2AKWY-XBP501EPAPER DISPLAY

1 NV13A / NV13AP / NVA2A / NVA2AP USER MANUAL For more information about DynaScan, visit our website at www.dynascan.com. Copyright © DynaScanTechnology Inc. All rights reserved. All specifications and descriptions are subject to change without notice. Reproduction without permission is prohibited. Please read this manual carefully before operating the product and keep it for future reference. The use of diagrams and illustrations in the manual are for reference only,the actual product may be different. 2 MODEL MODEL CODENVA2ANVA2AP MODEL NAME 6830568307 MODEL CODENV13ANV13AP MODEL NAME 6830368301 A2(28.6”)Models 13” Models 3 CONTENTS SAFETY PRECAUTIONS 6 7 8 9 10 Safety Symbols Important Safety Information Installation Operation Clean LI-ION BATTERY USAGE GUIDELINES 11Li-ion Battery Usage Guidelines INSTALLATION 67Installation DECLARATION OF CONFORMITY 4Declaration of Conformity GETTING STARTED 13 14 Contents Requirements INTERFACE 15 16 NV13A / NV13AP / NVA2A / NVA2AP Input / Output Terminals (Port) UPDATE 49 50 File Format Update File RESET 53 55 57 58 Reset via Bluetooth Reset via USB Reset via Buttons Reset via Safe Mode TROUBLESHOOTING 73Troubleshooting SPECIFICATIONS 71Specifications (All Models) CONFIGURE via BLUETOOTH 26 29 30 31 32 33 34 35 Start to Configure Settings Content Add Contents (Image/PDF) Set to Play Export to Device (via Bluetooth) Config(s)Upload (via Bluetooth) Export Config File (via Bluetooth) BUTTON OPERATION DESCRIPTIONS 17Button Operation Descriptions OPERATING INSTRUCTIONS 20 22 23 Power On Power Off Power Saving Mode INDICATOR LIGHT DESCRIPTIONS 18Indicator Light Descriptions CONFIGURE via USB 37 39 41 42 45 Start to Configure Export Config File (via USB) Import Config File Import Config File (from File) Import Config File (from Display) FTP 59 60 62 65 FTP Introduction FTP Settings via Bluetooth FTP Settings via USB Configure via FTP CONFIGURATION MODES OVERVIEW 25Configuration Modes Overview 4 DECLARATION OF CONFORMITY Modification Warning Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould voidtheuser'sauthoritytooperatetheequipment. RF Exposure Statement TocomplywithFCCRFexposurerequirements,a minimumseparationdistanceof20cmmust bemaintainedbetweentheantennaofthisdeviceandallpersons.Thistransmittermustnotbe co-locatedoroperatedinconjunctionwithanyotherantennaortransmitter. Class B Digital Device Statement Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassB digitaldevice, pursuanttoPart15oftheFCCRules. Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceina residentialinstallation. Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,if notinstalledand usedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications. However,thereis noguaranteethatinterferencewillnotoccurina particularinstallation. FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENTS (U.S. ONLY) FCC Part 15 Compliance Statement ThisdevicecomplieswithPart15oftheFCCRules. Operationis subjecttothefollowingtwoconditions: Thisdevicemaynotcauseharmfulinterference. Thisdevicemustacceptanyinterferencereceived, includinginterferencethatmaycauseundesiredoperation. If thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe interferencebyoneormoreofthefollowingmeasures: •Reorientorrelocatethereceivingantenna. •Increasetheseparationbetweentheequipmentandreceiver. •Connecttheequipmentintoanoutletona circuitdifferentfromthattowhichthereceiveris connected. •Consultthedealeroranexperiencedradio/TVtechnicianforhelp. 5 DECLARATION OF CONFORMITY INNOVATION, SCIENCE AND ECONOMIC DEVELOPMENT CANADA(ISED) STATEMENTS (CANADA ONLY) Thisdevicecontainslicence-exempttransmitter(s)/receiver(s)thatcomplywithInnovation,Science andEconomicDevelopmentCanada’slicence-exemptRSS (s). Operationis subjecttothefollowing twoconditions: Thisdevicemaynotcauseinterference.Thisdevicemustacceptanyinterference, includinginterferencethatmaycauseundesiredoperationofthedevice. Cetappareilcontientdesémetteurs/récepteursexemptsdelicenceconformesauxCNR d’Innovation,SciencesetDéveloppementéconomiqueCanadaapplicablesauxappareilsradio exemptsdelicence. L’exploitationestautoriséeauxdeuxconditionssuivantes: L’appareilnedoit pasproduiredebrouillage. L’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesi le brouillageestsusceptibled’encompromettrelefonctionnement. 6 SAFETY PRECAUTIONS SYMBOLNAMEMEANING WARNING Do NOT attempt. Failure to follow instructions may result in serious or fatal injury. CAUTIONFailure to follow instructions may result in personal injury or property damage. EMERGENCY Unplug the LCD and contact a DynaScancertified service professional immediately if any of the following occurs INSTRUCTIONFollow directions. SAFETY SYMBOLS Thefollowingsafetyinstructionsaretoensureyourpersonalsafetyandpreventpropertydamage. Pleasereadthefollowingtoensuretheproperuseoftheproduct. 7 IMPORTANT SAFETY INFORMATION Unplug the product and contact a DynaScancertified service professional immediately if any of the following occurs: Damagedpowercordorpowerplug. If liquidorforeignobjecthasenteredtheproduct. If theproducthasbeenexposedtorainorwater. If theproducthasbeendroppedorthecasinghasbecomedamaged. If anystructuraldamagesuchascracksorunnaturalvibrationis found. If theproductcannotbeoperatedfollowingthestepsoutlinedinthismanual. If theproductemitssmokeorotherodors,orgeneratesstrangenoises. 8 INSTALLATION WARNING CAUTION Donotinstallnearflammablematerialoranyheatsources.Pleaseinstalledthedisplayinwell-ventilatedplace,donotinstallina confinedspace. Suitableformountingonconcreteorothernon-combustiblesurfaceonly. Powersupplycordmustnotbeattachedtothebuildingsurface,norrunthroughwalls, ceilings,floorsandsimilaropeningsinthebuildingstructure. Powercordshallbeconnectedtoa socket-outletwithearthingconnection 9 OPERATION WARNING If it givesoffsmoke,st…

