter has their owen shielding. The shielding of the radio portion can be demonstrated in exhibition External Pohto. 2. The modular transmitter must have buffered modulation/data inputs Ans: Yes,Buffere data inputs stage has been integrated in chip AIC8800D80. 3. The modular transmitter must have its own power supply regulation Ans: Yes,The part number of the power regulator is AIC8800D80. Its own power supply regulation. Please referrer the schematics. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c Ans: Yes,The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition test report. 5. The modular transmitter must be tested in a stand-alone configuration Ans: Yes,Please refer the test setup photo. 6. The modular transmitter must be labelled with its own FCC ID number Ans: Yes,Please refer the label. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. Ans: Yes, Please refer the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. Ans: Yes, Please refer the exposure report. Yours sincerely, -------------------------------------------- Printed Name: Asson Ko Position: Director

Label Product Name: SE3 Wi-Fi 6 Radio Module Model: SKI.WB800D80U.5 FCC ID: 2AKWY-FBP207 IC: 35225-FBP207 Label location on the bottom of module

MRT Technology (Taiwan) Co., Ltd. Report No.: 2606TW6701-U4 Phone: +886-3-3288388 Report Version: V1.0 Web: www.mrt-cert.com Issue Date: 2026-08-07 Template Version: 2.1 1 of 11 RF Exposure Evaluation Declaration FCC ID: 2AKWY-FBP207 Applicant: Dynascan Technology Corp. Product: SE3 Wi-Fi 6 Radio Module Model No.: SKI.WB800D80U.5 Brand Name: DynaScan FCC Rule Part(s): FCC Part 2.1091 Result: Complies Received Date: 2026-06-25 Reviewed By: Paddy Chen Approved By: Chenz Ker The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2606TW6701-U4 2 of 11 Revision History Report No. Version Description Issue Date Note 2606TW6701-U4 V1.0 Original Report 2026-08-07 Valid Report No.: 2606TW6701-U4 3 of 11 CONTENTS Description Page 1. General Information ............................................................................................................................... 4 1.1. Applicant ........................................................................................................................................4 1.2. Manufacturer .................................................................................................................................4 1.3. Testing Facility ...............................................................................................................................4 1.4. Product Information .......................................................................................................................5 1.5. Antenna Details .............................................................................................................................6 1.6. Device Classification .....................................................................................................................6 1.7. Applied Standards .........................................................................................................................6 2. RF Exposure Evaluation ........................................................................................................................ 7 2.1. Limits .............................................................................................................................................7 2.2. MPE Exemptions ...........................................................................................................................8 2.3. Calculated Result ........................................................................................................................ 11 Report No.: 2606TW6701-U4 4 of 11 1. General Information 1.1. Applicant Dynascan Technology Corp. 6F, No.88, Wenmao Rd., Guishan Dist., Taoyuan City 333001,Taiwan 1.2. Manufacturer Dynascan Technology Corp. 6F, No.88, Wenmao Rd., Guishan Dist., Taoyuan City 333001,Taiwan 1.3. Testing Facility Test Site 1 - MRT Taiwan Laboratory Laboratory Location No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Test Site 2 - MRT Taiwan Laboratory Laboratory Location No. 64, Wenming Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2606TW6701-U4 5 of 11 1.4. Product Information Product Name SE3 Wi-Fi 6 Radio Module Model No. SKI.WB800D80U.5 Wi-Fi Specification 802.11a/b/g/n/ac/ax Operating Temperature 0 ~ 45 °C Power Type By AC/DC Adapter Note: The information of the EUT (Equipment Under Test) was provided by the manufacturer. The accuracy, completeness, and validity of the information are solely the responsibility of the manufacturer. Report No.: 2606TW6701-U4 6 of 11 1.5. Antenna Details Technology Frequency Range (MHz) Antenna Type Max Peak Gain (dBi) 2.4GHz Wi-Fi 2412 ~ 2462 Metal Antenna -3.04 5GHz Wi-Fi 5180 ~ 5825 -2.31 Note: The antenna gain is from antenna data sheet provided by the manufacturer. 1.6. Device Classification According to the user manual, this device is classified as a Mobile Device. So, the RF exposure evaluation requirements of § 2.1091 for mobile device exposure conditions subject to MPE limits. 1.7. Applied Standards According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ⚫ FCC Part 2.1091 ⚫ KDB 447498 D04 Interim General RF Exposure Guidance v01 Report No.: 2606TW6701-U4 7 of 11 2. RF Exposure Evaluation 2.1. Limits According to FCC §1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b) Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 0.3 ~ 3.0 614 1.63 *(100) ≤6 3.0 ~ 30 1842/f 4.89/f *(900/f 2 ) <6 30 ~ 300 61.4 0.163 1.0 <6 300 ~ 1500 -- -- f/300 <6 1500 ~ 100000 -- -- 5 <6 (B) Limits for General Population/ Uncontrolled Exposures 0.3 ~ 1.34 614 1.63 *(100) <30 1.34 ~30 824/f 2.19/f *(180/f 2 ) <30 30 ~ 300 27.5 0.073 0.2 <30 300 ~ 1500 -- -- f/1500 <30 1500 ~ 100000 -- -- 1.0 <30 f= frequency in MHz. * = Plane-wave equivalent power density. Report No.: 2606TW6701-U4 8 of 11 2.2. MPE Exemptions For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph §1.1307(b)(2) of this section): A single RF source is exempt if: (Option A) The available maximum time-averaged power is no more than 1 mW, regardless…

Text truncated - open the document above for the full version.

