2AL2E-PLANEXLong neck sander with BLE

enOriginal Instructions - Long-reach sander6 frNotice d'utilisation d'origine - Ponceuse à bras24 esManual de instrucciones original - Lijadora de pared44 Read all instructions before using Lire toutes les instructions avant de démarrer les travaux. Lea y comprende todas las instrucciones antes de usar. P L A N E X LHS 2 225 EQI Festool GmbH Wertstraße 20 73240 Wendlingen Germany www.festoolusa.com 721694_C / 2020-10-19 1 1-1 1-9 1-8 1-6 1-5 1-11 1-12 1-13 1-13 1-10 1-14 1-16 1-18 1-19 1-21 1-20 1-15 1-3 1-2 1-4 1-17 1-7 Contents 1About this manual.......................................6 2Symbols.......................................................6 3Safety warnings...........................................6 4Intended use................................................9 5Technical data.............................................9 6Functional description..............................10 7Commissioning..........................................10 8Settings......................................................12 9Working with the electric power tool........16 10Service and maintenance..........................18 11Accessories...............................................19 12Environment..............................................19 13General information..................................20 14Troubleshooting........................................21 1About this manual Save these instructions It is important for you to read and understand this manual. The information it contains relates to protecting your safety and preventing prob­ lems . The symbols below are used to help you recognize this information. DANGERDescription of imminent hazard and failure to avoid hazard will result in death. WARN­ ING Description of hazard and possible resulting injures or death. CAUTIONDescription of hazard and possible resulting injuries. NOTICEDescription of possible damage of the device or its surroundings. 2Symbols Warning of general danger Warning of electric shock Read the operating instructions and safety instructions. Wear ear protection. Wear a dust mask. Wear protective goggles. Pull out the mains plug Connecting the mains power cable Disconnecting the mains power cable CAUTION! Do not look directly into the light beam! Safety class II Tool contains a chip which stores data. See section 13.1 Tip or advice Handling instruction Hzhertz Wwatt Vvolt ~ a.c. alternating current n 0 no load speed rpm min -1 revolutions per minute revolutions per minute lb.pound kgkilogram diameter mmmillimetre mmetre "inch 3Safety warnings 3.1General power tool safety warnings WARNING! Read all safety warnings, in­ structions, illustrations and specifica­ tions provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. 1 WORK AREA SAFETY a.Keep work area clean and well lit. Clut­ tered or dark areas invite accidents. English 6 b.Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. c.Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. 2 ELECTRICAL SAFETY a.Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b.Avoid body contact with earthed or grounded surfaces, such as pipes, radia­ tors, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c.Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. d.Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of elec­ tric shock. e.When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. f.If operating a power tool in a damp loca­ tion is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3 PERSONAL SAFETY a.Stay alert, watch what you are doing and use common sense when operating a pow­ er tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inat­ tention while operating power tools may re­ sult in serious personal injury. b.Use personal protective equipment. Al­ ways wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries. c.Prevent unintentional starting. Ensure the switch is in the off-position before con­ necting to power source and/or battery pack, picking up or carrying the tool. Car­ rying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d.Remove any adjusting key or wrench be­ fore turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal in­ jury. e.Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected sit­ uations. f.Dress properly. Do not wear loose cloth­ ing or jewellery. Keep your hair and cloth­ ing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g.If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust…

Text truncated - open the document above for the full version.

Festool GmbH Wertstrasse 20, 73240 Wendlingen Germany RE: Long Term Confidentiality Request For EUT Name: LHS 2 225 EQI FCC ID: 2AL2E-PLANEX This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Parts List - Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition Please contact me if there is any information you may need. Sincerely, Date: 20.11.2020 City: Wendlingen Name: Mr Markus Roth (1) Function: Approval Manager Signature: Notes: (1): For FCC it must be the Grantee Code “owner” or the authorized agent.

SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia T +386 1 4778 100, F +386 1 4778 444, [email protected], www.siq.si External photos Project file: C20200253 Date: 2020-10-22 Pages: 4 Product: LONG NECK SANDER Type reference: LHS 2 225 EQI Page: 2 (4) Figure 1 Figure 2 Page: 3 (4) Figure 3 Figure 4 Page: 4 (4) Figure 5

LHS 2 225 EQI YYYY-MM Made in Germany 120 V~60 Hz400 W n 5000-8500 min 0 -1 S-Nr. 0002001x T-Nr. 205213 Ø 225 mm E113899 Electrical Safety 73240 Wendlingen · Germany Festool GmbH FCC ID 2AL2E - PLANEX IC: 22501-PLANEX EXT-LHS 2 225 YYYY-MM Wertstr . 20 Festool GmbH Made in Germany 0002001x T-Nr. 10440935 D-73240 Wendlingen TOP-LHS 2 225 YYYY-MM Made in Germany 0002001xT-Nr. 10440926 Wertstr . 20 ∙ D-73240 Wendlingen Festool GmbH

SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia T +386 1 4778 100, F +386 1 4778 444, [email protected], www.siq.si Internal photos Project file: C20200253 Date: 2020-10-22 Pages: 4 Product: LONG NECK SANDER Type reference: LHS 2 225 EQI Page: 2 (4) Figure 1 Figure 2 Page: 3 (4) Figure 3 Figure 4 Page: 4 (4) Figure 5

Antenna information © Copyright by TTS Tooltechnic Systems AG & Co. KG All rights reserved. Referred to protection notice ISO 16016. Änderungsstand / Modification status erstellt / created index a geändert / changed Zchn. freigegeben / drw. released Index: a Mitteilungs-Nr. / Notification No.: Anzahl Änderungen / Number of changes: 0 Datum / Date 19.12.2019 14.01.2020 Werkzeugnummer / Tool number: Name DOMO DOMO Werkstoff / Material: Blatt / Sheet: 1 / 1 Gefertigt aus / Made of: Benennung / Description: Typ / Type: BLE Modul Netzmaschine Antennen Information antenna information Maßstab / Scale: Dok-Art / Doc-Type: Zeichnungs-Nr. / Drawing No.: - DRW 10359850 Communication-Type Bluetooth Low Energy Target-Frequency 2.4 GHz ISM band Antenna Type Lambda/4 Antenna Name PCB meandered monopole antenna Gain 0.3dBi Impedance 50 Ohm Manufacturer Festool Antenna layout Antenna circuit C113 - Kondensator / capacitor: 721516, 0.7pF, C0G, 50V, ±0.1pF Murata, GJM1555C1HR70BB01 C110, L100: n.b.

TN405E - 02 Test report Number: T251-0868/20 Project file: C20200253 Date: 2020-11-25 Pages: 3 Product: LONG NECK SANDER Type reference: LHS 2 225 EQI Ratings: 120 V~; 60 Hz; 400 W Protection class: II Trademark: FESTOOL Applicant: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Manufacturer: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Place of manufacture: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Summary of testing Testing method: 47 CFR FCC Part 2.1093, KDB 447498 D01 General RF Exposure Guidance v06 Testing location: SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia Remarks: Date of receipt of test items: 2019-12-12 Number of items tested: 1 Date of performance of tests: 2020-10-29 The test results presented in this report relate only to the items tested. The product complies with the requirements of the testing methods. Tested by: Luka Tosetto Approved by: Marjan Mak The report shall not be reproduced except in full. T251-0868/20 Page: 2 (3) CONTENTS page 1 GENERAL 3 1.1 EQUIPMENT UNDER TEST 3 2 LIMITS 3 3 ASSESSMENT PROCEDURE 3 4 MEASUREMENTS 3 T251-0868/20 Page: 3 (3) 1 GENERAL History sheet Date Report No. Change Revision 2020-11-25 T251-0868/20 Initial Test Report issued. -- 1.1 Equipment under test LONG NECK SANDER Type: LHS 2 225 EQI Environment: Uncontrolled / General Public Assessment distance: 5 mm Device usage: Hand FCC ID: 2AL2E-PLANEX 2 LIMITS According to 47 CFR FCC Part 2.1093 and KDB 447498 D01 General RF Exposure Guidance v06, evaluation assessment is not required if maximum treshold exclusion for 1-g SAR or 10-g extremity SAR is fulfiled. 1-g SAR Treshold exclusion is ≤ 3 (body worn devices) 10-g extremity SAR Treshold exclusion is ≤ 10 (i.e., hands, wrists, feet and ankles) 3 ASSESSMENT PROCEDURE MPE EVALUATION OF PORTABLE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1093) may be evaluated based on the General SAR exclusion under clause 4.3.1 of KDB 447498 D01 General RF Exposure Guidance v06. For 100 MHz to 6 GHz and test separation distances ≤50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: Treshold = f * P max (CH)_T R Where: f = channel frequency in GHz P max (CH)_T = maximum tuned up power of a channel in mW R = Evaluation distance 4 MEASUREMENTS Measured values for each configuration are listed in the following table: Frequency (GHz) Maximum* Power with antenna gain (dBm) Maximum* Power with antenna gain (mW) Test distance (mm) Treshold Exclusion treshold 2.440 2.9 1.95 5 0,61 3 (1-g SAR) 7.5 (10-g SAR) * Gated power with Duty Cycle calculated in Conclusion: SAR Evaluation is not required

SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia T +386 1 4778 100, F +386 1 4778 444, [email protected], www.siq.si TN405E - 02 Test report Number: T251-0302/20 Project file: C20200253 Date: 2021-01-19 Pages: 44 Product: LONG NECK SANDER Type reference: LHS 2 225 EQI Ratings: 120 V~; 60 Hz; 400 W Protection class: II Trademark: FESTOOL Applicant: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Manufacturer: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Place of manufacture: FESTOOL GmbH Wertstrasse 20, DE-73240 Wendlingen, Germany Summary of testing Testing method: 47 CFR Part 15, Subpart C (Clause 15.247) in conjuction with ANSI C63.10.2013 Testing location: SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia Remarks: Date of receipt of test items: 2020-01-28 Number of items tested: 1 Date of performance of tests: 2020-02-21 - 2020-07-25 The test results presented in this report relate only to the items tested. The product complies with the requirements of the testing methods. Tested by: Luka Cvajnar Approved by: Marjan Mak The report shall not be reproduced except in full. T251-0302/20 Page: 2 (46) CONTENTS page 1 GENERAL 3 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST 3 1.2 DESCRIPTION OF THE TEST MODES 3 1.3 TEST EQUIPMENT USED FOR TESTING 4 1.4 TEST SETUP CONFIGURATIONS 5 2 TEST SUMMARY 7 2.1 APPLICATION OF DECISION RULE 7 3 TESTS RESULTS 8 3.1 47 CFR § 15.203 – ANTENNA REQUIREMENTS 8 3.2 47 CFR § 15.207 – AC LINE CONDUCTED EMISSION 9 3.3 47 CFR § 15.247(D) - SPURIOUS EMISSION - CONDUCTED 13 3.4 47 CFR § 15.205, § 15.209, § 15.247 (D) – SPURIOUS EMISSION - RADIATED 15 3.5 47 CFR § 15.247 (A) (2) – 6 DB EMISSION BANDWIDTH 32 3.6 47 CFR § 15.247 (B) (3) – MAXIMUM PEAK OUTPUT POWER 35 3.7 47 CFR § 15.247 (D) –100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 36 3.8 47 CFR § 15.247 (E) – POWER SPECTRAL DENSITY 41 4 ANNEX I – ADDITIONAL DATA 43 4.1 OCCUPIED BANDWIDTH (99% EMISSION BANDWIDTH) 44 T251-0302/20 Page: 3 (46) 1 GENERAL EUT passed the performed tests. History sheet Date Report No. Change Revision 2021-01-19 T251-0302/20 Initial Test Report issued. -- 1.1 Description of equipment under test LONG NECK SANDER Type: LHS 2 225 EQI FCC ID: 2AL2E-PLANEX IC: 22501-PLANEX Adaptive / non-adaptive equipment non-adaptive equipment Modulation type GFSK Operating mode Single antenna Operating temperature range -20 °C to +80 °C Maximum RF Output power 4 dBm Operating frequency 2402 MHz – 2480 MHz Number of channels 40 Antenna type and gain Integral antenna, 0,3 dBi Antenna Beamforming / Nominal channel bandwidth 2 MHz Firmware: 10103959_B Software: 10133435-Index-H 1.2 Description of the test modes The equipment uses only one antenna at any moment. On all devices run test firmware Bluetooth Direct Test Mode and accompanied by a USB-UART converter interface. For testing purposes sample with integral antenna and modified sample with added SMA connector was provided. For testing nRFgo Studio software program from Nordic Semiconductor was used. 1.2.1 Tested Channels Channels Data rate Frequency [MHz] TX power Settings [dBm] Packet type Packet length (bytes) 0 (Lowest) 1 Mbps 2402 4 PRBS9 37 19 (Middle) 1 Mbps 2440 4 PRBS9 37 39 (Highest) 1 Mbps 2480 4 PRBS9 37 Normal test condition: Ambient temperature: 15 C