Text truncated - open the document above for the full version.

Dynascan Technology Corp. TEST REPORT Model: 68301, 68303, 68305, 68307 REPORT NUMBER 251200020THC-001 ISSUE DATE May 26, 2026 PAGES 22 DOCUMENT CONTROL NUMBER GFT-OP-10h (28-Nov-2018) © 2020 Intertek Report No.: 251200020THC-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. GFT-OP-10h (28-Nov-2018) Page 1 of 22 Test Report 0597 Radio Spectrum TEST REPORT Applicant: Dynascan Technology Corp. 6F., No. 88, Wenmao Rd., Guishan Dist., Taoyuan City 333001, Taiwan Product: EPAPER DISPLAY Model No.: 68301, 68303, 68305, 68307 FCC ID: 2AKWY-XBP501 Test Method/ Standard: 47 CFR FCC Part 15.407 KDB 789033 D02 v02r01 ANSI C63.10 2020 KDB 662911 D01 v02r01 KDB 905462 D02 v02 Test By: Intertek Testing Services Taiwan Ltd., Hsinchu Laboratory No. 17, Ln. 246, Niupu S. Rd., Xiangshan Dist, Hsinchu City 300075, Taiwan Rich Nien Engineer Rico Deng Reviewer Report No.: 251200020THC-001 GFT-OP-10h (28-Nov-2018) Page 2 of 22 TEST REPORT Revision History Report No. Issue Date Revision Summary 251200020THC-001 May 26, 2026 Original report Report No.: 251200020THC-001 GFT-OP-10h (28-Nov-2018) Page 3 of 22 TEST REPORT Table of Contents Summary of Test Data ................................................................................................................. 4 1. General Information ............................................................................................................... 5 1.1 Identification of the EUT ................................................................................................... 5 1.2 Adapter information ......................................................................................................... 5 1.3 Additional information about the EUT ............................................................................. 5 1.4 Antenna description ......................................................................................................... 6 1.5 Operation mode ................................................................................................................ 6 1.6 Peripherals equipment ..................................................................................................... 6 2. Dynamic Frequency Selection (DFS) test ................................................................................ 7 2.1 UNII Device Description .................................................................................................... 7 2.2 Operating mode ................................................................................................................ 8 2.3 Test Protocol and Requirements ....................................................................................... 8 2.4 DFS Detection Thresholds and Limitations of each Parameter ...................................... 10 2.5 Radar Test Waveforms .................................................................................................... 11 2.6 Radar Waveform Calibration .......................................................................................... 14 2.6.1 Radar Waveform Calibration Plot ................................................................................ 15 2.7 Test instruments and setup ............................................................................................ 16 2.7.1 Deviation about the radar waveform .......................................................................... 16 2.7.2 Test setup ..................................................................................................................... 16 2.8 DFS test results ............................................................................................................... 16 2.8.1 Test summary ............................................................................................................... 16 2.8.2 DFS test result .............................................................................................................. 17 2.8.2.1 Channel Move & Closing Transmission time ............................................................ 18 2.9 Non-Occupancy Period ................................................................................................... 20 Appendix A: Test equipment list ............................................................................................... 21 Appendix B: Measurement Uncertainty ................................................................................... 22 Report No.: 251200020THC-001 GFT-OP-10h (28-Nov-2018) Page 4 of 22 TEST REPORT Summary of Test Data Test Requirement Applicable Rule (Section 15.407) Result Dynamic Frequency Selection (DFS) 15.407(h)(2) Pass Antenna requirement 15.203 Pass Note: Please note that the test results with statement of conformity, the decision rules which are based on: Safety Testing: the specification, standard or IEC Guide 115. Other Testing: the specification, standard and not taking into account the measurement uncertainty. Report No.: 251200020THC-001 GFT-OP-10h (28-Nov-2018) Page 5 of 22 TEST REPORT 1. General Information 1.1 Identification of the EUT Product: EPAPER DISPLAY Mod…

Text truncated - open the document above for the full version.

DFS Test set-up photo

Radiated Emission Test set-up photo 9kHz~30MHz Radiated Emission Test set-up photo 30MHz~1GHz Radiated Emission Test set-up photo Above 1GHz

