2AMIN-WPB15PDZMXiaomi 10W Wireless Power Bank 10000

Для получения подробной информации об импортере, пожалуйста, обратитесь к информации, указанной на коробке. Дата изготовления: см. на упаковке Изготовлено для: Xiaomi Communications Co., Ltd. Изготовитель: Zimi Corporation Адрес: A913, No. 159 Chengiang Road, Цзянъинь, Цзянсу, Китай Чтобы получить дополнительную информацию, посетите сайт w w w.mi.com Благодарим за выбор Беспроводного аккумулятора Xiaomi 10W Wireless Power Bank 10000. Данное устройство представляет собой беспроводное зарядное устройство с большой емкостью, в котором установлена литий-ионная полимерная батарея и микросхема зарядки и разрядки, обеспечивающая отличные характеристики безопасности, эффективности и совместимости. Устройство поддерживает как беспроводную зарядку, так и проводную. Перед использованием внимательно прочтите это руководство. Сохраните его — оно может понадобиться вам в дальнейшем. Обзор прибора Внешний аккумулятор автоматически распознает режим беспроводной и проводной зарядки и разрядки. Безопасность: Этот внешний аккумулятор имеет средства защиты, которые предотвращают избыточную зарядку или разрядку, перегрев и короткие замыкания в любом рабочем состоянии. Быстрая зарядка: Максимальная выходная мощность составляет 22,5 Вт при использовании порта USB-A или Type-C для зарядки устройства. Порт USB-A или порт Type-C поддерживает быструю зарядку с выходами 5 В/2,4 А, 9 В/2,23 А и 12 В/1,67 А макс. Совместимость: Встроенный интеллектуальный USB-контроллер заряда, совместимый с большинством мобильных телефонов и других устройств на рынке. 36 Порт USB-A (выход) Порт типа Type-C (Вход/Выход) Кнопка проверки уровня заряда аккумулятора Беспроводная зарядная площадка Индикатор уровня заряда аккумулятора Индикатор беспроводной зарядки 38 т елефон будет помещен на зарядное устройство (нет необходимости нажимать кнопку проверки уровня заряда аккумулятора). Вы также можете включить беспроводную зарядку, нажав или дважды нажав кнопку проверки уровня заряда аккумулятора/подключив адаптер питания к внешнему аккумулятору (внешний аккумулятор перейдет в режим ожидания беспроводной зарядки, если загорится индикатор беспроводной зарядки). Для отключения функции беспроводной зарядки, нажмите и удерживайте кнопку проверки уровня заряда аккумулятора более 3 секунд (индикатор беспроводной зарядки погаснет). Индикатор показывает состояние работы следующим образом: Когда внешний аккумулятор не заряжается, вы можете нажать кнопку проверки уровня заряда аккумулятора, чтобы включить функцию беспроводной зарядки. Функция беспроводной зарядки будет отключена, если не будет обнаружено поддерживающего беспроводную зарядку устройства через прибл. 30 секунд. Если устройство обнаружено, но затем снято с беспроводного зарядного устройства для зарядки, то функция беспроводной зарядки будет отключена прибл. через 30 секунд, а затем внешний аккумулятор перейдет в спящий режим*. Находясь в спящем режиме, внешний аккумулятор автоматически определяет, находится ли какое-либо устройство, поддерживающее беспроводную зарядку, на беспроводном зарядном устройстве. После обнаружения функция беспроводной зарядки будет включена, и внешний аккумулятор начнет заряжать устройство. * Спящий режим: Индикатор беспроводной зарядки и индикатор уровня заряда аккумулятора выключены. Состояние работы Ожидание Заряжание устройства Ошибка зарядки Питание отключено Индикатор беспроводной зарядки Медленное мигание Вкл Мигание Выкл. 37 Разрядка Данное устройство поддерживает одновременно беспроводную и проводную разрядку. Во время разрядки индикатор отображает уровень заряда аккумулятора следующим образом: Слаботочный разряд: когда внешний аккумулятор не заряжается, дважды нажмите на кнопку проверки уровня заряда, чтобы перейти в режим слаботочного разряда. Этот режим можно использовать для зарядки небольших устройств, например, Bluetooth-гарнитуры или умных браслетов. При использовании этого режима, индикаторы будут мигать по очереди. Чтобы выйти из режима слаботочного разряда, нажмите кнопку проверки уровня заряда. Через два часа устройство автоматически выйдет из этого режима. Беспроводная зарядка будет активирована автоматически, как только мобильный Пожалуйста, подключайтесь через порт Type-C при зарядке с помощью зарядного устройства Xiaomi и кабеля для зарядки. Во время зарядки индикатор отображает уровень заряда аккумулятора следующим образом: Зарядка LED1 LED3 LED2 LED4 Ка чество: высококачественный литий-полимерный аккумулятор, а также чип зарядки и разрядки с продолжительным сроком работы. LED4 Выкл. Выкл. Выкл. Мигание Вкл. Мигание LED3 Выкл. Выкл. Мигание Вкл. Вкл. Мигание LED2 Выкл. Мигание Вкл. Вкл. Вкл. Мигание LED1 Мигание Вкл. Вкл. Вкл. Вкл. Мигание Уровень заряда 0 -25% 25-50% 50 -75% 75-99% Полная зарядка Ошибка зарядки LED4 Выкл. Выкл. Выкл. Выкл. Мигание LED3 Выкл. Выкл. Выкл. Мигание Мигание LED2 Выкл. Выкл. Мигание Мигание Мигание LED1 Выкл. Мигание Мигание Мигание Мигание Уровень заряда Понижение напряжения 0 -25% 25-50% 50 -75% 75 -10 0% 39404142 Примечание. Иллюс трации изделия, комплектующих и пользовательского интерфейса в руководстве пользователя представлены исключительно в ознакомительных целях. Фактические характеристики прибора и его функции могут отличаться в связи с улучшениями продукта. Мер ы безопасности Перед первым использованием полностью зарядите устройство. Чтобы зарядить внешний аккумулятор или другие устройства, используйте соответствующее зарядное устройство и USB-кабель (рекомендуется торговая марка Mi). Если внешний аккумулятор используется для беспроводной зарядки устройства, на которое надет защитный чехол, убедитесь, что этот чехол не содержит металлических компонентов, а его толщина не превышает 4 мм. Если для зарядки блока питания во время беспроводной зарядки устройства, используется адаптер питания, этот адаптер должен отвечать следующим требованиям: 1. Иметь выход 5 В/1 A или выше или режим быстрой зарядки, Quick Charge (QC) 2.0 и поддерживать беспроводную зарядку 5 Вт. 2. Иметь выход 9 В или 12 В, или режим …