□ □ Specification for Approval W E 9 G 6 7 3 0 0 1 *1500mm(2.4G+5G)(#3709) RFMTA34071AIMLB401 Walsin ： 1. Gain 承 認 書 Approval sheet Customer : 光遠科技股份有限公司 Customer P/N : WE9G673001 Brand : INPAQ Supplier P/N : RFMTA34071AIMLB401 Description : 天線*1500mm(2.4G+5G)(#3709) 廠 商 簽 認 承辦人 : 技術 / 負責人: 認可 : Prepared by : Andy Li Date : 2022/3/30 Tel: +886-2-2795-6500 #777 Fax: +886-2-2795-6900 Http:\\www.thz.com.tw E-mail: [email protected] Add.: 4F-3, No. 26, Jinzhung Rd., Neihu Dist., Taipei City 11469, Taiwan(R.O.C.) 品名：RFMTA34071AIMLB401 History List 版本 REV. 修訂者 EDITOR 修訂頁次 PAGE 修訂內容 ITEMS OF CHANGE 申請日期 DATE 生效日期 VALID DATE ECN 編號 ECN NO. P0 李欣樺 ALL Temporary Release 2022/03/29 According to the date of PLM Release N/A P1 李欣樺 ALL 增加Gain值 2022/04/25 According to the date of PLM Release N/A INPAQ TECHNOLOGY CO., LTD 2022/04/25 品名：RFMTA34071AIMLB401 1. Explanation of part number： RF MTA 3407 1A I M L B 4 01 Type Code Product Code Dimension (Unit: mm) Cable Length (unit: cm) Connector Brand Type of Connector Application Project status Wire Diameter Project RF Device MTA: Metal Antenna Per 2 digits of length, width e.g.:3407 Length 34mm, Width 7.8mm 2 digits for cable length e.g.:1A Cable Length:150cm A: N C:MCX D:IPEX III E: IPEX IV F: IPEX A13 H: Hirose I: IPEX M: MMCX S: SMA T: TNC U:MURATA N: None A: Reverse Female B: Reverse Male F: Female M: Male N: None 0: 0GHz 3: 3GHz 5: 5GHz 6: 6GHz A: 2.4GHz ISM band B: GSM 900/1800 dual band G: GPS band L: 2.4/5.2/5.8 GHz tri-band N: NFC T: LTE band W: WCDMA band B: MP T:During Test X: Pile Run 0:None 1:∅0.81 3:∅1.13 4:Low Loss∅1.1 3 6:RG316 7:∅1.37 8:RG178 01~99 series number 2. Electrical Specification： UNLESS OTHER SPECIFIED TOLERANCES ON： X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A INPAQ TECHNOLOGY CO., LTD. SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：李欣樺 CHECKED BY：詹惠雯 DESIGNED BY：林育帆 APPROVED BY：陳振榮 TITLE：RFMTA34071AIMLB401 DOCUMENT NO. SPEC REV. P0 PAGE 1 OF 2 Item Specification Working Frequency Range 2.4 ~ 2.5 / 5.15 ~ 5.85 GHz Return Loss -10 dB(Max) VSWR 2 max. Gain -3.04 [email protected] ~ 2.5 GHz -2.31 [email protected] ~ 5.85 GHz Polarization Linear Radiation Pattern Omni-directional Impedance 50 INPAQ TECHNOLOGY CO., LTD 2022/04/25 3. Antenna Drawing： UNLESS OTHER SPECIFIED TOLERANCES ON： X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A INPAQ TECHNOLOGY CO., LTD. SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：李欣樺 CHECKED BY：詹惠雯 DESIGNED BY：林育帆 APPROVED BY：陳振榮 TITLE：RFMTA34071AIMLB401 DOCUMENT NO. SPEC REV. P0 PAGE 2 OF 2 3D Gain table: Frequency(MHz) Efficiency(%) Gain(dBi) Frequency(MHz) Efficiency(%) Gain(dBi) 2400 31.77 -3.51 5150 24.72 -2.31 2410 32.58 -3.49 5250 23.99 -2.69 2420 32.58 -3.73 5350 21.73 -2.8 2430 32.58 -3.77 5450 20.94 -2.68 2440 33.27 -3.55 5550 19.91 -2.77 2450 34.67 -3.73 5650 18.84 -3.1 2460 35.73 -3.49 5750 17.26 -2.93 2470 35.89 -3.27 5850 15.07 -3.11 2480 35.56 -3.04 2490 35.81 -3.23 2500 34.43 -3.39 3D Gain pattern: 2D Gain table: ZX plane ZY plane XY plane Frequency Max Value Average Max Value Average Max Value Average [MHz] [dBi] [dBi] [dBi] [dBi] [dBi] [dBi] 2400 -9.59 -12.28 -5.22 -11.01 -4.01 -11.03 2450 -8.62 -11.55 -4.97 -10.58 -4.24 -10.61 2500 -9.28 -12.51 -5.57 -11.53 -5.66 -11.49 5150 -11.51 -14.79 -7.4 -13.42 -6.26 -11.46 5450 -8.23 -11.09 -3.71 -10.05 -3.04 -8.55 5850 -8.66 -12.34 -4.81 -11.16 -5.25 -10.26 2D Gain pattern:

MRT Technology (Taiwan) Co., Ltd. Report No.: 2606TW6701-U2 Phone: +886-3-3288388 Report Version: V1.0 Web: www.mrt-cert.com Issue Date: 2026-08-07 Template Version: 2.2 1 of 367 RF MEASUREMENT REPORT FCC ID: 2AKWY-FBP207 IC: 35225-FBP207 Applicant: Dynascan Technology Corp. Product: SE3 Wi-Fi 6 Radio Module Model No.: SKI.WB800D80U.5 Brand Name: DynaScan FCC Classification: Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): Part 15 Subpart E (Section 15.407) ISED Rule(s): RSS-247 Issue 4, RSS-GEN Issue 5 Result: Complies Received Date: 2026-06-25 Test Date: 2026-07-02~2026-07-22 Reviewed By: Paddy Chen Approved By: Chenz Ker The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Taiwan) Co., Ltd. Report No.: 2606TW6701-U2 2 of 367 Revision History Report No. Version Description Issue Date Note 2606TW6701-U2 V1.0 Original Report 2026-08-07 Valid Report No.: 2606TW6701-U2 3 of 367 CONTENTS Description Page 1. General Information ................................................................................................................................ 6 1.1. Applicant ..................................................................................................................................... 6 1.2. Manufacturer............................................................................................................................... 6 1.3. Testing Facility ............................................................................................................................ 6 1.4. Product Information .................................................................................................................... 7 1.5. Radio Specification under Test ................................................................................................... 8 1.6. Working Frequencies .................................................................................................................. 9 1.7. Antenna Details ........................................................................................................................ 10 2. Test Configuration ................................................................................................................................. 11 2.1. Test Mode .................................................................................................................................. 11 2.2. Test System Connection Diagram ............................................................................................ 12 2.3. Test Software ............................................................................................................................ 12 2.4. Applied Standards .................................................................................................................... 13 2.5. Test Environment Condition ...................................................................................................... 