Conducted Emission Test set-up photo

Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 210 of 261 TEST REPORT Chain0 : 99% OBW @ 802.11ax(HE80) Mode Ch106 Chain0 : 99% OBW @ 802.11ax(HE80) Mode Ch122 Chain0 : 99% OBW @ 802.11ax(HE80) Mode Ch155 Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 211 of 261 TEST REPORT Chain1 : 99% OBW @ 802.11ax(HE80) Mode Ch42 Chain1 : 99% OBW @ 802.11ax(HE80) Mode Ch58 Chain1 : 99% OBW @ 802.11ax(HE80) Mode Ch106 Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 212 of 261 TEST REPORT Chain1 : 99% OBW @ 802.11ax(HE80) Mode Ch122 Chain1 : 99% OBW @ 802.11ax(HE80) Mode Ch155 Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 213 of 261 TEST REPORT 5. Emissions in Restricted Frequency Bands (Radiated emission measurements) 5.1 Limit for emission in restricted frequency bands (Radiated emission measurement) Frequency (MHz) Field Strength (microvolts/meter) Measurement distance (meters) 0.009~0.490 2400/F(kHz) 300 0.490~1.705 2400/F(kHz) 30 1.705~30 30 30 30-88 100 3 88-216 150 3 216-960 200 3 Above 960 500 3 Remark: 1. In the above table, the tighter limit applies at the band edges. 2. Distance refers to the distance in meters between the measuring instrument antenna and the closed point of any part of the device or system As specified in 15.407(b), For transmitters operating in the 5.15-5.25 GHz band: All emissions outside of the 5.15-5.35 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (2) For transmitters operating in the 5.25-5.35 GHz band: All emissions outside of the 5.15-5.35 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (3) For transmitters operating in the 5.47-5.725 GHz band: All emissions outside of the 5.47-5.725 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (4) For transmitters operating in the 5.725-5.85 GHz band: All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25 MHz above or below the band edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or below the band edge, and from 5 MHz above or below the band edge increasing linearly to a level of 27 dBm/MHz at the band edge. However, an out-of-band emission that complies with both the average and peak limits of 15.209 is not required to satisfy the -27 dBm/MHz or -17 dBm/MHz peak emission limit. Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 214 of 261 TEST REPORT 5.2 Measuring instrument setting Below 1GHz measurement Receiver settings Receiver function Setting Detector QP RBW 9-150 kHz ; 200-300 Hz 0.15-30 MHz; 9-10 kHz 30-1000 MHz; 100-120 kHz VBW ≧3 x RBW Sweep Auto couple Attenuation Auto Above 1GHz measurement Spectrum analyzer settings Spectrum Analyzer function Setting Detector Peak ; Average RBW 1MHz VBW 3MHz for Peak; 1/T Minimum kHz for Average Sweep Auto couple Start Frequency 1GHz Stop Frequency Tenth harmonic Attenuation Auto Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 215 of 261 TEST REPORT 5.3 Test procedure 1. Configure the EUT according to ANSI C63.10: 2013 The EUT was placed on the top of the turntable 1.5 meter above ground for above 1GHz and placed on the top of the turntable 0.8 meter above ground for below 1GHz. The center of the receiving antenna mounted on the top of a height-variable antenna tower was placed 3 meters far away from the turntable. 2. Power on the EUT and all the companion devices. The turntable was rotated by 360 degree to find the position of the maximum emission level. 3. The height of the receiving antenna was varied between one meter and four meters above ground to find the maximum emission field strength of the both horizontal and vertical polarization 4. If find the frequencies above the limit or below within 3dB, the antenna tower was scan (from 1m to 4m) and then the turntable was rotated to find the maximum reading. 5. Set the test-receiver system to peak or CISPR quasi-peak detector with specified bandwidth under maximum hold mode. 6. For emissions above 1GHz, use 1MHz VBW and 3MHz RBW for peak reading. Then 1MHz RBW and 10Hz VBW for average reading in spectrum analyzer. Place the measurement antenna away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. 7. If the emissions level of the EUT in peak mode was 3dB lower than the average limit specified then testing will be stopped and peak values of the EUT will be reported. Otherwise, the emissions which do not have 3dB margin will be measured using the quasi-peak method for below 1GHz. 8. For testing above 1GHz, The emissions level of the EUT in peak mode was lower than average limit, then testing will be stopped and peak values of the EUT will be reported, otherwise, the emission will be measured in average mode again and reported. 9. In case the emission is lower than 30MHz, loop antenna has to be used for measurement and the recorded data should be quasi-peak measured by receiver. Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 216 of 261 TEST REPORT 5.4 Test configuration 5.4.1 Radiated emission from 9 kHz to 30MHz using Loop Antenna Radiated emission from 9kHz to 30MHz uses Loop Antenna: Radiated emission below 1GHz using Bilog Antenna RF Test Receiver 0.8 m Antenna Tower Ground Plane Receiver Antenna 1.0~4.0 meters 3 meters □ EUT & Peripherals EUT & Peripherals 0.8m EMI Test Receiver □ 3 meters Loop Antenna 1m Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 217 of 261 TEST REPORT Radiated emission above 1GHz using Horn Antenna Horn or Bilog Antenna Spectrum Analyzer Ground Plane Antenna Tower □ 3 meters 1-4 meter 1.5 m HPF and Pre-Amp. (if necessary) EUT & Peripherals Report No.: 251200019THC-001 GFT-OP-10h (28-Nov-2018) Page 218 of 261 TEST REPORT 5.5 Test res…

Text truncated - open the document above for the full version.