to 35 C Relative humidity: 30 % to 60 % Atmospheric pressure: 860 mbar to 1060 mbar T251-0302/20 Page: 4 (46) 1.3 Test Equipment used for testing Manufacturer & Description Model No. SIQ No. Used Calibrated until Comtest engineering, SAC2 (together with controlling equipment) SAC 3m NPS002 X 2021-06 Maturo, Turn table (2 m diameter) TT 2.0 SI X / Maturo, Bore-sight antenna mast BAM-4.0-P X / Maturo, positioning equipment NCD X / Rohde & Schwarz, RFI receiver ESU 26 X 2020-10 Schwarzbeck, Biconical antenna VHBB9124 109080 X 2020-09 R&S, Ultra Broadband Antenna HL562E X 2022-07 R&S, Horn Antenna HF907 X 2022-08 EMCO, Horn Antenna EMCO 3116 X 2020-09 R&S, Spectrum Analyzer FSV 40 X 2021-05 R&S, Vector signal generator SMBV100B / 2021-05 R&S, Signal generator SMB100A / 2021-05 R&S High resolution power meter OSP-B157W8 X 2021-05 Wainwright Instruments, High pass filter High pass filter WHNX6-2555-3500-26500 X Wainwright Instruments, High pass filter WHNX6-5925-7500-26500 / / Wainwright Instruments, High pass filter WHW2-16340-21500-40000 / / Hp, Manual step attenuator 8494B 11 DB / / Hp, Manual step attenuator 8496B 110 DB / / KEYSIGHT, attenuator 8491B 10 DB / / PMI Low noise amplifier PEC-42-1G40G X 2022-03 1.3.1 Measurement uncertainty The following measurement uncertainty levels have been estimated for tests performed on the product, as specified in ETSI TR 100 028-2 and C63.23. This represents an expanded uncertainty expressed at 95% confidence level using a coverage factor k=2. Measurements ULAB U ETSI TR 100 028-2 U C63.23 AC Line Conducted Emission 3.2 dB / ±4,13 Spurious emission 30 – 300 MHz 4.2 dB ±6 / Spurious emission 300 – 1000 MHz 4.4 dB ±6 / Spurious emission 1 GHz – 18 GHz 5.1 dB ±6 / Spurious emission 18 GHz – 26GHz 5.6 dB ±6 / Tx spurious emission - conducted < 1.8 dB ±4 / 6 dB Emission Bandwidth < 2% ±5% / Maximum peak output power < 1 dB ±0,75 dB / 100 kHz Bandwidth of Frequency Band Edge < 0.8 dB / / Power Spectral Density < 1.3 dB ±3 dB / Occupied bandwidth (99% emission bandwidth) < 2% ±5% / Note: Measurement uncertainty calculated in accordance with ETSI TR 100 028-2 and C63.23. T251-0302/20 Page: 5 (46) 1.4 Test setup configurations 1.4.1 Conducted measurement test setup 1.4.2 Radiated measurement test setup Note: Bellow 1G non-conductive Table 80 cm above ground plane and above 1G non-conductive Table 150 cm above ground plane. T251-0302/20 Page: 6 (46) 1.4.3 AC Line Conducted Emission For the actual test configuration, please refer to the related item – Photographs of the Test Configuration. LISN E U T H o r i z o n t a l R e f e r e n c e G r o u n d P l a n e Test Receiver Vertical Reference Ground Plane 80 cm 80 cm 40 cm T2…

Text truncated - open the document above for the full version.

SIQ Ljubljana, Mašera-Spasićeva ulica 10, SI-1000 Ljubljana, Slovenia T +386 1 4778 100, F +386 1 4778 444, [email protected], www.siq.si Test setup photos Project file: C20200253 Date: 2020-06-04 Pages: 4 Product: LONG NECK SANDER Type reference: LHS 2 225 EQI Page: 2 (4) Figure 1:Conducted emission Figure 2: Spurious emission 30 MHz-200 MHz Page: 3 (4) Figure 3: Spurious emission 200 MHz-1000 MHz Figure 4: Spurious emission 1-18 GHz Page: 4 (4) Figure 5: Spurious emission 18- 26 GHz Figure 6: Conducted measurements test setup