13 3. Antenna Requirements ......................................................................................................................... 14 4. Measuring Instrument ........................................................................................................................... 15 5. Decision Rules and Measurement Uncertainty .................................................................................. 16 5.1. Decision Rules .......................................................................................................................... 16 5.2. Measurement Uncertainty ........................................................................................................ 16 6. Test Result .............................................................................................................................................. 17 6.1. Summary .................................................................................................................................. 17 6.2. 26 dB & 99% Bandwidth Measurement .................................................................................... 18 6.2.1. Test Limit ................................................................................................................................... 18 6.2.2. Test Procedure ......................................................................................................................... 18 6.2.3. Test Setting ............................................................................................................................... 18 6.2.4. Test Setup ................................................................................................................................. 19 6.2.5. Test Result ................................................................................................................................ 19 6.3. 6 dB Bandwidth Measurement ................................................................................................. 20 6.3.1. Test Limit ................................................................................................................................... 20 6.3.2. Test Procedure ......................................................................................................................... 20 6.3.3. Test Setting ............................................................................................................................... 20 6.3.4. Test Setup ................................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: 2606TW6701-U2 55 of 367 802.11ax-HE20 26 dB Bandwidth & 99% Bandwidth Channel 36 (5180 MHz) Channel 44 (5220 MHz) Channel 48 (5240 MHz) Channel 52 (5260 MHz) Channel 60 (5300 MHz) Channel 64 (5320 MHz) Report No.: 2606TW6701-U2 56 of 367 Channel 100 (5500 MHz) Channel 116 (5580 MHz) Channel 132 (5660 MHz) Channel 140 (5700 MHz) Channel 144(5720 MHz) Channel 149 (5745 MHz) Report No.: 2606TW6701-U2 57 of 367 Channel 157 (5785 MHz) Channel 165 (5825 MHz) Report No.: 2606TW6701-U2 58 of 367 802.11ax-HE40 26 dB Bandwidth & 99% Bandwidth Channel 38 (5190 MHz) Channel 46 (5230 MHz) Channel 54 (5270 MHz) Channel 62 (5310 MHz) Channel 102 (5510 MHz) Channel 110 (5550 MHz) Report No.: 2606TW6701-U2 