Agent letter FCC attestation statement Kiwa Page 2 of 2 RF_753, Issue 4 17-07-2025 [PLACE ON APPLICANT/COMPANY LETTERHEAD] Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 01 07-02-2023 1 st version RvdM 02 1 15-05-2023 Added FRN to Agent details RvdM 03 1 06-06-2024 Added FRN to Applicant details RvdM 04 1 17-07-2025 -Changed Grantee code into FCC ID -Added additional option regarding the use of a FRN for the US Agent PR Issued/modified by : Pieter Robben Function : Certification assessor Revision : 04 Date : 17-07-2025 Verified by : Willem Jan Jong Function : Team Lead Date : 17-07-2025 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 17-07-2025

F-09-13 零 件 承 認 書 Specification for Approval A97G015100 □ 限 量 生 產 □ 暫 承 認 ■第 2 次 承 認 □第 次限量生產 pcs 原 封 面：■作 廢 □變 更 □沿 用 原 內 容：■作 廢 □變 更 □追 加 西 元 2025 年 7 月 8 日 發 行 ■電 子 □ 機 構 □ 系列承認零件 ■環保零件 ■安規零件 料 品 編 號 ： A 9 7 G 0 1 5 1 0 0 品 名： 天線*80mm 廠 商 零 件 編 碼： 製 造 商： 頤曜數位股份有限公司 代 理 商： 備 註： 承認書增加頻譜測試資料 光遠科技股份有限公司 DOC-3000-2502001 P.1/9 Version.1.00 2.4G/5G/BLE Antenna 01 (80mm) Product Specification Issue Date : 2025/6/26 DOC-3000-2309001 P.2/9 Version.1.00 Record of Revision Version Date Page Desciption 1.00 2025/2/18 First Release DOC-3000-2502001 P.3/9 Version.1.00 INDEX 1. General Information .................................................................................................................... 4 1.1. Introduction ......................................................................................................................... 4 1.2. Electrical Characteristics...................................................................................................... 4 1.3. Test Report .......................................................................................................................... 4 2. Mechanical Drawing ................................................................................................................... 8 3. Electrical Definition .................................................................................................................... 9 3.1. Antenna connector U.FL/IPX 13 .......................................................................................... 9 4. Packing Information .................................................................................................................... 9 DOC-3000-2309001 P.4/9 Version.1.00 1. General Information 1.1. Introduction 2.4G/5G Wifi, Bluetooth antenna, Cable length 80mm ◼ Connector : U.FL/IPX 13 ◼ Cable : Black RG1.13, silver-coated copper wire (∅1.13mm) ◼ VSWR : 2.0 ◼ Double tape: 3M9888T 1.2. Electrical Characteristics 1.3. Test Report Test Equipment & Conditions ◼ Network Analyzers： Agilent 8753D/5071C ◼ HSPA and LTE protocol test set R&S： CMW500 -PT ◼ Communications Test Set： Agilent 8960 ◼ 3D Chamber Test System DOC-3000-2502001 P.5/9 Version.1.00 Voltage Standing Wave Ratio(VSWR). DOC-3000-2309001 P.6/9 Version.1.00 Efficient and gain. Radiation pattern. DOC-3000-2502001 P.7/9 Version.1.00 Reliability Test DOC-3000-2309001 P.8/9 Version.1.00 2. Mechanical Drawing (please refer to the attached document) DOC-3000-2502001 P.9/9 Version.1.00 3. Electrical Definition 3.1. U.FL/IPX 13 PIN FUNCTION 1 ANT 2 GND- 4. Packing Information Packing Size: TBD/Box Q'ty: TBD ( pcs./Layer, Layer/Box)

