2AMQ6-HAYLOUGT5Haylou Wireless Earbuds

55 mm 80 mm 料号 资料确认表 名称 材质工艺 软件料号 物料承认 书编号 法务 市场 包装 软件 电子 结构 声学 品牌 A 热缩膜 防爆袋 外箱 公差: mm名称 ±0.5 ±0.5 ±1.0 宽:±3,高:±15 宽:±3,高:±15 彩盒 标签 说明书 ±5.0 70g书写纸折页 GT5中文说明书 东莞市猎声电子科技有限公司 Dongguan Liesheng Electronics Co., Ltd. 注意：尺寸要求：图面标注尺寸为必检尺寸 0000430C Charging contacts Pogo pins MFB Medium ear cap LED LED Charging port MIC Overview Stickers Haylou-GT5 True Wireless Earbuds User Manual Basic Parameters(earbuds) Basic Parameters(charging case) Input parameter:5V 500mA Output parameter:5V 150mA Charging time: approx. 3hr Standby time: approx. 4 months Battery capacity: 800mAh Battery type: li-ion What's in the Box Eartips * 3 pairs(medium size eartips have been put on), earbuds, charging case, charging cable, user manual. Operation range: 10m(open space with no obstacle) Battery capacity: 40mAh(single earbud) Charging time: approx. 2hr Talk time: approx. 3.5hr Standby time: approx. 150hr Input parameter: 5V 100mA Battery type: li-ion Bluetooth version: v5.0 How to Wear Please adjust Mic towards your mouth to gain better calling experience. Please keep Mic out of ear when calling How to Charge For first time use, please remove stickers from the case then top up earbuds. Power-on Pick up earbuds from the case to power them on. If earbuds are out of the case, hold MFB for 1.5s to power them on(LED glows white for 1s). Hold for 1.5s LED glows white for 1s Power-off Pop earbuds into the case to power them off. Hold MFB for 4.5s to power them off.(LED glows red for 2s). Hold for 4.5s LED glows red for 2s Stereo Mode Auto connection: take up two earbuds from the case, they will auto power on and pair with each other in 3s. When LED on right earbud blinks white slowly, search for Haylou-GT5_R and tap on cellphone to connect both earbuds to cellphone. If earbuds fail to connect to cellphone, please pop them back into case and repeat the above steps. Earbuds will auto reconnect to the last device in connectivity records, if any. (Bluetooth faculty needs to be activated). Note: GT5 has been set to factory before shipping out. Manual pairing: power off earbuds then manually power on them. Earbuds will auto pair with each other when LED on right earbud blinks white slowly. On cellphone, search for GT5_R and tap to connect both earbuds to cellphone. Hold for 1.5s to power on LED Haylou-GT2_R Haylou-GT5_R Mono Mode Auto Connection: take up either earbud from the case. The earbud will auto power on and LED will then blink white slowly. On cellphone, search for Haylou-GT5_R/L and tap to connect the earbud to cellphone. Earbud will auto reconnect to the last device in connectivity records, if any. ( Bluetooth faculty needs to be activated ). Note: it will cost more time for left earbud to reconnect to cellphone. Manual pairing: power off earbuds then manually power on either earbud. When LED on the earbud blinks white slowly, search for Haylou-GT5_R/L and tap on cellphone to connect. Charge the case via USB cable. LED will glow solid red when charging and turn off once topping up. Charge the Case Charging: solid red Top-up: LED turns off Functions Press MFB Answer incoming call/end the call Activate voice assitant(standy) Ignore incoming call Skip track backward Skip track forward Pause music/resume playing Press MFB Triple press MFB Hold MFB for 1.5s Double press MFB on left earbud Double press MFB on right earbud Daily maintenance Please do not shower with earbuds. Do not wear them in rainy day. Do not leave them in washing machine or other extreme situations. Clean them with dry cloth after use in pursuing a longer service life. Caveats 1. Please charge the product, in case it has not been used over two weeks. 2. Please use certificated charger. 3. Do not wear earphones for a long term to protect your hearing. 4. Do not wear earphones in any situations with potential risks as wearing them may reduce your perception to the outside world. If earphones do not function well, plea se refer the fo llowing steps to reset factory: take earbuds out fr om the case. Power o ff the earphones then hold MFBs on both earbuds for about 15s ( LED will blink red and white thr ee times twice). After that, put them bac k to the case. Delete connectivity r ecord on cellphone bef ore p rocessing another pa iring (All con nec itvity rec ord s r elating to the earb uds will all be removed). Factory Setting Audio only outputs from single earbud Other problems in charging It's a rare case . Please reset the earphones, remove connectivity record on your cellphone and re-connect the earphones to your cellphone. LE D glows sol id white for 1 minute when earbuds are topped up. Carry case will not charge earbuds, if its battery drains. LEDs on carry case will turn off once the case is topped up. If you charge it once again, LEDs will not give any notice, which does not mean the case is not charged. Haza rdous substances and t heir contents in the item Notes: Please arrange using time properly as your hearing may be damaged by using the device for a long time. Hazardous Substances Part Name Pb Hg Cd Cr (VI) PBB PBDE DIBP DEHP DBP BBP Main body Battery Ear tips Accessories Charging cable This form is made by SJ/T 11364 regulation. O：means that hazardous substance content in the homogeneous materials of this part is within the limits of (EU）2015/863 regulation . X ：means tha t hazardous substance content i n ,a t least, one certain homogeneous material o f this pa rt is beyond the limits of (EU）2015/863 regulation ,but there is no mature alternative in the industry at present, it still conforms to the EU ROHS Directive in the scope of exemption. Aftersales & Support Warranty Period: 12 months after purchase (please keep your receipt properly) Free Service: If any quality defects happen during the warranty period, please take the receipt and contact with your distributor for aftersales service. Following cases or any damages/defects that are not due to quality issue are not covered in the warranty. 1. Any defects or damages caused by natural disaste…