59 of 367 Channel 134 (5670 MHz) Channel 142 (5710 MHz) Channel 151 (5755 MHz) Channel 159 (5795 MHz) Report No.: 2606TW6701-U2 60 of 367 802.11ax-HE80 26 dB Bandwidth & 99% Bandwidth Channel 42 (5210 MHz) Channel 58 (5290 MHz) Channel 106 (5530 MHz) Channel 122 (5610 MHz) Channel 138 (5690 MHz) Channel 155 (5775 MHz) Report No.: 2606TW6701-U2 61 of 367 A.3 6 dB Bandwidth Test Result Test Site SR7 Test Engineer Wen Test Date 2026-07-02~2026-07-05 Test Mode Data Rate / MCS Channel No. Frequency (MHz) 6 dB Bandwidth (MHz) Limit (MHz) 11a 6 Mbps 149 5745 16.400 ≥0.5 11a 6 Mbps 157 5785 16.400 ≥0.5 11a 6 Mbps 165 5825 16.410 ≥0.5 11ac-VHT20 MCS0 149 5745 17.670 ≥0.5 11ac-VHT20 MCS0 157 5785 17.660 ≥0.5 11ac-VHT20 MCS0 165 5825 17.660 ≥0.5 11ac-VHT40 MCS0 151 5755 36.430 ≥0.5 11ac-VHT40 MCS0 159 5795 36.410 ≥0.5 11ac-VHT80 MCS0 155 5775 76.390 ≥0.5 11ax-HE20 MCS0 149 5745 19.150 ≥0.5 11ax-HE20 MCS0 157 5785 19.150 ≥0.5 11ax-HE20 MCS0 165 5825 19.150 ≥0.5 11ax-HE40 MCS0 151 5755 38.250 ≥0.5 11ax-HE40 MCS0 159 5795 38.250 ≥0.5 11ax-HE80 MCS0 155 5775 78.110 ≥0.5 Report No.: 2606TW6701-U2 62 of 367 802.11a 6 dB Bandwidth Channel 149 (5745 MHz) Channel 157 (5785 MHz) Channel 165 (5825 MHz) Report No.: 2606TW6701-U2 63 of 367 802.11ac-VHT20 6 dB Bandwidth Channel 149 (5745 MHz) Channel 157 (5785 MHz) Channel 165 (5825 MHz) Report No.: 2606TW6701-U2 64 of 367 802.11ac-VHT40 6 dB Bandwidth Channel 151 (5755 MHz) Channel 159 (5795 MHz) 802.11ac-VHT80 6 dB Bandwidth Channel 155 (5775 MHz) Report No.: 2606TW6701-U2 65 of 367 802.11ax-HE20 6 dB Bandwidth Channel 149 (5745 MHz) Channel 157 (5785 MHz) Channel 165 (5825 MHz) Report No.: 2606TW6701-U2 66 of 367 802.11ax-HE40 6 dB Bandwidth Channel 151 (5755 MHz) Channel 159 (5795 MHz) 802.11ax-HE80 6 dB Bandwidth Channel 155 (5775 MHz) Report No.: 2606TW6701-U2 67 of 367 A.4 Output Power & EIRP Test Result Test Site SR7 Test Engineer Wen Test Date 2026-07-02~2026-07-21 Test Mode FCC Power Test Mode Data Rate / MCS Channel No. Freq. (MHz) Average Power (dBm) Power Limit (dBm) 11a 6 Mbps 36 5180 16.24 ≤ 23.98 11a 6 Mbps 44 5220 18.65 ≤ 23.98 11a 6 Mbps 48 5240 18.51 ≤ 23.98 11a 6 Mbps 52 5260 18.86 ≤ 23.98 11a 6 Mbps 60 5300 18.72 ≤ 23.98 11a 6 Mbps 64 5320 18.54 ≤ 23.98 11a 6 Mbps 100 5500 18.74 ≤ 23.98 11a 6 Mbps 116 5580 18.39 ≤ 23.98 11a 6 Mbps 140 5700 17.46 ≤ 23.98 11a 6 Mbps 144 5720 18.92 ≤ 23.48 11a 6 Mbps 149 5745 18.86 ≤ 30.00 11a 6 Mbps 157 5785 18.44 ≤ 30.00 11a 6 Mbps 165 5825 17.86 ≤ 30.00 11ac-VHT20 MCS0 36 5180 15.21 ≤ 23.98 11ac-VHT20 MCS0 44 5220 17.57 ≤ 23.98 11ac-VHT20 MCS0 48 5240 17.31 ≤ 23.98 11ac-VHT20 MCS0 52 5260 17.33 ≤ 23.98 11ac-VHT20 MCS0 60 5300 17.62 ≤ 23.98 11ac-VHT20 MCS0 64 5320 16.42 ≤ 23.98 11ac-VHT20 MCS0 100 5500 17.17 ≤ 23.98 11ac-VHT20 MCS0 116 5580 17.35 ≤ 23.98 11ac-VHT20 MCS0 140 5700 17.32 ≤ 23.98 11ac-VHT20 MCS0 144 5720 17.55 ≤ 22.50 11ac-VHT20 MCS0 149 5745 17.89 ≤ 30.00 11ac-VHT20 MCS0 157 5785 17.48 ≤ 30.00 11ac-VHT20 MCS0 165 5825 17.85 ≤ 30.00 Report No.: 2606TW6701-U2 68 of 367 Test Mode Data Rate / MCS Channel No. Freq. (MHz) Average Power (dBm) Power Limit (dBm) 11ac-VHT40 MCS0 38 5190 15.11 ≤ 23.98 11ac-VHT40 MCS0 46 5230 17.39 ≤ 23.98 11ac-VHT40 MCS0 54 5270 17.11 ≤ 23.98 