F-09-13 零 件 承 認 書 Specification for Approval A97G015200 □ 限 量 生 產 □ 暫 承 認 ■第 2 次 承 認 □第 次限量生產 pcs 原 封 面：■作 廢 □變 更 □沿 用 原 內 容：■作 廢 □變 更 □追 加 西 元 2025 年 7 月 8 日 發 行 ■電 子 □ 機 構 □ 系列承認零件 ■環保零件 ■安規零件 料 品 編 號 ： A 9 7 G 0 1 5 2 0 0 品 名： 天線*345mm 廠 商 零 件 編 碼： 製 造 商： 頤曜數位股份有限公司 代 理 商： 備 註： 承認書增加頻譜測試資料 光遠科技股份有限公司 DOC-3000-2502001 P.1/9 Version.1.00 2.4G/5G/BLE Antenna 01 (345mm) Product Specification Issue Date : 2025/6/26 DOC-3000-2309001 P.2/9 Version.1.00 Record of Revision Version Date Page Desciption 1.00 2025/2/18 First Release DOC-3000-2502001 P.3/9 Version.1.00 INDEX 1. General Information .................................................................................................................... 4 1.1. Introduction ......................................................................................................................... 4 1.2. Electrical Characteristics...................................................................................................... 4 1.3. Test Report .......................................................................................................................... 4 2. Mechanical Drawing ................................................................................................................... 8 3. Electrical Definition .................................................................................................................... 9 3.1. Antenna connector U.FL/IPX 13 .......................................................................................... 9 4. Packing Information .................................................................................................................... 9 DOC-3000-2309001 P.4/9 Version.1.00 1. General Information 1.1. Introduction 2.4G/5G Wifi, Bluetooth antenna, Cable length 80mm ◼ Connector : U.FL/IPX 13 ◼ Cable : Black RG1.13, silver-coated copper wire (∅1.13mm) ◼ VSWR : 2.0 ◼ Double tape: 3M9888T 1.2. Electrical Characteristics 1.3. Test Report Test Equipment & Conditions ◼ Network Analyzers： Agilent 8753D/5071C ◼ HSPA and LTE protocol test set R&S： CMW500 -PT ◼ Communications Test Set： Agilent 8960 ◼ 3D Chamber Test System DOC-3000-2502001 P.5/9 Version.1.00 Voltage Standing Wave Ratio(VSWR). DOC-3000-2309001 P.6/9 Version.1.00 Efficient and gain. Radiation pattern. DOC-3000-2502001 P.7/9 Version.1.00 Reliability Test DOC-3000-2309001 P.8/9 Version.1.00 2. Mechanical Drawing (please refer to the attached document) DOC-3000-2502001 P.9/9 Version.1.00 3. Electrical Definition 3.1. U.FL/IPX 13 PIN FUNCTION 1 ANT 2 GND- 4. Packing Information Packing Size: TBD/Box Q'ty: TBD ( pcs./Layer, Layer/Box)