Text truncated - open the document above for the full version.

ZIMI CORPORATION To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: ZIMI CORPORATION Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Regarding: Confidentiality Request regarding application for FCC ID: 2AMIN-WPB15PDZM LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Signature: Printed Name: Guodong Jia Company Name: ZIMI CORPORATION

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name ZIMI CORPORATION Address Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Grantee Code 2AMIN FCC ID 2AMIN-WPB15PDZM Authorized Contact Name Guodong Jia Contact Email [email protected] Contact Phone +86 025 87156369 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1)labeling the equipment with the exact FCC ID as specified in this application, (2)compliance statement labeling pursuant to the applicable rules, (3)compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1)the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2)the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3)the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2021/07/01 Print Name: Guodong Jia Title: *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database PM

ZIMI CORPORATION Date: 2021/07/01 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2AMIN-WPB15PDZM To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan whose is the project engineer from SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with < ZIMI CORPORATION >. This authorization is valid until further written notice from the applicant. Title: PM Name (Printed): Guodong Jia Signature: On behalf of Company: ZIMI CORPORATION

Cover Letter-Wireless Charger Approval Date: 2021-07-01 Gentlemen: There’s a Xiaomi 10W Wireless Power Bank 10000 that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, Xiaomi 10W Wireless Power Bank 10000, with its designed features and specified description, meets special requirements for KDB 680106 D01 v03r01 section 5. b) requirements. Company: ZIMI CORPORATION Product Name: Xiaomi 10W Wireless Power Bank 10000 Model Number: WPB15PDZM FCC ID: 2AMIN-WPB15PDZM KDB 680106 D01 Section 5. b) Requirements Product Technical Specification Result 1)Power transfer frequency is less that 1 MHz127.5kHz Complied 2) Output power from each primary coil is less than or equal to 15 watts. 10watts Complied 3)The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. Single coils Complied 4) Client device is placed directly in contact with the transmitter. Placed directly in transmitter Complied 5) Mobile exposure conditions only Mobile Complied 6) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Reference MPE report Complied Sincerely, Print Name: Guodong Jia Title: Certification engineer Signature: On behalf of Company: Certification engineer Telephone: +86 025 87156369 Email: [email protected]

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 External Photos Applicant: ZIMI CORPORATION Address of Applicant: Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Equipment Under Test (EUT): Product Name: Xiaomi 10W Wireless Power Bank 10000 Model No.: WPB15PDZM SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4 End