11ac-VHT40 MCS0 62 5310 14.44 ≤ 23.98 11ac-VHT40 MCS0 102 5510 17.99 ≤ 23.98 11ac-VHT40 MCS0 110 5550 17.94 ≤ 23.98 11ac-VHT40 MCS0 134 5670 17.65 ≤ 23.98 11ac-VHT40 MCS0 142 5710 17.97 ≤ 23.98 11ac-VHT40 MCS0 151 5755 17.77 ≤ 30.00 11ac-VHT40 MCS0 159 5795 17.92 ≤ 30.00 11ac-VHT80 MCS0 42 5210 13.55 ≤ 23.98 11ac-VHT80 MCS0 58 5290 12.37 ≤ 23.98 11ac-VHT80 MCS0 106 5530 11.92 ≤ 23.98 11ac-VHT80 MCS0 122 5610 17.57 ≤ 23.98 11ac-VHT80 MCS0 138 5690 17.71 ≤ 23.98 11ac-VHT80 MCS0 155 5775 15.34 ≤ 30.00 11ax-HE20 MCS0 36 5180 15.21 ≤ 23.98 11ax-HE20 MCS0 44 5220 17.91 ≤ 23.98 11ax-HE20 MCS0 48 5240 17.77 ≤ 23.98 11ax-HE20 MCS0 52 5260 17.62 ≤ 23.98 11ax-HE20 MCS0 60 5300 17.51 ≤ 23.98 11ax-HE20 MCS0 64 5320 16.42 ≤ 23.98 11ax-HE20 MCS0 100 5500 17.99 ≤ 23.98 11ax-HE20 MCS0 116 5580 17.32 ≤ 23.98 11ax-HE20 MCS0 140 5700 16.58 ≤ 23.98 11ax-HE20 MCS0 144 5720 17.52 ≤ 22.73 11ax-HE20 MCS0 149 5745 17.74 ≤ 30.00 11ax-HE20 MCS0 157 5785 17.81 ≤ 30.00 11ax-HE20 MCS0 165 5825 17.73 ≤ 30.00 Report No.: 2606TW6701-U2 69 of 367 Test Mode Data Rate / MCS Channel No. Freq. (MHz) Average Power (dBm) Power Limit (dBm) 11ax-HE40 MCS0 38 5190 15.04 ≤ 23.98 11ax-HE40 MCS0 46 5230 17.89 ≤ 23.98 11ax-HE40 MCS0 54 5270 17.59 ≤ 23.98 11ax-HE40 MCS0 62 5310 15.47 ≤ 23.98 11ax-HE40 MCS0 102 5510 16.85 ≤ 23.98 11ax-HE40 MCS0 110 5550 17.89 ≤ 23.98 11ax-HE40 MCS0 134 5670 17.66 ≤ 23.98 11ax-HE40 MCS0 142 5710 17.99 ≤ 23.98 11ax-HE40 MCS0 151 5755 17.63 ≤ 30.00 11ax-HE40 MCS0 159 5795 17.65 ≤ 30.00 11ax-HE80 MCS0 42 5210 13.38 ≤ 23.98 11ax-HE80 MCS0 58 5290 13.23 ≤ 23.98 11ax-HE80 MCS0 106 5530 13.38 ≤ 23.98 11ax-HE80 MCS0 122 5610 17.67 ≤ 23.98 11ax-HE80 MCS0 138 5690 17.82 ≤ 23.98 11ax-HE80 MCS0 155 5775 15.33 ≤ 30.00 Note 1: For Band-Crossing channel, Average Power Limit = 23.98 dBm or 11+10×log 10 EBW 2C , which is less. Report No.: 2606TW6701-U2 70 of 367 Test Site SR7 Test Engineer Wen Test Date 2026-07-02~2026-07-21 Test Mode IC Power Test Mode Data Rate / MCS Channel No. Freq. (MHz) AV Power (dBm) AV Power Limit (dBm) EIRP (dBm) EIRP Limit (dBm) 11a 6 Mbps 36 5…

Text truncated - open the document above for the full version.

Report No.: 2606TW6701-U2 82 of 367 802.11ac-VHT20 Power Spectral Density - Ant 0 Channel 36 (5180 MHz) Channel 44 (5220 MHz) Channel 48 (5240 MHz) Channel 52 (5260 MHz) Channel 60 (5300 MHz) Channel 64 (5320 MHz) Report No.: 2606TW6701-U2 83 of 367 Channel 100 (5500 MHz) Channel 116 (5580 MHz) Channel 140 (5700 MHz) Channel 144(5720 MHz) Channel 149 (5745 MHz) Channel 157 (5785 MHz) Report No.: 2606TW6701-U2 84 of 367 Channel 165 (5825 MHz) Report No.: 2606TW6701-U2 85 of 367 802.11ac-VHT40 Power Spectral Density - Ant 0 Channel 38 (5190 MHz) Channel 46 (5230 MHz) Channel 54 (5270 MHz) Channel 62 (5310 MHz) Channel 102 (5510 MHz) Channel 110 (5550 MHz) Report No.: 2606TW6701-U2 86 of 367 Channel 134 (5670 MHz) Channel 142(5710 MHz) Channel 151 (5755 MHz) Channel 159 (5795 MHz) Report No.: 2606TW6701-U2 87 of 367 802.11ac-VHT80 Power Spectral Density - Ant 0 Channel 42 (5210 MHz) Channel 58 (5290 MHz) Channel 106 (5530 MHz) Channel 122 (5610 MHz) Channel 138 (5690 MHz) Channel 155 (5775 MHz) Report No.: 2606TW6701-U2 88 of 367 802.11ax-HE20 Power Spectral Density …