Dynascan Technology Corp. TEST REPORT Model: 68301, 68303, 68305, 68307 REPORT NUMBER 251200021THC-001 ISSUE DATE May 26, 2026 PAGES 18 DOCUMENT CONTROL NUMBER GFT-OP-10h (28-Nov-2018) © 2020 Intertek Report No.: 251200021THC-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. GFT-OP-10h (28-Nov-2018) Page 1 of 18 Test Report Maximum Permissible Exposure (MPE) Evaluation Report Applicant: Dynascan Technology Corp. 6F., No. 88, Wenmao Rd., Guishan Dist., Taoyuan City 333001, Taiwan Product: EPAPER DISPLAY Model No.: 68301, 68303, 68305, 68307 FCC ID: 2AKWY-XBP501 Test Method/ Standard: 47 CFR FCC 1.1310 KDB 447498 D01 V06 Test By: Intertek Testing Services Taiwan Ltd., Hsinchu Laboratory No. 17, Ln. 246, Niupu S. Rd., Xiangshan Dist, Hsinchu City 300075, Taiwan Rich Nien Engineer Rico Deng Reviewer Report No.: 251200021THC-001 GFT-OP-10h (28-Nov-2018) Page 2 of 18 TEST REPORT Revision History Report No. Issue Date Revision Summary 251200021THC-001 May 26, 2026 Original report Report No.: 251200021THC-001 GFT-OP-10h (28-Nov-2018) Page 3 of 18 TEST REPORT Table of Contents Summary of Tests ....................................................................................................................... 4 1. General Information ............................................................................................................... 5 1.1 Identification of the EUT .................................................................................................. 5 1.2 Adapter information ......................................................................................................... 5 1.3 Additional information about the EUT ............................................................................. 5 1.4 Antenna description ......................................................................................................... 6 1.5 Peripherals equipment ..................................................................................................... 6 2. Test specifications ................................................................................................................... 7 2.1 Introduction ...................................................................................................................... 7 2.2 RF Exposure Limit ............................................................................................................. 8 2.3 RF Exposure calculations ................................................................................................ 11 2.4 Operation mode ............................................................................................................. 11 2.5 Test equipment ............................................................................................................... 12 2.6 Test Set-up ...................................................................................................................... 12 3. Test results ............................................................................................................................ 13 Report No.: 251200021THC-001 GFT-OP-10h (28-Nov-2018) Page 4 of 18 TEST REPORT Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997, IEEE C95.1-2005 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 Complies Note: Please note that the test results with statement of conformity, the decision rules which are based on: Safety Testing: the specification, standard or IEC Guide 115. Other Testing: the specification, standard and not taking into account the measurement uncertainty. Report No.: 251200021THC-001 GFT-OP-10h (28-Nov-2018) Page 5 of 18 TEST REPORT 1. General Information 1.1 Identification of the EUT Product: EPAPER DISPLAY Model No.: 68301, 68307 Operating Frequency: 1. 2402MHz ~ 2480MHz (BTC, BLE) 2. 2412MHz ~ 2462MHz (Wi-Fi 2.4G) 3. 5180MHz~5240MHz (Wi-Fi 5G) 4. 5260MHz~5320MHz (Wi-Fi 5G) 5. 5500MHz~5700MHz (Wi-Fi 5G) 6. 5745MHz~5825MHz (Wi-Fi 5G) Rating: 1. DC 5V 2.5A from USB-C Charger for 68301 2. DC 12V 2.5A from USB-C Charger for 68307 Sample receiving date: 1. 2025/12/02 for 68301 2. 2026/04/22 for 68307 Sample condition: Workable Test Date(s): 2025/12/19 ~ 2026/01/09 1.2 Adapter information The EUT will be supplied with a power supply from below list: No. Model no. Specification USB-C Charger A1C030AC I/P: 100-240V~ 50/60Hz, 1.2A O/P: 5.0V⎓3.0A 15.0W/9.0V⎓3.0A 27.0W/12.0V⎓2.5A 30.0W/15.0V⎓2.0A 30.0W/ 20.0V⎓1.5A 30.0W 1.3 Additional information about the EUT The customer confirmed the models listed as below were series model to model 68301 (EUT), the difference between main model and series model are listed as below. Model Number Protective Glass Dimensions 68301 V 13.3” 68303 X 13.3” 68305 X 28.54” 68307 V 28.54” Report No.: 251200021THC-001 GFT-OP-10h (28-Nov-2018) Page 6 of 18 TEST REPORT 1.4 Antenna description Antenna 1 For BLE, BTC, Wi-Fi…

Text truncated - open the document above for the full version.