1ICP10/61/115 Input: 5V=3A 9V=2.5A Wireless Output: 10W Max. Cell Capacity: 10000mAh 3.7V (37Wh) Wired Output: (USB-A/Type-C)5V =3A 9V=2.23A 12V=1.67A 10V=2.25Max. (Dual-port)5V=3A Rated Capacity: 5600mAh5V/3ACAUTION: RISK OF FIRE AND BURNS Date: 202106 Modle: WPB15PDZM Xiaomi 10W Wireless Power Bank 10000 3.7V mAh Made in China Date202106 SN: 00000/00000000000000 SN: 00000/00000000000000 SN码字体规范： Pantone Black 6U 同wpb15黑色版 面漆后印刷 5.0mm 5.0mm 二维码镭雕，镭雕灰色（以实物样确认为准） 二维码编码规则如下； 1） 按如下19位编码规则生成二维码； 2） 如有空间，需在机器上镭雕code明码； 3） 二维码及SN码由组装厂镭雕 公差：±0.2 对稿 蓝色部分为厂商自行生成， 字体生成标准： * 内容为“年份月份”，月份为当前生产月份。 * 例：壳料为2018年7月份生产，镭雕内容为 “201807” V1.0新建唐芬陶光荣 A壳字稿 2021/06/25 需求发起/审核 WPB15PD-黑色 13.0 1.8 64.03.3 1.0±0.1 2.1±0.1 18.5 31.3 26.1 1.0 1.8 5.0 34.8 3.0 0.9 1.8 3.3

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 6 Page 1 of 6 Internal Photos Applicant: ZIMI CORPORATION Address of Applicant: Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Equipment Under Test (EUT): Product Name: Xiaomi 10W Wireless Power Bank 10000 Model No.: WPB15PDZM SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 6 Page 2 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 6 Page 3 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 6 Page 4 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 6 Page 5 of 6 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 6 of 6 Page 6 of 6 END

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210600568302 Page: 1 of 12 Parlam Zhan Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electric al Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. Human Exposure Report Application No.: SHEM2106005683CR FCC ID: 2AMIN-WPB15PDZM Applicant: ZIMI CORPORATION Address of Applicant: Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Manufacturer: ZIMI CORPORATION Address of Manufacturer: Room A913, No.159 Chengjiang Road, Jiangyin City, Jiangsu Province, 214431, P.R.C Equipment Under Test (EUT): EUT Name: Xiaomi 10W Wireless Power Bank 10000 Model No.: WPB15PDZM Trade Mark: Mi Standards: 47 CFR PART 1, Subpart I, Section 1.1310 Date of Receipt: 2021-06-08 Date of Test: 2021-06-08 to 2021-07-22 Date of Issue: 2021-07-23 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210600568302 Page: 2 of 12 Revision Record Version Description Date Remark 00 Original 2021-07-23 / Authorized for issue by: Micheal Niu / Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210600568302 Page: 3 of 12 2 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 CONTENTS .............................................................................................................................................................. 3 3 GENERAL INFORMATION ................................................................................................................................... 4 3.1 DETAILS OF E.U.T. ................................................................................................................................................... 4 3.2 DESCRIPTION OF SUPPORT UNITS .............................................................................................................................. 4 3.3 TEST LOCATION ........................................................................................................................................................ 5 3.4 TEST FACILITY .......................................................................................................................................................... 5 3.5 DEVIATION FROM STANDARDS ................................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ........................................................................................................ 5 4 EQUIPMENTS USED DURING TEST .................................................................................................................. 6 5 TEST RESULTS ...................................................................................................................................................... 7 5.1 RF EXPOSURE TEST ................................................................................................................................................... 7 5.2 E.U.T. OPERATION ................................................................................................................................................... 8 5.2.1 Operating Environment ................................................................................................................................ 8 5.2.2 EUT Operation: ............................................................................................................................................. 8 5.2.3 Simulation Load Mode ................................................................................................................................. 8 5.2.4 Mobile phone Load Mode ............................................................................................................................ 9 6 PHOTOGRAPHS ................................................................................................................................................... 10 6.1 TEST PHOTOS .......................................................................................................................................................... 10 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHEM210600568302 Page: 4 of 12 3 General Information 3.1 Details of E.U.T. Cell Capacity: 37Wh, 3.7V, 10000mAh Rated Capacity: 5600mAh (5 V/3 A) Port: Input Port: Type-C, Output Port: USB-A/Type-C Input Parameters: Type-C Input (Single): 5V, 3A; 9V, 2.5 A Type-C Input (simultaneous USB-A Output): 5V, 3A Type-C Input (simultaneous Wireless Output): 5V,2A; 9V, 2A; 12V, 1.5A Type-C Input (simultaneous USB-A and Wireless Output): 5V, 3A Wired Output: (USB-A) 5V, 3A; 9V, 2.23A; 12V, 1.67A; 10V, 2.25A Max. (Type-C) 5V, 3A; 9V, 2.23A; 12V, 1.67A;10V, 2.25A Max. (Dual-port) 5V, 3A Wireless Output: 10W Max. Remark: Simultaneous wired and wireless output: 15W Test voltage: AC 120V/60Hz Antenna Type: Loop Antenna Modulation Type: Load Modulation Operation Frequency: 127.5kHz 3.2 Description of Support Units Description Manufacturer Model No. Serial No. AC Adapter MI AD651 N/A Load N/A N/A N/A MobilePhone MI MI 9 / MobilePhone Apple Iphone 12 / SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: …