Text truncated - open the document above for the full version.

Product Name : Haylou Wireless Earbuds Model No. : Haylou-GT5 FCC ID: 2AMQ6-HAYLOUGT5 The device have left and right earphones ，the left and right earphones are electrically identical .

Model No.: Haylou-GT5

Haylou-GT5 Haylou Wireless Earbuds Input： 5V 500mA（for charging box） Output： 5V 150mA（for charging box） Input：5V 100mA（for earphone） Dongguan Liesheng Electronic Co., Ltd. FCC ID: 2AMQ6-HAYLOUGT5

Model No.: Haylou-GT5

RF Exposure Evaluation Statement Product Name: Haylou Wireless Earbuds Model No.：Haylou-GT5 FCC ID：2AMQ6-HAYLOUGT5 1.1 RF Exposure Compliance Requirement 1.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 1.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 17 The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion 1.1.3 EUT RF Exposure Operational Mode: EDR （8-DPSK worst case） Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dB) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) 2402MHZ 4.65 ±1 5.65 3.67 1.14 3.0 2441MHZ 4.73 ±1 5.73 3.74 1.17 2480MHZ 4.33 ±1 5.33 3.41 1.07 Operational Mode: BLE（worst case） 3.0 2402MHZ 1.54 ±1 2.54 1.79 0.56 2442MHZ 1.89 ±1 2.89 1.95 0.61 2480MHZ 1.54 ±1 2.54 1.79 0.57 Conclusion: the calculated value ≤3.0, SAR is exempted.

Page 1 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TEST REPORT Product Name : Haylou Wireless Earbuds Brand Mark : Haylou Model No. : Haylou-GT5 FCC ID : 2AMQ6-HAYLOUGT5 Report Number : BLA-EMC-202007-A5101 Date of Sample Receipt : 2020/7/17 Date of Test : 2020/7/17 to 2020/7/31 Date of Issue : 2020/8/3 Test Standard : 47 CFR Part 15, Subpart C 15.247 Test Result : Pass Prepared for: Dongguan Liesheng Electronic Co., Ltd. 13/F, Project Phrase 2 of GaoshengTechTower, No.5, Longxi Road, Nancheng, Dongguan, Guangdong, China Prepared by: BlueAsia of Technical Services(Shenzhen) Co.,Ltd. IOT Test Centre of BlueAsia No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen,China TEL: +86-755-28682673 FAX: +86-755-28682673 Compiled by: Review by: Approved by: Date: 2020/8/3 Report No.: BLA-EMC-202007-A5101 Page 2 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] REPORT REVISE RECORD Version No. Date Description 00 2020/8/3 Original Report No.: BLA-EMC-202007-A5101 Page 3 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TABLE OF CONTENTS 1 TEST SUMMARY ........................................................................................................................................6 2 GENERAL INFORMATION .........................................................................................................................7 3 GENERAL DESCRIPTION OF E.U.T. .........................................................................................................7 4 TEST ENVIRONMENT ................................................................................................................................8 5 TEST MODE ................................................................................................................................................8 6 MEASUREMENT UNCERTAINTY ..............................................................................................................8 7 DESCRIPTION OF SUPPORT UNIT...........................................................................................................9 8 LABORATORY LOCATION .........................................................................................................................9 9 TEST INSTRUMENTS LIST ..................................................................................................................... 10 ANTENNA REQUIREMENT .............................................................................................................................. 14 CONCLUSION ...................................................................................................................................................................... 14 CONDUCTED SPURIOUS EMISSIONS ........................................................................................................... 15 LIMITS ............................................................................................................................................................................. 15 BLOCK DIAGRAM OF TEST SETUP .................................................................................................................................... 15 TEST DATA ........................................................................................................................................................................ 16 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ............................................................. 17 LIMITS ............................................................................................................................................................................. 17 BLOCK DIAGRAM OF TEST SETUP .................................................................................................................................... 17 PROCEDURE ................................................................................................................................................................... 17 TEST DATA ........................................................................................................................................................................ 19 RADIATED SPURIOUS EMISSIONS ............................................................................................................... 21 LIMITS ............................................................................................................................................................................. 21 BLOCK DIAGRAM OF TEST SETUP .................................................................................................................................... 22 PROCEDURE ................................................................................................................................................................... 22 TEST DATA ........................................................................................................................................................................ 24 RADIATED EMISSIONS WHICH FALL IN THE RESTRICTED BANDS ......................................................... 32 LIMITS ............................................................................................................................................................................. 32 BLOCK DIAGRAM OF TEST SETUP .......................................................…

Text truncated - open the document above for the full version.

Report No.: BLA-EMC-202007-A5101 Page 36 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Highest channel Peak Value Report No.: BLA-EMC-202007-A5101 Page 37 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] CONDUCTED BAND EDGES MEASUREMENT Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.8 & Section 11.13.3.2 Test Mode (Pre-Scan) TX Test Mode (Final Test) TX Tester Eason Temperature 25°C Humidity 60% LIMITS Limit: In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval, as permitted under paragraph (b)(3) of this section, the attenuation required under this paragraph shall be 30 dB instead of 20 dB. Attenuation below the general limits specified in §15.209(a) is not required. In addition, radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). BLOCK DIAGRAM OF TEST SETUP Report No.: BLA-EMC-202007-A5101 Page 38 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TEST DATA Pass: Please Refer To Appendix: Appendix1 For Details Report No.: BLA-EMC-202007-A5101 Page 39 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] DWELL TIME Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.4 Test Mode (Pre-Scan) TX_non-Hop mode Test Mode (Final Test) TX_non-Hop mode Tester Eason Temperature 25°C Humidity 60% LIMITS Frequency(MHz) Limit 902-928 0.4S within a 20S period(20dB bandwidth<250kHz) 0.4S within a 10S period(20dB bandwidth≥250kHz) 2400-2483.5 0.4S within a period of 0.4S multiplied by the number of hopping channels 5725-5850 0.4S within a 30S period BLOCK DIAGRAM OF TEST SETUP Report No.: BLA-EMC-202007-A5101 Page 40 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] TEST DATA Pass: Please Refer To Appendix: Appendix1 For Details Report No.: BLA-EMC-202007-A5101 Page 41 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] HOPPING CHANNEL NUMBER Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.3 Test Mode (Pre-Scan) TX_non-Hop mode Test Mode (Final Test) TX_non-Hop mode Tester Eason Temperature 25°C Humidity 60% LIMITS Frequency range(MHz) Number of hopping channels (minimum) 902-928 50 for 20dB bandwidth <250kHz 25 for 20dB bandwidth ≥250kHz 2400-2483.5 15 5725-5850 75 BLOCK DIAGRAM OF TEST SETUP TEST DATA Pass: Please Refer To Appendix: Appendix1 For Details Report No.: BLA-EMC-202007-A5101 Page 42 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] CARRIER FREQUENCIES SEPARATION Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.2 Test Mode (Pre-Scan) TX_non-Hop mode Test Mode (Final Test) TX_non-Hop mode Tester Eason Temperature 25°C Humidity 60% LIMITS Limit: 2/3 of the 20dB bandwidth base on the transmission power is less than 0.125W BLOCK DIAGRAM OF TEST SETUP TEST DATA Pass: Please Refer To Appendix: Appendix1 For Details Report No.: BLA-EMC-202007-A5101 Page 43 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 20DB BANDWIDTH Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.7 Test Mode (Pre-Scan) TX Test Mode (Final Test) TX Tester Eason Temperature 25°C Humidity 60% BLOCK DIAGRAM OF TEST SETUP TEST DATA Pass: Please Refer To Appendix: Appendix1 For Details Report No.: BLA-EMC-202007-A5101 Page 44 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] CONDUCTED PEAK OUTPUT POWER Test Standard 47 CFR Part 15, Subpart C 15.247 Test Method ANSI C63.10 (2013) Section 7.8.5 Test Mode (Pre-Scan) TX Test Mode (Final Test) TX Tester Eason Temperature 25°C Humidity 60% LIMITS Frequency range(MHz) Output power of the intentional radiator(watt) 902-928 1 for ≥50 hopping channel…

Text truncated - open the document above for the full version.

Report No.: BLA-EMC-202007-A5101 Page 71 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 2DH1_Ant1_2402_30~1000 2DH1_Ant1_2402_1000~26500 2DH1_Ant1_2441_0~Reference Report No.: BLA-EMC-202007-A5101 Page 72 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 2DH1_Ant1_2441_30~1000 2DH1_Ant1_2441_1000~26500 2DH1_Ant1_2480_0~Reference Report No.: BLA-EMC-202007-A5101 Page 73 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 2DH1_Ant1_2480_30~1000 2DH1_Ant1_2480_1000~26500 3DH1_Ant1_2402_0~Reference Report No.: BLA-EMC-202007-A5101 Page 74 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 3DH1_Ant1_2402_30~1000 3DH1_Ant1_2402_1000~26500 3DH1_Ant1_2441_0~Reference Report No.: BLA-EMC-202007-A5101 Page 75 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 3DH1_Ant1_2441_30~1000 3DH1_Ant1_2441_1000~26500 3DH1_Ant1_2480_0~Reference Report No.: BLA-EMC-202007-A5101 Page 76 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] 3DH1_Ant1_2480_30~1000 3DH1_Ant1_2480_1000~26500 Report No.: BLA-EMC-202007-A5101 Page 77 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] APPENDIX A: PHOTOGRAPHS OF TEST SETUP Antenna Requirement Conducted Emissions at AC Power Line (150kHz-30MHz) Report No.: BLA-EMC-202007-A5101 Page 78 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Radiated Spurious Emissions Report No.: BLA-EMC-202007-A5101 Page 79 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] APPENDIX B: PHOTOGRAPHS OF EUT Report No.: BLA-EMC-202007-A5101 Page 80 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 81 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 82 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 83 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 84 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 85 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 86 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 87 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 88 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 89 of91 BlueAsia of Technical Services(Shenzhen) Co., Ltd. IOT Test Centre of BlueAsia,No. 448 Bulong Road, Bantian Street, Longgang District, Shenzhen, China Telephone: TEL: +86-755-28682673 FAX: +86-755-28682673 Email:[email protected] Report No.: BLA-EMC-202007-A5101 Page 90 of9…

Text truncated - open the document above for the full version.

Model No.: Haylou-GT5
